Installation and Operation Manual
CONTENTS
Important Information ...................................................................................................................................... 2
Step 1 - Getting Ready ..................................................................................................................................... 2
Step 2 - Choosing the Fan Site ......................................................................................................................... 3
Step 3 - Installing the Ceiling Plate ................................................................................................................... 6
Step 4 - Assembling the Fan ............................................................................................................................. 6
Step 5 - Wiring the Fan .................................................................................................................................... 8
Step 6 - Assembling the Fan Blades .................................................................................................................. 9
Step 7 - Operating Your Hunter Fan ............................................................................................................... 10
Step 8 - Installing Light Fixture ....................................................................................................................... 11
Step 9 - Installing Light Fixture ....................................................................................................................... 11
Step 10 - Wiring the Light Fixture ................................................................................................................... 12
Step 11 - Installing the Globes ........................................................................................................................ 12
Troubleshooting .............................................................................................................................................. 14
Your new Hunter ceiling fan is an addition to your home or office that will provide comfort and performance for
many years. This manual gives you complete instructions for installing and operating your fan.
We are proud of our work. We appreciate the opportunity to supply you with the best ceiling fan available any-
where in the world.
Before installing your fan, record the following information for your records and warranty assistance. Please refer
to the carton and the Hunter nameplate (located on top outside fan motor housing) for the proper information.
41473-01 12/6/2001
Model Name __________________
Catalog No. ___________________
Serial No. _____________________
Date Purchased ________________
Where Purchased ______________
_____________________________
®
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Hunter Installer's Choice
Summary of Contents for Hunter Installer's Choice
-
Page 1: Table Of Contents
Step 11 - Installing the Globes ........................12 Troubleshooting .............................. 14 Your new Hunter ceiling fan is an addition to your home or office that will provide comfort and performance for many years. This manual gives you complete instructions for installing and operating your fan. -
Page 2: Important Information
handy for identifying parts during installation; the dia IMPORTANT STEP 1 - GETTING READY INFORMATION GATHERING THE TOOLS CAUTIONS You will need the following tools for installing the fan: • Read entire booklet carefully before begin- • Electric drill with 9/64" bit ning installation and save these instructions. -
Page 3: Step 2 - Choosing The Fan Site
gram indicates the step in which each part is used. STEP 2 - CHOOSING THE FAN SITE FAN SUPPORT SYSTEM Fan must attach directly to building structure Within the room where you want to install the fan, Fan support system must hold full weight of fan and choose a fan site where light kit •... - Page 4 PREPARING A NEW FAN SITE To prepare the fan site follow four steps: 2. Orient the outlet box so that both the inner and outer holes in the box align with the joist or support brace. Step 1: Cutting the Ceiling Hole 3.
- Page 5 INSTALLER’S CHOICE ® This patented 3-position mounting system provides you maximum installation flexibility and ease. You can install your Hunter fan in one of three ways. The steps in this manual include specific instructions for the fan mounting method of your choice.
-
Page 6: Step 3 - Installing The Ceiling Plate
STEP 3 - INSTALLING THE Ceiling Joist CEILING PLATE 2 x 4 Brace 1. Drill two pilot holes into the wood support structure through the outermost holes on the outlet box. The pilot holes should be 9/64" in diameter. 2. Thread the lead wires from the outlet box through Ceiling the hole in the middle of the ceiling plate. - Page 7 FLUSH MOUNTING For Low Ceilings 4. Position the slots in the assembly washer over the 1. Position the three rubber spacers over the threaded holes in the adapter as shown in Figure 4c. threaded holes in the motor adapter as shown in Figure 4b NOTE: Upon completing step 3, the slots in the as- sembly washer, the rubber spacers and the threaded...
-
Page 8: Step 5 - Wiring The Fan
STEP 5 - WIRING THE FAN 3. You can use either one or two wall switches to con- trol the fan and/or lights separately. Use connection 1. Disconnect the power by turning off the circuit break- 1 below to ers to the outlet box and associated wall switch loca- •... - Page 9 STEP 6 - HANGING THE Sub-steps 1 and 2 apply to Flush, Standard, and Angle mounting. Sub-step 3 applies to Standard and Angle mounting only. 1. Swing the fan up so as to align the canopy screw holes with the mounting holes on the ceiling plate. Refer to Figure 6a.
-
Page 10: Step 6 - Assembling The Fan Blades
STEP 7 - ASSEMBLING FAN BLADES Builder's fans use several styles of fan blade irons (brack- Grommet ets that hold the blade to the fan). 1. Your fan may include blade grommets (see Parts List). If your fan has grommets, insert them by hand into Blade the holes as shown in Figure 7a. -
Page 11: Step 7 - Operating Your Hunter Fan
Switch STEP 9 - INSTALLING LIGHT FIXTURE Your Hunter fan may include an integrated light fixture. If you are not installing a light fixture, turn directly to OPERATING YOUR HUNTER FAN for additional instructions. Information for wiring and installing all included Hunter light fixtures are included in the following section “Attach- ing Light Fitter to Switch Housing,”... -
Page 12: Step 10 - Wiring The Light Fixture
STEP 10 - WIRING THE LIGHT FIXTURE WARNING INSTALLING INCLUDED SINGLE-GLOBE LIGHT FIXTURE • To avoid possible electrical shock, before install- 1. Remove the plug cap from the lower switch housing. ing light fixtures, disconnect power by turning off Note: Do not discard the plug cap. You will need this the circuit breakers both to the outlet box and to its associated wall switch location. -
Page 13: Step 11 - Installing The Globes
Black/White White Wire Wire from from Switch Switch Housing Housing Wire Nut Black Wire White Wire from Light from Light Fixture Fixture Light Fixture Figure 10b - Wiring Light Fixture to Fan STEP 11 - INSTALLING THE GLOBES Instructions follow for installing globes for all included light fixtures. INSTALLING INTEGRAL MULTI-LIGHT FIXTURE BULBS INSTALLING SINGLE-GLOBE FIXTURE BULB AND AND GLOBES... -
Page 14: Troubleshooting
If you have tried these troubleshooting solutions and still have trouble, call 901/248-2222 or visit our Web site at http://www.hunterfan.com. Hunter Fan Company 2500 Frisco Avenue Memphis, TN 38114...
