ASSEMBLY
Assembly requires two persons. Place all parts of the elliptical exerciser in a cleared area and re-
move the packing materials. Do not dispose of the packing materials until assembly is completed.
In addition to the included tool(s), assembly requires a Phillips screwdriver
an adjustable
As you assemble the exercice bike, use the drawings below to identify small parts. The number in
parentheses below each drawing is the key number of the part, from the PART LIST near the end of
this manual. The number following the parentheses is the quantity needed for assembly.
Note: If a part is not in the hardware kit, check to see if it has been preassembled.
伞头内六角 M10*90（46）*2
伞头内六角 M8*110（100）*2
伞头内六角 M8*85（3）*2
伞头内六角 M8*70（30）*1
内六角扳手 5mm（115）*2
wrench.
马车螺丝 M8*75（36）*2
马车螺丝 M6*55（52）*4
伞头内六角 M8*20（15）*6
尼帽 M8（22）*3
尼帽 M10（50）*2
袋帽 M8（40）*2
圆花旋钮 M6（59）*4
华司 Φ10*Φ19*2T（49）*2
华司 Φ6*Φ14*2T（57）*4
开口扳手（116）*1
5
弹垫 Φ8（14）*6
弹垫 Φ6（58）*4
弧形华司 Φ8*Φ19*1.5T（13）*10
