  • Page 2: Copyright Notice

    (including damages for loss of proits, loss of business, loss of data, interruption of business and the like), even if ASRock Rack has been advised of the possibility of such damages arising from any defect or error in the documentation or product.
  • Page 3 Contact Information If you need to contact ASRock Rack or want to know more about ASRock Rack, you’re welcome to visit ASRock Rack’s website at www.ASRockRack.com; or you may contact your dealer for further information. ASRock Rack Incorporation 6F., No.37, Sec. 2, Jhongyang S. Rd., Beitou District,...

  • Page 4: Table Of Contents

    Contents Chapter 1 Introduction 1.1 Package Contents 1.2 Speciications 1.3 Unique Features 1.4 Motherboard Layout 1.5 I/O Panel 1.6 Block Diagram Chapter 2 Installation 2.1 Screw Holes 2.2 Pre-installation Precautions 2.3 Half Width Server Motherboard Installation 2.4 Installing the CPU 2.5 Installing the CPU Fan and Heatsink 2.6 Installation of Memory Modules (DIMM) 2.7 Expansion Slots (Mezzanine Card Slot and PCI Express Slot)
  • Page 5 3.1.1 UEFI Menu Bar 3.1.2 Navigation Keys 3.2 Main Screen 3.3 Advanced Screen 3.3.1 CPU Coniguration 3.3.2 Chipset Coniguration 3.3.3 Storage Coniguration 3.3.4 Super IO Coniguration 3.3.5 ACPI Coniguration 3.3.6 USB Coniguration 3.3.7 WHEA Coniguration 3.3.8 Intel Server Platform Services 3.3.9 Serial Port Console Redirection 3.3.10 Voltage Control 3.3.11 Instant Flash...
  • Page 6 4.2.3 Utilities Menu 4.2.4 Contact Information Chapter 5 Troubleshooting 5.1 Troubleshooting Procedures 5.2 Technical Support Procedures 5.3 Returning Merchandise for Service Chapter 6: Net Framework Installation Guide 6.1 Installing .Net Framework 3.5.1 (For Server 2008 R2)

  • Page 7: Chapter 1 Introduction

    In case any modiications of this manual occur, the updated version will be available on ASRock Rack website without further notice. You may ind the latest memory and CPU support lists on ASRock Rack website as well. ASRock Rack’s Website: www.ASRockRack.com If you require technical support related to this motherboard, please visit our website for speciic information about the model you are using.

  • Page 8: Speciications

    1.2 Speciications E3C224D4HM-8R / E3C224D4HM MB Physical Status Form Factor Half Dimension 13'' x 5.96'' (33.0 cm x 15.1 cm) Processor System Intel® Xeon® E3-1200 v3 Series and next generation 22nm CoreTM i3 processors Socket Single socket (LGA1150) Power Phase...
  • Page 9 BIOS Features - Plug and Play (PnP) - ACPI 1.1 Compliance Wake Up Events - SMBIOS 2.3.1 Support - DRAM Voltage Multi-adjustment - ASRock Rack Instant Flash Hardware Monitor Temperature - CPU Temperature Sensing - System Temperature Sensing - CPU/Rear/Front Fan Tachometer...
  • Page 10 Voltage - CPU/Rear/Front Fan Multi-Speed Control - Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM, 1.05V_PCH, +BAT, 3VSB, 5VSB Support OS ® ® Microsot Windows - Server 2008 R2 (64 bit) - Server 2012 (64 bit) - Server 2012 R2 (64 bit) ®...

  • Page 11: Unique Features

    . With this utility, you can press the <F6> key during the POST or the <F2> key to enter into the BIOS setup menu to access ASRock Rack Instant Flash. Just launch this tool and save the new BIOS ile to your USB lash drive, loppy disk or hard drive, then you can update your BIOS only in a few clicks without preparing an additional loppy diskette or other complicated lash utility.

