Summary of Contents for MaxTech XT4861
-
Page 1: Color Monitor
XT4861 14 INCH COLOR MONITOR USER'S MANUAL Features: • 1024 x 768, Non-Interlaced • .28 mm Dot Pitch • 72 Hz Refresh Rate (VGA/SVGA) • Power Saving Operation (VESA DPMS) • Full Screen Display • Easy Access Front Controls • Unlimited Palette of Colors •... -
Page 2: Table Of Contents
Table of Contents Section 1 - General Information ... 2 Section 2 - Installation ... 3 Section 3 - Monitor Controls and LEDs ... 4 Section 4 - Troubleshooting ... 5 Appendix A - Specifications ... 5 Appendix B - Video Cable Pinout ... 6 Appendix C - Three Year Warranty ... -
Page 3: Section 1 - General Information
Section 1 - General Information Congratulations on purchasing the 14 inch Color Monitor. The monitor uses one of the finest CRTs available in the industry. The .28 mm dot pitch non-glare tube and a crisp, vivid color display with an 80 MHz video bandwidth, make it the perfect monitor for applications ranging from business presentations to desktop publishing. -
Page 4: Section 2 - Installation
signal is re-enabled the monitor returns to normal operation. The monitor enters DPMS OFF mode when the computer turns off both the Horizontal and Vertical Synchronization signals. This mode reduces the monitor’s power consumption to 3W. When the synchronization signals are re-enabled the monitor returns to normal operation. -
Page 5: Section 3 - Monitor Controls And Leds
connector on the rear of your computer system. The video output connector on your computer may be either in a location similar to Figure 2-2 or on an expansion board. Secure the cable to the computer using the thumbscrews on the 15-pin connector. ·... -
Page 6: Section 4 - Troubleshooting
Brightness Control: Adjusts the display brightness. Turn clockwise to increase the brightness. 10. Contrast Control: Adjusts the contrast. Turn clockwise to increase the contrast. Section 4 - Troubleshooting No picture, power indicators A, and B off • Check AC cord is plugged into outlet and monitor. •... -
Page 7: Appendix B - Video Cable Pinout
Assignment Chart Appendix C - Three Year Warranty MAXTECH warrants to the original buyer of this product against defects in material and workmanship for three years from the date of purchase. Except as specified below, this warranty covers all defects in material or workmanship in this product. - Page 8 (562) 921-4438 between 9:00 a.m. and 6:00 p.m. (PST Monday through Friday). When you are instructed by the Technical Support Representative to return the product to MaxTech for repair, you will be given an RMA (Return Merchandise Authorization) number. You must have an RMA Number to return the product for service .
-
Page 9: Appendix D - Notices
EXCLUSION OF DAMAGES MAXTECH'S liability for any defective product is limited to the repair or replacement of the product, at our option. MAXTECH shall not be liable for: 1. Damage to other property caused by any defects in this product, damages based upon inconvenience, loss of use of the product, loss of time, commercial loss;... - Page 10 All registered trademarks are the property of their respective owners. Copyright © 1997 MAXTECH. All rights reserved. No reproduction of this document in any form is allowed without written permission from MAXTECH.
