OKIPAGE 12i
LED Page Printer

Maintenance Manual

ODA / OEL / INT
Rev.6 2000-03-27
1 / 210
40718301TH Rev.6

Advertisement

Table of Contents
loading

Related Manuals for Oki OKIPAGE 12i

Summary of Contents for Oki OKIPAGE 12i

  • Page 1: Maintenance Manual

    OKIPAGE 12i LED Page Printer Maintenance Manual ODA / OEL / INT Rev.6 2000-03-27 1 / 210 40718301TH Rev.6...

  • Page 2: Table Of Contents

    CONTENTS 1. CONFIGURATION ....................5 1.1 System Configuration ..................5 1.2 Printer Configuration ..................7 1.3 Optional Configuration ..................8 1.4 Specification ....................11 1.5 Safety Standards .................... 13 1.5.1 Certification Label ....................13 1.5.2 Warning Label ......................13 1.5.3 Warning/Caution Marking ..................
  • Page 3 4. ADJUSTMENT ......................76 4.1 Maintenance Modes and Functions ..............76 4.1.1 User Maintenance Mode ..................76 4.1.2 System Maintenance Mode ..................76 4.1.3 Engine Maintenance Mode ..................77 4.1.4 EEPROM initialization .................... 78 4.2 Adjustment When Replacing a Part ..............79 4.2.1 Setting of LED Head Drive Time ................
  • Page 4 Parts Replacement Method164 3.3.1 Link ......................165 3.3.2 Separator ....................166 3.3.3 OLEV-11-PCB ..................167 3.3.4 Pulse Motor .................... 168 3.3.5 Planet Gear .................... 169 3.3.6 Roller-A and B ..................170 TROUBLESHOOTING..................171 Precautions Prior to the Troubleshooting ............... 171 Preparations for the Troubleshooting ..............

  • Page 5: Configuration

    CONFIGURATION System Configuration OKIPAGE 12i consists of control and engine blocks in the standard configuration, as shown in Figure 1-1. In addition, the options marked with asterisk(*) are available. 40718301TH Rev.6...
  • Page 6 Operator Panel Engine Unit Paper Cassette Face Up Stacker *High Capacity Second Paper Paper Feeding Mechanism Feeder (First Tray Unit) Face *Multi Purpose Down Feeder Stacker Electrophotographic Processing Unit Power Supply and Sensor Board Centronics Main Control Board * : Optional Memory* Expansion Board ** : Optional (ODA/INT)

  • Page 7: Printer Configuration

    Printer Configuration The printer unit consists of the following hardware components: • Electrophotographic Processor • Paper Feeder • Controller • Operator Panel • Power Supply Unit The printer unit configuration is shown in Figure 1-2. Upper cover Operator panel assy Toner-cartridge(Type 5) (consumable) Stacker assy...

  • Page 8: Optional Configuration

    Optional Configuration The options shown below are available for use with OKIPAGE 12i. These are available separately from the printer unit. (1) High Capacity Second Paper Feeder (2) Multi Purpose Feeder (3) 1MB Memory Expausion Board 40718301TH Rev.6...
  • Page 9 (4) RS-232C Serial Interface Board (5) Network Interface Board (6) DRAM SIMM Memory DRAM SIMM memory is available with memory of 1MB (min.) to 32MB (max.). The access time of SIMM memories are 60ns, 70ns, 80ns, and 100ns. 40718301TH Rev.6...
  • Page 10 (7) Flash memory SIMM 10 / 40718301TH Rev.6...

  • Page 11: Specification

    Specification (1) Type Desktop (2) External dimensions Height 7.9” (200 mm) Width 13.6” (345 mm) Depth 15.7” (400 mm) (3) Weight Approx. 10 kg (4) Developing method Dry electrophotography Exposing method LED stationary head (5) Paper used <Type> • Standard paper –...
  • Page 12 (8) Paper delivery method Face down/face up 600 × 600 dots/inch (9) Resolution 600 × 1200 dots/inch (10) Power input 120 VAC + 5.5%, -15% 230 VAC ± 10% 120VAC 230VAC (11) Power consumption Peak: Approx. 515W Approx. 520W Typical operation: Approx.

  • Page 13: Safety Standards

    Safety Standards 1.5.1 Certification Label The safety certification label is affixed to the printer in the position described below. INT AC : 230V model ODA AC : 120V model ODA AC : 230V model 1.5.2 Warning Label The warning labels are affixed to the sections which may cause bodily injury. Follow the instructions on warning labels during maintenance.

  • Page 14: Warning/Caution Marking

    1.5.3 Warning/Caution Marking The following warning and caution markings are made on the power supply/sensor board. WARNING AVERTISSEMENT ADVERTENCIA CAUTION HEATSINK AND TRANSFORMER ATTENTION ATENCÃO PRESENT RISK OF ELECTRIC SHOCK CUIDADO CUIDÃDO TEST BEFORE TOUCHING * No fuse is mounted here for 200V series ENGLISH Heatsink and transformer core present risk of electric shock.

  • Page 15: Operation Description

    OPERATION DESCRIPTION OKIPAGE 12i consists of a main control board, a power supply/sensor board, an operator panel, an electrophotographic process mechanism, and revision for illumination of LED head. The main control board receives data via the host I/F, it then decodes, edits and stores the data in memory.

  • Page 16: Main Control Board

    Paper sensor Toner supply roller Outlet sensor Cleaning roller Thermistor Paper out sensor Fusing temperature control circuit Heater drive Toner low sensor Heater circuit transformer Filter circuit AC IN Figure 2-1 OKIPAGE 12i Block Diagram 16 / 40718301TH Rev.6...

  • Page 17: Main Control Board

    Main Control Board The main control board consists of a single chip CPU, two program/font ROMs, two DRAMs, an EEPROM, a host interface circuit, and a mechanism driving circuit. (1) Single chip CPU The single chip CPU is a custom CPU (32-bit internal bus, 32-bit external bus, 40.55-MHz clock (20.75 MHz ×...

  • Page 18: Power Supply/Sensor Board

    Power Supply/Sensor Board The power supply/sensor board consists of an AC filter circuit, a low voltage power supply circuit, a high voltage power supply circuit, heater drive circuit, and photosensors. (1) Low Voltage Power Supply Circuit This circuit generates the following voltages. Output voltage +5 V Logic circuit supply voltage...
  • Page 19 The sensor layout diagram is shown in Figure 2-2. Exit roller Outlet sensor Heat roller Transfer roller Paper sensor Toner Inlet sensor sensor 2 Registration roller Paper end sensor Hopping roller Inlet sensor 1 Figure 2-2 Sensor Function Sensing state Inlet sensor 1 Detects the leading part of the paper and gives the monitor timing : Paper exists.

  • Page 20: Electrophotographic Process

    Electrophotographic Process 2.3.1 Electrophotographic Process Mechanism This mechanism actuates the printing of image data supplied by the main control board on the paper by electrophotographic process. The layout of the electrophotographic process mechanism is shown in Figure 2-3. 20 / 40718301TH Rev.6...
  • Page 21 Figure 2-3 21 / 40718301TH Rev.6...
  • Page 22 (1) Image Drum Unit The image drum unit consists of a sensitive drum, a charger, and a developer. The unit forms a toner image on the sensitive drum, using a electrostatic latent image formed by the LED head. (2) Registration Motor The registration motor is a pulse motor of 48 steps/rotation with two-phase excitement by the signal from the main control board.

  • Page 23: Electrophotographic Process

    2.3.2 Electrophotographic Process The electrophotographic processing is outlined below. The electrophotographic printing process is shown in Figure 2-4. 1 Charging The surface of the image drum is charged uniformly with a negative charge by applying the negative voltage to the charge roller. 2 Exposure Light emitted from the LED head irradiates the negatively charged surface of the image drum.
  • Page 24 Figure 2-4 24 / 40718301TH Rev.6...
  • Page 25 PRINT-N PRDY-N DM-ON-N RM-ON INSNS OUTSNS-N Feed start IN Sensor OFF OUT Sensor OFF Feed stop...

