MK2000 MicroKiosk Product Reference Guide

MK2000 Wall Mounting Options

The MK2000 mounting options include:
• Wall Mount Kit, see page 2-4
• Recessing the MK2000 into a kiosk or wall, see page 2-6.
Using the Wall Mount Kit
1. Determine the MK2000 mounting location.
2. Follow the instructions and use the template provided in the Wall Mount Kit. Four
#10 wood screws are provided for securing the Connector/Port Cover to the wall.
The installer may need to source alternate fasteners appropriate for the wall
material.
3. Connect the cables to the MK2000 (see Figure 1-3 on page 1-5) and ensure the
cables have been routed and secured correctly (see Figure 2-4 on page 2-6).
Cables that are incorrectly mounted or secured may become pinched when the
terminal is attached to the Connector/Port Cover. Install the Connector/Port Cover,
place the keyholes on the back housing over the shoulder head bolts protruding
from the plate and slide the MK2000 to the left and down to secure in place, see
Wall Mounting Kit on page 2-5 and Mounting Directions on page 2-5.
4. After the MK2000 is installed, screw one 8-32 pan head screw (lock screw) into the
Connector/Port Cover tab (located at the top left corner). Hand tighten the screw or
for additional security use a nylon locknut (not included). This screw prevents
removal of the terminal.
5. When the mounting is completed, return to Installation Overview on page 2-2 and
proceed with step 2 supplying power.
