SERVICE MANUAL
Ver 1.0 2001. 06
Sony Corporation
9-873-207-01
2001F1600-1
Home Audio Company
© 2001.6
Shinagawa Tec Service Manual Production Group
SS-LA500ED
SPECIFICATIONS
Speaker system
2-way, magnetically
shielded
Speaker units
Woofer: 11 cm, cone
type
Tweeter: 2.5 cm, dome
type
Enclosure type
Bass reflex
Rated impedance
8 ohms
Power handling capacity Maximum input power:
120 watts
Sensitivity level
87 dB (1 W, 1 m)
Frequency range
58 Hz - 70,000 Hz
Approx. 160 × 320 × 220
Dimensions (w/h/d)
mm
Mass
Approx. 5 kg
Supplied accessories
Bracket (1)
Allen (Hex) head driver (1)
Screws (4)
It may be desirable to use WS-FV500 (floor stand;
not supplied), depending on the place you set up
the speaker.
Design and specifications are subject to change
without notice.
US Model
Canadian Model
AEP Model
E Model
SPEAKER SYSTEM