  • Page 26: Process Operation Descriptions

    2.3.3 Process Operation Descriptions (1) Hopping and Feeding Hopping and feeding motions are actuated by a single registration motor in the mechanism as shown below: Registration motor Idle gear Registration roller Hopping roller Motor gear Registration gear Hopping gear The registration motor turning in direction "a" drives the hopping roller. The registration motor turning in direction "b"...
  • Page 27 Hopping 1 For hopping, the registration motor turns in direction "a" (clockwise direction) and drives the hopping roller to advance the paper until the inlet sensor turns on (in this case, the registration gear also turns, but the registration roller is prevented from turning by the one- way bearing).
  • Page 28 (2) Charging Charging is actuated by the application of the DC voltage to the charge roller that is in contact with the image drum surface. Power Charge roller supply Image drum The charge roller is composed of two layers, a conductive layer and a surface protective layer, both having elasticity to secure good contact with the image drum.
  • Page 29 (3) Exposure Light emitted by the LED head irradiates the image drum surface with a negative charge. The surface potential of the irradiated portion of the image drum drops, forming an electrostatic latent image associated with the image signal. LED head LED head Charge roller Power...
  • Page 30 The image roller surface is charged to about –750 V by the contact charge of the charge roller. When the light from the LED head irradiates the image drum surface, the light energy generates positive and negative carriers in the CGL. The positive carriers are moved to the CTL by an electrical field acting on the image drum.
  • Page 31 (4) Developing Toner is attracted to the electrostatic latent image on the image drum surface, converting it into a visible toner image. Developing takes place through the contact between the image drum and the developing roller. 1 As the toner supply roller rotates while rubbing on the developing roller, a friction charge is generated between the developing roller and the toner, allowing the toner to be attracted to the developing roller (the developing roller surface is charged positive and the toner, negative).
  • Page 32 Note: The bias voltage required during the developing process is supplied to the toner supply roller and the developing roller, as shown below. –500 VDC is supplied to the toner supply roller, –265 VDC to the developing roller. Connected and bias supplied when the cover is closed.
  • Page 33 (5) Transfer The transfer roller is composed of conductive sponge material, and is designed to get the image drum surface and the paper in a close contact. Paper is placed over the image drum surface, and the positive charge, opposite in polarity to that of the toner, is applied to the paper from the reverse side.
  • Page 34 (6) Fusing When the transfer is completed, the toner image is fused to the paper by heat and pressure as the paper with unfused toner image passes between the heater roller and the back-up roller. The heater roller with Teflon coating incorporates a 400W heater (Halogen lamp), which generates heat. A thermistor which is in contact with the heater roller regulates the temperature of the heater roller to a designated temperature in the menu, depending on the thickness of the paper (tray 1&2: light=165°C, medium light=170°C, medium=175°C, medium heavy and heavy=195°C/manual...
  • Page 35 (7) Cleaning When the transfer is completed, the residual toner left on the image drum is attracted to the cleaning roller temporarily by static electricity, and the image drum surface is cleaned. Image drum Cleaning roller Power supply Transfer roller (8) Cleaning of rollers The charge, transfer and cleaning rollers are cleaned for the following cases: •...

  • Page 36: Revision Of Led Head Illumination36

    2.3.4 Revision of LED Head Illumination An LED correcting head, which is capable of correcting the illumination of the LED for each dot, is being used in this printer. LED illumination correction function of 16 steps is carried out by using an EEPROM which is installed in the LSI that maintains the LED illumination correction values, and an LED correction drivers (MSM6731BWAF or MSM6732BWAF) together as a pair.
  • Page 37 The printing operation timing chart is shown below. Normal Mode Printing Timing Chart CLOCKI LOADI DATAI3~0 STRB1I-N STRB2I-N STRB3I-N STRB4I-N First line printing data sent Second line printing data sent First line printing The printing operation is carried out in normal mode. Under ordinary circumstances such as when the power is turned on or when LOADI signal level is low, the normal mode is enabled.
  • Page 38 The mode setting timing chart during illumination correction is shown below. Illumination Correction Mode Setting Timing Chart 50ns 50ns 100ns min 200ns min 100ns min CLOCKI LOADI DATAI0 D4 D3 D2 D1 D0 STRB1I-N STRB2I-N STRB3I-N STRB4I-N Mode setting Mode enabled Mode set The mode setting is carried out in the following manner.
  • Page 39 The LED driver (MSM6731BWAF) corrects the LED illumination by controlling the LED current. The LED illumination can be set in 16 steps, with 7 steps in the direction of illumination increase in relation to the standard value, and 8 steps in the direction of decrease. For this reason, the LED correction data is a 4-bit data for each dot.

  • Page 40: Paper Jam Detection

    Paper Jam Detection The paper jam detection function monitors the paper condition when the power is turned on and during printing. When any of the following conditions arises, this function interrupts the printing process. If any of the following errors is encountered, printing can be recovered by removing the jammed paper (by opening the upper cover, removing the jammed paper and closing the upper cover).
  • Page 41 Paper Feed Check List Error Type of error Monitor Standard value Plus Minus Paper feed error Hopping start In sensor on 72.0 36.0 – Paper feed jam In sensor on Write sensor on 20.0 22.0 – Paper feed jam Write sensor on Out sensor on 140.5 25.0...

  • Page 42: Cover Open

    Cover Open When the stacker cover is opened, the cover open microswitch on the power supply/sensor board is turned off to cut +5V supply to the high voltage power supply circuit. This results in the interruption of all high-voltage outputs. At the same time, the CVOPN signal is sent to the main control board to notify that the microswitch is off, and the main control board carries out the cover open process.

  • Page 43: Toner Low Detection

    Toner Low Detection • Device The Toner Low Detection device consists of a stirring gear which rotates at a constant rate, a stirring bar and a magnet on the stirring bar. The stirring bar rotation is driven by the link to the gouged portion in the stirring gear.

  • Page 44: Toner Full State

    TONER FULL state 160 ms < t1 < 0.7 sec TNRSNS-N 2.24 sec. TONER LOW state t1 > 0.7 sec. TNRSNS-N 2.24 sec. • When the Toner Low state is detected 2 times consecutively, Toner Low is established. • When the Toner Full state is detected 2 times consecutively, Toner Low is cancelled. When there is no change with the toner sensor for 2 cycles (2.24 sec.

  • Page 45: Parts Replacement

    PARTS REPLACEMENT The section explains the procedures for replacement of parts, assemblies, and units in the field. Only the disassembly procedures are explained here. For reassembly, reverse the disassembly procedure. Precautions for Parts Replacement (1) Before starting to replace parts, remove the AC cord and interface cable. Remove the AC cord in the following sequence: Turn off (“o”) the power switch of the printer Disconnect the AC inlet plug of the AC cord from the AC receptacle.
  • Page 46 [Service Tools] The tools required for field replacement of printed circuit boards, assemblies and units are listed in Table 3-1. Table 3-1 Service Tools Service Tools Q' ty Application Remarks No. 1-100 Philips screwdriver 2~2.5 mm screws No. 2-100 Philips screwdriver 3~5 mm screws No.

  • Page 47: Parts Layout

    Parts Layout This section explains the layout of main components of the equipment. [Lower base unit] Pulse motor Stacker cover assy (main/drum) Eject roller assy Back-up roller View A Pulse motor Transfer roller (registration) Diselectrification bar Registration roller Spacer bearing R Fusing unit Spacer bearing L Lower base unit...
  • Page 48 [Upper cover unit] Upper cover Figure 3-2 48 / 40718301TH Rev.6...
  • Page 49 [Base unit] Operator panel assy Power supply/ sensor board Transformer Face up stacker assy DC fan assy Main control board Cassette guide (R) Cassette guide(L) Paper cassette Figure 3-3 49 / 40718301TH Rev.6...

  • Page 50: How To Change Parts

    How to Change Parts This section explains how to change parts and assemblies listed in the disassembly diagram below. In the parts replacement procedure, those parts marked with the part number inside with white letters are RSPL parts. Printer unit Upper cover assy Operator panel assy Face up stacker assy...

