ABOUT YOUR NEW HOME COMFORT CONTROL

EQUIPMENT CONTROL MODULE LEDs

POWER/STATUS – On solid during normal operation . Flashes when
connection to the Home Comfort Control is lost, and at power-up while
the connection is being established .
HEATING – On when heating outputs are active .
COOLING – On when cooling outputs are active .
FAN – On when fan output is active .
HUMIDIFIER – On when humidifier output is active .
DEHUMIDIFIER – On when dehumidifier output is active .
VENTILATION – On when ventilation output is active .
AIR CLEANING – On when air cleaner output is active .
6
WI-FI SETUP
To connect the 8830 Home Comfort Control ™ to a Wi-Fi network follow the steps below .
Note: You will need a computer or mobile device with Wi-Fi and a web browser .
STEP 1
Verify the Home Comfort Control is in
Wi-Fi Connection Mode.
The Home Comfort Control by default will be in Wi-Fi
Connection Mode . To confirm that the Home Comfort
Control is in Wi-Fi Connection Mode, verify that the
radio bars on the Home Comfort Control are strobing as
shown below .
Note: If the Home Comfort Control is not in Wi-Fi
Connection Mode, refer to Clearing Router Settings on
page 33 .
STEP 2
Connect to the Home Comfort Control using
a computer or mobile device.
On your computer or mobile device, scan for available
networks . The Home Comfort Control should appear
as APRILAIRE8830 followed by a unique identifier,
corresponding to the last 6 digits of the MAC address .
Connect to the Home Comfort Control you want to
configure .
If you are installing multiple Home Comfort Controls,
the MAC address of each Home Comfort Control will be
displayed in the message center on the display of the
Home Comfort Control . The MAC address can also be
found by removing the cover on the front of the Home
Comfort Control .
(Continued on the following page.)
