C9600 Software Installation Guide
Table of Contents
Network Installation ..............................................2
Windows® .......................................................2
Novell®............................................................6
Windows® Installation ..........................................7
USB Connection ..............................................7
Parallel Connection........................................10
Macintosh® Installation ......................................12
OS 9.1 to 9.2.x ...............................................12
OS X.1+ to X.3+ ............................................13
On-Line Manuals .................................................17
Service and Support.............................................18
Overview
Your printer comes with drivers for both Postscript (PS) and
PCL emulation. To set up the printer as a PostScript or PCL
printer, you must install the PostScript or PCL driver. Note: The
MAC Installer will install only the PostScript driver.
You must also configure either a local connection for printing
directly to your printer or a network connection for printing
over a network.
Select a printer driver in Windows
Select a driver appropriate for your application.
For the most recent printer driver version, see our web site:
http://my.okidata.com
PostScript printer driver
If you use PostScript fonts, or you will be printing PostScript
graphics, choose this driver. Performance is faster and graphics
print at their best quality.
PCL printer driver
If you use TrueType fonts and you do not print PostScript
(including ".eps" files) graphics, choose this driver. This is
more efficient and gives good results.
You can install both drivers and use either one depending on
your application. However, each driver must be installed
individually.
Do not connect this product to an uninterruptible
power supply (UPS). For further information
please contact Oki Data at 1-800-OKIDATA or
www.okidata.com.
Be sure to use the 15A AC power cord supplied
with the printer. Use of a power cord NOT supplied
with this printer, or an extension cord, may result
in overheating, and could be a safety hazard.
1
NOTE
CAUTION!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Oki C9600hdn
Summary of Contents for Oki C9600hdn
-
Page 1: Table Of Contents
CAUTION! Do not connect this product to an uninterruptible power supply (UPS). For further information please contact Oki Data at 1-800-OKIDATA or www.okidata.com. Be sure to use the 15A AC power cord supplied with the printer. Use of a power cord NOT supplied with this printer, or an extension cord, may result in overheating, and could be a safety hazard. -
Page 2: Network Installation
2. Loop the cable if necessary to keep the ferrite core in place. 3 Assign an IP address to the printer. 4 Install the printer driver and OKI LPR utility. 3. Place the open core about 1 inch from the cable connector on the printer end. 5 Install additional 4. - Page 3 Network Installation Windows (cont’d) 2 Connect the Ethernet Interface 3 Assign an IP address to the printer If you are not using DHCP, you need to obtain an IP Address from your network Administrator and enter it using the front panel: 1.
-
Page 4: Printer Driver
CD-ROM drive. Double-click . Click Wizard, you must manually load the LPR Utility from the Menu Installer on CD1. To do this, click Custom Install / Network Software/InstallationConfig/OKI LPR. 2. Select your language. Next To Install the PCL Driver as well 3. - Page 5 To activate in the PostScript driver → → 1. Click Start Settings Printer Oki Data PostScript 2. Right click the printer icon, then Printers/Properties click Windows 2000, XP Device Settings 1. Click the tab.
-
Page 6: Novell
6. Click the Network Software button. 7. Click the Installation/Config button. Launching the Utility To launch the utility click Start → Programs → Oki Data 8. Click the Admin Mgr/Quick Setup button. Setup Utility → Admin Manager. 9. Setup Assistant displays. Select your language. Click Next. -
Page 7: Windows® Installation
® Windows Installation USB Connection Overview 1 Connect the USB Cable Complete these steps to install your printer with a USB connection: 1 Connect the USB cable. 2 Install the printer driver. 3 Install productivity software. 4 Install the on-line user’s guide. -
Page 8: Windows Installation
® Windows Installation USB Connection (cont’d) 2 Install the PostScript Printer Driver NOTE NOTE If New Hardware Found Wizard displays: The installation procedure may vary slightly depending on Win 98: Select “Search for the best driver for your device”. the operating system you are using. Drivers are provided for Click Next. - Page 9 ® Windows Installation USB Connection (cont’d) 9. Click OK. Then, close the Printers dialog box. To print a test page: 10. Click Start → Settings → Printers. 11. Click the General Tab. Click the Print Test Page button. 3 Install the Productivity Software 1.
-
Page 10: Parallel Connection
® Windows Installation Parallel Connection Overview 1 Connect the parallel Interface Complete these steps to install your printer with a Parallel connection: 1 Connect the parallel Interface. 2 Install the printer driver. 3 Install the productivity software. 4 Install the User’s Guide. For direct connection to a PC This port requires a bi-directional (IEEE 1284 compliant) 5 Activate printer options. - Page 11 ® Windows Installation Parallel Connection (cont’d) → → 2 Install the PostScript Printer Driver 16. Click Properties General Tab Print Test Page NOTE 17. Click the Print Test Page button. The installation procedure may vary slightly depending on the operating system you are using. Drivers are provided for ®...
-
Page 12: Macintosh Installation
Macintosh Installation ® Network Interface Connection USB Interface Connection • Requires Mac OS 9.04 or higher IMPORTANT! Before connecting the network cable, install the Ferrite Core. • Printer operation is not assured if another USB compatible See “1 Install the Ferrite Core” on page 2. device is connected concurrently with it. -
Page 13: Install The Driver
5. Under USB Printer Selection, click 6. Highlight your OKI printer model. Click Install 10. Check the utilities you want to install. Click 7. Click Create. The OKI printer icon appears on the desktop. 11. Select your printer model. Click 8. Click AutoSetup. -
Page 14: To Load The Manuals
Macintosh Installation ® OS 9.1 to 9.2.x Accessing Advanced Features Requirements • Microsoft Internet Explorer version 4.0 or higher and 1. Select File on the desktop menu. Acrobat Reader. 2. Click Print Desktop from the drop down menu. To Load the Manuals 3. -
Page 15: Os X.1+ To X.3
2. Place the CD supplied with the printer in the CD-ROM Continue drive. 12. Click to install additional utilities. 3. Double-click the OKI CD icon that appears on the desktop. 13. When the installation is complete, click Quit → Driver Install 4. - Page 16 Macintosh Installation ® OS X.1+ to X.3+ Activating the Duplex Unit 1. From your application, click → → File Print Duplex MACosx_7.jpg 2. Select the Duplex binding. Print 3. Click To Run Job Accounting for Mac Clients Note: Requires OS 10. 2 or later. For details, refer to the "Print Job Accounting User’s Manual".
-
Page 17: On-Line Manuals
On-Line Manuals Overview For additional information on using printer features as well as printer utilities, see the on-line reference manual. Requirements Microsoft Internet Explorer version 4.0 or higher and Acrobat Reader. Load the Manuals In order to open the on-line manual, you must have Acrobat Reader installed. -
Page 18: Service And Support
Service and Support If you need further assistance or have questions See out web site: http://my.okidata.com In the U.S. and Canada, call: 1-800-OKI-DATA (1-800-654-3282) 24 hours a day, 7 days a week... - Page 20 Apple, Macintosh, Mac and Mac OS are registered trademarks of Apple Computer. Other product names and brand names are registered trademarks or trademarks of their proprietors. Oki Data Americas, Inc., 2000 Bishops Gate Blvd., Mt. Laurel, NJ 08054-4620 Tel: 1-800-654-3282 (856) 235-2600 Fax: (856) 222-5320, www.okidata.com ©...