  • Page 51: Upper Cover Assy

    3.3.1 Upper Cover Assy (1) With the power switch turned off, unplug the AC power cord from the outlet. (2) Disconnect the interface cable 1. (3) Press the knobs 2 on left and right sides and open the stacker cover assy 3. (4) Take out the image drum unit 4.

  • Page 52: Led Head

    3.3.2 LED Head (1) Press the knobs on left and right sides and open the stacker cover assy 1. (2) Open the hook section on the left side of the stacker cover and remove the LED head 2. Note: • Be sure not to touch directly or push on the SLA part of the LED head.

  • Page 53: Operator Panel Assy

    3.3.3 Operator Panel Assy (1) Unlock two latches on the upper cover from the rear side, lift the operator panel assy 1 from the back and remove it. (2) Remove the Sumi card (operator panel) 2 from the connector (CN1) 3. Note : You can remove the operator panel assy while the upper cover installed on the unit.

  • Page 54: Lower Base Unit

    3.3.4 Lower Base Unit (1) Remove the upper cover assy (see 3.3.1). (2) Remove the operator panel assy (see 3.3.3). (3) Remove the face up stacker assy (see 3.3.7). (4) Remove the connecting cables 2 and 3 of the pulse motors from the connectors (DM, RM) of the M5B-PCB 1.

  • Page 55: Pulse Motor (Main/Drum)

    3.3.5 Pulse Motor (Main/Drum) (1) Remove the upper cover assy (see 3.3.1). (2) Remove the lower base unit (see 3.3.4). (3) Remove two screws 1 and remove the pulse motor (main/drum) 2 from the motor bracket 3. View A View A 55 / 40718301TH Rev.6...

  • Page 56: Pulse Motor (Registration)

    3.3.6 Pulse Motor (Registration) (1) Remove the upper cover assy (see 3.3.1). (2) Remove the lower base unit (see 3.3.4). (3) Remove two screws 1 and remove the pluse motor (registration) 2 from the motor bracket 3. View A View A 56 / 40718301TH Rev.6...

  • Page 57: Face Up Stacker Assy

    3.3.7 Face Up Stacker Assy (1) Remove the upper cover assy (see 3.3.1). (2) Remove the operator panel assy (see 3.3.3). (3) Remove the screw 1 and remove the Sumi card (operator panel cable) 2 off the latch section of face up stacker 4.

  • Page 58: Eject Roller Assy

    3.3.8 Eject Roller Assy (1) Remove the upper cover assy (see 3.3.1). (2) Remove the operator panel assy (see 3.3.3). (3) Remove the face up stacker assy (see 3.3.7). (4) Remove the lower base unit (see 3.3.4). (5) Disengage the eject roller assy 1 from the lower base 2 by pressing the latch section of the eject roller assy 1 in the direction of the arrow shown below, and remove the eject roller assy 1.

  • Page 59: Motor Assy

    3.3.9 Motor Assy (1) Remove the upper cover assy (see 3.3.1). (2) Remove the operator panel assy (see 3.3.3). (3) Remove the face up stacker assy (see 3.3.7). (4) Remove the lower base unit (see 3.3.4). (5) Stand the lower base unit on its side as shown, and unlock two latches, then remove the motor assy 59 / 40718301TH Rev.6...

  • Page 60: Hopping Roller Shaft Assy

    3.3.10 Hopping Roller Shaft Assy (1) Remove the upper cover (see 3.3.1). (2) Remove the operator panel assy (see 3.3.3). (3) Remove the face up stacker assy (see 3.3.7). (4) Remove the lower base unit (see 3.3.4). (5) Remove the motor assy (see 3.3.9). (6) With the lower base unit 1 standing on its side, remove the one-way clutch gear 2 and the bearing (A) 3.

  • Page 61: Stacker Cover Assy

    3.3.11 Stacker Cover Assy (1) Remove the upper cover assy (see 3.3.1). (2) Remove the operator panel assy (see 3.3.3). (3) Remove the face up stacker assy (see 3.3.7). (4) Remove the reset lever R 1. (5) Detach the reset spring 2 from the lower base unit 3, turn the reset lever L 4 in the direction of arrow until it stops, and remove it in the direction of arrow (6) Unlock two latches of the lower base unit 3, then remove the stacker cover assy 5.

  • Page 62: Registration Roller

    3.3.12 Registration Roller (1) Remove the upper cover (see 3.3.1). (2) Remove the operator panel assy (see 3.3.3). (3) Remove the face up stacker assy (see 3.3.7). (4) Remove the lower base unit (see 3.3.4). (5) Remove the motor assy (see 3.3.9). (6) With the lower base unit standing on its side, remove the one-way clutch gear 1.

  • Page 63: 3.3.13 Roller Transfer Assy

    3.3.13 Roller Transfer Assy (1) With the power switch turned off, unplug the AC cord from the outlet. (2) Open the stacker cover. (3) Release the roller transfer assy 1 by unlocking the latch of the main unit (never apply excessive force when unlocking the latch).

  • Page 64: 3.3.14 Fusing Unit

    3.3.14 Fusing Unit (1) Remove the upper cover (see 3.3.1). (2) Remove the operator panel assy (see 3.3.3). (3) Remove the face up stacker assy (see 3.3.7). (4) Remove the stacker cover assy (see 3.3.11). (5) Remove four screws 1, lift and remove the fusing unit 2. Caution: Fusing unit may be hot.

  • Page 65: 3.3.15 Back-Up Roller

    3.3.15 Back-up Roller (1) Remove the fusing unit assy (see 3.3.14). (2) Lift the left side of the back-up roller 1, and pull it out to the left side (at this time, two bushings (back- up) 2 and the bias springs (back-up) 3 will also come off). 65 / 40718301TH Rev.6...

  • Page 66: Sensor Plate (Inlet)

    3.3.16 Sensor Plate (Inlet) (1) Remove the upper cover (see 3.3.1). (2) Remove the operator panel assy (see 3.3.3). (3) Remove the face up stacker assy (see 3.3.7). (4) Remove the lower base unit (see 3.3.4). (5) Press the clamps of three sensor plates (inlet and paper) 1, and remove them by pressing them upward from the bottom.

  • Page 67: Sensor Plate (Outlet)

    3.3.17 Sensor Plate (Outlet) (1) Remove the upper cover assy (see 3.3.1). (2) Remove the operator panel assy (see 3.3.3). (3) Remove the eject roller assy (see 3.3.8). (4) Remove the face up stacker assy (see 3.3.7). (5) Remove the lower base unit (see 3.3.4). (6) Remove the fusing unit assy (see 3.3.14).

  • Page 68: Manual Feed Guide Assy

    3.3.18 Manual Feed Guide Assy (1) Remove the upper cover assy (see 3.3.1). (2) Open the manual feed guide assy 1, and release the engagement on both sides with the main unit by carefully bending the manual feed guide assy 1. Note : When remounting, verify the proper the engagements as shown in the diagram.

  • Page 69: Sensor Plate (Paper Supply)

    3.3.19 Sensor Plate (Paper Supply) (1) Remove the upper cover assy (see 3.3.1). (2) Remove the operator panel assy (see 3.3.3). (3) Remove the face up stacker assy (see 3.3.7). (4) Remove the lower base unit (see 3.3.4). (5) Press the clamps of the sensor plate (paper supply) 1 to unlock the latch, and remove it from the base plate 2.

  • Page 70: M5E-Pcb

    3.3.20 M5B-PCB (1) Remove the upper cover assy (see 3.3.1). (2) Remove the operator panel assy (see 3.3.3). (3) Remove the face up stacker assy (see 3.3.7). (4) Remove the lower base unit (see 3.3.4). (5) Remove the connector (2NDTRAY) 6. (6) Remove three screws 1.

  • Page 71: 3.3.21 Transformer

    3.3.21 Transformer (1) Remove the upper cover assy (see 3.3.1). (2) Remove the operator panel assy (see 3.3.3). (3) Remove the face up stacker assy (see 3.3.7). (4) Remove the connectors (CN1 and CN2). (5) Remove two screws 1, and remove the transformer 2. Note : When reinstalling the transformer, be sure to lay the AC and transformer’s primary side cables under the divider (see view A diagram below).

