Page 1 2010 Chevrolet Express Owner Manual In Brief ............1-1 Instrument Panel ..........4-1 Instrument Panel ........1-2 Instrument Panel Overview ......4-3 Initial Drive Information Climate Controls ....... 1-4 ........4-15 Vehicle Features ........1-14 Warning Lights, Gages, and Indicators ..
Page 2 Customer Assistance Information ....8-1 Appearance Care ........6-102 Customer Assistance and Information ... 8-2 Vehicle Identiﬁcation ....... 6-109 Reporting Safety Defects ......8-16 Electrical System ........6-109 Vehicle Data Recording and Privacy ... 8-18 Capacities and Speciﬁcations ....6-116 Index ..............
Page 3: Canadian Owners
For vehicles ﬁrst sold in Canada, substitute the name To quickly locate information about the vehicle, use the “General Motors of Canada Limited” for Chevrolet Motor index in the back of the manual. It is an alphabetical Division wherever it appears in this manual.
Page 4: Vehicle Symbols
Safety Warnings and Symbols A circle with a slash through it is a safety symbol which means Warning Messages found on vehicle labels and in this “Do Not,” “Do not do this,” manual describe hazards and what to do to avoid or “Do not let this happen.”...
Page 5: Vehicle Symbol Chart
Vehicle Symbol Chart : Fuel Gage Here are some additional symbols that may be found on : Fuses the vehicle and what they mean. For more information on the symbol, refer to the index. : Headlamp High/Low-Beam Changer : Airbag Readiness Light : LATCH System Child Restraints : Air Conditioning : Malfunction Indicator Lamp...
Page 6 ✍ NOTES...
Page 7: In Brief
Section 1 In Brief Vehicle Features ..........1-14 Instrument Panel ..........1-2 Radio(s) ............1-14 Initial Drive Information ........1-4 Portable Audio Devices ........1-15 Remote Keyless Entry (RKE) System ....1-4 Steering Wheel Controls ........1-15 Remote Vehicle Start ........1-4 Cruise Control ..........1-16 Door Locks ............1-5 Power Outlets ..........1-16 Windows ............1-6 Performance and Maintenance ......1-16...
Page 8: Instrument Panel
Instrument Panel...
Page 9 A. Outlet Adjustment on page 4-17. L. Tilt Wheel on page 4-3. B. Driver Information Center (DIC) on page 4-36. M. Horn on page 4-3. C. Turn Signal/Multifunction Lever on page 4-4. N. Audio Steering Wheel Controls on page 4-77. D.
Page 10: Initial Drive Information
Initial Drive Information Press again within ﬁve seconds to unlock all remaining doors. This section provides a brief overview about some of Press to unlock only the cargo doors. the important features that may or may not be on your speciﬁc vehicle.
Page 11: Manual Door Locks
When the vehicle starts, the parking lamps will turn on Door Locks and remain on as long as the engine is running. The doors will be locked and the climate control system may Manual Door Locks come on. The engine will continue to run for 10 minutes. Repeat Lock and unlock the the steps for a 10-minute time extension.
Page 12: Seat Adjustment
Windows Seat Adjustment Manual Windows Manual Seats 1. Lift the bar to unlock Operate the manual windows by turning the hand crank the seat. on each door to raise or lower the side door windows. 2. Slide the seat to the See Manual Windows on page 3-16.
Page 13: Power Seats
Power Seats Reclining Seatbacks If the vehicle has front power seat(s), the controls are To recline the seatback: located at the front center of the seat cushion. 1. Lift the recline lever on the inboard side of the seats. Adjust the seat by moving the center knob up, down, right or left.
Page 14: Safety Belt
Safety Belt Airbag On-Off Switch If the instrument panel has one of the switches pictured in the following illustrations, the vehicle has an airbag on-off switch that you can use to manually turn on or off the right front passenger airbag. Refer to the following sections for important information on how to use safety belts properly.
Page 15: Sensing System For Passenger Airbag
Sensing System for Passenger Mirror Adjustment Airbag Exterior Mirrors The passenger sensing system, if equipped, will turn off Vehicles with outside manual mirrors can be adjusted the right front passenger frontal airbag under certain by moving the mirror up and down or left to right so you conditions.
Page 16: Steering Wheel Adjustment
Vehicles with towing Steering Wheel Adjustment mirrors can be adjusted manually for a clear view of the objects behind you. Manually fold the mirrors inward to prevent damage when going through an automatic car wash. To fold, pull the mirror toward the vehicle. Push the mirror outward, to return it to the original position.
Page 17: Interior Lighting
Interior Lighting Reading Lamps For vehicles with reading lamps, press the button Dome Lamp located next to each lamp to turn it on or off. The dome lamps come on when any door is opened. The vehicle may also have reading lamps in other They turn off after all the doors are closed.
Page 18 AUTO: Automatic operation of the headlamps at normal Windshield Wiper/Washer brightness and other exterior lamp. : Manual operation of the parking lamps and other exterior lamps, except headlamps. : Manual operation of the headlamps and other exterior lamps. For more information, see: •...
Page 19: Climate Controls
: Turns the wipers off. : Push the paddle on top of the multifunction lever to spray washer ﬂuid on the windshield. See Windshield Wipers on page 4-5 and Windshield Washer on page 4-6. Vehicles With Air Conditioning Climate Controls A.
Page 20: Vehicle Features
© ¨ Vehicle Features : Seek or scan stations. : Press to display additional text information related to Radio(s) the current FM-RDS station or MP3 song. A choice of additional information such as: Channel, Song, Artist, and CAT (category) can display. Continue pressing to highlight the desired label, or press the softkey located under any one of the tabs and the information about that tab displays.
Page 21: Steering Wheel Controls
Setting the Clock Steering Wheel Controls To set the time and date for the Radio with CD (MP3): If equipped, these controls 1. Press and the HR, MIN, MM, DD, YYYY are located on the right side of the steering wheel. (hour, minute, month, day, and year) displays.
Page 22: Performance And Maintenance
Cruise Control Power Outlets The accessory power outlets can be used to connect The cruise control buttons auxiliary electrical equipment, such as a cellular phone. are located on the left side The vehicle may have two accessory power outlets of the steering wheel. located on the instrument panel.
Page 23: Tire Pressure Monitor
Tire Pressure Monitor Note: The Tire Pressure Monitor can alert you about low tire pressure, but it does not replace normal monthly tire maintenance. It is the driver’s responsibility to This vehicle may have a Tire Pressure Monitor maintain correct tire pressures. System (TPMS).
Page 24 85% ethanol fuel (E85). Canada: 1-800-268-6800 See Fuel E85 (85% Ethanol) on page 6-8. As the owner of a new Chevrolet, you are automatically enrolled in the Roadside Assistance program. This Driving for Better Fuel Economy...
Page 25: Table Of Contents
Section 2 Seats and Restraint System Securing a Child Restraint in a Head Restraints ..........2-2 Rear Seat Position ........2-49 Front Seats ............2-2 Securing a Child Restraint in the Manual Seats ..........2-2 Right Front Seat Position Power Seat ...........2-3 (With Passenger Sensing System) ....2-52 Reclining Seatbacks ........2-4 Securing a Child Restraint in the Right Front Rear Seats ............2-6...
Page 26: Head Restraints
Head Restraints If the vehicle has a manual seat, it can be moved forward or rearward. On vehicles with factory installed seats, the front seats 1. Lift the bar to unlock have built-in head restraints that are not adjustable the seat. in the outboard seating positions.
Page 27: Power Seat
Power Seat If the vehicle has front power seat(s), the controls are located at the front center of the seat cushion. To raise or lower the seat, move the center knob up or down. To move the seat forward or rearward, move the center knob toward the right or left.
Page 28: Reclining Seatbacks
Reclining Seatbacks The seats have manual reclining seatbacks. The lever used to operate them is located on the inboard side of the seats. WARNING: You can lose control of the vehicle if you try to adjust a manual driver’s seat while the vehicle is moving.
Page 29 To return the seatback to an upright position: 1. Lift the lever fully without applying pressure to the WARNING: seatback and the seatback will return to the upright position. Sitting in a reclined position when the vehicle is in 2. Push and pull on the seatback to make sure it is motion can be dangerous.
Page 30: Rear Seats
Rear Seats Rear Seat Operation Removing the Rear Seat Disconnect the quick release latch plates for the lap-shoulder belts on the bench seat to be removed. 1. To do this, press the tip of a key into the release hole of the safety belt buckle while pulling up on the safety belt.
Page 31 3. Pull the pin handle up to disengage the pin from the retaining clip, then pull the pin out. 4. Repeat this procedure for the other pins. 5. Pull the seat rearward about 2 inches (5 cm) and then lift the seat from the ﬂoor rails. 6.
Page 32: Replacing The Rear Seats
Replacing the Rear Seats WARNING: (Continued) WARNING: could be seriously injured. After raising the rear seatback, always check to be sure that the safety belts are properly routed and attached, and are A seat that is not locked into place properly can not twisted.
Page 33 Three Passenger Seat Shown Three Passenger Seat Shown 4. Push the pin(s) marked “R” down until they are in 5. Push the pin(s) marked “L” down until they are in the retaining clip. the retaining clip. 6. If the vehicle has a ﬂoor mat, put the ﬂap back to its original position.
Page 34: Safety Belts
Safety Belts WARNING: Safety Belts: They Are for Everyone It is extremely dangerous to ride in a cargo area, This section of the manual describes how to use inside or outside of a vehicle. In a collision, people safety belts properly. It also describes some things not riding in these areas are more likely to be seriously to do with safety belts.
Page 35: Why Safety Belts Work
Why Safety Belts Work When you ride in or on anything, you go as fast as it goes. Put someone on it. Take the simplest vehicle. Suppose it is just a seat on wheels. 2-11...
Page 36 Get it up to speed. Then stop the vehicle. The rider The person keeps going until stopped by something. does not stop. In a real vehicle, it could be the windshield... 2-12...
Page 37 or the instrument panel... or the safety belts! With safety belts, you slow down as the vehicle does. You get more time to stop. You stop over more distance, and your strongest bones take the forces. That is why safety belts make such good sense. 2-13...
Page 38 Questions and Answers About If I am a good driver, and I never drive far from Safety Belts home, why should I wear safety belts? You may be an excellent driver, but if you are in a crash — even one that is not your fault — you and Will I be trapped in the vehicle after a crash if I your passenger(s) can be hurt.
Page 39: How To Wear Safety Belts Properly
How to Wear Safety Belts Properly This section is only for people of adult size. Be aware that there are special things to know about safety belts and children. And there are different rules for smaller children and infants. If a child will be riding in the vehicle, see Older Children on page 2-30 or Infants and Young Children on page 2-33.
Page 40 What is wrong with this? WARNING: You can be seriously hurt if your shoulder belt is too loose. In a crash, you would move forward too much, which could increase injury. The shoulder belt should ﬁt snugly against your body. The shoulder belt is too loose.
Page 41 What is wrong with this? WARNING: You can be seriously hurt if your lap belt is too loose. In a crash, you could slide under the lap belt and apply force on your abdomen. This could cause serious or even fatal injuries. The lap belt should be worn low and snug on the hips, just touching the thighs.
Page 42 What is wrong with this? WARNING: You can be seriously injured if your belt is buckled in the wrong place like this. In a crash, the belt would go up over your abdomen. The belt forces would be there, not on the pelvic bones. This could cause serious internal injuries.
Page 43 What is wrong with this? WARNING: You can be seriously injured if your belt goes over an armrest like this. The belt would be much too high. In a crash, you can slide under the belt. The belt force would then be applied on the abdomen, not on the pelvic bones, and that could cause serious or fatal injuries.
Page 44 What is wrong with this? WARNING: You can be seriously injured if you wear the shoulder belt under your arm. In a crash, your body would move too far forward, which would increase the chance of head and neck injury. Also, the belt would apply too much force to the ribs, which are not as strong as shoulder bones.
Page 45 What is wrong with this? WARNING: You can be seriously injured by not wearing the lap-shoulder belt properly. In a crash, you would not be restrained by the shoulder belt. Your body could move too far forward increasing the chance of head and neck injury.
Page 46 What is wrong with this? WARNING: You can be seriously injured by a twisted belt. In a crash, you would not have the full width of the belt to spread impact forces. If a belt is twisted, make it straight so it can work properly, or ask your dealer/retailer to ﬁx it.
Page 47: Lap-Shoulder Belt
Lap-Shoulder Belt All seating positions in the vehicle have a lap-shoulder belt. If you are using a rear seating position with a detachable safety belt and the safety belt is not attached, see Rear Seat Operation on page 2-6 for instruction on reconnecting the safety belt to the mini-buckle.
Page 48 5. To make the lap part tight, pull up on the To unlatch the belt, push the button on the buckle. The shoulder belt. belt should return to its stowed position. Slide the latch plate up the safety belt webbing when the safety It may be necessary to pull stitching on the safety belt is not in use.
Page 49: Shoulder Belt Height Adjuster
Shoulder Belt Height Adjuster Safety Belt Pretensioners The vehicle has a shoulder belt height adjuster for the If the GVWR (Gross Vehicle Weight Rating) of the driver and right front passenger positions. vehicle is below 8,500 lb (3 855 kg) then the vehicle has safety belt pretensioners for the front outboard Adjust the height so that the shoulder portion of the belt occupants.
Page 50: Rear Safety Belt Comfort Guides
Rear Safety Belt Comfort Guides Here is how to install a comfort guide to the safety belt: This vehicle may have rear shoulder belt comfort guides. If not, they are available through your dealer/retailer. The guides may provide added safety belt comfort for older children who have outgrown booster seats and for some adults.
Page 51 2. Place the guide over the belt, and insert the two 3. Be sure that the belt is not twisted and it lies ﬂat. edges of the belt into the slots of the guide. The elastic cord must be under the belt and the guide on top.
Page 52 WARNING: A safety belt that is not properly worn may not provide the protection needed in a crash. The person wearing the belt could be seriously injured. The shoulder belt should go over the shoulder and across the chest. These parts of the body are best able to take belt restraining forces.
Page 53: Safety Belt Use During Pregnancy
Safety Belt Use During Pregnancy The best way to protect the fetus is to protect the mother. When a safety belt is worn properly, it is more likely that the fetus will not be hurt in a crash. For Safety belts work for everyone, including pregnant pregnant women, as for anyone, the key to making women.
Page 54: Child Restraints
Child Restraints The manufacturer’s instructions that come with the booster seat state the weight and height limitations for that booster. Use a booster seat with a lap-shoulder belt Older Children until the child passes the below ﬁt test: • Sit all the way back on the seat. Do the knees bend at the seat edge? If yes, continue.
Page 55 What is the proper way to wear safety belts? WARNING: An older child should wear a lap-shoulder belt and get the additional restraint a shoulder belt can provide. The shoulder belt should not cross the face Never do this. or neck. The lap belt should ﬁt snugly below the hips, Never allow two children to wear the same safety just touching the top of the thighs.
Page 56 WARNING: Never do this. Never allow a child to wear the safety belt with the shoulder belt behind their back. A child can be seriously injured by not wearing the lap-shoulder belt properly. In a crash, the child would not be restrained by the shoulder belt.
Page 57: Infants And Young Children
Infants and Young Children Airbags plus lap-shoulder belts offer protection for adults and older children, but not for young children and infants. Neither the vehicle’s safety belt system nor Everyone in a vehicle needs protection! This includes its airbag system is designed for them. Every time infants and all other children.
Page 58 WARNING: Never do this. Never hold an infant or a child while riding in a vehicle. Due to crash forces, an infant or a child will become so heavy it is not possible to hold it during a crash. For example, in a crash at only 40 km/h (25 mph), a 5.5 kg (12 lb) infant will suddenly become a 110 kg (240 lb) force on a person’s arms.
Page 59 WARNING: Never do this. Children who are up against, or very close to, any airbag when it inﬂates can be seriously injured or killed. Never put a rear-facing child restraint in the right front seat. Secure a rear-facing child restraint in a rear seat.
Page 60 What are the different types of add-on child restraints? WARNING: Add-on child restraints, which are purchased by the vehicle’s owner, are available in four basic types. To reduce the risk of neck and head injury during Selection of a particular restraint should take a crash, infants need complete support.
Page 61: Child Restraint Systems
Child Restraint Systems WARNING: A rear-facing infant seat (A) provides restraint A young child’s hip bones are still so small that with the seating surface the vehicle’s regular safety belt may not remain against the back of low on the hip bones, as it should. Instead, it may the infant.
Page 62 A forward-facing child seat (B) provides restraint for the child’s body with the harness. A booster seat (C-D) is a child restraint designed to improve the ﬁt of the vehicle’s safety belt system. A booster seat can also help a child to see out the window.
