2. I
NTRODUCTION
Product Overview
DMX In
3 & 5 Pin
DMX Signal
Indicator
LED ON
Indicator
Product Dimensions
5.3 in
134 mm
1.8 in
46 mm
DataStream™ 4 User Manual Rev. 2
DMX Link
Out/Throughput
Front View
M8 Threaded
Insert
Back View
19 in
483 mm
Ears for
Rackmount
LED In Use
Indicators
DMX Outputs
Power In
Fuse Holder
Page 5 of 12