  • Page 72: 3.3.22 Power Supply/Sensor Board And Contact Assy

    3.3.22 Power Supply/Sensor Board and Contact Assy (1) Remove the upper cover assy (see 3.3.1). (2) Remove the lower base unit (see 3.3.4). (3) Remove the M5B-PCB (See 3.3.20). (4) Remove the transformer (see 3.3.21). (5) Remove the AC inlet 1 from the base plate 2. (6) Remove the screw 3 and remove the grounding (earth) wire 4.

  • Page 73: 3.3.23 Cassette Guide L Assy

    3.3.23 Cassette Guide L Assy (1) Remove the paper cassette. (2) Remove the upper cover assy (see 3.3.1). (3) Remove the lower base unit (see 3.3.4). (4) Remove the M5B-PCB (see 3.3.20). (5) Remove the transformer (see 3.3.21). (6) Remove the power supply/sensor board (see 3.3.22). (7) Remove two screws 1, and remove the guide rails 2.

  • Page 74: 3.3.24 Cassette Guide R Assy

    3.3.24 Cassette Guide R Assy (1) Remove the paper cassette. (2) Remove the upper cover assy (see 3.3.1). (3) Remove the lower base unit (see 3.3.4). (4) Remove the M5B-PCB (see 3.3.20). (5) Remove two screws 1, and remove the guide rails 2. (6) Remove the screw 3, and remove the cassette guide R 4 by shifting it in the direction of arrow.

  • Page 75: Spacer Bearing (L/R)

    3.3.25 Spacer Bearing (L/R) (1) Remove the back-up roller (see 3.3.15). (2) Remove spacer bearing (L/R) with a tip of screw driver. Spacer bearing L Spacer bearing R 75 / 40718301TH Rev.6...

  • Page 76: Adjustment

    ADJUSTMENT This chapter provides explanations concerning the adjustment necessary when replacing a part. The adjustment is made by changing the parameter value set in EEPROM on the main control board. The parameter can be set by the key operation from the operator panel. This printer has three kinds of maintenance modes, and it is necessary to select one of the modes when replacing any parts.

  • Page 77: Engine Maintenance Mode

    4.1.3 Engine Maintenance Mode Note: This mode is used only by maintenance personnel, and it should not be released to the end users. (1) To enter into the engine maintenance mode, turn the power on while holding ENTER and FORM FEED keys down.

  • Page 78: Eeprom Initialization

    4.1.4 EEPROM initialization The corresponding are of the EEPROM is initialized for each event as shown Table 4-1. Talbe 4-1 EEPROM Initial Setting Range EEPROM area No Event User maintenance menu reset System maintenance EEPROM reset Engine maintenance Note2) Note2) engine reset Firm revision check error at power-on...

  • Page 79: Adjustment When Replacing A Part

    Adjustment When Replacing a Part Adjustment is necessary when replacing any of the following parts. Part Replaced Adjustment LED Head Set the LED head drive time. Image Drum Cartridge Reset the image drum counter (refer to User's manual). Main Control Board EEPROM data Upload / Download 4.2.1 Setting of LED Head Drive Time...
  • Page 80 • Setting of LED Head Drive Time Drive time of the LED head is set by setting the parameter of drive time of EEPROM according to the luminous intensity marking on the LED head. a. Corresponding table of luminous intensity marking and drive time parameter Luminous intensity Luminous intensity Drive time parameter...
  • Page 81 b. Setting Example: Method for setting the parameter to 19 (for a case where the previous parameter setting was 8). Operation LCD display after operation Turn the POWER switch ENG MNT on while holding the FORM FEED and ENTER keys down. LED HEAD Displays previous Press the MENU key...

  • Page 82: Uploading/Downloading Eeprom Data

    4.2.2 Uploading/Downloading EEPROM data When the controller printed circuit board is replaced, the contents of the old EEPROM shall be copied to the new EEPROM on the new board to preserve customer settings. For the purpose, use the EEPROM operation on the Option of the Maintenance Utility. To copy follow the steps below. (1) Be sure to confirm that the printer and the PC are connected with a centronics I/F cable.

  • Page 83: Periodical Maintenance

    PERIODICAL MAINTENANCE Periodical Replacement Parts The parts are to be replaced periodically as specified below: Part name Condition for replacement Cleaning Remarks • Toner cartridge(Type 5) About 2,000 sheets of paper have been printed. • LED head Consumables • Image drum cartridge About 20,000 sheets of paper have been printed.
  • Page 84 (1) Set the LED head cleaner to the LED lens array as shown in the figure, then slide the cleaner back and forth horizontally several times to clean the head. Note: Gently press the LED head cleaner onto the LED lens array. LED head clean pad LED lens array (2) Throw the cleaner pad away.

  • Page 85: Cleaning

    5.2.2 Cleaning Page Function There is a charge roller cleaning function with this printer, which can be executed by the user. (1) While the printer is in off-line mode, press both keys simultaneously for at least 2 seconds. The printer enters the cleaning mode. (2) The LCD displays "CLEANING"...

  • Page 86: Troubleshooting Procedures

    TROUBLESHOOTING PROCEDURES Troubleshooting Tips (1) Check the troubleshooting section in the Printer Handbook. (2) Gather as much information about the situation as possible. (3) Inspect the equipment under the conditions close to those in which the problem had occurred. Points to Check before Correcting Image Problems (1) Is the printer being run in proper ambient conditions? (2) Are supplies (toner) and routine replacement part (image drum cartridge) being replaced properly? (3) Is the printing paper normal (acceptable quality)?

  • Page 87: Preparation For Troubleshooting

    Preparation for Troubleshooting (1) Operator panel display The failure status of the printer is displayed by the liquid crystal display (LCD) of the operator panel. Take proper corrective action as directed by messages which are being displayed on the LCD. OKIPAGE P A G E P R I N T E R MENU 1...

  • Page 88: Troubleshooting Flow

    Troubleshooting Flow Should there be a problem with the printer, carry out troubleshooting according to the following procedure flow: Problems Carry out a detailed Problems Troubleshoot from the LCD troubleshooting with the indicated by LCD status message list. troubleshooting chart. message See Section 6.5.1.
  • Page 89 89 / 40718301TH Rev.6...
  • Page 90 90 / 40718301TH Rev.6...
  • Page 91 91 / 40718301TH Rev.6...
  • Page 92 92 / 40718301TH Rev.6...
  • Page 93 93 / 40718301TH Rev.6...
  • Page 94 94 / 40718301TH Rev.6...
  • Page 95 95 / 40718301TH Rev.6...
  • Page 96 96 / 40718301TH Rev.6...
  • Page 97 97 / 40718301TH Rev.6...
  • Page 98 98 / 40718301TH Rev.6...

  • Page 99: Lcd Message Troubleshooting

    6.5.2 LCD Message Troubleshooting If the problems cannot be corrected by using the LCD status message/problem list, follow the troubleshooting flowcharts given here to deal with them. Trouble Flowchart number The printer does not work normally after the power is turned on. Jam alarm Paper input jam Paper feed jam...

  • Page 100: The Printer Does Not Work Normally After The Power Is Turned On

    The printer does not work normally after the power is turned on. • Turn the power off, then back on. • Is all black message being displayed by the LCD display? • No Is the AC cord being connected properly? •...
  • Page 101 • Take the measurement of the following voltage readings at connector CN2 on the power supply/ sensor board: Voltage between Pins 1 and 3: ... about 40 V AC Voltage between Pins 5 and 6: ... about 9.2 V AC Are the voltages within the normal range? •...

  • Page 102: Paper Input Jam

    [JAM error] Paper input jam • Does the JAM error occur when the power is turned on? • Yes Is the paper at the inlet sensor? • Yes Remove the paper. • No Is the operation of the inlet sensor plate normal (moves freely when it is touched)? •...

  • Page 103: Paper Feed Jam

    [JAM error] Paper feed jam • Does the paper feed jam occur when the power is turned on? • Yes Is the paper on the paper sensor plate? • Yes Remove the paper. • No Is the operation of the paper sensor plate normal (moves freely when it is touched)? •...

  • Page 104: Paper Exit Jam

    2-2-a • No Check the gears (transfer roller gear, idle gear and reduction gear). • Yes Is the fusing unit being installed properly? • No Install the fusing unit properly. • Yes Is the image drum cartridge being set properly? •...

