MK-101 Tile Saw
OWNER'S MANUAL,
PARTS LIST &

OPERATING INSTRUCTIONS

MK-101 Part # 167979
Revision 109
09.2013
Manual Part# 168237
Caution: Read all safety and operating instructions
before using this equipment. This manual MUST
accompany the equipment at all times.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MK-101 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MK Diamond Products MK-101

Summary of Contents for MK Diamond Products MK-101

  • Page 1: Parts List

    MK-101 Tile Saw OWNER'S MANUAL, PARTS LIST & OPERATING INSTRUCTIONS MK-101 Part # 167979 Revision 109 09.2013 Manual Part# 168237 Caution: Read all safety and operating instructions before using this equipment. This manual MUST accompany the equipment at all times.
  • Page 2 Congratulations on your purchase of a MK-101 Tile Saw. We are certain that you will be pleased with your purchase. MK Diamond takes pride in producing the finest construction power tools and diamond blades in the industry. Operated correctly, your MK-101 Tile Saw should provide you with years of service. In order to help you, we have included this manual.

  • Page 3: Table Of Contents

    TaBle OF CONTeNTS SaFeTY Safety Messages General Safety Precautions California Proposition 65 Message Hazard Symbols Electrical Requirements 8-10 Safety Label Locations Product Specifications UNPaCKiNG, TRaNSPORT and aSSeMBlY Unpacking Contents Transport Stand Assembly 16-17 SeTUP, STaRTUP, aDJUSTMeNT, OPeRaTiON and SHUTDOwN Setup 18-20 Operation 20-23...

  • Page 4: Safety Messages

    MK-101 SaFeTY Read and follow all safety, operating and maintenance instructions. Failure to read and follow these instructions could result in injury or death to you or others. Failure to read and follow these instructions could also result in damage and/or reduced equipment life. Safety warnings and guidelines do not by themselves eliminate danger.
  • Page 5 MK-101 SaFeTY PeRSONal PROTeCTiVe eQUiPMeNT alwaYS wear approved respiratory, head, ear and eye protection when operating this machine. aCCiDeNTal STaRTS! Before starting the engine/motor, be sure the ON/OFF switch is in the OFF position to pre- vent accidental starting. Place the ON/OFF switch in the OFF position before performing any service operation.
  • Page 6 USe PROPeR aPPaRel DO NOT wear loose clothing, gloves, neckties, rings, bracelets, or other jewelry that may be caught in moving parts. Non-slip footwear is recommended. Wear protective hair cover- ing to contain long hair. SeCURe wORK Clamps or a vise should be used to hold work whenever practical. Keeping your hands free to operate a power tool is safer.
  • Page 7 CHeCK FOR DaMaGeD PaRTS Before using a power tool, check for damaged parts. A guard or any other part that is damaged should be carefully checked to determine if it would operate properly and perform its intended function. Always check moving parts for proper alignment or binding. Check for broken parts and mountings and all other conditions that may affect the operation of the power tool.

  • Page 8: California Proposition 65 Message

    MK-101 SaFeTY SiliCa DUST waRNiNG Grinding/cutting/drilling of masonry, concrete, metal and other materials with silica in their composition may give off dust or mists containing crystalline silica. Silica is a basic component of sand, quartz, brick clay, granite and numerous other minerals and rocks. Repeated and/or substantial inhalation of airborne crystalline silica can cause serious or fatal respiratory diseases, including silicosis.

  • Page 9: Electrical Requirements

    MK-101 SaFeTY eleCTRiCal ReQUiReMeNTS aND GROUNDiNG iNSTRUCTiONS In order to prevent electrical shock and injury, the following electrical safety precautions and symbols should be followed at all times! waRNiNG In case of a malfunction or breakdown, grounding provides a path of least resistance for electrical current to reduce the risk of electric shock.
  • Page 10 MK-101 SaFeTY eleCTRiC MOTOR SaFeTY For maintenance care and operation of the electric motor, refer to your electric motor instruction book- let furnished with the electric motor. Protect the electric motor from dust as much as possible and keep ventilating openings clean. Before plugging in the machine, make sure that the outlet voltage is within the voltage marked on the machines's data plate.
  • Page 11 MK-101 SaFeTY waRNiNG To avoid the possibility of the appliance or plug receptacle getting wet, position the machine to one side of a wall mounted receptacle. This will prevent water from dripping into the receptacle or plug. A "drip loop," shown in the picture below, should be arranged by the user to properly position the power cord relative to the power source.
  • Page 12 MK-101 SaFeTY waRNiNG Use of undersized extension cords result in low voltage to the motor that can result in motor burnout and premature failure. MK Diamond warns that equipment returned to us showing signs of being run in a low voltage condition, through the use of undersized extension cords,will be repaired or replaced totally at the customer’s expense.

