Maytag MGDB400VQ0 Parts List page 4

Illus. Part
No. No. DESCRIPTION
1 W10007520 Clip, Ground
2 8544753 Bracket, Burner
3 3390631 Screw, 10−16 x 3/8
4 8558833 Plate, Cover
Terminal Block
5 8564012 Switch, Assembly
6 344020 Cord, Power
7 W10183827 Cabinet
8 3392100 Foot, Dryer
279810 Foot − Optional
(Extended Length
Package Of 2)
(Not Included)
9 660658 Clamp, Motor (2)
10 3387374 Spring, Idler
11 3389420 Retainer, Idler
12 W10001340 Nut, Fly Wheel
13 8547160 Pulley Assembly
14 W10201446 Bracket−Gas Pipe
15 W10111867 Filler
16 8539892 Wire,Motor
(To Belt Switch)
CABINET PARTS
For Model: MGDB400VQ0
(White Color Coordinated)
Illus. Part
No. No. DESCRIPTION
17 W10153170 Badge
18 W10167613 Wire−Belt Switch
(To Protector)
19 3394083 Clip,
Front Panel (2)
20 8564010 Switch & Actuator
Assembly
21 8579717 Assembly,
Hinge (2)
22 W10183818 Cover, gas valve
23 8564011 Bracket, Switch
24 8576626 Fly−Wheel
26 3393657 Restrainer, Belt
27 W10136932 Motor, Assembly
60 HZ.
28 8558830 Panel, Rear
29 W10139247 Pulley, Blower
30 W10136934 Belt, Drive
31 8578560 Hole, Plug
(Cabinet Base)
32 8547158 Bracket, Motor
33 W10111905 Door Catch
Assembly
4
Illus. Part
No. No. DESCRIPTION
34 W10002600 Screw,
6−20 x 1 1/4
35 8568303 Locator,
Snap Down (2)
36 W10215725 Cover, door switch
37 3400805 Screw, 8−18 x.375
38 W10144494 Plug−Hole
39 W10215728 Seal−Door
40 342055 Screw, 8−18 x 18
41 W10201785 Door Switch
Assembly
43 8576625 Lock, Top Front
44 W10044490 Seal, Front Panel
45 8564457 Plug, Front Panel
46 238088 Hinge Top (2)
47 W10111879 Door, Inner
48 W10226482 Seal, foam
49 W10111876 Door, Outer
50 W10136930 Pulley,
Drum Motor
51 W10236201 Panel, Front
52 W10111906 Strike & Plate
Assembly
53 W10111888 Plug, Strike
W10247616