  • Page 105: Paper Size Error

    Paper size error • Is paper of the specified size being used? • No Use paper of the specified size. • Yes Are inlet sensor plates 1 and 2 operating properly (moves freely when they are touched)? • No Replace the inlet sensor plate or clean the inlet sensor on the power supply/sensor board.

  • Page 106: Fusing Unit Error

    Fusing unit error (ERROR 71) (ERROR 72) (ERROR 73) • Turn the power off, then back on again. • Yes Is the thermistor open or shorted? Measure the resistance between thermistor contacts (heater contacts 120V/3Ω or 240V/10Ω, and thermistor contacts 200KΩ at room temperature) (see Figure 6-2 or Section 7.3).

  • Page 107: Fan Error

    Synchronous serial I/O error (ERROR 74) or I/F timeout between printer and op- tional tray (ERROR 81) • Is an option tray (High Capacity Second Paper Feeder or Power Envelope Feeder) being used? • Yes Is the cable between the main control board and the optional tray being connected properly? •...

  • Page 108: Image Troubleshooting

    6.5.3 Image Troubleshooting Procedures for troubleshooting for abnormal image printouts are explained below. Figure 6-3 below shows typical abnormal images. Problem Flowchart number Images are light or blurred entirely (Figure 6-3 Dark background density (Figure 6-3 Blank paper is output (Figure 6-3 Black vertical belts or stripes (Figure 6-3 Cyclical defect (Figure 6-3 Prints voids...
  • Page 109 Images are light or blurred entirely. • Is toner low (is the TONER LOW message displayed)? • Yes Supply toner. • No Is paper of the specified grade being used? • No Use paper of the specified grade. • Yes Is the lens surface of the LED head dirty? LED head •...
  • Page 110 Dark background density • Has the image drum been exposed to external light? • Yes Install the image drum in the printer and wait about 30 minutes. • No Perform the cleaning page function (see Section 5.2.2). • Has the problem been solved? •...
  • Page 111 Blank paper is output. • Is the LED head being connected properly (check the HEAD1 and HEAD2 connectors on the main control board and PC connector on the LED head)? • No Connect the LED head properly or replace the head cable(s). •...
  • Page 112 Black vertical belts or stripes • Perform the cleaning page function (see Section 5.2.2). • Has the problem been solved? • Yes End. • No Replace the image drum cartridge. • Has the problem been solved? • Yes Note: After replacing the image drum cartridge, set the printer to the user mainte- nance mode by turning the power on while pressing the MENU key, and reset the drum counter (see Printer Handbook).

  • Page 113: Cyclical Defect

    Cyclical defect Frequency Remedy Image drum 3.71" (94.2mm) Replace or clean the image drum cartridge. Developing roller 1.86" (47.12mm) Replace the image drum cartridge. Toner supply roller 2.96" (75.27mm) Replace the image drum cartridge. Charging roller 1.21" (30.63mm) Replace the image drum cartridge. Cleaning roller 0.93"...
  • Page 114 Prints voids • Is the contact plate of the transfer roller in proper contact with the power supply/sensor board (see Figure 6-5)? • No Adjust the contact plate so that it touches the power supply/sensor board and the shaft of the transfer roller properly. •...
  • Page 115 Poor fusing (images are blurred or peels off when the printed characters and im- ages on the paper are touched by hand) • Is paper of the specified grade being used? • No Use paper of the specified grade. • Yes Is the tension between the back-up roller (7.52kg) and the surface of back-up roller normal? •...
  • Page 116 White vertical belts or streaks • Are the LED lens dirty? • Yes Clean the LED lens. • No Is the contact plate of the transfer roller in proper contact with the power supply/sensor board (see Figure 6-5)? • No Adjust the contact plate to make a proper contact with the power supply/sensor board.
  • Page 117 Figure 6-4 117 / 40718301TH Rev.6...
  • Page 118 Contact plate for transfer roller Power supply/sensor board Contact Figure 6-5 118 / 40718301TH Rev.6...

  • Page 119: Wiring Diagram

    Centronics Parallel I/F Option Feeder I/F Option Board Registration Motor CENT ENVELOPE OPTION PLD-N RMPH1-P PDATAOUT-P Operator RMPH1-N PANEL PDATAIN-P RMPH2-P Panel RMPH2-N PSCLK-N Main (Drum) Motor OVLOGIC DMPH1-P HEAD2 Main Control Board HDCLK-P DMPH1-N 12: FG DMPH2-P 0VLOGIC DMPH2-N HDD2-P M5E-PCB 7~11: OVLED...

  • Page 120: Pcb Layout And Connector Signal List

    PCB Layout and Connector Signal List (1) Main Control Board (M5E-PCB) Printer front side OPTION HEAD1 HEAD2 OPTION CENT LED Head Operator panel Printer front side Contact face Contact face Printer front side 6 – 1 1– 14 12 – 1 120 / 40718301TH Rev.6...
  • Page 121 (2) Power Supply/Sensor Board TR OUT * In case of 200V series, there is no F2 on the power supply/sensor board. 121 / 40718301TH Rev.6...
  • Page 122 • FAN Connector Pin Assignment (To fan motor) PIN NO. I/O* Signal Description FANPOW Power supply for fan driving Opening Ground FANALM-N Fan alarm • DM Connector Pin Assignment (To main/drum motor) PIN NO. I/O* Signal Description DMPH1-P Coil 1-P DMPH1-N Coil 1-N DMPH2-P...
  • Page 123 • RM Connector Pin Assignment (To registration motor) PIN NO. I/O* Signal Description RMPH1-P Coil 1-P RMPH1-N Coil 1-N RMPH2-P Coil 2-P RMPH2-N Coil 2-N * I: In O: Out Excitation sequence Step No. PIN NO. Line Color Yellow Black Orange Brown Rotary direction...
  • Page 124 • HEAD1 Connector Pin Assignment (To LED head) PIN NO. I/O* Signal Description 0VLOGIC Ground for Logic HDCLK-P Clock 0VLOGIC Ground for Logic HDD2-P Data 2 HDD3-P Data 3 0VLED Ground for LED HDD0-P Data 0 HDD1-P Data 1 +3.3V +3.3V power supply for LED driving HDDLD-P Load...
  • Page 125 • PANEL Connector Pin Assignment (To operator panel) PIN NO. I/O* Signal Description PLD-N Load Logic groud PDATAOUT-P Data output PDATAIN-P Data input +5V power supply PSCLK-N Clock * I: In O: Out C: Common • ENVELOPE Connector Pin Assignment (To option feeder I/F) PIN NO.
  • Page 126 126 / 40718301TH Rev.6...
  • Page 127 127 / 40718301TH Rev.6...
  • Page 128 128 / 40718301TH Rev.6...

  • Page 129: Resistance Check

    Resistance Check 129 / 40718301TH Rev.6...
  • Page 130 130 / 40718301TH Rev.6...

  • Page 131: Short Plug Setting

    Short Plug Setting (1) Main Control Board (M5E-PCB) • Short plug settings Short plug Plug setting Description Factory setting Provided Debug mode Not provided Not provided Normal 131 / 40718301TH Rev.6...

