  • Page 1: Mx46L

    MX46L DOC. NO.: MX46L-OL-E0203A...

  • Page 2: Table Of Contents

    ’ ’ MX46L ................................1 What’s in this manual ..................................2 You Must Notice .................................... 8 Before You Start .................................... 9 Overview ..................................... 10 Feature Highlight ..................................11 Quick Installation Procedure ............................... 14 Motherboard Map ..................................15 Block Diagram ..................................... 16 Hardware Installation ..........................17 About “Optional”...
  • Page 3 AC Power Auto Recovery................................30 IDE and Floppy Connector ................................31 IrDA Connector.................................... 33 AGP (Accelerated Graphic Port) Expansion Slot ........................34 WOM (Zero Voltage Wake on Modem) Connector........................35 WOM by External BOX Modem..............................36 WOM by Internal Modem Card..............................37 WOL (Wake on LAN)...................................
  • Page 4 Resettable Fuse ..................................52 1500µF Low ESR Capacitor ................................ 53 Layout (Frequency Isolation Wall)............................... 54 Pure Aluminum Heatsink ................................55 Driver and Utility ............................56 Auto-run Menu from Bonus CD Disc ............................57 Installing LAN Driver..................................58 Installing Onboard Sound Driver ..............................59 ACPI Suspend to Hard Drive...............................
  • Page 5 ACPI (Advanced Configuration & Power Interface) ........................75 AGP (Accelerated Graphic Port) ..............................75 AMR (Audio/Modem Riser) ................................. 76 Bonus Pack CD ................................... 76 APM (Advanced Power Management) ............................76 ATA (AT Attachment) ................................... 76 ATA/66 ......................................76 ATA/100 ....................................... 77 ATA/133 .......................................
  • Page 6 EPROM (Erasable Programmable ROM)............................ 79 EV6 Bus ...................................... 80 FCC DoC (Declaration of Conformity)............................80 FC-PGA (Flip Chip-Pin Grid Array).............................. 80 Flash ROM ....................................80 FSB (Front Side Bus) Clock ................................ 81 C Bus ......................................81 IEEE 1394 ....................................81 Parity Bit ......................................
  • Page 7 SDRAM (Synchronous DRAM) ..............................84 Shadow E PROM ..................................84 SIMM (Single In Line Memory Module) ............................85 SMBus (System Management Bus) ............................85 SPD (Serial Presence Detect)..............................85 Ultra DMA....................................85 USB (Universal Serial Bus) ................................. 86 VCM (Virtual Channel Memory) ..............................86 ZIP file ......................................

  • Page 8: You Must Notice

    No part of this document may be used or reproduced in any form or by any means, or stored in a database or retrieval system without prior written permission from our Corporation. © Copyright 1996-2002, AOpen Inc. All Rights Reserved.

  • Page 9: Before You Start

    This Online Manual will introduce to the user how this product is installed. All useful information will be described in later chapters. Please keep this manual carefully for future upgrades or system configuration changes. This Online Manual is saved in format, we recommend using Adobe Acrobat Reader 4.0 for online viewing, it is included in Bonus CD disc...

  • Page 10: Overview

    Socket 478 motherboard (M/B) based on the Micro ATX form factor ® featuring the SIS 650 / SIS 961B chipset. As high performance chipset built in the M/B, the MX46L motherboard can support Intel Socket ® 478 Pentium 4 (Willamette / Northwood) and 400 MHz Front Side Bus (FSB) clock.

  • Page 11: Feature Highlight

    1056MB/s. MX46L motherboard includes one AGP expansion slot for a bus mastering AGP graphic card. For AD and SBA signaling, MX46L motherboard can support 4X mode. Of three PCI slots provided, all of them are master PCI slots with...

  • Page 12: Lan Port

    Memory With SIS 650 / 961B chipset, the MX46L can support Double-Data-Rate (DDR) SDRAM. The DDR SDRAM interface allows zero wait state bursting between the SDRAM and the data buffers at 66/100/133MHz. The four banks of DDR SDRAM can be composed of an arbitrary mixture of 1M/2M4M/8M/16M/32M/64Mx1GB DDR SDRAM and maximum up to 2 GB.
  • Page 13 Dr. LED (Upgrade Optional) Dr. LED has 8 LEDs on this MX46L M/B to easily show what kind of problems you may encounter. Power Management/Plug and Play Supports the power management function that confirms to the power-saving standards of the U.S. Environmental Protection Agency (EPA) Energy Star program.

  • Page 14: Quick Installation Procedure

    This page gives you a quick procedure on how to install your system. Follow each step accordingly. Installing CPU and Fan Installing System Memory (DIMM) Connecting Front Panel Cable Connecting IDE and Floppy Cable Connecting ATX Power Cable Connecting Back Panel Cable Power-on and Load BIOS Setup Default Setting CPU Frequency Reboot...