Page 63: Securing The Child Within The Child Restraint
Securing an Add-On Child Restraint in When securing an add-on child restraint, refer to the instructions that come with the restraint which may be on the Vehicle the restraint itself or in a booklet, or both, and to this manual. The child restraint instructions are important, so if they are not available, obtain a replacement copy WARNING: from the manufacturer.
Page 64: Where To Put The Restraint
Where to Put the Restraint A label on the sun visor says, “Never put a rear-facing child seat in the front.” This is because the risk to the rear-facing child is so great, if the airbag deploys. According to accident statistics, children and infants are safer when properly restrained in a child restraint system or infant restraint system secured in a rear WARNING:...
Page 65 When securing a child restraint in a rear seating position, study the instructions that came with the child WARNING: (Continued) restraint to make sure it is compatible with this vehicle. Even if the passenger sensing system or airbag If the vehicle does not have a rear seat that will switch has turned off the right front passenger accommodate a rear-facing child restraint, a rear-facing frontal airbag, no system is fail-safe.
Page 66: Lower Anchors And Tethers For Children (Latch)
Lower Anchors and Tethers for Lower Anchors Children (LATCH) The LATCH system holds a child restraint during driving or in a crash. This system is designed to make installation of a child restraint easier. The LATCH system uses anchors in the vehicle and attachments on the child restraint that are made for use with the LATCH system.
Page 67 Top Tether Anchor Some child restraints that have a top tether are designed for use with or without the top tether being attached. Others require the top tether always to be attached. In Canada, the law requires that forward-facing child restraints have a top tether, and that the tether be attached.
Page 68 Do not install three child restraints in the same row at the same time and never install two top tethers using the same top tether anchor. (Top Tether Anchor): Seating positions with top tether anchors. Second, Third and Fourth Row with Three Passenger Front Passenger Seat —...
Page 69 Do not secure a child restraint in a position without a top tether anchor if a national or local law requires that the top tether be attached, or if the instructions that come with the child restraint say that the top tether must be attached.
Page 70 Securing a Child Restraint Designed for the LATCH System WARNING: Do not attach more than one child restraint to a WARNING: single anchor. Attaching more than one child restraint to a single anchor could cause the anchor If a LATCH-type child restraint is not attached to or attachment to come loose or even break during anchors, the child restraint will not be able to a crash.
Page 71 Notice: Do not let the LATCH attachments rub 2. If the child restraint manufacturer recommends that against the vehicle’s safety belts. This may damage the top tether be attached, attach and tighten the these parts. If necessary, move buckled safety top tether to the top tether anchor, if equipped.
Page 72 If the position you are If the position you are using does not have a using has an integrated headrest or head restraint headrest or head restraint and you are using a and you are using a dual tether, route the tether single tether, route the over the seatback.
Page 73: Securing A Child Restraint In A Rear Seat Position
Securing a Child Restraint in a Rear In Canada, the law requires that forward-facing child restraints have a top tether, and that the tether be Seat Position attached. If the child restraint does not have the LATCH system, When securing a child restraint in a rear seating position, you will be using the safety belt to secure the child study the instructions that came with the child restraint to restraint in this position.
Page 74 3. Push the latch plate into the buckle until it clicks. 4. Pull the rest of the shoulder belt all the way out of the retractor to set the lock. Position the release button on the buckle so that the safety belt could be quickly unbuckled if necessary.
Page 75 6. If the child restraint has a top tether, follow the child restraint manufacturer’s instructions regarding the use of the top tether. See Lower Anchors and Tethers for Children (LATCH) on page 2-42 for more information. 7. Push and pull the child restraint in different directions to be sure it is secure.
Page 76: Securing A Child Restraint In The Right Front Seat Position (With Passenger Sensing System)
Securing a Child Restraint in the WARNING: Right Front Seat Position (With Passenger Sensing System) A child in a rear-facing child restraint can be This vehicle has airbags. A rear seat is a safer place to seriously injured or killed if the right front passenger secure a forward-facing child restraint.
Page 77 If the vehicle does not have a rear seat that will In Canada, the law requires that forward-facing child accommodate a rear-facing child restraint, a rear-facing restraints have a top tether, and that the tether be child restraint should not be installed in the vehicle, attached.
Page 78 4. Push the latch plate into the buckle until it clicks. 5. Pull the rest of the shoulder belt all the way out of the retractor to set the lock. Position the release button on the buckle so that the safety belt could be quickly unbuckled if necessary.
Page 79 7. If the vehicle does not have a rear seat and the child restraint has a top tether, follow the child restraint manufacturer’s instructions regarding the use of the top tether. See Lower Anchors and Tethers for Children (LATCH) on page 2-42 for more information.
Page 80: Securing A Child Restraint In The Right Front Seat Position (With Airbag On-Off Switch)
Securing a Child Restraint in WARNING: the Right Front Seat Position (With Airbag On-Off Switch) A child in a rear-facing child restraint can be The vehicle has airbags. A rear seat is a safer place to seriously injured or killed if the right front passenger secure a forward-facing child restraint.
Page 81 Do not secure a child seat in a position without a top tether anchor if a national or local law requires that the WARNING: top tether be anchored, or if the instructions that come with the child restraint say that the top strap must be anchored.
Page 82 4. Push the latch plate into the buckle until it clicks. 5. Pull the rest of the shoulder belt all the way out of the retractor to set the lock. Position the release button on the buckle so that the safety belt could be quickly unbuckled if necessary.
Page 83 7. If the vehicle does not have a rear seat and the child restraint has a top tether, follow the child restraint manufacturer’s instructions regarding the use of the top tether. See Lower Anchors and Tethers for Children (LATCH) on page 2-42 for more information.
Page 84: Airbag System
Airbag System • A roof-rail airbag for the driver, passenger seated directly behind the driver, and the third row The vehicle has the following airbag: outboard passenger position (passenger van equipped with a sliding or hinged door). • A frontal airbag for the driver. •...
Page 85 Here are the most important things to know about the airbag system: WARNING: WARNING: Airbags inﬂate with great force, faster than the blink of an eye. Anyone who is up against, or very close to, any airbag when it inﬂates can be You can be severely injured or killed in a crash if seriously injured or killed.
Page 86 There is an airbag readiness light on the WARNING: instrument panel, which shows the airbag symbol. Children who are up against, or very close to, any airbag when it inﬂates can be seriously injured or killed. Airbags plus lap-shoulder belts offer protection for adults and older children, but not for The system checks the airbag electrical system for young children and infants.
Page 87: Where Are The Airbags
Where Are the Airbags? If the vehicle has one, the right front passenger airbag is in the instrument panel on the passenger side. The driver frontal airbag is in the middle of the steering wheel. 2-63...
Page 88 Driver Side shown, Passenger Side similar Driver Side shown, Passenger Side similar If the vehicle is a cargo or passenger van with a sliding If the vehicle has roof-rail airbags for the driver, right door and it has a roof-rail airbag for the driver and front passenger, passengers behind the driver and right right front passenger position, the roof-rail airbags are in front passenger, and the third row outboard passengers,...
Page 89: When Should An Airbag Inﬂate
For passenger vans with a sliding door, on the When Should an Airbag Inﬂate? passenger side of the vehicle, you will have a separate roof-rail airbag for the passenger seated directly Frontal airbags are designed to inﬂate in moderate to behind the right front passenger and the third row severe frontal or near-frontal crashes to help reduce the outboard passenger position.
Page 90 Frontal airbags may inﬂate at different crash speeds. If the GVWR (Gross Vehicle Weight Rating) of the For example: vehicle is 8,500 lb (3 855 kg) or above, the vehicle may have single stage airbags. If the GVWR is below •...
Page 91: What Makes An Airbag Inﬂate
In any particular crash, no one can say whether an How Does an Airbag Restrain? airbag should have inﬂated simply because of the damage to a vehicle or because of what the repair costs In moderate to severe frontal or near frontal collisions, were.
Page 92: What Will You See After An Airbag Inﬂates
What Will You See After an Airbag WARNING: Inﬂates? After the frontal airbags inﬂate, they quickly deﬂate, so When an airbag inﬂates, there may be dust in the quickly that some people may not even realize an air. This dust could cause breathing problems for airbag inﬂated.
Page 93 In many crashes severe enough to inﬂate the airbag, windshields are broken by vehicle deformation. WARNING: Additional windshield breakage may also occur from the right front passenger airbag. A crash severe enough to inﬂate the airbags may • Airbags are designed to inﬂate only once. After an have also damaged important functions in the airbag inﬂates, you will need some new parts for vehicle, such as the fuel system, brake and...
Page 94: Airbag Off Switch
Airbag Off Switch This switch should only be turned to the off position if the person in the right front passenger position is a member of a passenger risk group identiﬁed by If the instrument panel has one of the switches pictured the national government as follows: in the following illustrations, the vehicle has an airbag on-off switch that you can use to manually turn on or off...
Page 95 Medical Condition. A passenger has a medical condition which, according to his or her physician: • Causes the passenger airbag to pose a special risk for the passenger; and • Makes the potential harm from the passenger airbag in a crash greater than the potential harm from turning off the airbag and allowing the passenger, even if belted, to hit the dashboard or windshield in a crash.
Page 96 The airbag off light will come on to let you know that the right front passenger airbag is off. The airbag off light will stay on to remind you that the airbag is off. See Airbag Off Light on page 4-24. The airbag off light will stay on to remind you that the airbag is off.
Page 97: Passenger Sensing System
Passenger Sensing System The passenger sensing system will turn off the right front passenger frontal airbag under certain conditions. The driver airbag and roof-rail airbags, if equipped, If the instrument panel has one of the indicators are not part of the passenger sensing system. pictured in the following illustrations, the vehicle has a passenger sensing system unless there is an airbag The passenger sensing system works with sensors that...
Page 98 A label on the sun visor says, “Never put a rear-facing child seat in the front.” This is because the risk to WARNING: (Continued) the rear-facing child is so great, if the airbag deploys. Even if the passenger sensing system has turned WARNING: off the right front passenger frontal airbag, no system is fail-safe.
Page 99 The passenger sensing system is designed to turn off When the passenger sensing system has allowed the the right front passenger frontal airbag if: airbag to be enabled, the on indicator will light and stay lit to remind you that the airbag is active. •...
Page 100 If the On Indicator is Lit for a Child If the Off Indicator is Lit for an Restraint Adult-Size Occupant If a child restraint has been installed and the on indicator is lit: 1. Turn the vehicle off. 2. Remove the child restraint from the vehicle. 3.
Page 101 If this happens, use the following steps to allow the Additional Factors Affecting System system to detect that person and enable the right front Operation passenger frontal airbag: Safety belts help keep the passenger in position on the 1. Turn the vehicle off. seat during vehicle maneuvers and braking, which 2.
Page 102: Servicing Your Airbag-Equipped Vehicle
We recommend that you not use seat covers or other Servicing Your Airbag-Equipped aftermarket equipment except when approved by GM for Vehicle your speciﬁc vehicle. See Adding Equipment to Your Airbag-Equipped Vehicle on page 2-79 for more Airbags affect how the vehicle should be serviced. information about modiﬁcations that can affect how the There are parts of the airbag system in several places system operates.
Page 103: Adding Equipment To Your Airbag-Equipped Vehicle
Adding Equipment to Your passenger sensing system. This could either prevent proper deployment of the passenger Airbag-Equipped Vehicle airbag(s) or prevent the passenger sensing system from properly turning off the passenger airbag(s). See Passenger Sensing System on page 2-73. Is there anything I might add to or change If you have any questions about this, you should about the vehicle that could keep the airbags from working properly?
Page 104: Restraint System Check
Restraint System Check Airbags The airbag system does not need regularly scheduled maintenance or replacement. Make sure the airbag Checking the Restraint Systems readiness light is working. See Airbag Readiness Light on page 4-23 for more information. Safety Belts Notice: If an airbag covering is damaged, opened, Now and then, check that the safety belt reminder light, or broken, the airbag may not work properly.
Page 105: Replacing Restraint System Parts After A Crash
Replacing Restraint System Parts If the vehicle has been in a crash, do you need new safety belts or LATCH system (if equipped) parts? After a Crash After a very minor crash, nothing may be necessary. But the safety belt assemblies that were used during any crash may have been stressed or damaged.
Page 106 ✍ NOTES 2-82...
Page 107: Features And Controls
Section 3 Features and Controls Windows ............3-16 Keys ...............3-3 Manual Windows ..........3-16 Remote Keyless Entry (RKE) System ....3-4 Power Windows ..........3-17 Remote Keyless Entry (RKE) System Swing-Out Windows ........3-18 Operation ...........3-4 Enhanced Technology Glass ......3-19 Remote Vehicle Start ........3-7 Sun Visors ...........3-19 Doors and Locks ..........3-9 Theft-Deterrent Systems ........3-19 Door Locks ............3-9...
Page 108 Section 3 Features and Controls Automatic Transmission Operation Mirrors ............3-42 (Six Speed Automatic Transmission) ....3-27 Manual Rearview Mirror .........3-42 Automatic Transmission Operation Outside Manual Mirrors ........3-42 (Four Speed Automatic Transmission) ..3-32 Outside Towing Mirrors ........3-42 Tow/Haul Mode ..........3-34 Outside Power Mirrors ........3-43 Parking Brake ..........3-36 Outside Convex Mirror ........3-43 Shifting Into Park ..........3-37...
Page 109: Keys
Keys WARNING: Leaving children in a vehicle with the ignition key is dangerous for many reasons, children or others could be badly injured or even killed. They could operate the power windows or other controls or even make the vehicle move. The windows will function with the keys in the ignition and children could be seriously injured or killed if caught in the path of a closing window.
Page 110: Remote Keyless Entry (Rke) System
Remote Keyless Entry (RKE) Remote Keyless Entry (RKE) System System Operation See Radio Frequency Statement on page 8-20 for The Remote Keyless Entry (RKE) transmitter functions information regarding Part 15 of the Federal work up to 20 m (65 feet) away from the vehicle. Communications Commission (FCC) Rules and There are other conditions which can affect the RSS-210/211 of Industry and Science Canada.
Page 111: Programming Transmitters To The Vehicle
The horn may chirp when is pressed again within (Vehicle Locator/Panic Alarm): Press and release ﬁve seconds. See DIC Vehicle Customization on to locate the vehicle. The turn signal lamps ﬂash and page 4-52 for additional information. the horn sounds three times. Press and hold for more than two seconds to (Unlock): Press to unlock the driver door.
Page 112: Battery Replacement
Battery Replacement Replace the battery if the REPLACE BATTERY IN REMOTE KEY message displays in the DIC. See “REPLACE BATTERY IN REMOTE KEY” under DIC Warnings and Messages on page 4-44 for additional information. Notice: When replacing the battery, do not touch any of the circuitry on the transmitter.
Page 113: Remote Vehicle Start
Remote Vehicle Start (Remote Vehicle Start): This button will be on the RKE transmitter if you have remote start. Your vehicle may have a remote start feature. This To start the engine using the remote start feature: feature allows you to start the engine from outside the vehicle.
Page 114 The maximum number of remote starts between ignition The remote vehicle start feature will not operate if: cycles with the key is two. • The remote start system is disabled through If the remote start procedure is used again before the the DIC.
Page 115: Doors And Locks
Doors and Locks WARNING: (Continued) Door Locks • Outsiders can easily enter through an unlocked door when you slow down or stop your vehicle. Locking your doors can help WARNING: prevent this from happening. Unlocked doors can be dangerous. To lock the door from the •...
Page 116: Power Door Locks
Power Door Locks Pressing the power lock switch twice or the lock button on the RKE transmitter twice will override the delayed locking feature and immediately lock all the doors. On vehicles with power door locks, the switches are located on the doors. This feature will not operate if the key is in the ignition.