  • Page 132: Parts List

    PARTS LIST Figure 8-1 Lower Base Unit 132 / 40718301TH Rev.6...
  • Page 133 Table 8-1 Lower Base Unit (1/2) Name/Rating Part No. Remarks ODA Part No. Hopping roller shaft 3PP4083-6020P001 51112601 Bearing 4PP4083-6022P002 51607402 Hopping roller one-way clutch gear 4PB4083-6024P001 51228901 Roller-Registration 40740601 Bearing (registration) 4PP4083-6031P001 51607501 Roller-Transfer B Assy 40437801 Bearing TR 40438001 Roller-Back up 40739201...
  • Page 134 Table 8-1 Lower Base Unit (2/2) Name/Rating Part No. Remarks ODA Part No. FG plate (O.P.) 4PP4083-7663P001 Rubber Hopping roller 4PB4076-5447P001 Diselectritication Film 3PB4083-6089P001 LED Contact 4PP4083-6173P001 Washer C 4PP4120-1210P001 Washer B 4PP4120-1209P001 Spacer-Bearing R 40392801 Spacer-Bearing L 40392901 Bias Spring A 4PP4083-6065P001 Special parts for envelope *...
  • Page 135 Figure 8-2 Upper cover unit 135 / 40718301TH Rev.6...
  • Page 136 Table 8-2 Upper cover unit Name/Rating Part No. Remarks ODA Part No. Cover-Upper 40715101 136 / 40718301TH Rev.6...
  • Page 137 Figure 8-3 Base unit 137 / 40718301TH Rev.6...
  • Page 138 Table 8-3 Base unit Name/Rating Part No. Remarks ODA Part No. Base plate (adhesion) 2PP4083-7672G001 808A0000001~ 51012901 810AXXXXXXX Plate Assy-Base 40919401 811AXXXXXXX~ Cassette guide (L) assy 3PP4083-7670G001 51011201 Cassette guide (R) assy 3PP4083-7671G001 51011301 Sensor plate (paper supply) 4PP4083-7667P001 51011401 Insulator 3PB4083-6144P001 51709401...

  • Page 139: Appendix A Rs-232C Serial Interface (Option)

    Appendix A RS-232C SERIAL INTERFACE (option) 1) Connector • Printer side 25-pin receptacle Type DB-25S (made by Canon) or equivalent • Cable side 25-pin plug Type DB-25S (made by Canon) Shell Type DB-C8-J10-F2-1 (made by Nihon Kouku Denshi) or equivalent Note: Plug shall be fixable with a lock screw.
  • Page 140 4) Signal Level • MARK polarity : -3V to -15V (LOGIC = 1) • SPACE polarity : +3V to +15V (LOGIC = 0) 5) Interface Circuit Receiving Circuit 75188 or equivalent OUTPUT INPUT +12V -12V INPUT Sending Circuit 75188 or equivalent OUTPUT INPUT OUTPUT...
  • Page 141 8) Interface Parameter Setting The following settings are possible by pressing the ENTER key, after selecting the display contents of the LCD of the operator panel by using the keys. Settings are retained even when the printer power is turned off. By pressing the ON LINE key, menu setting mode is completed and the printer returns to on- line state.
  • Page 142 Press the MENU key. Item Baud Rate Contents of Display Function 300 baud 600 baud BAUDRATE Ready 1200 1200 baud Contens 2400 2400 baud 4800 4800 baud 9600 9600 baud 19200 19200 baud Factory Setting: 9600 baud Press the MENU key. Item Bit Length DATABITS...
  • Page 143 Press the MENU key. Item Minimum BUSY Time MIN BUSY Contents of Display Function Ready Contents 200 m SEC 200 ms 1 SEC 1 sec (1000 ms) Factory Setting: 200 m SEC (PCL only) Press the ON LINE key. Setting completed. ON-LINE Ready XXX : PCL, AUTO, Adobe PS, HEX DUMP, PRR or FX...

  • Page 144: Appendix B Centronics Parallel Interface

    2) Cable • Cable length 6 ft (1.8 m) max. (A Shielded cable composed of twisted pair wires is recommended for noise prevention.) Note: Cable is not supplied with the printer, and is not available from Oki. 144 / 40718301TH Rev.6...
  • Page 145 3) Table of Parallel I/F Signals Pin No. Signal name Signal direction Functions DATA STROBE Parallel data sampling strobe DATA BIT - 1 DATA BIT - 2 DATA BIT - 3 DATA BIT - 4 PR Parallel input and output data DATA BIT - 5 DATA BIT - 6 DATA BIT - 7...
  • Page 146 4) Signal Level • LOW 0 V to +0.8 V • HIGH +2.4 V to 5.0 V 5) Specifications Item Description Mode Compatibility mode, Nibble mode, ECP mode Data bit length 8 bits (in the compatibility mode) Input prime Valid/Invalid Receive buffer 8K, 20K, 50K, 100K, 1M Bytes Control...
  • Page 147 On-line → off-line switching timing by ON-LINE SW ON-LINE SW BUSY SELECT 100 ms max. Off-line → on-line switching timing by ON-LINE SW ON-LINE SW BUSY SELECT 0 min. ACKNOWLEDGE 100 ms max. 0.5 µs to 10 µs INPUT PRIME timing (when set to the effective INPUT PRIME signal) 50 µs min.
  • Page 148 Interface Parameter Setting The following settings are possible by pressing the ENTER key, after selecting the display contents of the LCD of the operator panel by using the keys. Settings are retained even when the printer power is turned off. By pressing the ON LINE key, menu setting mode is completed and the printer returns to on- line state.
  • Page 149 Press the MENU key. Item Direction of Data Transfer BI–DIRCT Contents of Display Function Ready Contents Bi-directional data transmission ENABLE Uni-directional data transmission DISABLE Factory Setting: ENABLE Press the MENU key. Item I-PRIME I–PRIME Contents of Display Function Ready Contents I-PRIME signal ignored I-PRIME signal effective Factory Setting: OFF...

  • Page 150: Appendix C Loop Test (Rs-232C Interface)

    Appendix C LOOP TEST (RS-232C INTERFACE) 1) Connect the test connector DB-25S made by Cannon or equivalent Test Connector Connection Diagram 2) Select "LOOP Test" in the system maintenance mode. The codes transmitted from the TD signals are comparatively checked with the data received from the RD signals.

  • Page 151: Appendix D Diagnostics Test

    Appendix D DIAGNOSTICS TEST Maintenance Modes • The maintenance modes consist of the user maintenance mode which are released to the user, and the system and engine maintenance modes in the maintenance personnel level not released to the user. • Press the MENU key to update each category.
  • Page 152 (5) Operator Panel Menu Disable • This function is for enabling and disabling the operation panel menu functions (Menu 1, Menu 2, Tray Select, Copies and Paper Size). LCD display USER MNT Press the After the completion MENU key. Press the of processing ENTER key.
  • Page 153 System Maintenance Mode To enter the system maintenance mode, turn the power on while keeping the Recover key pressed • down. • This mode adopts the menu for function selection. • The system maintenance mode provides the following functions: (1) Page Count Display •...
  • Page 154 • The following items are excluded: Head drive time setting Fine adjustment of printing start position Standard tray paper feed amount setting • Transition to the operation mode occurs upon completion of resetting. • Press the MENU key to update each category. The operation returns to the first category after updating the last category, in a loop.
  • Page 155 Engine Maintenance Mode • The engine maintenance mode is activated when the power is turned ON while keeping the FORM FEED key and ENTER key pressed down. • This mode adopts the menu for function selection. • The method for exit from this mode depends on the setting. •...

  • Page 156: Engine Maintenance Mode Menu System

    • Engine maintenance mode menu system LCD display ENG MNT Writing into the EEPROM is performed No. 1 Press the after pressing the ENTER key. Press No. 4 key. the ON LINE key if you wish to get out LED HEAD No.
  • Page 157 0 mm * Press the + 1 mm key. Do not change the default setting. T2 POS + 7 mm 0 mm* - 8 mm Press the - 1 mm MENU key. Press the key. Do not change the default setting. No.
  • Page 158 User Factory Set Operation The desired destination can be set by turning the power on while depressing two keys corresponding to the destination according to the following table. Destination Keys to be Depressed MENU MENU INT A (A4) MENU, PAPER SIZE (Australia, etc.) INT L (Letter) MENU, TRAY TYPE...

  • Page 159: Appendix E Multi Purpose Feeder Maintenance

    APPENDIX E MULTI PURPOSE FEEDER MAINTENANCE OUTLINE Functions This Multi-Purpose Feeder is installed on the front section of the printer, and it supplies paper automatically through the operation of pulse motor, which is driven by signals sent from the printer. The main functions are the followings: •...

  • Page 160: Mechanism Description

    MECHANISM DESCRIPTION General Mechanism The Multi-Purpose Feeder feeds the envelopes and paper into the printer by receiving the signal from the printer, which drives the pulse motor inside the Multi-Purpose Feeder, and this motion is transmitted to rotate roller-A and B. The envelope or paper is delivered from the separator into the printer. Once delivered into the printer, the envelope or paper is then controlled and fed through by pulse motor (registration) of the printer.

