PathBuilder S21x Switch Cabling
This Appendix identifies the cables and pinout requirements for the PathBuilder
S21x switch. The following cables are described in this appendix:
• CTP Access Cable
• Dual FXS Voice Relay Cable
• 10BaseT Crossover Cable
• RemoteVu Video Cables
• DSU Daughtercard Cable
• V.35/V.36 Cable
• V.11 Cable
• V.24 Cable
Cables for optional daughtercards are shipped with the daughtercards. If your
PathBuilder S21x switch is shipped with pre-installed daughtercards you will receive
the cables. For daughtercard installation and more cable information, please refer to
the PathBuilder S200 Series Daughtercard Installation Guide (Part Number, T0020).
To order cables please contact a 3Com representative. In addition to the cables
listed above the following cables can be ordered:
• DB25 Male to M34 Female cable
• DB25 Male to M34 Male cable
PathBuilder S21x Switch Cabling
Appendix B
B-1