Page 117: Automatic Door Lock
Automatic Door Lock For the 60/40 side swing-out door, move the button to the right for The doors will automatically lock when the shift lever is the driver side door or to moved out of P (Park). The automatic door locking the left for the passenger feature cannot be disabled.
Page 118: Sliding Side Door
For the side sliding door, Sliding Side Door move the button up to engage the security feature. Move the button down to return the door locks to normal operation. Side Sliding Door Lockout Protection This feature protects you from locking the key in the To open the sliding side door from the outside, pull the vehicle when the key is in the ignition and a door handle toward the rear of the vehicle and slide the...
Page 119: 60/40 Swing-Out Side Door
60/40 Swing-Out Side Door To open the sliding side door from the inside, pull the handle toward the rear of the vehicle. Then, slide the door toward the rear of the vehicle. To open the front portion of a 60/40 door from the outside, pull out on the handle and open the door.
Page 120 To open the front portion of a 60/40 door from the To open the rear portion of a 60/40 door from the inside, pull the handle toward you and push the outside, pull the handle on the side of the rear door and door open.
Page 121: Rear Doors
Rear Doors To open the rear doors from the outside, pull the handle toward you to open the passenger side rear door ﬁrst. WARNING: Unlocked doors can be dangerous. • Passengers, especially children, can easily open the doors and fall out of a moving vehicle.
Page 122: Windows
Windows WARNING: Leaving children, helpless adults, or pets in a vehicle with the windows closed is dangerous. They can be overcome by the extreme heat and suffer permanent injuries or even death from heat stroke. Never leave a child, a helpless adult, or a pet alone in a vehicle, especially with the windows closed in warm or hot weather.
Page 123: Power Windows
Power Windows If the vehicle has power windows, the controls are located on each of the side doors. WARNING: Leaving children in a vehicle with the keys is dangerous for many reasons, children or others could be badly injured or even killed. They could operate the power windows or other controls or even make the vehicle move.
Page 124: Swing-Out Windows
Swing-Out Windows Rear Swing-Out Windows Side Swing-Out Window The vehicle also has rear swing-out windows. The rear swing-out windows work the same way as the side swing out window, but the latch is located at the bottom To open the side door swing-out window, pull up on the edge of the window.
Page 125: Enhanced Technology Glass
Enhanced Technology Glass Sun Visors The vehicle may be equipped with Enhanced To block out glare, swing down the sun visors. You can Technology Glass (ETG). ETG is part of the overall also swing them to the side. occupant protection system on passenger vans. ETG Visor Vanity Mirror may help to keep passengers sitting next to these ﬁxed windows from being ejected through the glass in...
Page 126: Pass-Key Iii+ Electronic Immobilizer
® PASS-Key III+ Electronic The security light will come on if there is a problem with arming or disarming the theft-deterrent system. Immobilizer ® When the PASS-Key III+ system senses that someone is using the wrong key, it shuts down the vehicle’s See Radio Frequency Statement on page 8-20 for starter and fuel systems.
Page 127 ® It is possible for the PASS-Key III+ decoder to learn 3. After the engine has started, turn the key to the transponder value of a new or replacement key. Up LOCK/OFF and remove the key. to 10 keys may be programmed for the vehicle. This 4.
Page 128: Starting And Operating Your Vehicle
Starting and Operating Your Ignition Positions Vehicle The ignition switch has four different positions. New Vehicle Break-In Notice: The vehicle does not need an elaborate break-in. But it will perform better in the long run if you follow these guidelines: •...
Page 129: Retained Accessory Power (Rap)
B (ACC/ACCESSORY): This is the position in which Retained Accessory Power (RAP) you can operate things like the radio and the windshield wipers when the engine is off. These vehicle accessories can be used for up to 10 minutes after the engine is turned off: C (ON/RUN): This position can be used to operate the •...
Page 130 Starting Procedure 2. If the engine does not start after 5-10 seconds, especially in very cold weather (below 0°F or 1. With your foot off the accelerator pedal, turn the −18°C), it could be ﬂooded with too much gasoline. ignition key to START. When the engine starts, Try pushing the accelerator pedal all the way to let go of the key.
Page 131: Fast Idle System
Fast Idle System When the fast idle is active the Driver Information Center (DIC) will display “FAST IDLE ON.” Fast Idle System with Switch One of the following actions will turn off the fast idle: • Pressing the brake. If the vehicle has this feature it is available only with cruise control.
Page 132: To Use The Engine Coolant Heater
To Use the Engine Coolant Heater WARNING: 1. Turn off the engine. 2. Open the hood and unwrap the electrical cord. Plugging the cord into an ungrounded outlet could The cord for the engine coolant heater is located cause an electrical shock. Also, the wrong kind of on the driver side of the engine compartment and is attached to the hose for the power steering extension cord could overheat and cause a ﬁre.
Page 133: Automatic Transmission Operation (Six Speed Automatic Transmission)
Automatic Transmission Operation WARNING: (Six Speed Automatic Transmission) Vehicles with a six speed automatic transmission It is dangerous to get out of the vehicle if the shift have a shift position indicator within the instrument panel lever is not fully in P (Park) with the parking brake cluster.
Page 134 N (Neutral): In this position, the engine does not D (Drive): This position is for normal driving. It provides connect with the wheels. To restart when you are the best fuel economy. If you need more power for already moving, use N (Neutral) only. Also, use passing, and you are: N (Neutral) when the vehicle is being towed.
Page 135 The vehicle has a shift stabilization feature that adjusts When temperatures are very cold, the transmission’s the transmission shifting to the current driving gear shifting could be delayed providing more stable conditions in order to reduce rapid upshifts and shifts until the engine warms up. Shifts could be more downshifts.
Page 136 1 (First): This position reduces vehicle speed without Range Selection Mode using the brakes. You can use it for major/severe downgrades where the vehicle would otherwise accelerate due to steepness of grade. When you shift to 1 (First) it provides the lowest gear appropriate to current road speed and continues to downshift as the vehicle slows, eventually downshifting to 1 (First) gear.
Page 137 To use this feature, do the following: While using Range Selection Mode, cruise control and the Tow/Haul mode can be used. 1. Move the shift lever to M (Manual Mode). Notice: Spinning the tires or holding the vehicle in 2. Press the plus/minus buttons, located on the one place on a hill using only the accelerator steering column shift lever, to select the desired pedal may damage the transmission.
Page 138 Automatic Transmission Operation WARNING: (Four Speed Automatic Transmission) It is dangerous to get out of the vehicle if the shift lever is not fully in P (Park) with the parking brake ﬁrmly set. The vehicle can roll. Do not leave the vehicle when the engine is running unless you have to.
Page 139 R (Reverse): Use this gear to back up. Notice: Shifting out of P (Park) or N (Neutral) with the engine running at high speed may damage Notice: Shifting to R (Reverse) while the vehicle is the transmission. The repairs would not be covered moving forward could damage the transmission.
Page 140: Tow/Haul Mode
2 (Second): This position reduces vehicle speed even Tow/Haul Mode more than 3 (Third) without using the brakes. You can use 2 (Second) on hills. It can help control vehicle speed as you go down steep mountain roads, but then you would also want to use the brakes off and on. You may use this feature for reducing torque to the rear wheels when you are trying to start the vehicle from a stop on slippery road surfaces.
Page 141 Grade Braking (Six Speed Automatic Transmission) The Grade Braking shift modes can be activated by pressing the tow/haul button on the dash. While in Range Selection Mode, Grade Braking is deactivated allowing the driver to select a desired range of gears. Grade Braking is only active while the Tow/Haul Mode is selected and you are not in the Range Selection Turn the tow/haul mode on and off by pressing the...
Page 142: Parking Brake
Cruise Grade Braking (Six Speed Parking Brake Automatic Transmission) Cruise Grade Braking operates only while cruise control is engaged in Tow/Haul mode. Cruise Grade Braking assists in maintaining desired vehicle speeds when driving on downhill grades in cruise control by automatically shifting to lower gears when the cruise set speed is exceeded.
Page 143: Shifting Into Park
To release the parking brake, hold the regular brake Shifting Into Park pedal down. Pull the handle, located just above the parking brake pedal, with the parking brake symbol, to release the parking brake. WARNING: If the ignition is on when the parking brake is released, the brake system warning light will go off.
Page 144: Torque Lock
Leaving the Vehicle With the Engine Torque Lock Running If you are parking on a hill and you do not shift the vehicle into P (Park) properly, the weight of the vehicle may put too much force on the parking pawl in the WARNING: transmission.
Page 145: Parking Over Things That Burn
The shift lock control system is designed to do the If you still are unable to shift out of P (Park): following: 1. Ease the pressure on the shift lever. • Prevent the ignition key from being removed unless 2. While holding down the brake pedal, push the shift the shift lever is in P (Park).
Page 146: Engine Exhaust
Engine Exhaust WARNING: (Continued) WARNING: • There are holes or openings in the vehicle body from damage or after-market modiﬁcations that are not completely sealed. Engine exhaust contains Carbon Monoxide (CO) If unusual fumes are detected or if it is suspected which cannot be seen or smelled.
Page 147: Running The Vehicle While Parked
Running the Vehicle While Parked WARNING: It is better not to park with the engine running. But if you ever have to, here are some things to know. It can be dangerous to get out of the vehicle if the automatic transmission shift lever is not fully in WARNING: P (Park) with the parking brake ﬁrmly set.
Page 148: Mirrors
Mirrors Outside Towing Mirrors Vehicles with towing Manual Rearview Mirror mirrors can be adjusted manually for a clear view of Hold the inside rearview mirror in the center to move it for the objects behind you. a clearer view behind your vehicle. Adjust the mirror to avoid glare from the headlamps behind.
Page 149: Outside Power Mirrors
Outside Power Mirrors Outside Convex Mirror Vehicles with outside power mirrors have WARNING: controls located on the driver side door. A convex mirror can make things, like other vehicles, look farther away than they really are. If you cut too sharply into the right lane, you could hit a vehicle on the right.
Page 150: Outside Heated Mirrors
Storage Areas Outside Heated Mirrors For vehicles with heated mirrors: Your vehicle may have a front storage compartment. It is located at the center of the instrument panel < (Rear Defogger): Press to heat the mirrors. extension, by the ﬂoor. To open the compartment, pull up on the latch.
Page 151: Instrument Panel
Section 4 Instrument Panel Climate Controls ..........4-15 Instrument Panel Overview .......4-3 Climate Control System .........4-15 Hazard Warning Flashers ........4-3 Outlet Adjustment .........4-17 Horn .............4-3 Rear Heating System ........4-18 Tilt Wheel .............4-3 Rear Air Conditioning and Heating System ..4-18 Turn Signal/Multifunction Lever ......4-4 Turn and Lane-Change Signals ......4-4 Warning Lights, Gages, and Indicators ....4-20 Headlamp High/Low-Beam Changer ....4-5...
Page 152 Section 4 Instrument Panel Security Light ..........4-34 Audio System(s) ..........4-59 Cruise Control Light ........4-35 Setting the Clock ..........4-60 Highbeam On Light ........4-35 Radio(s) ............4-62 Tow/Haul Mode Light ........4-35 Using an MP3 ..........4-72 Fuel Gage ...........4-35 Theft-Deterrent Feature ........4-77 Audio Steering Wheel Controls .......4-77 Driver Information Center (DIC) .......4-36 Radio Reception ...........4-78 DIC Operation and Displays ......4-37...
Page 153: Instrument Panel Overview
Instrument Panel Overview Tilt Wheel Hazard Warning Flashers (Hazard Warning Flasher): Press this button located on top of the steering column, to make the front and rear turn signal lamps ﬂash on and off. This warns others that you are having trouble. Press again to turn the ﬂashers off.
Page 154: Turn Signal/Multifunction Lever
Turn Signal/Multifunction Lever Turn and Lane-Change Signals : An arrow on the instrument panel cluster ﬂashes in the direction of the turn or lane change. To signal a turn, move the lever all the way up or down. To signal a lane change, raise or lower the lever until the arrow starts to ﬂash.
Page 155: Headlamp High/Low-Beam Changer
Headlamp High/Low-Beam Changer Windshield Wipers The windshield wiper control is located on the (Headlamp High/Low-Beam Changer): Pull the multifunction lever on the left side of the steering wheel. turn signal lever all the way toward you to change the headlamps from low to high beam. Then release it. Turn the band with on it to select the wiper speed.
Page 156: Windshield Washer
Windshield Washer Cruise Control The windshield wiper paddle is located on top of the multifunction lever. WARNING: (Washer Fluid): Push the paddle to spray washer ﬂuid on the windshield. The wipers will clear the window Cruise control can be dangerous where you and then either stop or return to the preset speed.
Page 157 The cruise control buttons Setting Cruise Control are located on left side of Cruise control will not work if the parking brake is set, or the steering wheel. if the master cylinder brake ﬂuid level is low. The cruise control light on the instrument panel cluster comes on after the cruise control has been set to the desired speed.
Page 158 Resuming a Set Speed Reducing Speed While Using Cruise Control If the cruise control is set at a desired speed and then the brakes are applied, this shuts off the cruise To reduce the vehicle speed while using cruise control: control.
Page 159: Exterior Lamps
Ending Cruise Control It controls the following systems: • Headlamps There are three ways to end cruise control: • • Taillamps Step lightly on the brake pedal. • Parking Lamps • Press the button on the steering wheel. • License Plate Lamps •...
Page 160: Headlamps On Reminder
Headlamps on Reminder (Parking Lamps): Turns on the parking lamps together with the following: If a door is open, a reminder chime sounds when the • Instrument Panel Lights headlamps or parking lamps are manually turned on and • the key is out of the ignition. To turn off the chime, Taillamps turn the headlamp switch to off or auto and then back •...
Page 161: Automatic Headlamp System
The automatic headlamp system automatically switches There is a delay in the transition between the daytime from DRL to the headlamps depending on the and nighttime operation of the Daytime Running darkness of the surroundings. Lamps (DRL) and the automatic headlamp systems so that driving under bridges or bright overhead street lights To turn off the DRL, turn the exterior lamp control to the does not affect the system.
Page 162: Dome Lamps
Dome Lamps Dome Lamp Override The dome lamps come on when any door is opened. The dome lamp override button is located next to the They turn off after all the doors are closed. exterior lamps control. The dome lamps can also be turned on by turning the The dome lamp override sets the dome lamps to remain instrument panel brightness knob, located on the off or come on automatically when a door is opened.
Page 163: Entry/Exit Lighting
Entry/Exit Lighting The battery can be discharged at idle if the electrical loads are very high. This is true for all vehicles. This is because the generator (alternator) may not be spinning The vehicle has an illuminated entry/exit feature. fast enough at idle to produce all the power that is The dome lamps come on if the dome override button is needed for very high electrical loads.
Page 164: Battery Run-Down Protection
Battery Run-Down Protection Notice: Adding any electrical equipment to the vehicle can damage it or keep other components from working as they should. The repairs would not This feature shuts off the dome lamps if they are left on be covered by the vehicle warranty. Do not use for more than 10 minutes when the ignition is in equipment exceeding maximum amperage rating of LOCK/OFF.
Page 165: Ashtray(S) And Cigarette Lighter
Climate Controls Ashtray(s) and Cigarette Lighter For vehicles with an ashtray it is located in the center Climate Control System console or on the instrument panel. Pull up on the ashtray door to open it if it is in the console or pull the The heating, cooling, and ventilation for the vehicle can door open it if it is on the instrument panel.
Page 166 Air Delivery Mode Control: Turn the knob clockwise or counterclockwise to change the current airﬂow mode. (Vent): Air is directed to the instrument panel outlets. (Bi-Level): Air is divided between the instrument panel and ﬂoor outlets, with some air directed toward the Vehicles With Air Conditioning windshield.
Page 167: Rear Window Defogger
Rear Window Defogger Outlet Adjustment For vehicles with a rear window defogger, a warming Use the outlets located near the center and on the sides grid is used to remove fog or frost from the rear window. of the instrument panel to change the direction of airﬂow. It only works when the ignition is in ON/RUN.
Page 168: Rear Heating System
Rear Heating System (High): This position supplies the most amount of heat to the rear-seating area. For vehicles with a rear heating system, it lets you adjust the amount of air ﬂowing into the rear of the vehicle, from (Medium): This position supplies half the amount of the front-seating area.