  • Page 161: Parts Replacement

    PARTS REPLACEMENT This section covers the procedures for the disassembly, reassembly and installations in the field. This section describes the disassembly procedures, and for reassembly procedures, basically proceed with the disassembly procedures in the reverse order. Precautions Concerning Parts Replacement (1) Parts replacements must be carried out, by first turning the printer power switch off “O”...
  • Page 162 [Service Tools] Table 3-1 shows the tools required for the replacement of printed circuit boards, assemblies and units in the field. Table 3-1 Service Tools Service Tools Q'ty Application Remarks No. 1-100 Philips 2 ~ 2.5 mm screws screwdriver No. 2-100 Philips 3 ~ 5 mm screws screwdriver No.

  • Page 163: Parts Layout

    Parts Layout This section describes the layout of the main components. Upper Frame Pulse Motor Link Roller-A Roller-B OLEV-11-PCB Separator Figure 3-1 163 / 40718301TH Rev.6...
  • Page 164 Parts Replacement Methods This section describes the parts replacement methods for the components listed in the disassembly order diagram below. Multi-Purpose Feeder Link (3.3.1) Separator (3.3.2) OLEV-11-PCB (3.3.3) Pulse motor (3.3.4) Planet gear (3.3.5) Roller-A (3.3.6) 164 / 40718301TH Rev.6...

  • Page 165: Link

    3.3.1 Link (1) Open paper feed cover 1, and disengage the paper feed cover 1 and link 3, while lifting the paper hold 2. (2) Remove the paper hold 2 off the arm 4. (3) Disengage the link 3 from the arm 4, and remove it. * Be careful not to deform the link and arm.

  • Page 166: Separator

    3.3.2 Separator (1) Turn the power switch off “O” and remove the connector cable. (2) Disengage the link and paper feeder cover (see 3.3.1). (3) Remove 2 screws 1, disengage the locks at 2 locations on the upper frame 2 with a screwdriver, and remove the upper frame 2.

  • Page 167: Olev-11-Pcb

    3.3.3 OLEV-11-PCB (1) Remove the upper frame [ see 3.3.2 steps (1) through (3) ]. (2) Remove the connector 1. (3) Remove 2 screws 2, and remove the OLEV-11 PCB 3. When reinstalling the printed circuit board, be careful to make sure that the sensor plate is being set correctly.

  • Page 168: Pulse Motor

    3.3.4 Pulse Motor (1) Remove the upper frame [ see 3.3.2 steps (1) through (3) ]. (2) Remove the OLEV-11-PCB (see 3.3.3). (3) Remove 2 screws 1, and remove the pulse motor 2. 168 / 40718301TH Rev.6...

  • Page 169: Planet Gear

    3.3.5 Planet Gear (1) Remove the upper frame [ see 3.3.2 steps (1) through (3) ]. (2) Remove the OLEV-11-PCB (see 3.3.3). (3) Remove 2 screws 1, and remove the motor bracket assembly 2 and planet gear 3. 169 / 40718301TH Rev.6...

  • Page 170: Roller-A And B

    3.3.6 Roller-A and B While only the removal procedure for roller-A is described here, the removal procedure for roller-B is basically same. When removing roller-B, however, be careful not to deform the sensor plate. (1) Remove the upper frame [ see 3.3.2 steps (1) through (3) ]. (2) Remove the separator assembly (see 3.3.2).

  • Page 171: Troubleshooting

    TROUBLESHOOTING Precautions Prior to the Troubleshooting (1) Go through the basic checking items provided in the Printer Handbook. (2) Obtain detailed information concerning the problem from the user. (3) Go through checking in the conditions similar to that in which the problem occurred. Preparations for the Troubleshooting (1) Display on the operator panel The status of the problem is displayed on the LCD (Liquid Crystal Display) on the operator panel.

  • Page 172: Troubleshooting Method

    Troubleshooting Method When a problem occurs, go through the troubleshooting according to the following procedure. Problem occurs Problem displayed by Troubleshooting Carry out detailed the LCD message according to the LCD troubleshooting Status Message List according to the (see 4.3.1) Troubleshooting Flow (see 4.3.1) 4.3.1...
  • Page 173 • ( JAM error ) Paper Inlet Jam • Does paper jam at the inlet when the power is turned on? • YES Is the paper located above the sensor plate (inlet)? • YES Remove the paper. • NO Is the sensor plate (inlet) operating normally? •...

  • Page 174: Connection Diagram

    CONNECTION DIAGRAM Interconnection Diagram Pulse motor 2 M-T3 1 M-T4 4 M-T1 3 M-T2 OLEV - 11-PCB To the Printer or High Capacity Second Paper Feeder 174 / 40718301TH Rev.6...

  • Page 175: Pcb Layout

    PCB Layout OLEV-11-PCB SEN2 175 / 40718301TH Rev.6...

  • Page 176: Parts List

    PARTS LIST Figure 6-1 Multi-Purpose Feeder 176 / 40718301TH Rev.6...
  • Page 177 Table 6-1 Multi-Purpose Feeder Description OKI-J Part No. ODA Part No. Q'ty Remark Roller-A 3PB4083-5514P001 Roller-B 3PB4083-5524P001 Planet gear 4PP4083-5520P001 Link 3PP4083-5540P001 Separator 4PP4083-5544G001 Pulse motor 4PB4083-6075P001 Same as printer unit. OLEV-11-PCB 4YA4121-1014G011 Connector cable 3YS4011-3141P003 ODA (exist the label)

  • Page 178: Appendix F High Capacity Second Paper Feeder

    APPENDIX F HIGH CAPACITY SECOND PAPER FEEDER OUTLINE Functions The printer is mounted on top of this High Capacity Second Paper Feeder. The High Capacity Second Paper Feeder supplies paper automatically through the operation of pulse motor (hopping), which is driven by signals sent from the printer.

  • Page 179: Mechanism Description

    MECHANISM DESCRIPTION General Mechanism The High Capacity Second Paper Feeder feeds the paper into the printer by receiving the signal from the printer, which drives the pulse motor inside the High Capacity Second Paper Feeder, and this motion is transmitted to rotate the one-way clutch of the hopping frame assembly. The paper is delivered from the hopper into the printer through the turning of the hopping roller and feed roller.

  • Page 180: Parts Replacement

    PARTS REPLACEMENT This section covers the procedures for the disassembly, reassembly and installations in the field. This section describes the disassembly procedures, and for reassembly procedures, basically proceed with the disassembly procedures in the reverse order. Precautions Concerning Parts Replacement (1) Parts replacements must be carried out, by first turning the printer power switch off “O”...
  • Page 181 [Service Tools] Table 3-1 shows the tools required for the replacement of printed circuit boards, assemblies and units in the field. Table 3-1 Service Tools Service Tools Q'ty Application Remarks No. 1-100 Philips 2 ~ 2.5 mm screws screwdriver No. 2-100 Philips 3 ~ 5 mm screws screwdriver No.

  • Page 182: Parts Layout

    Parts Layout This section describes the layout of the main components. Cassette Assy Upper Plate Hopping Roller Assy Guide R (2nd) Assy (includes stepping motor and TQSB-2 PCB) One-way Clutch Gear Hopping Frame Assy Stepping Motor Guide L (2nd) Assy Figure 3-1 182 / 40718301TH Rev.6...

  • Page 183: Parts Replacement Methods

    Parts Replacement Methods This section describes the parts replacement methods for the components listed in the disassembly order diagram below. High Capacity Paper Feeder Stepping motor (hopping) (3.3.1) TQSB-2 PCB (3.3.2) Hopping roller shaft assy and One-way clutch gear (3.3.3) 183 / 40718301TH Rev.6...

