Computer Connections & Software Install Guide
Installation Checklist
□
Network Install: Hardware ..........................2
□
Network Install: Software ...........................3
• TCP/IP ...............................................................3
• Novell.................................................................6
□
Local Install: Windows USB Port...............7
• Computer Connection ........................................7
• Software for Windows 98 ..................................8
• Software for Windows Me.................................9
• Software for Windows 2000 ............................10
• Software for Windows XP ...............................11
□
Local Install: Windows Parallel Port .......12
• Computer Connection ......................................12
• Software for Windows .....................................13
□
Macintosh Install: Hardware ....................14
• Network ...........................................................14
• USB..................................................................15
□
Macintosh Install: Software......................16
• OS 8.6 to 9.4 ....................................................16
• OS X.v1.1 and higher ......................................18
□
Service and Support .................................19
Executive Series 1220n
USB Versus Parallel: Windows
Installation instructions are included for both USB and
parallel connections. Oki Data recommends using a USB
connection, as your printer is performance optimized for a
USB interface.
Printer Drivers Available
Your printer comes with Windows drivers for PCL and
PostScript emulation.
When to Use the PCL Driver
If you use TrueType fonts and you do not print PostScript
graphics (including ".eps" files), choose the PCL driver.
This will be more efficient and give good results.
When to Use the PostScript Emulation Driver
If you use PostScript fonts or you will be printing PostScript
graphics, choose the PostScript emulation driver.
Performance will be faster and graphics will be printed at
their best quality.
Manuals
Note: In order to open the on-line manual, you must have
®
Adobe
Acrobat
To view the manual, click the User's Guide button on the
Menu Installer screen.
Readme File
Please refer to the readme file on the Drivers CD
supplied with your printer for the latest information on
printer drivers.
1
®
Reader installed.
Advertisement
Table of Contents
Related Manuals for Oki ES1220n
Summary of Contents for Oki ES1220n
-
Page 1: Installation Checklist
USB Versus Parallel: Windows Installation Checklist Installation instructions are included for both USB and □ Network Install: Hardware ......2 parallel connections. Oki Data recommends using a USB connection, as your printer is performance optimized for a □ Network Install: Software ......3 USB interface. -
Page 2: Network Install: Hardware
Network Install: Hardware ® No Ethernet cable is supplied with the printer. Use an Ethernet cable with two twisted wire pairs and an RJ45 Note: plug. □ Turn off the printer. □ Remove the plug from the Ethernet port ( ), then connect your Ethernet cable to the port. -
Page 3: Network Install: Software
□ Click Finish. Press until you see on the display, then • NETWORK MENU Use the Oki LPR Utility to discover the printer: press ENTER □ Click Remote Print, then click Add Printer. Press until you see , then press •... - Page 4 Network Install: Software TCP/IP (cont.) Network Client Distribution Configuring the Print Server via the Embedded Web Page If you are installing the software on a network for network clients, the software must be installed on all clients’ For more detailed information, see the OkiLAN Note: workstations.
- Page 5 Network Install: Software TCP/IP (cont.) Activating the Duplex Unit, To Activate in the PCL Driver: Internal Hard Drive and Click Start → Settings → Printer. □ □ Second Paper Tray Options Right click the PCL printer icon, then click Properties (Windows 2000/XP/Me/9x), or Document Defaults (Windows NT 4.0).