Page 169 If the vehicle has a 343 cm (135 inch) wheelbase, a rear control panel for this system is located in the second row behind the driver in the rear of the vehicle. The temperature, air delivery mode, and the fan speed can be adjusted for the rear seating area by a rear seat passenger.
Page 170: Warning Lights, Gages, And Indicators
Warning Lights, Gages, and Air Delivery Mode Control: Turn clockwise or counterclockwise to change the direction of the airﬂow Indicators in the rear seating area. To change the current mode, select one of the following: Warning lights and gages can signal that something is wrong before it becomes serious enough to cause (Vent): Air is directed to the upper outlets, with an expensive repair or replacement.
Page 171: Instrument Panel Cluster
Instrument Panel Cluster United States 4-Speed Version shown, 6-Speed and Canada similar 4-21...
Page 172: Speedometer And Odometer
Speedometer and Odometer Safety Belt Reminders The speedometer shows the vehicle speed in both miles Safety Belt Reminder Light per hour (mph) and kilometers per hour (km/h). When the engine is started, a chime sounds for several The odometer shows how far the vehicle has been seconds to remind a driver to fasten the safety belt, driven, in either miles (used in the United States) unless the driver safety belt is already buckled.
Page 173: Airbag Readiness Light
This chime and light are The airbag readiness light repeated if the passenger ﬂashes for a few seconds remains unbuckled and when the engine is the vehicle is in motion. started. If the light does not come on then, have it ﬁxed immediately.
Page 174: Airbag Off Light
Airbag Off Light WARNING: When the right front passenger airbag is manually turned off using the airbag on-off switch on the instrument panel, if equipped, the indicator light OFF or If the right front passenger’s airbag is turned off the off symbol will come on and stay on as a reminder for a person who is not in a risk group identiﬁed that the airbag has been turned off.
Page 175: Passenger Airbag Status Indicator
Passenger Airbag Status Indicator WARNING: If the vehicle has a passenger sensing system, the instrument panel will have a passenger airbag status indicator. See Passenger Sensing System on page 2-73 If the airbag readiness light ever comes on and for important safety information. The instrument panel stays on, it means that something may be wrong has a passenger airbag status indicator.
Page 176: Charging System Light
If the word OFF or the off symbol is lit on the airbag Charging System Light status indicator, it means that the passenger sensing system has turned off the right front passenger This light comes on brieﬂy frontal airbag. when the ignition key is If, after several seconds, both status indicator lights turned to START, but remain on, or if there are no lights at all, there may be a...
Page 177: Voltmeter Gage
Voltmeter Gage The vehicle can be only driven for a short time with the reading in either warning zone. If it must be driven, turn off all unnecessary accessories. When the engine is not Readings in either warning zone indicate a possible running, but the ignition is problem in the electrical system.
Page 178: Antilock Brake System (Abs) Warning Light
When the ignition is on, the brake system warning light Antilock Brake System (ABS) also comes on when the parking brake is set. See Warning Light Parking Brake on page 3-36 for more information. The light stays on if the parking brake does not fully release. If it stays on after the parking brake is fully released, For vehicles with the it means the vehicle has a brake problem.
Page 179: Stabilitrak ® Indicator Light
For vehicles with a Driver Information Center (DIC), see Engine Coolant Temperature Gage DIC Warnings and Messages on page 4-44 for all brake related DIC messages. ® StabiliTrak Indicator Light For vehicles with the ® StabiliTrak system, this light comes on or ﬂashes, according to the description table for the StabiliTrak system.
Page 180: Tire Pressure Light
Tire Pressure Light When the Light Flashes First and Then is On Steady For vehicles with a tire This indicates that there may be a problem with the Tire pressure monitoring Pressure Monitor System. The light ﬂashes for about system, this light comes a minute and stays on steady for the remainder of on brieﬂy when the engine the ignition cycle.
Page 181 If the check engine light comes on and stays on, while This light comes on during a malfunction in one of the engine is running, this indicates that there is an two ways: OBD II problem and service is required. Light Flashing: A misﬁre condition has been detected.
Page 182: Emissions Inspection And Maintenance Programs
Light On Steady: An emission control system If none of the above have made the light turn off, your malfunction has been detected on the vehicle. Diagnosis dealer/retailer can check the vehicle. The dealer/retailer and service might be required. has the proper test equipment and diagnostic tools to ﬁx any mechanical or electrical problems that might have An emission system malfunction might be corrected by developed.
Page 183: Oil Pressure Gage
This can take several days of routine driving. If this Oil pressure may vary with engine speed, outside has been done and the vehicle still does not temperature and oil viscosity, but readings above the pass the inspection for lack of OBD II system low pressure zone indicate the normal operating range.
Page 184: Oil Pressure Light
Oil Pressure Light This light comes on brieﬂy while starting the engine. If it does not, have the vehicle serviced by your dealer/retailer. If the system is working normally the indicator light then goes off. If the light comes on and stays on, it means that oil is not ﬂowing through the engine properly.
Page 185: Cruise Control Light
Cruise Control Light Tow/Haul Mode Light The cruise control light This light comes on when comes on whenever the the Tow/Haul mode has cruise control is set. been activated. The light goes out when the cruise control is turned off. For more information, see Tow/Haul Mode on page 3-34.
Page 186: Driver Information Center (Dic)
Driver Information Center (DIC) An arrow on the fuel gage indicates the side of the vehicle the fuel door is on. Your vehicle has a Driver Information Center (DIC). The gage ﬁrst indicates empty before the vehicle is out of fuel, and the fuel tank should be refueled soon. All messages will appear in the DIC display located at the bottom of the instrument panel cluster.
Page 187: Dic Operation And Displays
DIC Operation and Displays (Vehicle Information): Press this button to display the oil life, units, tire pressure readings for vehicles with The DIC has different displays which can be accessed the Tire Pressure Monitor System (TPMS), engine hours, by pressing the DIC buttons located on the instrument Tire Pressure Monitor System (TPMS) programming for panel, next to the instrument panel cluster.
Page 188 Trip Odometers If the retro-active reset feature is activated after the vehicle is started, but before it begins moving, the Press the trip/fuel button until A or B displays. This display will show the number of kilometers (km) or display shows the current distance traveled in either miles (mi) that were driven during the last ignition cycle.
Page 189 Average Economy The timer will record up to 99 hours, 59 minutes and 59 seconds (99:59:59) after which the display will return Press the trip/fuel button until AVG ECONOMY displays. to zero. This display shows the approximate average liters To stop the timer, press the set/reset button brieﬂy while per 100 kilometers (L/100 km) or miles per gallon (mpg).
Page 190 Vehicle Information Menu Items It cannot be reset accurately until the next oil change. To reset the engine oil life system, see Engine Oil Life System on page 6-18. (Vehicle Information): Press this button to scroll through the following menu items: Units Oil Life Press the vehicle information button until UNITS...
Page 191 If the tire pressure display shows dashes instead of a Relearn Remote Key value, there may be a problem with your vehicle. If this To access this display, the vehicle must be in P (Park). consistently occurs, see your dealer/retailer for service. This display allows you to match Remote Keyless Engine Hours Entry (RKE) transmitters to your vehicle.
Page 192: Dic Compass
DIC Compass Your vehicle may have a compass in the Driver Information Center (DIC). Compass Zone Your dealer/retailer will set the correct zone for your location. Under certain circumstances, such as during a long distance cross-country trip or moving to a new state or province, it will be necessary to compensate for compass variance by resetting the zone through the DIC if the zone is not set correctly.
Page 193 Compass Calibration To calibrate the compass, use the following procedure: Compass Calibration Procedure The compass can be manually calibrated. Only calibrate the compass in a magnetically clean and safe location, 1. Before calibrating the compass, make sure the such as an open parking lot, where driving the vehicle compass zone is set to the variance zone in in circles is not a danger.
Page 194: Dic Warnings And Messages
DIC Warnings and Messages AUTOMATIC LIGHT CONTROL ON This message displays when the automatic headlamps Messages are displayed on the DIC to notify the driver are turned on. See Exterior Lamps on page 4-9 for that the status of the vehicle has changed and that some more information.
Page 195 CHANGE ENGINE OIL SOON DRIVER DOOR OPEN This message displays when the engine oil needs to be This message displays and a chime sounds if the driver changed. When you change the engine oil, be sure door is not fully closed and the vehicle is in a drive to reset the CHANGE ENGINE OIL SOON message.
Page 196: Engine Overheated Stop Engine
ENGINE OIL LOW ADD OIL ENGINE OVERHEATED STOP ENGINE If your vehicle has an oil level sensor, this message Notice: If you drive your vehicle while the engine displays if the oil level in the vehicle is low. Check the oil is overheating, severe engine damage may occur.
Page 197: Oil Pressure Low Stop Engine
The vehicle may be driven at a reduced speed while OIL PRESSURE LOW STOP ENGINE this message is on, but acceleration and speed may be reduced. Anytime this message stays on, the vehicle Notice: If you drive your vehicle while the engine should be taken to your dealer/retailer for service oil pressure is low, severe engine damage may as soon as possible.
Page 198: Service Air Bag
REMOTE KEY LEARNING ACTIVE SERVICE A/C SYSTEM This message displays while you are matching a This message displays when the electronic sensors that Remote Keyless Entry (RKE) transmitter to your vehicle. control the air conditioning and heating systems are See “Matching Transmitter(s) to Your Vehicle” under no longer working.
Page 199: Service Brake System
SERVICE BRAKE SYSTEM SERVICE THEFT DETERRENT SYSTEM This message displays along with the brake system This message displays when there is a problem with the warning light if there is a problem with the brake system. theft-deterrent system. The vehicle may or may not See Brake System Warning Light on page 4-27.
Page 200: Service Transmission
SERVICE TRANSMISSION However, you should turn StabiliTrak off if your vehicle gets stuck in sand, mud, ice, or snow and you want to This message displays when there is a problem with the rock your vehicle to attempt to free it, or if you are driving transmission.
Page 201 STARTING DISABLED SERVICE TIRE LEARNING ACTIVE THROTTLE If your vehicle has the Tire Pressure Monitor System (TPMS), this message displays when the This message displays if the starting of the engine is system is re-learning the tire positions on your vehicle. disabled due to the electronic throttle control system.
Page 202: Dic Vehicle Customization
TRANSMISSION HOT IDLE ENGINE WAIT TO START This message displays brieﬂy when the theft-deterrent Notice: If you drive your vehicle while the system has initially found incorrect conditions within transmission ﬂuid is overheating and the the vehicle and is making a double check. If your vehicle transmission temperature warning is displayed on does not start soon after, try to start it again.
Page 203 The customization preferences are automatically Press the customization button until the PRESS recalled. DISPLAY IN ENGLISH screen appears on the DIC display. Press the set/reset button once to display all To change customization preferences, use the following DIC messages in English. procedure.
Page 204 AUTO DOOR LOCK AUTO DOOR UNLOCK This feature allows you to select when the vehicle’s This feature allows you to select whether or not to turn doors will automatically lock. See Programmable off the automatic door unlocking feature. It also Automatic Door Locks on page 3-10 for more allows you to select which doors and when the doors information.
Page 205 REMOTE DOOR LOCK To select a setting, press the set/reset button while the desired setting is displayed on the DIC. This feature allows you to select the type of feedback REMOTE DOOR UNLOCK you will receive when locking the vehicle with the Remote Keyless Entry (RKE) transmitter.
Page 206 DELAY DOOR LOCK NO CHANGE: No change will be made to this feature. The current setting will remain. This feature allows you to select whether or not the To select a setting, press the set/reset button while the locking of the vehicle’s doors will be delayed. When desired setting is displayed on the DIC.
Page 207 2 MINUTES: The exterior lamps will stay on for ON (default): If it is dark enough outside, the exterior two minutes. lights will turn on brieﬂy when you unlock the vehicle with the RKE transmitter. The lights will remain on NO CHANGE: No change will be made to this feature.
Page 208 NO CHANGE: No change will be made to this feature. EXIT FEATURE SETTINGS The current setting will remain. This feature allows you to exit the feature There is no default for chime volume. The volume will settings menu. stay at the last known setting. Press the customization button until FEATURE To select a setting, press the set/reset button while the SETTINGS PRESS...
Page 209: Audio System(S)
Audio System(s) For more information, see Defensive Driving on page 5-2. If the vehicle came without a radio, the wiring provisions Notice: Contact your dealer/retailer before adding for a radio and an antenna were installed at the any equipment. assembly plant, so that if you want, a radio can be Adding audio or communication equipment could installed at the dealer/retailer.
Page 210: Setting The Clock
Setting the Clock MP3 Radio with a Single CD Player If your vehicle has a radio with a single CD (MP3) AM/FM Radio with Optional CD Player player, the radio has a button for setting the time If your vehicle has an AM/FM radio with an optional and date.
Page 211 Changing the Time and Date Default MP3 Radio with a Six-Disc CD Player Settings If your vehicle has a radio with a six-disc CD player, the You can change the time default setting from 12 hours radio has a MENU button instead of the button to to 24 hours or change the date default setting from set the time and date.
Page 212: Radio(S)
Changing the Time and Date Default Radio(s) Settings To change the time default setting from 12 hours to 24 hours or change the date default setting from month/day/year to day/month/year. To change the time or date default settings, follow these instructions: 1.
Page 213: Playing The Radio
broadcast incorrect information that causes the radio features to work improperly. If this happens, contact the radio station. Playing the Radio (Power/Volume): Press to turn the system on and off. Turn clockwise or counterclockwise to increase or decrease the volume. When the radio is turned on, it plays at the volume level that was last set.
Page 214: Finding A Station
Finding a Station (Clock) (AM-FM Radio and Radio with CD (Base)): The radio has a clock button for setting the time. BAND: Press to switch between FM1 and FM2 and AM. With this type of radio, the clock can be set with either The selection displays.
Page 215: Setting Preset Stations
Setting Preset Stations FAV (Favorites): If the vehicle has a FAV button, a maximum of 36 stations can be programmed as favorites If the radio does not have a FAV button, up to using the six pushbuttons positioned below the radio 18 stations (six FM1, six FM2, and six AM), can be station frequency labels and by using the radio favorites programmed on the six numbered pushbuttons,...
Page 216 The number of favorites pages can be setup using the Setting the Tone MENU button. To setup the number of favorites pages: (Bass/Midrange/Treble) 1. Press the MENU button to display the radio setup menu. BASS/MID/TREB (Bass, Midrange, or Treble): To adjust bass, midrange, or treble, press the knob until 2.
Page 217: Radio Messages
Adjusting the Speakers (Balance/Fade) Finding a Category (CAT) Station (AM-FM Radio and Radio CAT (Category): The CAT button is used to ﬁnd with CD (Base)) XM™ stations while the radio is in the XM™ mode. XM™ is a satellite radio service that is based in (Balance/Fade): To adjust the balance or fade, the United States and Canada only.
Page 218 Playing a CD(s) (Six-Disc CD Player) When the CD is inserted, the CD symbol displays. As each new track starts to play, the track number displays. LOAD : Press to load CDs into the CD player. The CD player can play the smaller 3 inch (8 cm) This CD player holds up to six CDs.
Page 219 Care of Your CD and DVD Player (Tune): Turn to select tracks on the CD currently playing. Do not add any label to a CD, it could get caught in the CD or DVD player. If a CD is recorded on a personal ©...
Page 220 To use random on an Uplevel Radio with a Single CD (Information) (Base Radio with CD): Press to switch player, do the following: the display between the track number, elapsed time of the track, and the time. When the ignition is off, press 1.
Page 221: Using The Auxiliary Input Jack
CD Messages NO: This message displays if the EJECT or CD/AUX buttons are pressed and a CD has not been inserted into the player. REMOVE/CHECK DISC: Radios with a Single CD player or radios with a Six-Disc player displays CHECK DISC If the CD is not playing correctly, for any other reason, and/or ejects the CD if an error occurs.
Page 222: Using An Mp3
Drivers are encouraged to set up any auxiliary device Using an MP3 while the vehicle is in P (Park). See Defensive Driving on page 5-2 for more information on driver MP3 CD-R or CD-RW Disc distraction. The radio plays MP3 ﬁles that were recorded on a To use a portable audio player, connect a 3.5 mm CD-R or CD-RW disc.
