Installing or Removing the Lithium Battery
Removing/
Installing the
Battery
To remove the battery:
To install the battery:
2-14
Figure 2-6 shows how to install and replace the battery.
Using your fingers, push the retaining
tabs aside and pry the battery out of the
holder.
Place the battery in the holder, with the
positive (+) side up, and press down until
the retaining tabs click into place.
Figure 2-6. Replacing the Battery
Retaining Tabs
Installing the PathBuilder S21x Switch Hardware
Battery
Battery Holder