  • Page 13: Safety Label Locations

    MK-101 SaFeTY SaFeTY laBel lOCaTiONS Safety labels contain important safety information. Please read the information contained on each safety label. These labels are considered a permanent part of your saw. If a label comes off or becomes hard to read, contact MK Diamond or your dealer for a replacement.

  • Page 14: Product Specifications

    GeNeRal DeSCRiPTiON The MK-101 Tile Saw is engineered as a tabletop or stand mounted wet tile saw. The saw includes a powerful 120V electric motor. The saw is capable of cutting tile up to twenty (20) inches in length, depth of cut 3".

  • Page 15: Unpacking

    If within one (1) Year from the date of purchase, this MK Diamond saw fails due to defect in material or workmanship, MK will repair it, free of charge when the unit is re- turned to the dealer where it was purchased. This warranty DOES NOT cover normal wear or damage resulting from operator abuse. In no event shall MK Diamond Products, Inc.

  • Page 16: Transport

    2. Never transport the MK-101 with water in the Water Pan. The MK-101 is designed with a rigid frame and removable Cutting Head. Two people are required to transport the MK-101 with the Cutting Head installed. The Cutting Head must be removed first, if one person is transporting the saw (see Cutting Head Installation and Removal in the following section).

  • Page 17: Stand

    MK-101 STaND STaND (Optional) CaUTiON The MK-101 weighs eighty-four (84) pounds; follow the guidelines the Transport section when placing it on the stand (MK Diamond Part# 168244). NOTe: If using the Optional MK Diamond Stand, follow these steps: Open the stand and place on...

  • Page 18: Assembly

    MK-101 aSSeMBlY aSSeMBlY Follow the assembly instructions to prepare your MK-101 for operation. CUTTiNG HeaD iNSTallaTiON NOTe: If the Cutting Head is installed, go to the next step. Align Cutting Head rear Install the Cutting Head onto the Pivot Hole to the Post Pivot...
  • Page 19 MK-101 aSSeMBlY aDJUSTaBle CUTTiNG GUiDe iNSTallaTiON NOTe: The Adjustable Cutting Guide can be used on either side of the Diamond Blade. Loosen Adjustable Cutting Place the Adjustable Cutting Guide retaining thumbscrew Guide onto the Movable Cutting and place it over the Movable...

  • Page 20: Setup

    Table moves freely damage. Verify the blade is cor- rect for the material being cut Inspection the Pump Assem- Inspect the MK-101 for bly for damage. Ensure the damage. Ensure the cord is cord is free of cracks of cuts...
  • Page 21 MK-101 SeTUP CONNeCTiNG waTeR PUMP To prevent the possibility of electrical shock, the MK-101 MUST be de-energized waRNiNG when connecting the Water Pump. To prevent the possibility of electrical shock, use only MK Diamond qualified replacement parts. To prevent pump damage, the Water Pump must be disconnected from its power NOTe: supply if cutting with a Dry Blade.
  • Page 22 Check for damaged, broken, or missing parts. Verify the ON/OFF switch is in the OFF position. Before connecting the MK-101 to a power supply, be sure the voltage, cycle and phase of the job site power source meet the requirements in the Table below.