Page 223 • The CD player is able to read and play a maximum Playlists can be changed by using the (previous) of 50 folders, 15 playlists, and 512 folders and ﬁles. (next) folder buttons, the knob, or the © ¨ • Create a folder structure that makes it easy to ﬁnd SEEK arrows.
Page 224 No Folder File System and Naming When the CD contains only compressed ﬁles, the ﬁles The song name that displays is the song name that is are located under the root folder. The next and previous contained in the ID3 tag. If the song name is not present folder function does not display on a CD that was in the ID3 tag, then the radio displays the ﬁle name recorded without folders or playlists.
Page 225 As each new track starts to play, the track number and REV (Reverse): Press and hold this button to song title displays. reverse playback quickly within an MP3 ﬁle. Sound is heard at a reduced volume. Release this button to EJECT: Press this button to eject CD-R(s) or resume playing the ﬁle.
Page 226 To change from playback by artist to playback by album, (Music Navigator): Use the music navigator press the pushbutton located below the Sort By label. feature to play MP3 ﬁles on the CD-R or CD-RW in order From the sort screen, push one of the buttons below the by artist or album.
Page 227: Theft-Deterrent Feature
Theft-Deterrent Feature Audio Steering Wheel Controls Non-RDS Radios Vehicles with audio steering wheel controls ® THEFTLOCK is designed to discourage theft of your could differ depending on vehicle’s radio. The feature works automatically by your vehicle’s options. learning a portion of the Vehicle Identiﬁcation Some audio controls can Number (VIN).
Page 228: Radio Reception
night. Static can also occur when things like storms and (Mute): Press this button to silence the system. power lines interfere with radio reception. When this Press this button again, to turn the sound on. happens, try reducing the treble on your radio. SRCE (Source): Press this button to switch between FM Stereo the radio, CD, and auxiliary input jack.
Page 229: Driving Your Vehicle
Section 5 Driving Your Vehicle Driving at Night ..........5-12 Your Driving, the Road, and the Vehicle ....5-2 Driving in Rain and on Wet Roads ....5-13 Defensive Driving ...........5-2 Before Leaving on a Long Trip .......5-14 Drunk Driving ..........5-2 Highway Hypnosis ........5-14 Control of a Vehicle ........5-3 Hill and Mountain Roads ........5-15 Braking ............5-3...
Page 230: Your Driving, The Road, And The Vehicle
Your Driving, the Road, and Drunk Driving the Vehicle WARNING: Defensive Driving Drinking and then driving is very dangerous. Your Defensive driving means “always expect the reﬂexes, perceptions, attentiveness, and judgment unexpected.” The ﬁrst step in driving defensively is to can be affected by even a small amount of alcohol.
Page 231: Control Of A Vehicle
For persons under 21, it is against the law in every Braking U.S. state to drink alcohol. There are good medical, psychological, and developmental reasons for See Brake System Warning Light on page 4-27. these laws. Braking action involves perception time and reaction The obvious way to eliminate the leading highway time.
Page 232: Antilock Brake System (Abs)
Avoid needless heavy braking. Some people drive Antilock Brake System (ABS) in spurts — heavy acceleration followed by heavy braking — rather than keeping pace with traffic. This is a This vehicle has the Antilock Brake System (ABS), an mistake. The brakes might not have time to cool between advanced electronic braking system that helps prevent a hard stops.
Page 233: Braking In Emergencies
® ABS can change the brake pressure to each wheel, as StabiliTrak System required, faster than any driver could. This can help the driver steer around the obstacle while braking hard. The vehicle may have a vehicle stability enhancement system called StabiliTrak. It is an advanced computer As the brakes are applied, the computer keeps controlled system that assists the driver with directional receiving updates on wheel speed and controls braking...
Page 234 Press and hold the For your safety, the system can only be disabled when StabiliTrak button located the vehicle speed is less than 20 mph (32 km/h). on the instrument panel Three chimes will be heard and the StabiliTrak light for more than ﬁve seconds comes on.
Page 235: Traction Control Operation
StabiliTrak System Operation Traction Control Operation The StabiliTrak system is normally on, except when the The traction control system is part of the StabiliTrak system is initializing or has been disabled with the system. Traction control limits wheel spin by reducing StabiliTrak button.
Page 236: Locking Rear Axle
Locking Rear Axle Steering Vehicles with a locking rear axle can give more traction Power Steering on snow, mud, ice, sand or gravel. It works like a standard axle most of the time, but when traction is low, If power steering assist is lost because the engine stops this feature will allow the rear wheel with the most or the system is not functioning, the vehicle can be traction to move the vehicle.
Page 237: Steering In Emergencies
Steering in Emergencies There are times when steering can be more effective than braking. For example, you come over a hill and ﬁnd a truck stopped in your lane, or a car suddenly pulls out from nowhere, or a child darts out from between parked cars and stops right in front of you.
Page 238: Off-Road Recovery
Off-Road Recovery Passing The vehicle’s right wheels can drop off the edge of a Passing another vehicle on a two-lane road can be road onto the shoulder while driving. dangerous. To reduce the risk of danger while passing: • Look down the road, to the sides, and to crossroads for situations that might affect a successful pass.
Page 239 Skidding Of course, traction is reduced when water, snow, ice, gravel, or other material is on the road. For safety, slow In a skid, a driver can lose control of the vehicle. down and adjust your driving to these conditions. It is Defensive drivers avoid most skids by taking reasonable important to slow down on slippery surfaces because care suited to existing conditions, and by not overdriving...
Page 240: Driving At Night
Driving at Night • Watch for animals. • When tired, pull off the road. Night driving is more dangerous than day driving because • some drivers are likely to be impaired — by alcohol or Do not wear sunglasses. drugs, with night vision problems, or by fatigue. •...
Page 241: Driving In Rain And On Wet Roads
Driving in Rain and on Wet Roads Hydroplaning Hydroplaning is dangerous. Water can build up under Rain and wet roads can reduce vehicle traction your vehicle’s tires so they actually ride on the and affect your ability to stop and accelerate. Always water.
Page 242: Before Leaving On A Long Trip
Before Leaving on a Long Trip Highway Hypnosis To prepare your vehicle for a long trip, consider having Always be alert and pay attention to your surroundings it serviced by your dealer/retailer before departing. while driving. If you become tired or sleepy, ﬁnd a safe place to park your vehicle and rest.
Page 243: Hill And Mountain Roads
Hill and Mountain Roads WARNING: Driving on steep hills or through mountains is different than driving on ﬂat or rolling terrain. Tips for driving in these conditions include: Coasting downhill in N (Neutral) or with the ignition • off is dangerous. The brakes will have to do all the Keep the vehicle serviced and in good shape.
Page 244: Winter Driving
Winter Driving Try not to break the fragile traction. If you accelerate too fast, the drive wheels will spin and polish the surface under the tires even more. Driving on Snow or Ice The Antilock Brake System (ABS) on page 5-4 improves Drive carefully when there is snow or ice between the vehicle stability during hard stops on a slippery roads, tires and the road, creating less traction or grip.
Page 245 Blizzard Conditions WARNING: (Continued) Being stuck in snow can be in a serious situation. Stay with the vehicle unless there is help nearby. If possible, • use the Roadside Assistance Program on page 8-8. To Check again from time to time to be sure get help and keep everyone in the vehicle safe: snow does not collect there.
Page 246: If Your Vehicle Is Stuck In Sand, Mud, Ice, Or Snow
To save fuel, run the engine for only short periods as If the vehicle has a traction system, it can often help to needed to warm the vehicle and then shut the engine off free a stuck vehicle. Refer to the vehicle’s traction and close the window most of the way to save heat.
Page 247: Rocking Your Vehicle To Get It Out
Rocking Your Vehicle to Get It Out Loading the Vehicle Turn the steering wheel left and right to clear the It is very important to know how much weight your area around the front wheels. Turn off any traction or vehicle can carry.
Page 248 Tire and Loading Information Label The tire and loading information label shows the number of occupant seating positions (A), and the maximum vehicle capacity weight (B) in kilograms and pounds. The Tire and Loading Information label also shows the size of the original equipment tires (C) and the recommended cold tire inﬂation pressures (D).
Page 249 Steps for Determining Correct Load Limit Determine the combined weight of luggage and cargo being loaded on the vehicle. That Locate the statement “The combined weight weight may not safely exceed the available of occupants and cargo should never exceed cargo and luggage load capacity calculated in XXX kg or XXX lbs”...
Page 250 Example 1 Example 2 Item Description Total Item Description Total Vehicle Capacity Vehicle Capacity 1,000 lbs 1,000 lbs Weight for Weight for (453 kg) (453 kg) Example 1 = Example 2 = Subtract Occupant Subtract Occupant Weight 150 lbs 300 lbs (136 kg) Weight 150 lbs 750 lbs (136 kg) (68 kg) ×...
Page 251 Refer to your vehicle’s tire and loading information label for speciﬁc information about your vehicle’s capacity weight and seating positions. The combined weight of the driver, passengers, and cargo should never exceed your vehicle’s capacity weight. Example 3 Item Description Total Vehicle Capacity 1,000 lbs...
Page 252 Certiﬁcation/Tire Label weight capacity of your vehicle. This is called Gross Vehicle Weight Rating (GVWR). The GVWR includes the weight of the vehicle, all occupants, fuel, and cargo. The Certiﬁcation/Tire label also tells you the maximum weights for the front and rear axles, called Gross Axle Weight Rating (GAWR).
Page 253 WARNING: WARNING: Do not load the vehicle any heavier than the Things you put inside your vehicle can strike Gross Vehicle Weight Rating (GVWR), or and injure people in a sudden stop or turn, or either the maximum front or rear Gross Axle in a crash.
Page 254: Towing
Add-On Equipment To tow the vehicle behind another vehicle for recreational purposes, such as behind a motorhome, When you carry removable items, you may need see “Recreational Vehicle Towing” following. to put a limit on how many people you carry inside your vehicle.
Page 255: Dinghy Towing
Here are some important things to consider before Dinghy Towing recreational vehicle towing: • What is the towing capacity of the towing vehicle? Be sure to read the tow vehicle manufacturer’s recommendations. • What is the distance that will be travelled? Some vehicles have restrictions on how far and how long they can tow.
Page 256: Dolly Towing
All-Wheel-Drive Vehicles Dolly Towing The vehicle was not designed to be towed with all four Rear Towing (Rear Wheels Off the Ground) wheels on the ground. To properly tow these vehicles, they should be placed on a platform trailer with all Two-Wheel-Drive Vehicles four wheels off the ground.
Page 257 3. Firmly set the parking brake. See Parking Brake on All-Wheel-Drive Vehicles page 3-36 for more information. 4. Put the transmission in P (Park). 5. Secure the vehicle to the dolly following the manufacturer’s instructions. 6. Use an adequate clamping device designed for towing to ensure that the front wheels are locked into the straight position.
Page 258: Towing A Trailer
Towing a Trailer Notice: Pulling a trailer improperly can damage the vehicle and result in costly repairs not covered ® by the vehicle warranty. To pull a trailer correctly, If the vehicle has a diesel engine, see the DURAMAX follow the advice in this section and see your Diesel manual for more information.
Page 259: Pulling A Trailer
Pulling A Trailer Three important considerations have to do with weight: • The weight of the trailer Here are some important points: • The weight of the trailer tongue • There are many different laws, including speed limit • restrictions, having to do with trailering. Make sure The weight on the vehicle’s tires the rig will be legal, not only where you live but Also see Tow/Haul later in this section for information...
Page 260 Use the following chart to determine how much the vehicle can weigh, based upon the vehicle model and options. Vehicle Axle Ratio Maximum Trailer Weight GCWR* G1500 Cargo Van 2WD 4.3L V6 3.42 4,400 lbs (1 996 kg) 9,500 lbs (4 309 kg) 3.42 5.3L V8 6,700 lbs (3 039 kg)
Page 261 Vehicle Axle Ratio Maximum Trailer Weight GCWR* G2500 Passenger Van 2WD Short Wheelbase 6.0L V8 3.73 7,600 lbs (3 447 kg) 14,000 lbs (6 350 kg) 6.0L V8 4.10 9,600 lbs (4 355 kg) 16,000 lbs (7 257 kg) G3500 Cargo Van 2WD Short Wheelbase 3.73 6,400 lbs (2 903 kg) 12,000 lbs (5 443 kg)
Page 262: Weight Of The Trailer Tongue
Weight of the Trailer Tongue The tongue load (A) of any trailer is an important weight to measure because it affects the total gross weight of the vehicle. The Gross Vehicle Weight (GVW) includes the curb weight of the vehicle, any cargo carried in it, and the people who will be riding in the vehicle.
Page 263 Do not exceed the maximum allowable tongue weight Consider the following example: for the vehicle. Choose the shortest hitch extension that A vehicle model base weight is 5,500 lbs (2 495 kg); will position the hitch ball closest to the vehicle. This 2,800 lbs (1 270 kg) at the front axle and 2,700 lbs will help reduce the effect of trailer tongue weight on the (1 225 kg) at the rear axle.
Page 264 If the vehicle has many options and there is a front seat It is important that the vehicle does not exceed any of passenger and two rear seat passengers with some its ratings — GCWR, GVWR, RGAWR, Maximum Trailer luggage and gear in the vehicle as well. 300 lbs (136 kg) Rating or Tongue Weight.
Page 265: Safety Chains
Weight-Distributing Hitches and Weight If the loaded trailer being pulled will weigh more than 5,000 lbs (2 270 kg), be sure to use a properly mounted Carrying Hitches weight-distributing hitch and sway control of the proper size. This equipment is very important for proper vehicle loading and good handling when driving.
Page 266: Trailer Brakes
Tow/Haul Mode Tow/Haul is designed to be most effective when the vehicle and trailer combined weight is at least 75 percent of the vehicle’s Gross Combined Weight Rating (GCWR). Pressing this button at See “Weight of the Trailer” later in the section. Tow/Haul the end of the shift lever is most useful under the following driving conditions: turns on and off the...
Page 267: Driving With A Trailer
Driving with a Trailer Towing a trailer requires a certain amount of experience. Get to know the rig before setting out for the open road. Get acquainted with the feel of handling and braking with the added weight of the trailer. And always WARNING: keep in mind that the vehicle you are driving is now longer and not as responsive as the vehicle is by itself.
Page 268: Driving On Grades
Backing Up When towing a trailer, the arrows on the instrument panel ﬂash for turns even if the bulbs on the trailer are Hold the bottom of the steering wheel with one hand. burned out. For this reason you may think other Then, to move the trailer to the left, move that hand drivers are seeing the signal when they are not.
Page 269: Parking On Hills
Parking on Hills Leaving After Parking on a Hill 1. Apply and hold the brake pedal while you: • start the engine, WARNING: • shift into a gear, and • Parking the vehicle on a hill with the trailer release the parking brake. attached can be dangerous.
Page 270: Trailer Wiring Harness
Trailer Wiring Harness • Red/Black Stripe: Battery Feed (30A Fuse) • Brown: Trailer Park Lamp Supply Voltage The optional heavy-duty trailer wiring package includes (15A fuse)** a wiring harness, with a seven-pin connector at the rear of the vehicle and a four-wire harness assembly •...
Page 271: Service And Appearance Care
Section 6 Service and Appearance Care Cooling System ..........6-28 Service ............6-3 Engine Coolant ..........6-29 Accessories and Modiﬁcations ......6-3 Engine Overheating ........6-35 California Proposition 65 Warning .....6-4 Engine Fan Noise .........6-37 California Perchlorate Materials Requirements ..6-4 Power Steering Fluid ........6-38 Doing Your Own Service Work ......6-4 Windshield Washer Fluid ........6-39 Adding Equipment to the Outside of Brakes ............6-40...
Page 272 Section 6 Service and Appearance Care Tires ..............6-60 Instrument Panel, Vinyl, and Other Plastic Tire Sidewall Labeling ........6-61 Surfaces ..........6-104 Tire Terminology and Deﬁnitions .....6-65 Care of Safety Belts ........6-104 Inﬂation - Tire Pressure .........6-68 Weatherstrips ..........6-105 Dual Tire Operation ........6-70 Washing Your Vehicle ........6-105 Tire Pressure Monitor System ......6-70 Cleaning Exterior Lamps/Lenses ....6-105...
Page 273: Service
Service Accessories and Modiﬁcations When non-dealer/non-retailer accessories are added For service and parts needs, visit your dealer/retailer. to the vehicle, they can affect vehicle performance and You will receive genuine GM parts and GM-trained and safety, including such things as airbags, braking, stability, supported service people.
Page 274: California Proposition 65 Warning
California Proposition 65 Warning Doing Your Own Service Work Most motor vehicles, including this one, contain and/or emit chemicals known to the State of California to cause WARNING: cancer and birth defects or other reproductive harm. Engine exhaust, many parts and systems, many ﬂuids, and some component wear by-products contain and/or You can be injured and the vehicle could be emit these chemicals.
Page 275: Adding Equipment To The Outside Of The Vehicle
Keep a record with all parts receipts and list the Look for the TOP TIER label on the fuel pump to mileage and the date of any service work performed. ensure gasoline meets enhanced detergency standards See Maintenance Record on page 7-16. developed by auto companies.
