Power
Requirements
Power Supply
Description
Safety
Physical
A-2
PathBuilder S21x switch typically has the following power requirements:
• 100 to 240 VAC nominal at 47 to 63 Hz
• 32 watts input power (64 VA)
• maximum input current 0.7 amps
PathBuilder S21x switch products are powered by a switch mode power supply with
22.5 watts maximum output power.
PathBuilder S21x switch meets the following safety standards:
• EN60950
• CSA 950
• UL Listed per UL 1950
PathBuilder S21x switch has the following measurements:
• Height: 2.75 in. (6.7 cm)
• Length: 6.7 in. (17 cm)
• Width: 9.5 in. (24.5 cm)
• Weight: 2.2 lb (1.0 kg)
Specifications