  • Page 12: Motherboard Layout

    PSU_A LT _ SEL 3 PSU_DA TA_SEL 2 PSU_CLK_SEL 1 SPEAKER1 USB_1_ 2 HDLED RESE T IPMB_1 NMI_BTN1 BMC_SMB_1 CLRMOS 2 CPU_FAN1 P ANEL1 E3C224D4HM-8R BMC_SMB_2 64M b B IOS BMC_SMB_3 COM1 SATA_SGPIO1 Intel IPMI_LAN1 TR 1 Dr . Debug FRNT_FAN 1...
  • Page 13 E3C224D4HM / E3C224D4HM-8R Description Non Maskable Interrupt Button (NMI_BTN1) Buzzer (BUZZER1) Speaker Header (SPEAKER1) BMC SMB Header (BMC_SMB_1) BMC SMB Header (BMC_SMB_2) BMC SMB Header (BMC_SMB_3) Intelligent Platform Management Bus header (IPMB_1) System Panel Header (PANEL1) Clear CMOS Pad (CLRMOS2) USB 3.0 Header (USB3_2_3)
  • Page 14 Description Mezzanine Card Slot (MEZZ_MB1)* NCSI Share NIC Header (NCSI_TX_EN1) NCSI Share NIC Header (NCSI_CRS_DV1) NCSI Share NIC Header (NCSI_CLK1) hermal Sensor Header (TR1) Serial Port Connector (COM1) *he PCIE1 slot is shared with the MEZZ_MB1 and LSI_SAS_0_3 / LSI_SAS_4_7. For more details, please refer to 2.7 Expansion Slots (p.25).
  • Page 15 4 5 6 33.0cm (13 in) USB3_2_3 REAR_F AN1 PSU_SMB 1 USB3 PCIE 1 ATXPWR1 BUZZER1 PLED PWRBT N PSU_DA TA_SEL 2 AT X 12V1 PSU_A LT _ SEL 3 PSU_CLK_SEL 1 SPEAKER1 USB_1_ 2 HDLED RESE T IPMB_1 NMI_BTN1 BMC_SMB_1 CLRMOS 2 CPU_FAN1...
  • Page 16 Description Non Maskable Interrupt Button (NMI_BTN1) Buzzer (BUZZER1) Speaker Header (SPEAKER1) BMC SMB Header (BMC_SMB_1) BMC SMB Header (BMC_SMB_2) BMC SMB Header (BMC_SMB_3) Intelligent Platform Management Bus header (IPMB_1) System Panel Header (PANEL1) Clear CMOS Pad (CLRMOS2) USB 3.0 Header (USB3_2_3) USB 2.0 Header (USB_1_2) Vertical Type A USB 2.0 (USB_3) PSU Jumpers (PSU_ALT_SEL3)
  • Page 17 E3C224D4HM / E3C224D4HM-8R Description NCSI Share NIC Header (NCSI_CRS_DV1) NCSI Share NIC Header (NCSI_CLK1) hermal Sensor Header (TR1) Serial Port Connector (COM1) *he PCIE1 slot is shared with the MEZZ_MB1. For more details, please refer to 2.7 Expansion Slots (p.25).

  • Page 18: I/O Panel

    1.5 I/O Panel No. Description No. Description VGA Port (VGA1) LAN RJ-45 Port (LAN1, NCSI)* LAN RJ-45 Port (IPMI_LAN1)** LAN RJ-45 Port (LAN2)* UID Switch and LED (UID1) USB 3.0 Ports (USB3_1) LAN Port LED Indications *here are two LED next to the LAN port. Please refer to the table below for the LAN port LED indications.
  • Page 19 E3C224D4HM / E3C224D4HM-8R **here are two LEDs on each LAN port. Please refer to the table below for the LAN port LED indications. SPEED LED ACT/LINK LED LAN Port LAN Port (LAN1, LAN2) LED Indications Activity / Link LED Speed LED...

  • Page 20: Block Diagram

    1.6 Block Diagram E3C224D4HM-8R he PCIE1 slot shares lanes with the MEZZ_MB1 and LSI_SAS_0_3 / LSI_SAS_4_7 slots. PCIE1 Slot MEZZ_MB1 LSI_SAS_0_3/_4_7 Disabled Disabled *For more details, please refer to 2.7 Expansion Slots (p.25).
  • Page 21 E3C224D4HM / E3C224D4HM-8R E3C224D4HM he PCIE1 slot shares lanes with the MEZZ_MB1 slot. PCIE1 Slot MEZZ_MB1 *For more details, please refer to 2.7 Expansion Slots (p.25).

  • Page 22: Chapter 2 Installation

    Chapter 2 Installation This is a half-width form factor (13’’ x 5.96’’, 33.0 cm x 15.1 cm) motherboard. Before you install the motherboard, study the coniguration of your chassis to ensure that the motherboard its into it. Make sure to unplug the power cord before installing or removing the motherboard. Failure to do so may cause physical injuries to you and damages to motherboard components.

