Tile saw

Advertisement

Warning:
• For your own safety read instruction manual
before operating saw.
• Wear eye protection.
• Use splash hood for every operation for which it
can be used.
• Disconnect saw before servicing, when
changing cutting wheels, and cleaning.
• Use tool only with smooth edge cutting wheels
free of openings and grooves.
• Replace damaged cutting wheel before
operating.
please record the serial number (Located on the
cover post casting) of your saw in this block.
serial number
For your warranty to be effective, complete the
warranty card (include the serial number) and
mail it in as soon as possible.
Manual Part No. 156934
Revision 10/01
Model MK-470
Tile Saw
Owner's Manual
Parts List &
Operating
Instructions
R

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MK-470 and is the answer not in the manual?

Questions and answers

Summary of Contents for MK Diamond Products MK-470

  • Page 1: Parts List

    • Replace damaged cutting wheel before operating. please record the serial number (Located on the cover post casting) of your saw in this block. serial number For your warranty to be effective, complete the warranty card (include the serial number) and mail it in as soon as possible.
  • Page 2: Table Of Contents

    Danger Warning Caution I M P O RTANT SAFETY INSTRUCTIONS FOR T H E MK-470 T I L E S AW Foryour safety, read all instructions! pg 1-2 These safety precautions should be followed at all times. Failure to follow these safety precautions could result in injury to yourself and others.
  • Page 3: Hazard Symbols

    “notice.” n o t i c e Your MK-470 Tile Saw or other pro p e rty could be damaged if you don’t follow instru c t i o n s . California Proposition 65 Message Warning suitable to the material being saws or drilled.
  • Page 4: Water Recirculation System

    Built of rugged composite material, the one-piece table allows for the cutting of 14” (355mm) tile and diagonally cuts 10" (254mm). Frame The structural steel frame of the MK-470 provides high strength and rigidity, while keeping weight to a minimum. The MK-470 is very portable at 29 pounds and an overall size of 28”L x 21”W x 25”H.
  • Page 5: Electrical Requirements And Grounding Instructions

    Electrical Requirements and Grounding Instructions The MK-470 tile saw is wired for 120V, single phase operation, and draws 5.3 amps at 120V. This is not a large load, however if the machine is operated on any circuit that is already close to its capacity, the circuit breaker may be tripped. If this occurs, eliminate other loads from the circuit.
  • Page 6: Extension Cords

    Then unplug and examine for presence of water in the receptacle. power To avoid the possibility of the appliance plug or receptacle getting wet, position tile saw to one side of a wall mounted receptacle to supply cord p revent water from dripping onto the receptacle or plug. A “drip loop,” shown in the figure below, should be arranged by the user to properly position the power cord relative to the power source.
  • Page 7: Rip Cutting

    Center for technical support and parts information 1-800-474-5594 for help in solving any problems. Periodic maintenance your MK-470 allows for long life and tro u b l e - f ree operation. The cutting residue that the saw generates could be considerable.
  • Page 8: Optional Accessories

    [part# 152792] Sturdy, compact & rugged steel saw stand designed for the MK-470 Tile Saw. The stand easily affixes to the water reservoir and orients the saw to a comfortable operating height. Easy assembly...
  • Page 9: Parts Listing

    MK-470 Exploded View...
  • Page 10 MK-470 Parts List Model MK-470 Tile Saw 120v/7.4a, Part # 155779 Item Description Wrench, Blade Nut, 15/16 Boxed End Wrench, Blade Shaft, 11/16 Open End Blade, 7 Dia X 5/8 Arbor Owner’s Manual Warranty Card Information Tag Assembly, Rip Guide w/ Screw, _-20 X _ Thumb Assembly, Blade Guard, 7”...
  • Page 11 Wheel, Roller Screw, 1/4-20 X 1 1/4 Hex Head Cap Washer, 1/4 SAE Flat Nut, 1/4-20 Hex Assembly, Splash Curtain Curtain, Splash Bracket, Splash Curtain Washer, 1/4 SAE Flat Wingscrew, 1/4-20 X 1/2 Table, 470 Assembly, PES-100 120v Water Pump Pump, Water, PES-100 120v Hose, Vinyl, 1/4 ID Clamp, Flow, 1/4-1/2...
  • Page 12: How To Order Repair Parts

    HOW TO ORDER PARTS Please have the following information ready before calling: SERIAL NUMBER OF YOUR SAW MODELNUMBER OF SAW WHERE PURCHASED AND WHEN PART NUMBER PART DESCRIPTION All parts listed may be ordered from your local distributor or from mk diamond. If the part is not stocked locally, call :1 (800) 421-5830 or (310) 539- 5221 and ask for customer service.