  • Page 184: Stepping Motor (Hopping)

    3.3.1 Stepping Motor (Hopping) (1) Turn the printer power switch off, pull out the AC cord from the outlet. Remove the printer off High Capacity Second Paper Feeder. (2) Take the paper cassette assy 1 out of High Capacity Second Paper Feeder. (3) Remove six screws 2 and remove the upper plate 3.
  • Page 185 (6) Remove three screws 9 which are holding the guide R (2nd) assy 0 to the bottom plate A. Remove the screw B which is keeping the rear cover C and guide R (2nd) assy 0. Remove the guide R (2nd) assy 0. (7) Remove the protect (M) D, guide bracket E, planet gears F and planet gear bracket G.

  • Page 186: Tqsb-2 Pcb

    3.3.2 TQSB-2 PCB (1) Remove the pulse motor (see 3.3.1). (2) Remove the connector O from the TQSB-2 PCB P. (3) Remove the screw Q and remove the TQSB-2 PCB P. Note : Refer to Detall A in the previous page. 3.3.3 Hopping Roller Shaft Assy and One-way Clutch Gear (1) Follow up to step (3) of 3.3.1 and remove the hopping frame assy.

  • Page 187: Troubleshooting

    TROUBLESHOOTING Precautions Prior to the Troubleshooting (1) Go through the basic checking items provided in the Printer Handbook. (2) Obtain detailed information concerning the problem from the user. (3) Go through checking in the conditions similar to that in which the problem occurred. Preparations for the Troubleshooting (1) Display on the Operator panel The status of the problem is displayed on the LCD (Liquid Crystal Display) on the Operator panel.

  • Page 188: Troubleshooting Method

    Troubleshooting Method When a problem occurs, go through the troubleshooting according to the following procedure. Problem occurs Problem displayed by Troubleshooting Carry out detailed the LCD message according to the LCD troubleshooting Status Message List according to the (see 4.3.1) Troubleshooting Flow (see 4.3.1) 4.3.1...
  • Page 189 • ( JAM error ) Paper Inlet Jam • Does paper jam at the inlet when the power is turned on? • YES Is the paper located above the sensor plate (inlet)? • YES Remove the paper. • NO Is the sensor plate (inlet) operating normally? •...

  • Page 190: Connection Diagram

    CONNECTION DIAGRAM Interconnection Diagram Stepping motor 2 M-T3 1 M-T4 "MOTOR" 4 M-T1 3 M-T2 TQSB-2 PCB "PU" To Printer 190 / 40718301TH Rev.6...

  • Page 191: Pcb Layout

    PCB Layout TQSB-2 PCB MOTOR MOTOR CONTROLLER DRIVER SEN2 191 / 40718301TH Rev.6...

  • Page 192: Parts List

    PARTS LIST Figure 6-1 High Capacity Second Paper Feeder 192 / 40718301TH Rev.6...
  • Page 193 Table 6-1 High Capacity Paper Feeder Description OKI-J Part No. Q'ty Remark Hopping roller shaft assy 3PA4122-1367G001 One-way clutch gear 4PB4122-1382P001 Stepping motor 3PB4122-1399P001 TQSB-2 PCB 4YA4046-1651G002 Cassette assy (2nd tray) 1PA4122-1362G004 193 / 40718301TH Rev.6...
  • Page 194 2nd Tray ASSEMBLY SECTION1 CABINET & CASSETTE ASSEMBLY SECTION2 MECHANICAL ASSEMBLY SECTION1 CABINET & CASSETTE ASSEMBLY 194 / 40718301TH Rev.6...
  • Page 195 SECTION1 CABINET & CASSETTE ASSEMBLY 195 / 40718301TH Rev.6...
  • Page 196 SECTION2 MECHANICAL ASSEMBLY 196 / 40718301TH Rev.6...
  • Page 197 Table 6-2 2nd Tray Parts List Description OKI Parts No. Q'ty/U 1000 Plate, upper 1PP4122-1401P001 Sheet guide assembly 3PA4122-1370G001 Front cover assembly 1PA4122-1369G001* Inner guide assembly 3PA4122-1371G001 Cassette assembly (2nd tray) 1PA4122-1362G004*** Separation frame assembly 4PP4120-1009G001 Cover, rear 1PA4122-1323P001 Stick finger...
  • Page 198 *** For the rev. no. of the Parts List for the Cassette assembly (2nd tray) should be applied No.10. The No.10 includes a change of cassette and Tale Guide. Addition of projection part Addition of notch Addition of groove Addition of latch Tale Guide Cassette Note : Cassette and Tale Guide need concurrent replacing.

  • Page 199: Appendix G Network Interface (Option)

    APPENDIX G Network Interface (option) Connector • 8-pin modular jack Cable • 10BASE/T Signal Contact No. Plug Jack Polarity Power feeder3 – Power feeder3 – – Send Receive Receive Send Receive Send – Send Receive – Power feeder2 Power feeder2 –...
  • Page 200 TCP/IP a) Support OS SunOS 4.1.1, SunOS 4.1.2, SunOS 4.1.3 Solaris 2.1, Solaris 2.2, Solaris2.4, Solaris2.5 HP-UX 9.X Windows3.0+TCP/IP Windows3.1+TCP/IP Windows3.11+TCP/IP Windows95 WindowsNT 3.5+TCP/IP WindowsNT 3.5.1 WindowNT 4.0 b) LPR The LPR is an application to process the print data. The LPR of this system supports multiple clients.
  • Page 201 c) FTP FTP is an application to process the print data. The FTP of this system supports multiple of clients. Furthermore, it provides multiple connections for one client. Item Factory default Setup range Description Number of clients connected 1 to 4 clients Indicates the number of clients which can be connected simultaneously.
  • Page 202 f) SNMP SNMP is an application to reference and change the menu of the Network/Printer. The SNMP of this system supports simultaneous connection of multiple clients for the personal user. Furthermore, it provides multiple connections for one client. Netware a) Support OS Netware File Server 2.2C, 3.
  • Page 203 c) Q-Server The Q-Server is an application to process the print data. The Q-Server of this system supports multiple file serves. Furthermore, it allows connection of multiple print servers for one file server. Item Factory default Setup range Description Connection method Bindery method Indicates the connection method with the file server.
  • Page 204 One item by max. Indicates the zone to which the printer be- 36 characters longs. 10) OKI Original Port The OKI Original Port provides special processing which is beyond the scope of normal menu operation. Item Description Initial recognition Executes the processing of finding out the printer by the setup utility when the print- er is connected to the network.
  • Page 205 12) Setup Each setup item can be set by the menu and network management tool. Management Classification Setup item Menu change Description tool change Common Network valid/invalid Valid/invalid for entire network Frame type Frame type for transmission and reception TCP/IP TCP/IP valid/invalid TCP/IP valid/invalid IP address...
  • Page 206 13) TROUBLESHOOTING a) Basic Procedure Processing flow after the occurrence of an error An error occurs (operator panel indicates “HOST I/F ERROR” or the function would not perform normally.) Note STATUS CODE and SUB STATUS CODE 1~ 18. Power on again and retry to use. Another error occurs Take measures (See Appendix) for STATUS CODE/SUB STATUS CODE.
  • Page 207 c) Viewing STATUS CODE/SUB STATUS CODE How to view the area indicating “STATUS” in Network menu is shown below. This area comprises of 4 bytes and can hold 4 error states which have occurred recently. The figures which are indicated in 1st byte area in Figure represent the oldest error among 4 ones. The figures which are indicated in 4th byte area represent the newest error.
  • Page 208 NIC driver Error type Contents Handling Status code Sub status Significant problem Program error (there is possibility of pro- Update of Network Program, or re- gram malfunction or RAM breakage) placement of printer main PCB Network Driver Error type Contents Handling Status code Sub status Significant problem Program error (there is possibility of pro-...
  • Page 209 Socket Error type Contents Handling Status code Sub status Insignificant problem Program error Update of Network Program Telnet server Error type Contents Handling Status code Sub status Significant problem Program error (there is possibility of pro- Update of Network Program, or re- gram malfunction or RAM breakage) placement of printer main PCB Web server...
  • Page 210 Q-Server Error type Contents Handling Status code Sub status Insignificant problem Program error Update of Network Program MIB access function Error type Contents Handling Status code Sub status Significant problem Program error (there is possibility of pro- Update of Network Program, or re- gram malfunction or RAM breakage) placement of printer main PCB JCM &...

Table of Contents