  • Page 23: Half Width Server Motherboard Installation

    E3C224D4HM / E3C224D4HM-8R 2.3 Half Width Server Motherboard Installation ASRock Rack’s Innovation on Half Width Server Motherboard turns standard EATX compliant chassis into a 2 node clusters immediately. You can install both E3C224D4HM- 8R / E3C224D4HM into EATX supported server chassis with the bundled Motherboard Back Plate.
  • Page 24 3. Place one of the two motherboards into the chassis. 4. Place the other motherboard into the chassis.
  • Page 25 E3C224D4HM / E3C224D4HM-8R 5. Tighten the screws that secures the backplate to the chassis.

  • Page 26: Installing The Cpu

    2.4 Installing the CPU 1. Before you insert the 1150-Pin CPU into the socket, please check if the PnP cap is on the socket, if the CPU surface is unclean, or if there are any bent pins in the socket. Do not force to insert the CPU into the socket if above situation is found.
  • Page 27 E3C224D4HM / E3C224D4HM-8R Please save and replace the cover if the processor is removed. he cover must be placed if you wish to return the motherboard for ater service.

  • Page 28: Installing The Cpu Fan And Heatsink

    2.5 Installing the CPU Fan and Heatsink...

  • Page 29: Installation Of Memory Modules (Dimm)

    E3C224D4HM / E3C224D4HM-8R 2.6 Installation of Memory Modules (DIMM) his motherboard provides four 240-pin DDR3 (Double Data Rate 3) DIMM slots, and supports Dual Channel Memory Technology. he DIMM only its in one correct orientation. It will cause permanent damage to the motherboard and the DIMM if you force the DIMM into the slot at incorrect orientation.

  • Page 31: Expansion Slots (Mezzanine Card Slot And Pci Express Slot)

    Step 5. Fasten the card to the chassis with screws. Step 6. Replace the system cover. PCIE Coniguration for E3C224D4HM-8R The PCIE1 slot shares lanes with the MEZZ_MB1 and LSI_SAS_0_3 / LSI_SAS_4_7 slots. PCIE1 Slot MEZZ_MB1...
  • Page 32 work at x16 bandwidth, when there is no mezzanine card on the mezzanine card slot. When the PCIE1 slot is populated, the LSI SAS connectors are disabled. B. If you install a PCI Express x16 graphics card on the PCIE1 slot and a mezzanine card on the mezzanine card slot, both slots will work at x8 bandwidth.

  • Page 33: Jumper Setup

    E3C224D4HM / E3C224D4HM-8R 2.8 Jumper Setup he illustration shows how jumpers are setup. When the jumper cap is placed on the pins, the jumper is “Short”. If no jumper cap is placed on the pins, the jumper is “Open”. he illustration shows a 3-pin jumper whose pin1 and pin2 are “Short”...

  • Page 34: Onboard Headers And Connectors

    2.9 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage to the motherboard. PLED+ System Panel Header Connec t t he power sw itch, PLED- PWRBTN#...
  • Page 35 E3C224D4HM / E3C224D4HM-8R Auxiliary Panel Header his header supports multiple (18-pin AUX PANEL_1) functions on the front panel, including the front panel SMB, internet status indicator and chassis intrusion pin. A. Front panel SMBus connecting pin (6-1 pin FPSMB) his header allows you to connect SMBus (System Management Bus) equipment. It can be used for communication between peripheral equipment in the system, which has slower transmission rates, and power management equipment.
  • Page 36 Type A USB 2.0 Connector (USB_3) IntA_PA_D+ USB 3.0 Header Besides one default USB 3.0 IntA_PA_D- (19-pin USB3_2_3) port on the I/O panel, there IntA_PA_SSTX+ IntA_PA_SSTX- is one USB 3.0 header on this IntA_PA_SSRX+ IntA_PA_SSRX- motherboard. This USB 3.0 Vbus header can support two USB 3.0 ports.
  • Page 37 E3C224D4HM / E3C224D4HM-8R FAN_SPEED_CONTROL Rear Fan Connector Please connect fan cable to the FAN_SPEED FAN_VOLTAGE (4-pin REAR_FAN1) fan connector and match the black wire to the ground pin. ATX Power Connector his motherboard provides a (24-pin ATXPWR1) 24-pin ATX power connector.
  • Page 38 IPMB_SDA Intelligent Platform This 4-pin connector is used IPMB_SCL Management Bus header to provide a cabled base-board (4-pin IPMB_1) or front panel connection for value added features and 3rd- No Connect party add-in cards, such as Emergency Management cards, t h a t p r o v i d e m a n a g e m e n t features using the IPMB.

