MaxTech XT4871 User Manual

14 inch color monitor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
XT4871
14 INCH

COLOR MONITOR

USER'S
MANUAL
Features:
• 1024 x 768, Non-Interlaced
• 1280 x 1024, Interlaced
• .28 mm Dot Pitch
• 100 Hz Refresh Rate
• Power Saving Operation (VESA DPMS)
• Non-Glare Screen
• Full Screen Display
• Easy Access Front Controls
• Unlimited Palette of Colors
• Digital Controls
• Plug and Play
Part #MAN104 Rev 1.0
XT4871

Advertisement

Table of Contents
loading

Related Manuals for MaxTech XT4871

Summary of Contents for MaxTech XT4871

  • Page 1: Color Monitor

    XT4871 14 INCH COLOR MONITOR USER'S MANUAL Features: • 1024 x 768, Non-Interlaced • 1280 x 1024, Interlaced • .28 mm Dot Pitch • 100 Hz Refresh Rate • Power Saving Operation (VESA DPMS) • Non-Glare Screen • Full Screen Display •...

  • Page 2: Table Of Contents

    Table of Contents Section 1 - General Information ... 2 Section 2 - Installation ... 3 Section 3 - Monitor Controls and LEDs ... 4 Section 4 - Troubleshooting ... 5 Appendix A - Specifications ... 5 Appendix B - Video Cable Pinout ... 6 Appendix C - Three Year Warranty ...

  • Page 3: Section 1 - General Information

    Section 1 - General Information Congratulations on purchasing a MaxTech 14-inch Color Monitor. The monitor uses one of the finest CRTs available in the industry. The 0.28 mm dot pitch non-glare tube, provides a crisp and vivid color display. The monitor complies with the MRP-I standard to reduce electro-magnetic emissions.

  • Page 4: Section 2 - Installation

    Horizontal and Vertical Synchronization signals. This mode reduces the monitor’s power consumption to 5W. When the synchronization signals are re-enabled the monitor returns to normal operation. Section 2 - Installation Attaching the Base • Carefully place the monitor on its side or top.

  • Page 5: Section 3 - Monitor Controls And Leds

    • The monitor is now ready for use. Section 3 - Monitor Controls and LEDs 1. POWER LED: Lit when monitor is ON. Unlit when monitor is OFF. 2. POWER: Press once to turn monitor ON. Press again to turn monitor OFF.

  • Page 6: Section 4 - Troubleshooting

    6. PINCUSHION: Adjusts the pincushion (shape) of the display 7. HORIZONTAL-SIZE: Adjusts the display width. 8. VERTICAL-POSITION: Adjusts the vertical position 9. VERTICAL-SIZE: Adjusts the display height 10. HORIZONTAL-POSITION: Adjusts the horizontal position 11. SELECT: Press to select an adjustment parameter (5-10). 12.

  • Page 7: Appendix B - Video Cable Pinout

    1024 x 768 1152 x 864 1280 x 1024 Deflection Geometric distortion Linearity distortion Pincushion distortion High voltage regulation Low radiation* Front controls Power saving Input voltage Power consumption 85W maximum Plug and Play Operating Environment Connector *Low radiation monitors only. Specifications subject to change without notice.

  • Page 8: Appendix C - Three Year Warranty

    (562) 921-4438 between 9:00 a.m. and 6:00 p.m. (PST Monday through Friday). When you are instructed by the Technical Support Representative to return the product to MaxTech for repair, you will be given an RMA (Return Merchandise Authorization) number. You must have an RMA Number to return the product for service .

  • Page 9: Appendix D - Notices

    EXCLUSION OF DAMAGES MaxTech'S liability for any defective product is limited to the repair or replacement of the product, at our option. MaxTech shall not be liable for: 1. Damage to other property caused by any defects in this product, damages based upon inconvenience, loss of use of the product, loss of time, commercial loss;...
  • Page 10 All registered trademarks are the property of their respective owners. Copyright © 1997 MaxTech. All rights reserved. No reproduction of this document in any form is allowed without written permission from MaxTech.
