XT-7871
USER'S MANUAL
Features
• 0.28 mm Dot Pitch
• 1280 x 1024, Non-Interlaced
• 120 Hz Refresh Rate
• Power Saving Operation (VESA DPMS)
• Anti-Static, Anti-Glare Screen
• Full Screen Display
• Digital Controls with OSD
• Low Radiation (MPR-II)
• Plug and Play
• Three-Year Warranty
Part #MAN124 Rev. 1.0
XT7871
Advertisement
Table of Contents
Related Manuals for MaxTech XT-7871
Summary of Contents for MaxTech XT-7871
- Page 1 XT-7871 USER'S MANUAL Features • 0.28 mm Dot Pitch • 1280 x 1024, Non-Interlaced • 120 Hz Refresh Rate • Power Saving Operation (VESA DPMS) • Anti-Static, Anti-Glare Screen • Full Screen Display • Digital Controls with OSD • Low Radiation (MPR-II) •...
-
Page 2: Table Of Contents
Table of Contents Section 1 General Information ... 2 Section 2 Installation ... 2 Section 3 Monitor Controls and LEDs ... 3 Section 4 Troubleshooting ... 6 Appendix A Specifications ... 7 Appendix B Video Cable Pinout ... 8 Appendix C Power Saving Modes (DPMS) ... 8 Appendix D Three Year Warranty ... -
Page 3: General Information
Section 1 - General Information Congratulations on purchasing a MaxTech 17-inch high resolution color monitor. The monitor uses one of the finest CRTs available in the industry. The 0.28 mm dot pitch non-glare tube provides a crisp and vivid color display. The monitor complies with the MPR-II standard to reduce electro-magnetic emissions. -
Page 4: Monitor Controls And Leds
Figure 2-1 Monitor Connections Expansion boards COM1 COM2 LPT1 VIDEO Section 3 - Monitor Controls and LEDs 3.1 Controls and LEDs Figure 3-1 Master Power Control... - Page 5 Figure 3-2 Control and LED Locations Master Power (On rear): Push to provide power to the monitor. This switch should be left ON for daily operation. Use the front panel On/Off control (3) to turn the monitor display on and off. Power Saving Indicator: When lit, the monitor is in the DPMS OFF mode.
- Page 6 3.2 On-Screen Display 1280 X 1024 H: 64KHz The On-Screen Display (OSD) is enabled by pressing either button of control pair 6 (see Figure 3-2). Control pair 5 (+ and -) buttons are used to increase or decrease the value of selected parameter. A.
-
Page 7: Troubleshooting
Section 4 - Troubleshooting No picture, no LEDs lit. • Check that the AC cord is plugged into an outlet and the monitor. • Turn on the Master Power switch. No picture, power LED is lit. • Monitor is in DPMS STANDBY/SUSPEND mode. Press a key or move the mouse. -
Page 8: Appendix A Specifications
Appendix A - Specifications Picture Tube Size Dot pitch Horizontal Freq 30-66KHz Vertical Freq. 50-120 Hz Resolution (Max.) 1280 x 1024 Video Dot Rate 100 MHz Data Area 11.8 in. x 8.7 in. Maximum Refresh Rates Resolution 640 x 480 800 x 600 1024 x 768 1280 x 1024... -
Page 9: Appendix B Video Cable Pinout
Appendix B - Video Cable Pinout Figure B-1 Pin Layout and Pin Assignment Chart Appendix C - Power Saving Modes (DPMS) VESA Display Power Management Signaling (DPMS) defines a method for a computer to signal the monitor to reduce its power consumption when idle. DPMS features must be supported by both the computer and the monitor. -
Page 10: Appendix D Three Year Warranty
Except as specified below, this warranty covers all defects in material or workmanship in this product. The following are not covered by the warranty: 1. Any product which is not distributed in North America by MAXTECH or which is not purchased in North America from an authorized MAXTECH Dealer. -
Page 11: Appendix E Notices
EXCLUSION OF DAMAGES MAXTECH'S liability for any defective product is limited to the repair or replace- ment of the product, at our option. MAXTECH shall not be liable for: 1. - Page 12 All registered trademarks are the property of their respective owners. Copyright © 1997 MAXTECH. All rights reserved. No reproduction of this document in any form is allowed without written permission from MAXTECH. First Edition...