Page 276: Gasoline Octane
If the vehicle has the 4.8L V8 engine (VIN Code A), Gasoline Speciﬁcations the 5.3L V8 engine (VIN Code 4), or the 6.0L V8 engine (VIN Code G) and the N15 ﬂexible fuel option, you can At a minimum, gasoline should meet ASTM speciﬁcation use either regular unleaded gasoline or ethanol fuel D 4814 in the United States or CAN/CGSB-3.5 or 3.511 in containing up to 85% ethanol (E85).
Page 277: Additives
Additives Gasolines containing oxygenates, such as ethers and ethanol, and reformulated gasolines might be available in your area. We recommend that you use these gasolines, To provide cleaner air, all gasolines in the United States if they comply with the speciﬁcations described earlier. are now required to contain additives that help prevent However, E85 (85% ethanol) and other fuels containing engine and fuel system deposits from forming, allowing...
Page 278: Fuel E85 (85% Ethanol)
Fuel E85 (85% Ethanol) Many service stations will not have an 85% ethanol fuel (E85) pump available. The U.S. Department of Energy has an alternative fuels website (www.eere.energy.gov/ The 8th digit of the Vehicle Identiﬁcation Number (VIN) afdc/infrastructure/locator.html) that can help you ﬁnd shows the code letter or number that identiﬁes the E85 fuel.
Page 279: Fuels In Foreign Countries
If you do switch fuels, it is recommended that you add Notice: This vehicle was not designed for fuel that as much fuel as possible — do not add less than 11 L contains methanol. Do not use fuel containing (three gallons) when refueling.
Page 280: Filling The Tank
Filling the Tank The tethered fuel cap is located behind a hinged fuel door on the driver side of the vehicle. WARNING: Fuel vapor burns violently and a fuel ﬁre can cause bad injuries. To help avoid injuries to you and others, read and follow all the instructions on the fuel pump island.
Page 281 WARNING: WARNING: Fuel can spray out on you if you open the fuel cap If a ﬁre starts while you are refueling, do not too quickly. If you spill fuel and then something remove the nozzle. Shut off the ﬂow of fuel by ignites it, you could be badly burned.
Page 282: Filling A Portable Fuel Container
Checking Things Under Filling a Portable Fuel Container the Hood WARNING: WARNING: Never ﬁll a portable fuel container while it is in the vehicle. Static electricity discharge from the Things that burn can get on hot engine or fuel container can ignite the fuel vapor. You can be operated heater (FOH) parts and start a ﬁre.
Page 283: Hood Release
Hood Release To open the hood: 1. Pull the handle with this symbol on it. It is located in front of the driver’s side door frame near the ﬂoor. 3. Lift the hood, release the hood prop from its 2. Then go to the front of the vehicle and lift up retainer and put the hood prop into the slot in the secondary hood release, which is located the hood.
Page 284: Engine Compartment Overview
Engine Compartment Overview ® If the vehicle has a diesel engine, see the maintenance schedule section in the DURAMAX Diesel manual. When the hood is lifted: 6-14...
Page 285: Engine Oil
A. Battery. See Battery on page 6-43. Engine Oil B. Radiator Pressure Cap. See Cooling System on For diesel engine vehicles, see “Engine Oil” in the page 6-28. ® DURAMAX Diesel manual. C. Coolant Recovery Tank. See Cooling System on page 6-28.
Page 286: When To Add Engine Oil
When to Add Engine Oil See Engine Compartment Overview on page 6-14 for the location of the engine oil ﬁll cap. If the oil is below the cross-hatched area at the tip of the dipstick, add at least one quart/liter of the recommended Add enough oil to put the level somewhere in the proper oil.
Page 287: What Kind Of Engine Oil To Use
What Kind of Engine Oil to Use • American Petroleum Institute (API) starburst symbol Oils meeting these Look for three things: requirements should have the starburst symbol on the container. This symbol indicates that the oil has been certiﬁed by the American Petroleum Institute (API).
Page 288: Engine Oil Life System
Engine Oil Additives / Engine Oil When the system has calculated that oil life has been diminished, it indicates that an oil change is necessary. Flushes A CHANGE ENGINE OIL SOON message comes on. See DIC Warnings and Messages on page 4-44. Change Do not add anything to the oil.
Page 289: What To Do With Used Oil
How to Reset the Engine Oil Life What to Do with Used Oil System Used engine oil contains certain elements that can be unhealthy for your skin and could even cause cancer. The Engine Oil Life System calculates when to change Do not let used oil stay on your skin for very long.
Page 290: Engine Air Cleaner/Filter
Engine Air Cleaner/Filter When to Inspect the Engine Air Cleaner/Filter If your vehicle has the DURAMAX Diesel engine, see the DURAMAX Diesel manual for more information. Inspect the air cleaner/ﬁlter at the Maintenance II intervals and replace it at the ﬁrst oil change after each 50,000 mile (80 000 km) interval.
Page 291: Automatic Transmission Fluid (4-Speed Transmission)
To inspect or replace the engine air cleaner/ﬁlter, do the Notice: If the air cleaner/ﬁlter is off, a backﬁre following: can cause a damaging engine ﬁre. And, dirt can easily get into the engine, which will damage it. 1. Unhook the retainer clips and remove the cover. Always have the air cleaner/ﬁlter in place when 2.
Page 292 How to Check Automatic Transmission To get the right reading, the ﬂuid should be at normal operating temperature, which is 82°C to 93°C Fluid (180°F to 200°F). Because this operation can be a little difficult, you may Get the vehicle warmed up by driving about 24 km choose to have this done at the dealer/retailer service (15 miles) when outside temperatures are above 10°C department.
Page 293 Checking the Fluid Level See Engine Compartment Overview on page 6-14 for more information on location. Prepare your vehicle as follows: 1. Flip the handle up and then pull out the dipstick 1. Park your vehicle on a level place. Keep the engine and wipe it with a clean rag or paper towel.
Page 294: (6-Speed Transmission)
How to Add Automatic Transmission Automatic Transmission Fluid Fluid (6-Speed Transmission) Refer to the Maintenance Schedule to determine what When to Check and Change Automatic kind of transmission ﬂuid to use. See Recommended Transmission Fluid Fluids and Lubricants on page 7-12. Using a funnel, add ﬂuid down the transmission dipstick It is usually not necessary to check the transmission ﬂuid tube only after checking the transmission ﬂuid while it is...
Page 295 How to Check Automatic Transmission • In heavy traffic and hot weather. Fluid • While pulling a trailer. After driving under these conditions, a hot check can Because this operation can be difficult, it is recommended be performed. The ﬂuid should be Hot, which is to have this check done at the dealer/retailer service 71°C to 93°C (160°F to 200°F).
Page 296 Checking the Fluid Level Prepare the vehicle as follows: 1. Park the vehicle on a level place. Keep the engine running. 2. With the parking brake applied, place the shift lever in P (Park). 3. With foot on the brake pedal, move the shift lever through each gear range, pausing for about A.
Page 297 How to Add Automatic Transmission If the ﬂuid level is low, add only enough of the proper ﬂuid to bring the level up to the middle of the WARM (A) or Fluid HOT (B) range depending on the ambient temperature and prior driving conditions.
Page 298: Cooling System
Cooling System WARNING: If your vehicle has a diesel engine, see “Van Models” ® under “Cooling System” in the DURAMAX Diesel Supplement. An electric engine cooling fan under the hood can start up even when the engine is not running and The Cooling System allows the engine to maintain the correct working temperature.
Page 299: Engine Coolant
Engine Coolant WARNING: (Continued) The cooling system in the vehicle is ﬁlled with ® DEX-COOL engine coolant. This coolant is designed Do not run the engine if there is a leak. If you run to remain in the vehicle for ﬁve years or 150,000 miles the engine, it could lose all coolant.
Page 300 What to Use • Protects against rust and corrosion. • Will not damage aluminum parts. • Helps keep the proper engine temperature. WARNING: Notice: If an improper coolant mixture is used, the engine could overheat and be badly damaged. Adding only plain water to the cooling system can The repair cost would not be covered by the vehicle be dangerous.
Page 301: Checking Coolant
Checking Coolant How to Add Coolant to the Recovery Tank for Gasoline Engines The vehicle must be on a level surface when checking the coolant level. If your vehicle has a diesel engine, see “How to Add Coolant to the Coolant Recovery Tank” under Check to see if coolant is visible in the coolant recovery “Van Models”...
Page 302: How To Add Coolant To The Radiator
How to Add Coolant to the Radiator WARNING: If your vehicle has a diesel engine, see “How to Add Coolant to the Radiator” under “Van Models” in ® the Cooling System section of the DURAMAX Diesel Steam and scalding liquids from a hot cooling Supplement for the proper radiator ﬁll procedure.
Page 303 ® 1. You can remove the radiator pressure cap when 3. Fill the radiator with the proper DEX-COOL the cooling system, including the radiator pressure coolant mixture, up to the base of the ﬁller cap and upper radiator hose, is no longer hot. neck.
Page 304 4. Then ﬁll the coolant recovery tank to the 6. Start the engine and let it run until you can feel the COLD FILL mark. upper radiator hose getting hot. Watch out for the engine cooling fan. 5. Put the cap back on the coolant recovery tank, but leave the radiator pressure cap off.
Page 305: Engine Overheating
7. By this time, the coolant level inside the radiator You may decide not to lift the hood when this warning ﬁller neck may be lower. If the level is lower, add appears, but instead get service help right away. ®...
Page 306: If Steam Is Coming From The Engine Compartment
If Steam Is Coming From The Engine If No Steam Is Coming From The Compartment Engine Compartment If an engine overheat warning is displayed but no steam can be seen or heard, the problem may not be too WARNING: serious. Sometimes the engine can get a little too hot when the vehicle: •...
Page 307: Engine Fan Noise
If the temperature overheat gage is no longer in the Engine Fan Noise overheat zone or an overheat warning no longer displays, the vehicle can be driven. Continue to drive Your vehicle has a clutched engine cooling fan. When the the vehicle slow for about 10 minutes.
Page 308: Power Steering Fluid
Power Steering Fluid How to Check Power Steering Fluid To check the power steering ﬂuid, do the following: The power steering ﬂuid 1. Turn the key off and let the engine compartment reservoir is located in the cool down. engine compartment on the driver’s side of the vehicle.
Page 309: Windshield Washer Fluid
Windshield Washer Fluid Notice: • When using concentrated washer ﬂuid, follow the What to Use manufacturer’s instructions for adding water. • Do not mix water with ready-to-use washer ﬂuid. When you need windshield washer ﬂuid, be sure to read Water can cause the solution to freeze and the manufacturer’s instructions before use.
Page 310: Brakes
Brakes Do not top off the brake ﬂuid. Adding ﬂuid does not correct a leak. If ﬂuid is added when the linings are worn, there will be too much ﬂuid when new brake linings are Brake Fluid installed. Add or remove brake ﬂuid, as necessary, only when work is done on the brake hydraulic system.
Page 311: Checking Brake Fluid
Checking Brake Fluid WARNING: Check brake ﬂuid by looking at the brake ﬂuid reservoir. See Engine Compartment Overview on page 6-14. With the wrong kind of ﬂuid in the brake hydraulic The ﬂuid level should be system, the brakes might not work well. This could above MIN.
Page 312: Brake Wear
Brake Wear Some driving conditions or climates can cause a brake squeal when the brakes are ﬁrst applied or lightly applied. This vehicle has disc brakes. Disc brake pads have This does not mean something is wrong with the brakes. built-in wear indicators that make a high-pitched warning Properly torqued wheel nuts are necessary to help sound when the brake pads are worn and new pads...
Page 313: Battery
Replacing Brake System Parts Battery The braking system on a vehicle is complex. Its many Refer to the replacement number on the original battery parts have to be of top quality and work well together if label when a new battery is needed. See Engine the vehicle is to have really good braking.
Page 314: Vehicle Storage
Vehicle Storage Jump Starting If the vehicle battery has run down, you may want to use another vehicle and some jumper cables to start your WARNING: vehicle. Be sure to use the following steps to do it safely. Batteries have acid that can burn you and gas that WARNING: can explode.
Page 315 Notice: Ignoring these steps could result in costly To avoid the possibility of the vehicles rolling, set damage to the vehicle that would not be covered the parking brake ﬁrmly on both vehicles involved by the warranty. in the jump start procedure. Put an automatic transmission in P (Park) or a manual transmission Trying to start the vehicle by pushing or pulling it in N (Neutral) before setting the parking brake.
Page 316 4. Open the hoods and locate the positive (+) and negative (−) terminal locations of the other vehicle. WARNING: Your vehicle has a remote positive (+) jump starting terminal and a remote negative (−) jump starting terminal. You should always use these Using an open ﬂame near a battery can cause remote terminals instead of the terminals on the battery gas to explode.
Page 317 WARNING: Fans or other moving engine parts can injure you badly. Keep your hands away from moving parts once the engine is running. 5. Check that the jumper cables do not have loose or missing insulation. If they do, you could get a shock.
Page 318 8. Now connect the black negative (−) cable to the negative (−) terminal of the good battery. Use a remote negative (−) terminal if the vehicle has one. Do not let the other end touch anything until the next step. The other end of the negative (−) cable does not go to the dead battery.
Page 319: All-Wheel Drive
To disconnect the jumper cables from both vehicles, do How to Check Lubricant the following: To get an accurate reading, the vehicle should be on a 1. Disconnect the black negative (−) cable from the level surface. vehicle that had the dead battery. 2.
Page 320: Rear Axle
Rear Axle If you have the 1500 Series, the proper level is from 5/8 inch (15 mm) to 1 5/8 inch (40 mm) below the bottom of the ﬁller plug hole. The proper level for the 2500 and When to Check Lubricant 3500 Series is from 0 to 1/4 (6 mm) below the bottom of the ﬁller plug hole.
Page 321: Noise Control System
Noise Control System If the level is below the bottom of the ﬁller plug hole, you may need to Tampering with Noise Control add some lubricant. System Prohibited The following information relates to compliance with federal noise emission standards for vehicles with a Gross Vehicle Weight Rating (GVWR) of more than 10,000 lbs (4 536 kg).
Page 322 Among those acts presumed to constitute tampering are Air Intake: the acts listed below. • Removal of the air cleaner silencer. Insulation: • Modiﬁcation of the air cleaner. • Removal of the noise shields or any underhood Exhaust: insulation. • Removal of the muffler and/or resonator.
Page 323: Bulb Replacement
Bulb Replacement Headlamps To remove the headlamp assembly from the vehicle and For the proper type of replacement bulbs, see access the bulbs: Replacement Bulbs on page 6-58. 1. Open the hood. See Hood Release on page 6-13 For any bulb changing procedure not listed in this for more information.
Page 324 4. Lift the inboard side of the headlamp to release the inboard tab from the radiator support. 5. Lift the outboard side of the headlamp to release the outboard tab from the radiator support. 6. Lower the headlamp to allow the vertical adjustor to clear the tie bar.
Page 325: Front Turn Signal, Sidemarker And Parking Lamps
Front Turn Signal, Sidemarker and 3. Remove the lamp from the grille. 4. Squeeze the tab on the side of the bulb socket Parking Lamps while turning it counterclockwise. To replace the front turn signal, sidemarker and/or 5. Remove the bulb socket from the back of the lamp parking lamp bulb(s): assembly.
Page 326: Center High-Mounted Stoplamp (Chmsl)
Center High-Mounted Taillamps Stoplamp (CHMSL) To replace one of these bulbs: The Center High-Mounted Stoplamp (CHMSL) is located 1. Remove the two above the rear doors at the center of the vehicle. inboard nuts from the inside of the taillamp To replace a bulb: assembly.
Page 327 7. Turn the bulb counterclockwise to remove it. 8. Turn the bulb clockwise to install it in the socket. 9. Reinstall the bulb socket by squeezing the tab while turning it clockwise. 10. Reinstall the taillamp assembly and three nuts on the vehicle.
Page 328: License Plate Lamp
License Plate Lamp 3. Install the new bulb. 4. Reverse steps 1 and 2 to reinstall the license plate To replace one of these bulbs: bulb assembly. Replacement Bulbs Exterior Lamp Bulb Number Back-up, Rear Parking, 3157 Stoplamp, and Turn Signal Lamp Center High Mounted Stop Lamp (CHMSL) Front Parking and Turn...
Page 329: Windshield Wiper Blade Replacement
Windshield Wiper Blade 3. The insert has two notches at one end that are locked by bottom claws of the blade assembly. Replacement At the notched end, pull the insert from the blade assembly. Windshield wiper blades should be inspected for wear 4.
Page 330: Tires
Tires WARNING: (Continued) Your new vehicle comes with high-quality tires made by a leading tire manufacturer. If you ever • Underinﬂated tires pose the same danger have questions about your tire warranty and where as overloaded tires. The resulting accident to obtain service, see your vehicle Warranty could cause serious injury.
Page 331: Tire Sidewall Labeling
Tire Sidewall Labeling (B) TPC Spec (Tire Performance Criteria Speciﬁcation) Original equipment tires designed to GM’s speciﬁc tire performance criteria have a Useful information about a tire is molded into the TPC speciﬁcation code molded onto the sidewall. sidewall. The following illustrations are examples GM’s TPC speciﬁcations meet or exceed all federal of a typical P-Metric and a LT-Metric tire sidewall.