  • Page 23: Operation

    8Kw 120 Volts 20 Amps Single Phase Ensure the ON/OFF Switch is Plug MK-101 into GFCI Plug the GFCI into the power in the OFF position source SeT CUTTiNG DePTH When loosing the Cutting Head Adjusting Knob, the Cutting Head will pivot CaUTiON down unless held.
  • Page 24 MK-101 OPeRaTiON CUTTiNG STRaiGHT eDGeS DO NOT FORCe THe TOOl. It will do the job better and safer at the rate for CaUTiON which it was designed. Loosen the Adjustable Cutting Position the Adjustable Cutting Place the tile against the Ruler/...
  • Page 25 MK-101 OPeRaTiON Perform the cut. Turn the motor OFF when work is complete 45° MiTeR CUTTiNG DO NOT FORCe THe TOOl. It will do the job better and safer at the rate for CaUTiON which it was designed. Position the 45° Bullnose Position the tile on the 45°...
  • Page 26 MK-101 aDJUSTMeNT OFF-aNGle CUTTiNG NOTe: To cut angles other than 45° angles or Miter, a 90° Protractor (MK Diamond Part No. 134569-MK) should be used. CaUTiON DO NOT FORCe THe TOOl. It will do the job better and safer at the rate for which it was designed.
  • Page 27 MK-101 aDJUSTMeNT aDJUSTiNG THe CUTTiNG HeaD The Cutting Head is heavy. Care must be used when changing the position of the CaUTiON Cutting Head. Move Cutting Head Stop to down Remove the blade. Support the Remove the Cutting Head from...
  • Page 28 MK-101 aDJUSTMeNT aDJUSTiNG THe POST FOR MaXiMUM CUTTiNG leNGTH The Cutting Head and Post are heavy. Care must be used when changing the CaUTiON position of the Cutting Head. Remove the Cutting Head (See Remove Water Basin Loosen the Retaining Bolts Adjusting the Cutting Head) Remove the Retaining Bolts.
  • Page 29 Clean the remainder of the clean. ting Table Roller Wheel and MK-101 Frame Support MaiNTeNaNCe Perform the following after initial purchase and operation of the MK-101. Check and adjust V-belt tension following first 48 hours of operation (See V-belt Inspection).
  • Page 30 Perform the following after initial purchase and operation of the MK-101. MaiNTeNaNCe FOllOwiNG USe To extend the life of the MK-101, the following procedure should be performed after each use. Lubricate all points listed below with light oils such as, 3 in 1, WD-40, etc.

  • Page 31: Cutting Head Adjustment

    MK-101 MaiNTeNaNCe MONTHlY MaiNTeNaNCe CONT. Remove the Blade Guard. Remove the Cutting Head (See Lubricate the threads on the Lubricate the Blade Guard Adjusting the Cutting Head) Cutting Head Adjustment Pivot Shaft Tri-Knob Lubricate the Cutting Head Lubricate the Cutting Head...

  • Page 32: Maintenance

    MK-101 MaiNTeNaNCe BlaDe DReSSiNG Like most cutting instruments, a diamond blade performs best when it is dressed. Over time and use, diamonds on the outer edge of the blade will become smoothed or "glazed" over. This will reduce grinding efficiency and may cause the blade to "wander" or bend giving the illusion of an alignment problem.
  • Page 33 MaiNTeNaNCe MiCRO-V BelT iNSPeCTiON, aDJUSTMeNT aND RePlaCeMeNT The MK-101 is designed with power transmission Micro-V Belt. In order to ensure the MK-101 operates a peak efficiency, the Micro-V Belt should be inspected monthly, and changed if the Micro-V Belt shows damage and/or excessive wear.
  • Page 34 MK-101 MaiNTeNaNCe Push the motor toward the Remove the Micro-V Belt Install the new Micro-V Belt front of the Cutting Head to (MK Diamond Part No. 158194) loosen the Micro-V Belt Verify the Micro-V Belt is Tighten the Motor Adjustment...
  • Page 35 MK-101 MaiNTeNaNCe COOliNG FlOw Check cooling flow Adjusting Remove the Cooling Transfer Place Pump into a bucket of Clamp open Tube from the Blade Guard water and check flow inlet Remove the Cooling Transfer Inspect and clean pump. See Remove the Blade Guard...

