Summary of Contents for Oki C9600

  • Page 2: Table Of Contents

    Media Type selection. Print Environment Item Anheuser-Busch Comment Printer ® HDD and Duplexer C9600 are installed. Custom Media See page 2 for details. Custom AB media Table selections appear only in the Windows 2000 and XP drivers. Custom Color See page 8 for details.

  • Page 3: Ab Media

    AB Media • Media Type: Set the Media Type in the printer driver rather than in the printer menu. • Paper Tray/Output Bin: Use the suggested paper tray and output bin to prevent paper jams and misfeeding. • Color Profile: Use the Default setting for the Graphics Pro Color Mode Printer Output Profile...
  • Page 4 Settings to Use for AB Media (continued) Sort Edge Select Paper Versus Output Black Media Tray Finish Comments Select Media Type Long Edge Shelf Strip Media AB SHELFSTRIPS GL Short Edge Stacker Glossy Separate each sheet carefully to six 1.25" x 11" strips Tray (Face-up) avoid multi-sheet feeding.

  • Page 5: Media Feed Orientation

    4. Use the ∇ key to scroll down to MPTray Config, then Media Feed Orientation press Enter. MP Tray (MPT) The orientation of letter-size media must match the media size and orientation in the printer menu. When media is loaded for long edge feed, if the printer menu is not set to Letter Long Edge, pages will be printed rotated 90 degrees.

  • Page 6: Corel Draw 12 Settings

    Corel Draw 12 Settings PostScript Tab Make sure that the Screen frequency is set to Default Before printing, click the Tools pull-down menu and (the default setting). select Color Management. Make sure that the profiles in red boxes below are selected as shown (default settings).

  • Page 7: Printer Driver Settings

    Printer Driver Settings a. Set the Media Type: refer to the Media table on page 2. (Windows 2000/XP) In the Print dialog box, on the General tab: • Windows 2000: right click the printer icon, then select Printing Preferences. • Windows XP: click Preferences. Printing Preferences dialog box appears.

  • Page 8: Job Options Tab

    Job Options Tab b. Make sure that Media Check is set to (the default setting). If this option is set to On, the printer may show Media Type Mismatch on the LCD display during printing. c. Set the Tray Switch option to Off.

  • Page 9: Color Tab

    Color Tab Graphics Pro Details Dialog Box a. Make sure that the Input and Output Profiles in red boxes below are set as shown. NOTE For general office documents, select Automatic under Color Mode. NOTE The AB custom color simulation is designed to print Budweiser red as effectively as possible.
  • Page 10 Cleaning the MP Tray Cleaning the Inner Rollers Periodically, or if you should experience jamming even Rollers though you have cleaned the outer roller, you should clean the inner rollers as well. Cleaning your printer’s Multi-Purpose (MP) Tray rollers 1. Remove the paper from the MP Tray. assures smooth, jam-free operation.
  • Page 11 5. Lift the top roller cover. 8. Use a fresh area of the cleaning cloth to wipe the rubber pad on the front roller access door. 9. Close the front roller access door. 6. Swing open the front roller access door. 10.
  • Page 12 Oki Data Americas, Inc., 2735 Matheson Blvd. East, Unit 1, Mississauga (Ontario), Canada L4W 4M8 Tél. : 1 800 654-3282 Téléc. : (905) 238-4427 Oki Data de Mexico, S.A. de C.V., Mariano Escobedo No. 748 - 8 Piso, Col Anzures, e. p. 11590, Mexico, DF Tel: +52 555 263-8780 FAX: +52 555 250-3501 Oki Data do Brasil Informática, Ltda., Av.