Page 332 (G) Maximum Cold Inﬂation Load Limit (A) Tire Size The tire size code is a combination Maximum load that can be carried and the of letters and numbers used to deﬁne a particular maximum pressure needed to support that load. tire’s width, height, aspect ratio, construction For information on recommended tire pressure type, and service description.
Page 333 (E) Tire Identiﬁcation Number (TIN) The letters Tire Size and numbers following DOT code are the Tire The following examples show the different parts of Identiﬁcation Number (TIN). The TIN shows the a tire size. manufacturer and plant code, tire size, and date the tire was manufactured.
Page 334 (C) Aspect Ratio A two-digit number that indicates the tire height-to-width measurements. For example, if the tire size aspect ratio is 75, as shown in item C of the illustration, it would mean that the tire’s sidewall is 75 percent as high as it is wide.
Page 335: Tire Terminology And Deﬁnitions
(D) Construction Code A letter code is used to Tire Terminology and Deﬁnitions indicate the type of ply construction in the tire. The letter R means radial ply construction; the letter D Air Pressure The amount of air inside the means diagonal or bias ply construction;...
Page 336 Cold Tire Pressure The amount of air pressure Intended Outboard Sidewall The side of an in a tire, measured in pounds per square inch (psi) asymmetrical tire, that must always face outward or kilopascals (kPa) before a tire has built up heat when mounted on a vehicle.
Page 337 Occupant Distribution Designated seating Speed Rating An alphanumeric code assigned to positions. a tire indicating the maximum speed at which a tire can operate. Outward Facing Sidewall The side of an asymmetrical tire that has a particular side that Traction The friction between the tire and the faces outward when mounted on a vehicle.
Page 338: Inﬂation - Tire Pressure
Vehicle Maximum Load on the Tire Load on If your tires have too much air (over-inﬂation), an individual tire due to curb weight, accessory you can get the following: weight, occupant weight, and cargo weight. • Unusual wear Vehicle Placard A label permanently attached to •...
Page 339: When To Check
When to Check Remove the valve cap from the tire valve stem. Press the tire gage ﬁrmly onto the valve to Check your tires once a month or more. get a pressure measurement. If the cold tire inﬂation pressure matches the recommended Do not forget to check the pressure of the spare pressure on the Tire and Loading Information tire.
Page 340: Dual Tire Operation
Dual Tire Operation Tire Pressure Monitor System When the vehicle is new, or whenever a wheel, wheel bolt The Tire Pressure Monitor System (TPMS) uses radio or wheel nut is replaced, check the wheel nut torque after and sensor technology to check tire pressure levels. 100, 1,000 and 6,000 miles (160, 1 600 and 10 000 km) The TPMS sensors monitor the air pressure in of driving.
Page 341 Accordingly, when the low tire pressure telltale When the malfunction indicator is illuminated, the system illuminates, you should stop and check your tires may not be able to detect or signal low tire pressure as as soon as possible, and inﬂate them to the proper intended.
Page 342: Tire Pressure Monitor Operation
Tire Pressure Monitor Operation If your vehicle has DIC buttons, tire pressure levels can be viewed by the driver. For additional information and details about the DIC operation and displays see DIC This vehicle may have a Tire Pressure Monitor Operation and Displays on page 4-37 and DIC Warnings System (TPMS).
Page 343: Tpms Malfunction Light And Message
TPMS Malfunction Light and Message • One or more TPMS sensors are missing or damaged. The DIC message and the TPMS The TPMS will not function properly if one or more of the malfunction light should go off when the TPMS TPMS sensors are missing or inoperable.
Page 344: Tpms Sensor Matching Process
TPMS Sensor Matching Process The TPMS sensor matching process is outlined below: 1. Set the parking brake. Each TPMS sensor has a unique identiﬁcation code. 2. Turn the ignition switch to ON/RUN with the Any time you rotate your vehicle’s tires or replace one engine off.
Page 345: Tire Inspection And Rotation
4. Start with the driver side front tire. Tire Inspection and Rotation 5. Remove the valve cap from the valve cap stem. Inspect tires regularly for signs of wear or damage. Activate the TPMS sensor by increasing or Also inspect the spare tire. For more information decreasing the tire’s air pressure for ﬁve seconds, on tire inspection, see When It Is Time for or until a horn chirp sounds.
Page 346 Single Rear Wheels Dual Rear Wheels If your vehicle has single rear wheels, always If the vehicle has dual rear wheels and the tread use the correct rotation pattern shown here when design for the front tires is the same as the rotating the vehicle’s tires.
Page 347 Pressure on page 6-68 and Loading the Vehicle on page 5-19. Make certain that all wheel nuts are properly tightened. See “Wheel Nut Torque” under Capacities and Speciﬁcations on page 6-116. WARNING: Rust or dirt on a wheel, or on the parts to which it is fastened, can make wheel nuts become loose after time.
Page 348: When It Is Time For New Tires
When It Is Time for New Tires You need new tires if any of the following statements are true: Various factors, such as maintenance, temperatures, • You can see the indicators at three or more places driving speeds, vehicle loading, and road conditions, around the tire.
Page 349: Buying New Tires
Buying New Tires WARNING: GM has developed and matched speciﬁc tires for your vehicle. The original equipment tires installed on your vehicle, when it was new, were designed to meet Mixing tires could cause you to lose control General Motors Tire Performance Criteria Speciﬁcation while driving.
Page 350: Different Size Tires And Wheels
Vehicles that have a tire pressure monitoring system systems such as anti-lock brakes, rollover airbags, could give an inaccurate low-pressure warning if traction control, and electronic stability control, the non-TPC Spec rated tires are installed on your vehicle. performance of these systems can be affected. Non-TPC Spec rated tires may give a low-pressure warning that is higher or lower than the proper warning WARNING:...
Page 351: Uniform Tire Quality Grading
Uniform Tire Quality Grading Treadwear The treadwear grade is a comparative rating based Quality grades can be found where applicable on the wear rate of the tire when tested under on the tire sidewall between tread shoulder controlled conditions on a speciﬁed government and maximum section width.
Page 352: Wheel Alignment And Tire Balance
Temperature – A, B, C Wheel Alignment and Tire Balance The temperature grades are A (the highest), B, The tires and wheels on your vehicle were aligned and and C, representing the tire’s resistance to the balanced carefully at the factory to give you the longest generation of heat and its ability to dissipate heat tire life and best overall performance.
Page 353 Your dealer/retailer will know the kind of wheel Notice: The wrong wheel can also cause problems you need. with bearing life, brake cooling, speedometer or odometer calibration, headlamp aim, bumper height, Each new wheel should have the same load-carrying vehicle ground clearance, and tire or tire chain capacity, diameter, width, offset and be mounted clearance to the body and chassis.
Page 354: Tire Chains
Tire Chains WARNING: (Continued) WARNING: To help avoid damage to your vehicle, drive slowly, readjust, or remove the device if it is contacting your vehicle, and do not spin the If your vehicle has dual wheels or P245/70R17 or vehicle’s wheels. LT245/75R16 size tires, do not use tire chains.
Page 355: If A Tire Goes Flat
If a Tire Goes Flat WARNING: It is unusual for a tire to blowout while you are driving, especially if you maintain your vehicle’s tires properly. If air goes out of a tire, it is much more likely to leak out Lifting a vehicle and getting under it to do slowly.
Page 356: Changing A Flat Tire
Changing a Flat Tire WARNING: (Continued) If a tire goes ﬂat, avoid further tire and wheel damage by driving slowly to a level place. Turn on the hazard To be even more certain the vehicle will not move, warning ﬂashers. See Hazard Warning Flashers on page 4-3.
Page 357: Removing The Spare Tire And Tools
Removing the Spare Tire and Tools If you have a cargo van or a passenger van, the equipment you will need is located in the passenger side rear corner of the vehicle. To access the equipment, remove the retaining wing bolt and lift it out of the mounting bracket.
Page 358 To lower the spare tire from the vehicle: The tools you will be using include the jack (A), jack handle (B), hoist extension (C), jack handle A. Spare Tire E. Hoist Shaft extension (D), and the wheel wrench (E). B. Tire/Wheel Retainer F.
Page 359 1. Assemble the wheel wrench (G) to one or two of 4. When the tire has been lowered, pull the tire toward the jack handle extensions and the hoist extension. you so you can reach the tire retainer and pull it up Insert the hoist extension end through the hole through the wheel opening.
Page 360: Removing The Flat Tire And Installing The Spare Tire
Removing the Flat Tire and 3. Assemble the jack and tools: Installing the Spare Tire If your vehicle has plastic wheel nut caps, loosen them by turning the wheel wrench counterclockwise. The wheel nut caps are designed to remain with the center cap.
Page 361 Front Position Front Position 6-91...
Page 362 Rear Position Rear Alternative Position (Diesel Vehicles) 4. Position the jack under the vehicle as shown. The front position jacking point is on the frame. The rear position jacking point is on the rear axle. If the exhaust system interferes in the jack location in the rear axle, such as in Diesel vehicles, place the jack (A) on the rear axle between the axle housing and the shock absorber bracket in order to...
Page 363 5. Raise the vehicle by turning the wheel wrench clockwise. Raise the vehicle far enough off the WARNING: ground so there is enough room for the spare tire to ﬁt. Getting under a vehicle when it is jacked up is 6.
Page 364 8. Remove any rust or dirt from the wheel bolts, WARNING: mounting surfaces and spare wheel. Rust or dirt on a wheel, or on the parts to which it is fastened, can make wheel nuts become loose after time. The wheel could come off and cause an accident.
Page 365 9. Put the wheel nuts back on with the WARNING: rounded end of the nuts toward the wheel. Tighten each wheel If wheel studs are damaged, they can break. If all nut by hand until the studs on a wheel broke, the wheel could come the wheel is held off and cause a crash.
Page 366 WARNING: Wheel nuts that are improperly or incorrectly tightened can cause the wheels to become loose or come off. The wheel nuts should be tightened with a torque wrench to the proper torque speciﬁcation after replacing. Follow the torque speciﬁcation supplied by the aftermarket manufacturer when using accessory locking wheel nuts.
Page 367: Secondary Latch System
Secondary Latch System To release the spare tire from the secondary latch: Your vehicle has an underbody-mounted tire hoist WARNING: assembly equipped with a secondary latch system. It is designed to stop the spare tire from suddenly falling off the vehicle if the cable holding the spare tire is Someone standing too close during the procedure damaged.
Page 368 3. Attach the jack handle/jack handle extension and 4. Place the jack under the vehicle, ahead of the rear wheel wrench to the jack. bumper. Position the center lift point of the jack under the center of the spare tire and turn the handle clockwise to raise the jack until it lifts the secondary latch spring.
Page 369 6. Lower the jack by turning the wheel wrench 8. Tilt the retainer at the end of the cable and pull it counterclockwise. Keep lowering the jack until through the wheel opening. Pull the tire out from the spare tire slides off the jack or is hanging under the vehicle.
Page 370: Storing A Flat Or Spare Tire And Tools
Storing a Flat or Spare Tire and Tools WARNING: Storing a jack, a tire, or other equipment in the passenger compartment of the vehicle could cause injury. In a sudden stop or collision, loose equipment could strike someone. Store all these in the proper place.
Page 371: Spare Tire
Spare Tire This vehicle, when new, may have had a fully-inﬂated spare tire. A spare tire may lose air over time, so check its inﬂation pressure regularly. See Inﬂation - Tire Pressure on page 6-68 and Loading the Vehicle on page 5-19 for information regarding proper tire inﬂation and loading the vehicle.
Page 372: Appearance Care
Appearance Care surfaces for which they were not intended. Use glass cleaner only on glass. Remove any accidental over-spray from other surfaces immediately. To prevent over-spray, Interior Cleaning apply cleaner directly to the cleaning cloth. Notice: Using abrasive cleaners when cleaning The vehicle’s interior will continue to look its best if it is glass surfaces on the vehicle, could scratch cleaned often.
Page 373: Fabric/Carpet
Do not clean the vehicle using: Fabric/Carpet • A knife or any other sharp object to remove a soil Use a vacuum cleaner with a soft brush attachment from any interior surface. frequently to remove dust and loose dirt. A canister •...
Page 374: Instrument Panel, Vinyl, And Other Plastic Surfaces
If any of the soil remains, a commercial fabric cleaner products, or those containing organic solvents to or spot lifter may be necessary. When a commercial clean the vehicle’s interior because they can alter the upholstery cleaner or spot lifter is to be used, test appearance by increasing the gloss in a non-uniform a small hidden area for colorfastness ﬁrst.
Page 375: Weatherstrips
Weatherstrips from your dealer/retailer. Follow all manufacturers’ directions regarding correct product usage, necessary safety precautions and appropriate disposal of any Silicone grease on weatherstrips will make them last vehicle care product. longer, seal better, and not stick or squeak. Apply silicone grease with a clean cloth.
Page 376: Finish Care
Finish Care Protecting Exterior Bright Metal Parts Bright metal parts should be cleaned regularly to keep Occasional waxing or mild polishing of the vehicle their luster. Washing with water is all that is usually by hand may be necessary to remove residue from needed.
Page 377: Aluminum Wheels
Aluminum Wheels Notice: Driving the vehicle through an automatic car wash that has silicone carbide tire cleaning brushes, could damage the aluminum or chrome-plated Notice: Using strong soaps, chemicals, abrasive wheels. The repairs would not be covered by the polishes, cleaners, brushes, or cleaners that contain vehicle warranty.
Page 378: Finish Damage
Finish Damage At least every spring, ﬂush these materials from the underbody with plain water. Clean any areas where mud and debris can collect. Dirt packed in close areas Any stone chips, fractures or deep scratches in the of the frame should be loosened before being ﬂushed. ﬁnish should be repaired right away.
Page 379: Vehicle Identiﬁcation
Vehicle Identiﬁcation Service Parts Identiﬁcation Label This label, on the front passenger door frame, has the Vehicle Identiﬁcation Number (VIN) following information: • Vehicle Identiﬁcation Number (VIN) • Model designation • Paint information • Production options and special equipment Do not remove this label from the vehicle. Electrical System This legal identiﬁer is in the front corner of the instrument panel, on the driver side.
Page 380: Headlamp Wiring
The vehicle has an airbag system. Before attempting Although the circuit is protected from electrical overload, to add anything electrical to the vehicle, see Servicing overload due to heavy snow, etc., may cause wiper Your Airbag-Equipped Vehicle on page 2-78 and Adding linkage damage.
Page 381: Floor Console Fuse Block
Floor Console Fuse Block Mini-Fuse Usage Empty The ﬂoor console fuse block is located under the Steering Wheel Sensor driver seat. Auxiliary Parking Lamps (Cut-Away) Front Park Lamps Trailer Park Lamps Upﬁtter Park Lamps Right Rear Park Lamp Left Rear Park Lamp Outside Rear View Mirror Switch Airbag/AOS Empty...
Page 382: Engine Compartment Fuse Block
Mini-Fuse Usage Relays Usage Ignition Switch/Discrete Logic Run (High Current Micro) Ignition Sensor (PK3) Empty (High Current Micro) Instrument Panel Cluster Park Lamps (High Current Micro) Heating, Ventilation and Upﬁtter Auxiliary 2 Air Conditioning Control (High Current Mini) Auxiliary/Trailer Backup Rear Defogger (High Current Micro) Tail Lamps Backup Retained Accessory Power (RAP)
Page 383 Mini Fuse Usage Right Stop/Turn Trailer Spare Spare Fuel System Control Module Ignition Body Control Module 5 Body Control Module 7 Body Control Module 4 Instrument Panel Cluster Trailer Wiring Spare Brake Switch Windshield Washer Horn Transmission Air Conditioning Compressor Engine Control Module Battery Spare Left Stop/Turn Trailer...
Page 384 Mini Fuse Usage Mini Fuse Usage Special Equipment Option Spare Airbag Oxygen Sensor 2 (Post) Steering Wheel Sensor Fan Clutch (EV) Engine Control Module Ignition/ Mass Air Flow/Canister/LAMBDA Glow Plug Module Odd Ignition/Injectors Transmission Control Module Daytime Running Lamps 2 Ignition (LOLVL-V22) Transmission Control Module...
Page 385 J-Case Fuse Usage Relay Usage ABS Motor Run/Crank ABS Module Spare Spare Fuel Pump Trailer Wiring Crank Fan High Air Conditioning Compressor Starter Solenoid Fan High Engine Control Module/Powertrain Powertrain Fuel System Control Module Battery Fan Clutch (EV) Fan Lo Fan Low Front Blower Fan Control...
Page 386: Capacities And Speciﬁcations
Capacities and Speciﬁcations If your vehicle has the DURAMAX Diesel engine, see the DURAMAX Diesel manual for more information. The following approximate capacities are given in metric and English conversions. See Recommended Fluids and Lubricants on page 7-12 for more information. Capacities Application Metric...
Page 387 Capacities Application Metric English Fuel Tank Cutaway (Optional Tank)* 215.7 L 57.0 gal Cutaway (Standard Tank) 124.9 L 33.0 gal Passenger and Cargo 117.3 L 31.0 gal * 159 inch (4 039 mm) wheelbase or 177 inch (4 496 mm) wheelbase only Transmission Fluid (Pan Removal and Filter Replacement) 4-SPD 4L60-E 4.7 L...
Page 388 ✍ NOTES 6-118...
Page 389 Section 7 Maintenance Schedule Recommended Fluids and Lubricants ....7-12 Maintenance Schedule ........7-2 Maintenance Replacement Parts .....7-14 Introduction ...........7-2 Engine Drive Belt Routing ......7-15 Scheduled Maintenance ........7-3 Maintenance Record ........7-16 Owner Checks and Services ......7-10...
