- Page 1 Model 6CiM Combination Freezer, Ice Machine and Refrigerator Installation Operation & Maintenance Instructions Part of AGA Foodservice Group...
-
Page 2: Remove Packaging
20 psi for proper operation. Make certain all water connections are watertight after installation. Form the tubing so that it will not vibrate against the cabinet body or kink when your refrigerator is set in position. Electrical and Grounding The icemaker is already connected to the refrigerator's wiring. -
Page 3: Ice Maker Operation
The refrigerator section temperature of the unit can be adjusted using the adjusting slide located in the left side and rear of the refrigeration section. Turn in the cold direction indicted to make the refrigeration section cold- er and the opposite to warm the refrigeration section. -
Page 4: Unit Care
Things to Remember • Allow 24 hours for your refrigerator and freezer to reach a new temperature setting. • The unit will start and stop often. This is normal operation of the unit. -
Page 5: Door Features
Door Features There are many different door features available for your new unit. Full panel overlay doors and full wrap painted and stainless doors are available. These doors are fully reversible. To Reverse the Door Swing of the Full Panel Overlay and Full Wrap Doors The door you relieved is for a right hand swing unit. -
Page 6: Before Calling For Service
Things to remember •Allow 24 hours for your refrigerator and freezer to reach a new temperature setting. •The unit will start and stop often. This is normal oper- ation of the unit. -
Page 7: Five-Year Limited Warranty
First Year of Limited Warranty The mechanical system of you refrigerator is warrant- ed against defects in workmanship or material for a period of one year from date of purchase under the... - Page 8 Trouble Shooting One PROBLEM POSSIBLE CAUSE Odor in the cabinet The unit needs to be cleaned. Unit operates but does not The unit has just been started and it has produce any ice. been less than 24 hours. Water supply is not turned on. Inadequate water pressure to unit The icemaker shut-off arm is in the uppermost position.
-
Page 9: Diagnostic Led
24 hours before readjusting if necessary. Adjust temperature control slide as necessary in the refrigerator section of the unit. The drip tray heater will remain energized with the control knob in the off position. Unplug the unit if storing or leaving the unit off for extended periods of time. - Page 10 Notes...
- Page 11 Notes...
- Page 12 Phone: (765) 962-2521 Fax: (765) 962-2493 Marvel Industries Part of AGA Foodservice Group 233 Industrial Parkway P.O. Box 997 Richmond, IN 47375-0997 41008536 Rev B...