  • Page 39: Dr. Debug

    E3C224D4HM / E3C224D4HM-8R 2.10 Dr. Debug Dr. Debug is used to provide code information, which makes troubleshooting even easier. Please see the diagrams below for reading the Dr. Debug codes. Code Description Please check if the CPU is installed correctly and then clear CMOS.

  • Page 40: Driver Installation Guide

    2.11 Driver Installation Guide To install the drivers to your system, please insert the support CD to your optical drive irst. hen, the drivers compatible to your system can be auto-detected and listed on the support CD driver page. Please follow the order from top to bottom to install those required drivers.

  • Page 41: Dual Lan And Teaming Operation Guide

    E3C224D4HM / E3C224D4HM-8R 2.12 Dual LAN and Teaming Operation Guide Dual LAN with Teaming enabled on this motherboard allows two single connections to act as one single connection for twice the transmission bandwidth, making data transmission more efective and improving the quality of transmission of distant images. Fault tolerance on the dual LAN network prevents network downtime by transferring the workload from a failed port to a working port.

  • Page 42: Chapter 3 Uefi Setup Utility

    Chapter 3 UEFI Setup Utility 3.1 Introduction his section explains how to use the UEFI SETUP UTILITY to conigure your system. he UEFI chip on the motherboard stores the UEFI SETUP UTILITY. You may run the UEFI SETUP UTILITY when you start up the computer. Please press <F2> or <Del> during the Power-On-Self-Test (POST) to enter the UEFI SETUP UTILITY;...

  • Page 43: Navigation Keys

    E3C224D4HM / E3C224D4HM-8R 3.1.2 Navigation Keys Please check the following table for the function description of each navigation key. Navigation Key(s) Function Description Moves cursor let or right to select Screens Moves cursor up or down to select items + / - To change option for the selected items <Tab>...

  • Page 44: Main Screen

    3.2 Main Screen Once you enter the UEFI SETUP UTILITY, the Main screen will appear and display the system overview. he Main screen provides system overview information and allows you to set the system time and date.

  • Page 45: Advanced Screen

    E3C224D4HM / E3C224D4HM-8R 3.3 Advanced Screen In this section, you may set the conigurations for the following items: CPU Coniguration Chipset Coniguration, Storage Coniguration, Super IO Coniguration, ACPI Conigura- tion, USB Coniguration, WHEA Coniguration, Intel Server Platform Services, Serial Port Console Redirection, Voltage Control and Instant Flash.

  • Page 46: Cpu Coniguration

    3.3.1 CPU Coniguration Spread Spectrum Use this to enable and disable Spread Spectrum. Intel Hyper Threading Technology Intel Hyper hreading Technology allows multiple threads to run on each core, so that the overall performance on threaded sotware is improved. Active Processor Cores Select the number of cores to enable in each processor package.

  • Page 47: Adjacent Cache Line Prefetch

    E3C224D4HM / E3C224D4HM-8R Adjacent Cache Line Prefetch Automatically prefetch the subsequent cache line while retrieving the currently requested cache line. Enable for better performance. CPU AES Use this to enable or disable CPU Advanced Encryption Standard instructions. Intel SpeedStep Technology Intel SpeedStep technology is Intel’s new power saving technology.

  • Page 48: Chipset Coniguration

    3.3.2 Chipset Coniguration Primary Graphics Adapter If both AGPcard and PCI graphics card are installed on the motherboard, you may use this option to select [PCI Express] or [Onboard] (AGP) as the primary graphics adapter. Onboard VGA Use this to enable or disable the Onboard VGA function. he default value is [Auto]. DRAM Frequency If [Auto] is selected, the motherboard will detect the memory module(s) inserted and assigns appropriate frequency automatically.

  • Page 49: Onboard Lan

    E3C224D4HM / E3C224D4HM-8R Onboard LAN2 his allows you to enable or disable the Onboard LAN 2 feature. Restore on AC/Power Loss his allows you to set the power state ater an unexpected AC/power loss. If [Power Of] is selected, the AC/power remains of when the power recovers. If [Power On] is selected, the AC/power resumes and the system starts to boot up when the power recovers.

