Front Audio Connector
AUX-IN Connector
CD-IN Connector
FAN2 Connector
AC'97 CODEC
PCI LAN Controller
S/PDIF Connector
CNR Connector
support Intel PRO/100 VE (TP)
32-bit PCI V2.2 Expansion Slot
IrDA Connector
WOM(Wake on Modem)Connector
2nd
USB2.0 Connector
3rd
USB2.0 Connector
WOL (Wake on LAN) Connector
JP14 CMOS Clear Jumper
FAN3 Connector
Flash ROM
Intrusion Detector
Front Panel Connector
ATA/33/66/100 IDE Connector x2
PS/2 Mouse
SPP/EPP/ECP Parallel Port
Connector
PS/2 Keyboard
COM 1 Port
VGA Connector
Connector
RJ45 LAN
MIDI/Game Port
Jack
USB2.0 Port
MIC-In
Line-In
Speaker Out
Resettable Fuse
JP28 Mouse/Keyboard Wake-up Select Jumper
COM2
4-pin ATX-12V Power Connector
Low ESR Capacitors
AGP 4x Expansion Slot
(Support 1.5V AGP Card Only)
478-pin CPU socket (Willamette/
Northwood) with Voltage and Frequency
®
Auto-detection that supports Intel
®
Pentium
4 1.4~2.4GHz+ CPU
Intel 845G Chipset
CPU FAN connector
184-pin DIMMx2 supports DDR266 /
DDR333 maximum up to 2 GB
(CPU FSB 400 does not support DDR333)
ATX Power Connector
FDD Connector
Advertisement
Table of Contents
Related Manuals for AOpen MX4GR
Summary of Contents for AOpen MX4GR
- Page 1 RJ45 LAN PS/2 Mouse SPP/EPP/ECP Parallel Port MIDI/Game Port Jack Connector PS/2 Keyboard COM 1 Port VGA Connector USB2.0 Port Connector MIC-In Line-In Front Audio Connector Speaker Out AUX-IN Connector CD-IN Connector FAN2 Connector AC’97 CODEC Resettable Fuse PCI LAN Controller JP28 Mouse/Keyboard Wake-up Select Jumper S/PDIF Connector COM2...
-
Page 2: S/Pdif (Sony/Philips Digital Interface) Connector
However, you must have a S/PDIF supported speaker with S/PDIF digital input to connect to the S/PDIF digital output to make the most out of this function. (Optional) Pin 1 Connecting to Audio RCA Cable cable Connecting to Optical Cable +5VSB PART NO: 49.89Y10.E01 DOC. NO: MX4GR-EG-E0306B S/PDIFOUT S/PDIFIN... -
Page 3: Installing Processor
3. Installing Processor 5. Setting CPU Voltage & Frequency This socket supports FC-PGA2 package CPU, which is the latest CPU package developed Setting CPU Core Voltage by Intel. Other forms of CPU package are impossible to be fitted in. This motherboard supports CPU VID function. The CPU core voltage will be automatically detected. -
Page 4: Support Six Usb2.0 Connectors
6. Support Six USB2.0 Connectors 8. Connecting IDE and Floppy Cables Connect 34-pin floppy cable and 40-pin, 80-wire IDE cable to floppy connector FDC and This motherboard provides six connectors to connect USB devices, such as mouse, keyboard, modem, printer, etc. There are two connectors on the PC99 back panel. You IDE connector. - Page 5 12. Connecting CD-IN /AUX-IN Connector 10. Front Audio Connector If the housing has been designed with an audio port on the front panel, you’ll be able to The AUX-IN connector is used to connect MPEG AUX-IN (Green) CD-IN (Black) connect onboard audio to front panel through this connector. By the way, please remove Audio cable from MPEG card to onboard sound.
- Page 6 You can use the autorun menu of Bonus CD disc. Choose the utility and driver and select and it’s STRONGLY RECOMMENDED to close all the applications before you start the model name. upgrading. Download the new version of BIOS package zip file from AOpen official web site. (ex: http://www.aopen.com) Unzip download...
-
Page 7: Part Number And Serial Number
IDE cable. The problem should be caused by the Check if the system can IDE cables or HDD itself. reboot successfully. Re-install Windows 95, Windows 98 or Windows NT. MX4GR is the model name of the motherboard; R1.00 is BIOS version... - Page 8 Dear Customer, Test Report: We recommend choosing board/card/device from the Thanks for choosing AOpen products. To provide the best and fastest service to compatibility test reports for assembling your PC. our customer is our first priority. However, we receive numerous emails and http://www.aopen.com/tech/report/default.htm...