Page 390 Maintenance Schedule The maintenance schedule is for vehicles that: • carry passengers and cargo within recommended limits on the Tire and Loading Information label. Introduction See Loading the Vehicle on page 5-19. • This maintenance section applies to vehicles with a are driven on reasonable road surfaces within legal gasoline engine.
Page 391: Scheduled Maintenance
At your General Motors dealer/retailer, you can be Scheduled Maintenance certain that you will receive the highest level of service available. Your dealer /retailer has specially trained When the Change Engine Oil Soon service technicians, uses genuine GM replacement Message Displays parts, as well as, up to date tools and equipment to ensure fast and accurate diagnostics.
Page 392 When the Change Engine Oil Soon message displays, • Tire inﬂation check. See Inﬂation - Tire Pressure on certain services, checks, and inspections are required. page 6-68. The services described for Maintenance I should be • Tire wear inspection. See Tire Inspection and performed at every engine oil change.
Page 393 Maintenance II • Body hinges and latches, key lock cylinders, folding seat hardware, and rear compartment hinges, • Perform all services described in Maintenance I. linkage, and handle pivot points lubrication. See • Recommended Fluids and Lubricants on page 7-12. Steering and suspension inspection.
Page 394: Additional Required Services
• Once a Month Engine air cleaner ﬁlter inspection. See Engine Air Cleaner/Filter on page 6-20. • Tire inﬂation check. See Inﬂation - Tire Pressure on • Vehicles with diesel engine or GVWR above page 6-68. 4 536 kg (10,000 lbs) only: Shields inspection •...
Page 395 • • Exhaust system and nearby heat shields inspection All-wheel drive only: Transfer case ﬂuid change for loose or damaged components. (severe service) for vehicles mainly driven when frequently towing a trailer, or used for taxi, police, or • Throttle system inspection for interference, binding delivery service.
Page 396 First Engine Oil Change After Every First Engine Oil Change After Every 160 000 km/100,000 Miles 240 000 km/150,000 Miles • • Automatic transmission ﬂuid change (normal Engine cooling system drain, ﬂush, and reﬁll, service). See Automatic Transmission Fluid cooling system and cap pressure check, and (4-Speed Transmission) on page 6-21 or Automatic cleaning of outside of radiator and air conditioning Transmission Fluid (6-Speed Transmission) on...
Page 397 Scheduled Maintenance Service Maintenance I Maintenance II • • Change engine oil and ﬁlter. Reset oil life system. • • Engine coolant level check. • • Windshield washer ﬂuid level check. • • Tire inﬂation pressures check. • • Tire wear inspection. •...
Page 398: Owner Checks And Services
Owner Checks and Services Automatic Transmission Shift Lock Control System Check Starter Switch Check WARNING: WARNING: When you are doing this inspection, the vehicle When you are doing this inspection, the vehicle could move suddenly. If the vehicle moves, you or could move suddenly.
Page 399: Ignition Transmission Lock Check
Ignition Transmission Lock Check Park on a fairly steep hill, with the vehicle facing downhill. Keeping your foot on the regular brake, While parked, and with the parking brake set, try to turn set the parking brake. the ignition to LOCK/OFF in each shift lever position. •...
Page 400: Recommended Fluids And Lubricants
Recommended Fluids and Usage Fluid/Lubricant Lubricants DOT 3 Hydraulic Brake Fluid Hydraulic Brake (GM Part No. U.S. 12377967, System This maintenance section applies to vehicles with a in Canada 89021320). gasoline engine. If the vehicle has a diesel engine Windshield and/or an Allison Transmission, see the maintenance ®...
Page 401 Usage Fluid/Lubricant Usage Fluid/Lubricant Wheel bearing lubricant meeting Multi-Purpose Lubricant, Superlube requirements of NLGI #2, Hood Hinges (GM Part No. U.S. 12346241, Front Wheel Category GC or GC-LB in Canada 10953474). Bearings (GM Part No. U.S. 1051344, Weatherstrip Lubricant in Canada 993037). (GM Part No.
Page 402: Maintenance Replacement Parts
Maintenance Replacement Parts If the vehicle has the DURAMAX Diesel engine, see the DURAMAX Diesel manual for more information. Replacement parts identiﬁed below by name, part number, or speciﬁcation can be obtained by your dealer/retailer. Part GM Part Number ACDelco Part Number Engine Air Cleaner/Filter 15950115 A3097C...
Page 403: Engine Drive Belt Routing
Engine Drive Belt Routing V8 Engines V6 Engines ® If your vehicle has the DURAMAX Diesel engine, see ® the DURAMAX Diesel manual for more information. 7-15...
Page 404: Maintenance Record
Maintenance Record After the scheduled services are performed, record the date, odometer reading, who performed the service, and the type of services performed in the boxes provided. Retain all maintenance receipts. Maintenance Record Odometer Date Serviced By Services Performed Reading 7-16...
Page 405 Maintenance Record (cont’d) Odometer Date Serviced By Services Performed Reading 7-17...
Page 406 Maintenance Record (cont’d) Odometer Date Serviced By Services Performed Reading 7-18...
Page 407: Customer Assistance Information
Section 8 Customer Assistance Information Reporting Safety Defects ........8-16 Customer Assistance and Information ....8-2 Reporting Safety Defects to the Customer Satisfaction Procedure ......8-2 United States Government ......8-16 Online Owner Center ........8-5 Reporting Safety Defects to the Customer Assistance for Canadian Government ........8-16 Text Telephone (TTY) Users ......8-6 Reporting Safety Defects to General Motors ..8-16 Customer Assistance Offices ......8-6...
Page 408: Customer Assistance And Information
Your satisfaction and goodwill are important to your We encourage you to call the toll-free number in order to dealer and to Chevrolet. Normally, any concerns with the give your inquiry prompt attention. Have the following sales transaction or the operation of the vehicle will be information available to give the Customer Assistance resolved by the dealer’s sales or service departments.
Page 409 STEP THREE — U.S. Owners: Both General Motors You may contact the BBB Auto Line Program using the and your dealer are committed to making sure you are toll-free telephone number or write them at the following completely satisﬁed with your new vehicle. However, if address: you continue to remain unsatisﬁed after following the BBB Auto Line Program...
Page 410 STEP THREE — Canadian Owners: In the event that For further information concerning eligibility in the you do not feel your concerns have been addressed Canadian Motor Vehicle Arbitration Plan (CAMVAP), after following the procedure outlined in Steps 1 and 2, call toll-free 1-800-207-0685, or call the General Motors General Motors of Canada Limited wants you to be aware Customer Communication Centre, 1-800-263-3777...
Page 411: Online Owner Center
• Online service and maintenance records • My Dealers/Retailers: Save details such as address • Find Chevrolet dealers for service nationwide and phone number for each of your preferred GM • dealers/retailers. Exclusive privileges and offers •...
Page 412: Customer Assistance For Text Telephone (Tty) Users
Chevrolet encourages customers to call the toll-free 1908 Colonel Sam Drive number for assistance. However, if a customer wishes Oshawa, Ontario L1H 8P7 to write or e-mail Chevrolet, the letter should be addressed to: gmcanada.com 1-800-263-3777 (English) United States — Customer Assistance...
Page 413: Gm Mobility Reimbursement Program
Overseas — Customer Assistance GM Mobility Reimbursement Program Please contact the local General Motors Business Unit. Mexico, Central America and Caribbean Islands/Countries (Except Puerto Rico and U.S. Virgin Islands) — Customer Assistance General Motors de Mexico, S. de R.L. de C.V. Customer Assistance Center Paseo de la Reforma # 2740 Col.
Page 414: Roadside Assistance Program
Service is available 24 hours a day, 365 days a year. Roadside Assistance is not a part of the New Vehicle Calling for Assistance Limited Warranty. Chevrolet and General Motors of Canada Limited reserve the right to make any changes When calling Roadside Assistance, have the following...
Page 415: Services Provided
Towing or services for vehicles driven on a • Emergency Tow From a Public Road or Highway: non-public road or highway. Tow to the nearest Chevrolet dealer for warranty Services Speciﬁc to Canadian service, or if the vehicle was in a crash and cannot Purchased Vehicles be driven.
Page 416: Scheduling Service Appointments
• Scheduling Service Appointments Trip Interruption Beneﬁts and Assistance: Must be over 250 kilometres from where your trip was When your vehicle requires warranty service, contact started to qualify. General Motors of Canada Limited your dealer/retailer and request an appointment. requires pre-authorization, original detailed receipts, By scheduling a service appointment and advising your and a copy of the repair orders.
Page 417: Courtesy Transportation Program
Courtesy Transportation Program Transportation Options Warranty service can generally be completed while To enhance your ownership experience, we and you wait. However, if you are unable to wait, GM helps our participating dealers are proud to offer Courtesy to minimize your inconvenience by providing several Transportation, a customer support program for vehicles transportation options.
Page 418: Additional Program Information
Public Transportation or Fuel Requirements vary and may include minimum age requirements, insurance coverage, credit card, etc. Reimbursement You are responsible for fuel usage charges and may also If your vehicle requires overnight warranty repairs, and be responsible for taxes, levies, usage fees, excessive public transportation is used instead of the dealer’s mileage, or rental usage beyond the completion of the shuttle service, the expense must be supported by...
Page 419: Collision Damage Repair
Collision Damage Repair an acceptable choice to maintain your vehicle’s originally designed appearance and safety performance, however, the history of these parts is not known. Such parts are not If your vehicle is involved in a collision and it is covered by your GM New Vehicle Limited Warranty, and damaged, have the damage repaired by a qualiﬁed any related failures are not covered by that warranty.
Page 420: Insuring Your Vehicle
Insuring Your Vehicle If a Crash Occurs Protect your investment in your GM vehicle with Here is what to do if you are involved in a crash. comprehensive and collision insurance coverage. • Check to make sure that you are all right. If you There are signiﬁcant differences in the quality of are uninjured, make sure that no one else in coverage afforded by various insurance policy terms.
Page 421 • Managing the Vehicle Damage Repair Gather the important information you will need from the other driver. Things like name, address, phone Process number, driver’s license number, vehicle license plate, vehicle make, model and model year, Vehicle In the event that your vehicle requires damage repairs, Identiﬁcation Number (VIN), insurance company and GM recommends that you take an active role in its repair.
Page 422: Reporting Safety Defects To The United States Government
Call 1-800-222-1020, or write: To contact NHTSA, you may call the Vehicle Safety Hotline toll-free at 1-888-327-4236 Chevrolet Motor Division (TTY: 1-800-424-9153); go to Chevrolet Customer Assistance Center http://www.safercar.gov; or write to: P.O. Box 33170 Detroit, MI 48232-5170 Administrator, NHTSA In Canada, call 1-800-263-3777 (English) or 1200 New Jersey Avenue, S.E.
Page 423: Service Publications Ordering Information
Service Publications Ordering Current and Past Model Order Forms Information Technical Service Bulletins and Manuals are available for current and past model GM vehicles. To request Service Manuals an order form, specify year and model name of the vehicle. Service Manuals have the diagnosis and repair ORDER TOLL FREE: 1-800-551-4123 information on engines, transmission, axle suspension, brakes, electrical, steering, body, etc.
Page 424: Vehicle Data Recording And Privacy
Vehicle Data Recording and Event Data Recorders Privacy This vehicle has an Event Data Recorder (EDR). The main purpose of an EDR is to record, in certain Your GM vehicle has a number of sophisticated crash or near crash-like situations, such as an airbag computers that record information about the vehicle’s deployment or hitting a road obstacle, data that will assist performance and how it is driven.
Page 425: Onstar
Important: EDR data is recorded by your vehicle only GM will not access this data or share it with others if a non-trivial crash situation occurs; no data is recorded except: with the consent of the vehicle owner or, if the by the EDR under normal driving conditions and no vehicle is leased, with the consent of the lessee;...
Page 426: Navigation System
Navigation System Radio Frequency Statement If your vehicle has a navigation system, use of the system This vehicle has systems that operate on a radio may result in the storage of destinations, addresses, frequency that comply with Part 15 of the Federal telephone numbers, and other trip information.
Page 427 Antenna Fixed Mast ..........4-78 Accessories and Modiﬁcations ......6-3 Antilock Brake System (ABS) ......5-4 Accessory Power ..........3-23 Warning Light ..........4-28 Accessory Power Outlets ......... 4-14 Appearance Care Additives, Fuel ..........6-7 Aluminum Wheels ........6-107 Add-On Electrical Equipment ......6-109 Care of Safety Belts ........
Page 428 Audio System(s) ..........4-62 Bulb Replacement (cont.) Automatic Door Lock ........3-11 Headlamps ..........6-53 Automatic Door Unlock ........3-11 License Plate Lamps ........6-58 Automatic Headlamp System ......4-11 Taillamps ............ 6-56 Automatic Transmission Buying New Tires ........... 6-79 Fluid ..........
Page 429 Child Restraints Clock, Setting ..........4-60 Infants and Young Children ......2-33 Collision Damage Repair ........8-13 Lower Anchors and Tethers for Children ..2-42 Compass ............4-42 Older Children ..........2-30 Control of a Vehicle .......... 5-3 Securing a Child Restraint in a Rear Seat Coolant Position ..........
Page 430 Dome Lamps ..........4-12 Driving (cont.) Door Off-Road Recovery ........5-10 60/40 Swing-Out Side Door ......3-13 Rocking Your Vehicle to Get it Out ....5-19 Automatic Door Lock ........3-11 Winter ............5-16 Automatic Door Unlock ......... 3-11 Driving for Better Fuel Economy ....... 1-18 Cargo Door Relocking ........
Page 431 Engine (cont.) Flash-to-Pass ........... 4-5 Coolant Heater ..........3-25 Flat Tire ............6-85 Coolant Temperature Gage ......4-29 Flat Tire, Changing ......... 6-86 Cooling System ........... 6-28 Flat Tire, Storing ........... 6-100 Drive Belt Routing ........7-15 Fluid Exhaust ............. 3-40 Automatic Transmission ......
Page 432 Headlamps (cont.) Front Turn Signal, Sidemarker and Parking Gages Lamps ............ 6-55 Engine Coolant Temperature ......4-29 High/Low Beam Changer ........ 4-5 Fuel ............4-35 On Reminder ..........4-10 Oil Pressure ..........4-33 Heater ............4-15 Speedometer ..........4-22 Engine Coolant ........... 3-25 Trip Odometer ..........
Page 433 Lights Airbag Off ..........4-24 Jump Starting ..........6-44 Airbag Readiness ........4-23 Antilock Brake System (ABS) Warning .... 4-28 Brake System Warning ......... 4-27 Charging System ......... 4-26 Cruise Control ..........4-35 Keyless Entry Exterior Lamps ..........4-9 Remote (RKE) System ........3-4 Flash-to-Pass ..........
Page 434 Locks (cont.) Mirrors (cont.) Lockout Protection ........3-12 Outside Manual Mirrors ........ 3-42 Power Door ..........3-10 Outside Power Mirrors ........3-43 Programmable Automatic Door Locks ..... 3-10 Outside Towing Mirrors ......... 3-42 Rear Door Security Locks ......3-11 MP3 ............. 4-72 Loss of Control ..........
Page 435 OnStar, Privacy ..........8-19 Power Outlet Adjustment ..........4-17 Door Locks ..........3-10 Outlets Retained Accessory (RAP) ......3-23 Accessory Power ......... 4-14 Seat ............2-3 Outside Steering Fluid ..........6-38 Convex Mirror ..........3-43 Windows ............ 3-17 Heated Mirrors ..........3-44 Pregnancy, Using Safety Belts ......
Page 436 Rear Axle ............6-50 Restraint System Check Locking ............5-8 Checking the Restraint Systems ....2-80 Rear Door Security Locks ........ 3-11 Replacing Restraint System Parts After a Rear Doors ............ 3-15 Crash ............. 2-81 Rear Heating System ........4-18 Retained Accessory Power (RAP) ......
Page 437 Safety Warnings and Symbols ......iv Sheet Metal Damage ........6-107 Scheduled Maintenance ........7-3 Shifting Scheduling Appointments ......... 8-10 Out of Park ..........3-38 Seats Shifting Into Park ..........3-37 Head Restraints ..........2-2 Signals, Turn and Lane-Change ......4-4 Power Seat ..........
Page 438 Tires (cont.) Inspection and Rotation ........ 6-75 Taillamps ............6-56 Installing the Spare Tire ........ 6-90 Tampering with Noise Control System Pressure Light ..........4-30 Prohibited ........... 6-51 Pressure Monitor Operation ......6-72 Text Telephone (TTY) Users ....... 8-6 Pressure Monitor System ......6-70 Theft-Deterrent Feature ........
Page 439 Traction Vehicle Customization, DIC ......4-52 ® StabiliTrak System ........5-5 Vehicle Data Recording and Privacy ....8-18 Transmission Vehicle Identiﬁcation Fluid, Automatic ........6-21, 6-24 Number (VIN) ..........6-109 Transmission Operation, Automatic .... 3-27, 3-32 Service Parts Identiﬁcation Label ....6-109 Transportation Program, Courtesy ......
Page 440 Windows ............3-16 Enhanced Technology Glass ......3-19 Manual ............3-16 Power ............3-17 Swing-Out Windows ........3-18 Windshield Washer ............4-6 Washer Fluid ..........6-39 Wiper Blade Replacement ......6-59 Wiper Blades, Cleaning ......6-106 Wiper Fuses ..........6-110 Wipers ............

Chevrolet 2010 Express Owner's Manual

Section 2 Seats and Restraint System

Section 3 Features and Controls

Section 4 Instrument Panel

Instrument Panel Overview

Climate Controls

Warning Lights, Gages, and Indicators

Driver Information Center (DIC)

Audio System(S)

Section 5 Driving Your Vehicle

Section 6 Service and Appearance Care

Quick Links

Chapters

Related Manuals for Chevrolet 2010 Express

Summary of Contents for Chevrolet 2010 Express