  • Page 50: Storage Coniguration

    3.3.3 Storage Coniguration SATA Controller(s) Use this item to enable or disable the SATA Controller feature. SATA Mode Selection his item is for SATA_0_3 port. Use this to select SATA mode. Coniguration options: [IDE], [AHCI] and [RAID]. he default value is [AHCI]. AHCI (Advanced Host Controller Interface) supports NCQ and other new features that will improve SATA disk performance but IDE mode does not have these advantages.
  • Page 51 E3C224D4HM / E3C224D4HM-8R LSI Controller Use this item to enable or disable LSI controller. he default value is [Auto]. Bootable LSI Controller Use this to enable or disable Onboard LSI Option ROM. If Option ROM is disabled, you cannot use the SAS/SATA devices connected to the LSI controller as Boot Device.

  • Page 52: Super Io Coniguration

    3.3.4 Super IO Coniguration Serial Port 1 Coniguration Use this item to conigure the onboard serial port 1. Select and enter the "Serial Port 1 Coniguration" and you will see the followings: Serial Port Use this item to enable or disable the onboard serial port. Change Settings Use this item to select an optimal setting for Super IO device.

  • Page 53: Acpi Coniguration

    E3C224D4HM / E3C224D4HM-8R 3.3.5 ACPI Coniguration ACPI HPET Table Use this item to enable or disable ACPI HPET Table. he default value is [Enabled]. Please ® set this option to [Enabled] if you plan to use this motherboard to submit Windows certiication.

  • Page 54: Usb Coniguration

    3.3.6 USB Coniguration USB Controller Use this item to enable or disable the use of USB controller. he default value is [Enabled]. Intel USB 3.0 Mode Use t his item to enable or disable t he use of Intel USB 3.0 mode. There are four coniguration options: [Smart Auto], [Auto], [Disabled] and [Enabled].

  • Page 55: Whea Coniguration

    E3C224D4HM / E3C224D4HM-8R Legacy USB 3.0 Support Use this option to enable or disable legacy support for USB 3.0 devices. he default value is [Enabled]. 3.3.7 WHEA Coniguration WHEA Support Use this option to enable or disable Windows Hardware Error Architecture. he default...

  • Page 56: Intel Server Platform Services

    3.3.8 Intel Server Platform Services Intel Server Platform Services Coniguration his item displays the information of the Intel Server Platform Services, such as SPS version and ME FW(Firmware) state value.

  • Page 57: Serial Port Console Redirection

    E3C224D4HM / E3C224D4HM-8R 3.3.9 Serial Port Console Redirection Console Redirection Use this option to enable or disable Console Redirection. If this item is set to Enabled, you can select a COM Port to be used for Console Redirection. Console Redirection Settings Use this option to conigure Console Redirection Settings, and specify how your computer and the host computer to which you are connected exchange information.

  • Page 58: Flow Control

    Bits Per Second Use this item to select the serial port transmission speed. The speed used in the host computer and the client computer must be the same. Long or noisy lines may require lower transmission speed. he options include [9600], [19600], [57600] and [115200]. Flow Control Use this item to set the f low control to prevent data loss from buffer overf low.

  • Page 59: Voltage Control

    E3C224D4HM / E3C224D4HM-8R 3.3.10 Voltage Control DRAM Voltage Use this to select DRAM Voltage. he default value is [Auto]. PCH Voltage Use this to select PCH Voltage. he default value is [Auto]. PCH 1.5 Voltage I/O 1.5V Voltage. Use default settings for best performance.

  • Page 60: Instant Flash

    3.3.11 Instant Flash Instant Flash is a UEFI lash utility embedded in Flash ROM. his convenient UEFI update tool allows you to update system UEFI without entering operating systems ® irst like MS-DOS or Windows . Just save the new UEFI ile to your USB lash drive, loppy disk or hard drive and launch this tool, then you can update your UEFI only in a few clicks without preparing an additional loppy diskette or other compli- cated lash utility.

  • Page 61: H/W Monitor Screen (Hardware Health Event Monitoring)

    E3C224D4HM / E3C224D4HM-8R 3.4 H/W Monitor Screen (Hardware Health Event Monitoring) In this section, it allows you to monitor the status of the hardware on your system, includ- ing the parameters of the CPU temperature, motherboard temperature, CPU fan speed, chassis fan speed, and the critical voltage.

