Bandera
Bandera
CAUTION
THIS UNIT IS HEAVY!
DO NOT assemble without a helper.
CAUTION
Some parts may contain sharp edges – especially as
notedin manual.Wear protectivegloves if necessary.
CAUTION
Read andfollowall safety statements,warnings,
assemblyinstructionsanduse & care directionsbefore
attempting to assemble.
WARNING
All surfaces can be hot during use. Use protection as
requiredto preventburning.
WARNING
Do not use this unit on or near combustible surfaces or
structuressuch as wooddecks, dry leaves or grass, vinyl
or woodsiding, etc. SEE OWNER'S MANUALFOR
IMPORTANT SAFETY INFORMA TION.
WARNING
NE VE R L E AVE F IR E UNATTE NDE D!
Do not allow small children near flame. Hot embers can
fly outin breezyconditions.Adequatefire extinguishing
materialshouldbe readilyavailable.
WARNING
C AR B ON MONOXIDE HAZAR D
Burning charcoal inside can kill you. It gives off carbon
monoxide, w hichhas no odor . NEVER burncharcoal
inside homes,vehicles or tents.
06201345
04201101
42804228 (11-24-06)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Bandera 06201345 and is the answer not in the manual?

Questions and answers

Related Manuals for Char-Broil Bandera 06201345

Summary of Contents for Char-Broil Bandera 06201345

  • Page 1 04201101 06201345 Bandera Bandera CAUTION WARNING THIS UNIT IS HEAVY! Do not use this unit on or near combustible surfaces or structuressuch as wooddecks, dry leaves or grass, vinyl DO NOT assemble without a helper. or woodsiding, etc. SEE OWNER’S MANUALFOR IMPORTANT SAFETY INFORMA TION.