  • Page 36: Troubleshooting

    MK-101 TROUBleSHOOTiNG MOVaBle CUTTiNG TaBle DOeS NOT MOVe CORReCTlY Check that the Guide Bar is Check the Movable Cutting clean - clean if dirty table Roller Wheels for wear, replace if necessary BlaDe will NOT CUT PROPeRlY Ensure the Blade Core is not...
  • Page 37 NOTeS...
  • Page 38 MK-101 eXPlODeD View Saw Assembly Part# 167979...
  • Page 39 SHEET, WARNING LABELS, TILE SAW 166012 ASSY, CUTTING HEAD, MK-101 168167 ADAPTER, 1/2 NPT X 1/4 BARB 168261 ASSY, FRAME & POST, MK-101 170476 10" PREMIUM PORCELAIN TILE BLADE 170588 HOSE, VINYL, 1/4 X 3/8 (6.0') 132951 PUMP, WATER 115V/60HZ UL/CSA...
  • Page 40 MK-101 eXPlODeD View Frame Assembly Part# 170476...
  • Page 41 MK-101 PaRTS liST item Description Part # WASHER, LOCK, SPLIT, 3/8 150925 SHAFT, 10.63 PIVOT 153254 SCREW, SET, SOC, CUPT, 3/8 - 16 X 1/2 153710 PLATE, PRESSURE 155671 SCREW, 3/8 16 X 2-1.2 HEX HEAD CAP 156030 CASTING, POST, DC, 101 MKRED-COMP...
  • Page 42 MK-101 eXPlODeD View Table Assembly Part# 158477-NC...
  • Page 43 MK-101 PaRTS liST item Description Part # BAR, GUIDE PLATED MK-101 134759 SCREW, HEX HD, 5/16 - 18 X 1 151743 WASHER, LOCK, SPLIT, 5/16 151747 WASHER, FLAT, SAE, 5/16 151754 ASSY, WHEEL BRKT TSAW 151756 CASTING, TABLE MK-100 COMP...

  • Page 44: Exploded View

    MK-101 eXPlODeD View Cutting Head Assembly Part# 168167 INCLUDED WITH ITEM 8...
  • Page 45 WASHER, 1/4 SPLIT LOCK 152591 SCREW, HEX HD TAP, 1/4 - 20 X 1 152676 SCREW, 5/16 -18 X 3/8 SOCKET HEAD SET 157083 ASSY, SBU, CUTTING HEAD MK-101 158191 BELT, 6J260 158194 PULLEY, 6J19 X 5/8 BORE 158199 CASTING, 101 BELT GUARD-COMP...
  • Page 46 MK-101 eXPlODeD View Cutting Head Assembly Part# 158191...
  • Page 47 MK-101 PaRTS liST item Description Part # NUT, HEX, 5/16 - 18 101196 FLANGE, OUTER, 2 - 3/8 135830 NUT, HEX, 5/8 18 135848 BEARING, BALL, 17 X 40 X 12MM 137711 KEY, 3/16 SQ X 1 - 1/8 150344...
  • Page 48 MK-101 eXPlODeD View Blade Guard Assembly Part# 152582 Roller Wheel Assembly Part# 151756...
  • Page 49 MK-101 PaRTS liST Blade Guard assembly Part# 152582 item Description Part # SCREW, 5/16 - 18 X 1/2 SOCKET HD SET 152607 ELBOW, 1/8MNPT X 1/4 BARB, 90 DEG 154652 TUBE, WATER 155389 CASTING, 101 BLD GUARD-DC-COMP 162481 Roller wheel assembly Part# 151756...

  • Page 50: Accessories

    MK-101 aCCeSSORieS iTeM NUMBeR DeSCRiPTiON MK-200, 10 x 5/8 arbor 137166 Premium grade Diamond Blade for smooth, chip-free cutting on tile. MK-215, 10 x 5/8 arbor Supreme grade diamond blade for hard 128074 materials MK-315, 10 x 5/8 arbor 153252 Supreme super hi-rim diamond blade Dual 45°...
  • Page 51 NOTeS...

  • Page 52: Ordering Information

    MK-101 ORDeRiNG & ReTURN ORDeRiNG iNFORMaTiON You may order MK Diamond products through your local MK Diamond distributor or, you may order direct from MK Diamond. When ordering direct from MK Diamond, please have the following information ready before calling: •...
  • Page 53 © COPYRiGHT 2012, MK DiaMOND PRODUCTS, iNC. all RiGHTS ReSeRVeD. The MK Diamond logo is a registered trademark of MK Diamond Products, Inc. and may not be used, reproduced, or altered without written permission. All other trademarks are the property of their re- spective owners and used with permission.
  • Page 54 NOTeS...
  • Page 55 NOTeS...
  • Page 56 MK-101 Tile Saw OWNER'S MANUAL, PARTS LIST & OPERATING INSTRUCTIONS MK Diamond Products, Inc. 1315 Storm Parkway Torrance, CA 90501 Toll-Free: (800) 421-5830 Phone: (310) 539-5221 Fax: (310) 539-5158 www.mkdiamond.com...