  • Page 62: Watch Dog Timer

    and [Automatic]. he default value is [Full On]. Smart Fan Duty Control Smart Fan Duty x (x means 1 to 11 stage) his allows you to set duty cycle for each stage. Smart Fan Temp Control Smart Fan Temp x (x means 1 to 11 stage) his allows you to set temperature for each stage.

  • Page 63: Boot Screen

    E3C224D4HM / E3C224D4HM-8R 3.5 Boot Screen In this section, it will display the available devices on your system for you to conigure the boot settings and the boot priority. Boot Option #1 Use this item to set the system boot order.
  • Page 64 AddOn ROM Display Use this option to adjust AddOn ROM Display. If you enable the option “Full Screen Logo” but you want to see the AddOn ROM information when the system boots, please select [Enabled]. Coniguration options: [Enabled] and [Disabled]. he default value is [Enabled]. CSM Parameters Use this option to conigure the parameters of OpROM execution, boot options ilter, etc.

  • Page 65: Security Screen

    E3C224D4HM / E3C224D4HM-8R 3.6 Security Screen In this section, you may set or change the supervisor/user password for the system. For the user password, you may also clear it. Supervisor Password Set or change the password for the administrator account. Only the administrator has authority to change the settings in the UEFI Setup Utility.

  • Page 66: Event Logs

    3.7 Event Logs Change Smbios Event Log Settings his allows you to conigure the Smbios Event Log Settings. When entering the item, you will see the followings: Smbios Event Log Use this item to enable or disable all features of the SMBIOS Event Logging during system boot.

  • Page 67: View Smbios Event Log

    E3C224D4HM / E3C224D4HM-8R View Smbios Event Log his allows you to view the Smbios Event Log records. All values changed here do not take efect until computer is restarted.

  • Page 68: Server Mgmt (Server Management)

    3.8 Server Mgmt (Server Management) System Event Log Enter to conigure System Event Logging features during boot. BMC Network Coniguration Enter to conigure BMC Network parameters. Coniguration Address Source Select to conigure BMC network parameters statically or dynamically(by BIOS or BMC). Coniguration options: [Unspeciied], [Static] and [Dynamic].
  • Page 69 E3C224D4HM / E3C224D4HM-8R When [Dynamic] or [Static] is selected, do NOT modify the BMC network settings on the IPMI web page. BMC Mac Backup Tool Use this to restore BMC Mac from the backup.

  • Page 70: Exit Screen

    3.9 Exit Screen Save Changes and Exit When you select this option, the following message “Save coniguration changes and exit setup?” will pop-out. Select [Yes] to save the changes and exit the UEFI SETUP UTILITY. Discard Changes and Exit When you select this option, the following message “Discard changes and exit setup?” will pop-out.

  • Page 71: Chapter 4 Software Support

    4.2.4 Contact Information If you need to contact ASRock Rack or want to know more about ASRock Rack, welcome to visit ASRock Rack’s website at http://www.ASRockRack.com; or you may contact your...

  • Page 72: Chapter 5 Troubleshooting

    Chapter 5 Troubleshooting 5.1 Troubleshooting Procedures Follow the procedures below to troubleshoot your system. Always unplug the power cord before adding, removing or changing any hardware com- ponents. Failure to do so may cause physical injuries to you and damages to motherboard components.
  • Page 73 1. Verify if the battery on the motherboard provides ~3VDC. Install a new battery if it does not. 2. Conirm whether your power supply provides adaquate and stable power. Other problem... 1. Try searching keywords related to your problem on ASRock Rack’s FAQ page: http://www.ASRockRack.com/support...

  • Page 74: Technical Support Procedures

    5.2 Technical Support Procedures If you have tried the troubleshooting procedures mentioned above and the problems are still unsolved, please contact ASRock Rack’s technical support with the following information: 1. Your contact information 2. Model name, BIOS version and problem type.

  • Page 75: Chapter 6: Net Framework Installation Guide

    E3C224D4HM / E3C224D4HM-8R Chapter 6: Net Framework Installation Guide ® To let Intel RSTe works properly, it is required to install Net Framework. Please follow the ® ® steps below to enable “.Net Framework” feature on Microsot Windows Server 2008 R2.
  • Page 76 3. Check the box next to .Net Framework 3.5.1 and then click Next. 4. Click Next to continue.
  • Page 77 5. Click Install to start installing .Net Framework 3.5.1. 6. Ater the installation completes, click Close.