-
Page 6: Launching The Utility
The Menu Installer Software Installation screen Launching the Utility appears. □ Click the Network Software button. To launch the utility click Start → Programs → Oki Setup Utility → AdminManager. □ Click the Installation/Config button. □ Click the Admin Mgr / Quick Setup button. -
Page 7: Local Install: Windows Usb Port
Local Install: Windows USB Port Computer Connection No USB interface cable is supplied with the printer. Note: Use a USB cable that is compatible with USB specification 1.1 or 2.0. • A USB interface will only operate using Windows 2000, Windows XP, Windows Me, and Windows 98. Windows 95 and NT 4.0 do not support USB. -
Page 8: Software For Windows 98
Local Install: Windows USB Port Software for Windows 98 Install the Postscript To Install the PCL Driver as Emulation Driver Well □ With the Menu Installer Software Installation screen □ Make sure the USB cable is connected to your printer still open, click the Printer Driver Installer button. -
Page 9: Install Printer Software Utilities
Local Install: Windows USB Port Software for Windows Me Install the PostScript To Install the PCL Driver as Emulation Driver Well □ □ Make sure the USB cable is connected to your printer With the Menu Installer Software Installation screen and PC and your printer is turned OFF. -
Page 10: Software For Windows 2000
Local Install: Windows USB Port Software for Windows 2000 Install the PostScript □ The License Agreement appears. Click Next. The Menu Installer Software Installation screen appears. Emulation Driver □ Click the Printer Driver Installer button. □ □ Make sure the USB cable is connected to your printer Follow the on-screen instructions. -
Page 11: Software For Windows Xp
Local Install: Windows USB Port Software for Windows XP Install the PostScript When the installation is complete: Click Start → Settings → Printers. □ Emulation Driver □ Right click the printer icon. □ Make sure the USB cable is connected to your printer □... -
Page 12: Local Install: Windows Parallel Port
Local Install: Windows Parallel Port Computer Connection □ Turn off both the computer and the printer. □ Attach a standard IEEE-1284 parallel cable (not supplied) to the parallel port (1) on the printer, securing it with the spring clips. □ Attach the other end to the parallel port on the computer and secure it in place with the screws. -
Page 13: Software For Windows
Local Install: Windows Parallel Port Software for Windows To Install the PCL Driver as Drivers Supplied Well PostScript emulation and PCL drivers are supplied for the following Windows systems: □ With the Drivers CD still in your CD-ROM drive, click Windows 2000 •... -
Page 14: Macintosh Install: Hardware
Macintosh Install: Hardware Network ® Requires Mac OS 8.6 or above, running on a Macintosh computer with EtherTalk interface. Notes: The Ethernet cable is not supplied with the printer. Use an Ethernet cable with RJ45 connectors at either end. □ Turn off the printer. - Page 15 Macintosh Install: Hardware No USB interface cable is supplied with the printer. Use a cable that is compatible with USB specification 1.1 Note: or 2.0. Requires Mac OS 9.04 or higher • Printer operation is not assured if another USB compatible device is connected concurrently with it. •...
-
Page 16: Install The Driver
Macintosh Install: Software OS 8.6 to 9.4 Install the Driver Create the Desktop Printer For □ Turn on the printer, then turn on the computer. □ Place the Drivers CD supplied with your printer into the Mac OS 9.0.4: Navigate to your local hard drive → □... -
Page 17: Accessing Advanced Features
Macintosh Install: Software OS 8.6 to 9.4 (cont.) Accessing Advanced Features On-Line Manuals Requirements Mac OS 9.0.4 and higher □ Adobe® Acrobat® Reader. • Select File on the desktop menu. □ Click Print Desktop from the drop down menu. To Load the Manuals □... -
Page 18: Adding The Printer
Macintosh Install: Software OS X.v1.1 and higher Install the Driver Printing a Job Using the Optional Duplex Unit Be sure to switch off antivirus software before Note: installing a printer driver. From your application, click File → Print → Duplex. □... -
Page 19: Service And Support
Novell and NetWare are registered trademarks of Novell Corporation in the United States and other countries. PCL is a registered trademark of Hewlett Packard Company. OKI and OkiLAN are registered trademarks of Oki Electric Industry Company, Ltd. Adobe, Acrobat, Acrobat Reader and PostScript are trademarks of Adobe Systems, Inc. which may be registered in certain jurisdictions. - Page 20 Oki Data Americas, Inc., 2000 Bishops Gate Blvd., Mt. Laurel, NJ 08054-4620 Tel: 856-235-2600 Fax: 856-222-5247 http://www.okidata.com © 2003 Oki Data Americas, Inc. 59355701...
