Mounting

Before mounting this product, read and follow the Safety Notes.

Orientation

The DataStream™ 4 may be mounted in any position; however, make sure adequate
ventilation is provided around the product.

Rigging

Before deciding on a location for this product, always make sure that it will be easy to
access the unit for maintenance and programming purposes.
Make sure that the structure onto which you are mounting this product can support its
weight. See the Technical Specifications for weight information.
When mounting this product overhead, always use a safety cable. Mount the product
securely to a rigging point, whether an elevated platform or a truss.
When rigging this product onto a truss, you should use a mounting clamp of appropriate
weight capacity.
The product has an M8 threaded insert mounting hole located on the back of the unit for
easy truss mounting. There are also two ears for rack mounting. This product uses 1U of
space.
Rack
Mounting
Threaded Insert
Holes
Mounting Diagram
DataStream™ 4 User Manual Rev. 2 Page 7 of 12