  • Page 15: Motherboard Map

    Motherboard Map Flash ROM CD-IN Connector Front Audio Connector PC99 Colored Back Panel AC’97 CODEC MODEM-CN Resettable Fuse CNR Connecto PCI LAN Controller (Only CNR Audio Supported) 4-pin 12V. ATX Power Connector Low ESR Capacitors IrDA Connector 32-bit PCI Expansion Slot x3 AGP 4x Expansion Slot WOM (Wake on Modem) (1.5V and 3.3V supported)

  • Page 16: Block Diagram

    DDR266 DDR SDRAM Up to 2GB 32-bit PCI Slot x3 DIMM Socket x2 Socket 478 400MHz System Intel Pentium 4 CPU(Willamette /Northwood) PCI Bus SIS 650 Primary 66100/133 Channel IDE Drive x4 Secondary AGP 4X Slot Channel RealTek ALC201A SIS 961B AC97 CODEC Realtek...

  • Page 17: Hardware Installation

    This chapter describes jumpers, connectors and hardware devices of this motherboard. Note: Electrostatic discharge (ESD) can damage your processor, disk drives, expansion boards, and other components. Always observe the following precautions before you install a system component. Do not remove a component from its protective packaging until you are ready to install it. Wear a wrist ground strap and attach it to a metal part of the system unit before handling a component.

  • Page 18: About "Optional" And "Upgrade Optional

    When you read this online manual and start to assemble your computer system, you may find some of functions are called “Optional”, and some are called “Upgrade Optional”. Though all AOpen motherboards include many amazing and powerful features, in some situations, these powerful features are not used to every user.

  • Page 19: Jp14 Clear Cmos Data

    You can clear CMOS to restore system default setting. To clear the CMOS, follow the procedure below. Turn off the system and unplug the AC power. Remove ATX power cable from connector PWR2. Locate JP14 and short pins 2-3 for a few seconds. Return JP14 to its normal setting by shorting pin 1 &...

  • Page 20: Cpu Installation

    ® This motherboard supports Intel Pentium 4 Socket 478 series CPU (Willamette / Northwood). Be careful of CPU orientation when you plug it into CPU socket. 2. Locate Pin 1 in the socket and look for a black dot or cut edge on the CPU 1.
  • Page 21 3. Press down the CPU socket lever and finish CPU installation. CPU cut edge Note: If you do not match the CPU socket Pin 1 and CPU cut edge well, it may damage the CPU. Note: This socket supports Micro-FC-PGA2 package CPU, which is the latest CPU package developed by Intel.
  • Page 22 This motherboard comes with a retention module attached on the CPU socket when shipped, we strongly recommend you to install special designed CPU Fan as shown below on the retention module for better heat dissipation. Please install the CPU Fan correctly as the following pictures shown.

  • Page 23: Cpu Jumper-Less Design

    CPU VID signal and SMbus clock generator provide CPU voltage auto-detection and allows the user to set the CPU frequency through the BIOS setup, therefore no jumpers or switches are used. The disadvantages of the Pentium based jumper-less designs are eliminated. There will be no worry of wrong CPU voltage detection.
  • Page 24 This motherboard supports CPU VID function. The CPU core voltage will be automatically detected. BIOS Setup > Frequency/Voltage Control > CPU Clock Setting This motherboard is CPU jumper-less design, you can set CPU frequency through the BIOS setup, and no jumpers or switches are needed. The default setting is "table select mode".
  • Page 25 CPU Core System Ratio Frequency Clock Warning: SIS 650 / 961B chipset supports maximum 400MHz (100MHz*4) system bus Pentium 4 1.4G 1400MHz 100MHz 400MHz and 66MHz AGP clock; higher clock setting may cause serious system damage. Pentium 4 1.5G 1500MHz 100MHz 400MHz Pentium 4 1.6G...

  • Page 26: Cpu And System Fan Connector (With H/W Monitoring)

    Plug in the CPU fan cable to the 3-pin CPU FAN connector. If you have chassis fan, you can also plug it on System FAN (FAN2) or AUX FAN (FAN3) connector. FAN3 Connector (Without Hardware Monitor) +12V SENSOR CPU Fan Connector Note: Some CPU fans do not have sensor pin, so that cannot support FAN2 Connector...

  • Page 27: Dimm Sockets

    This motherboard has two 184-pin DIMM sockets that allow you to install DDR 266 memory up to 2 GB. DIMM1 DIMM2...
  • Page 28 Please follow the procedure as shown below to finish memory installation. Make sure the DIMM module’s pin face down and match the socket’s size as depicted below. 40 pins 52 pins Insert the module straight down to the DIMM slot with both hands and press down firmly until the DIMM module is securely in place. Note: The tabs of the DIMM slot will close-up to hold the DIMM in place when the DIMM touches the...

  • Page 29: Front Panel Connector

    Attach the power LED, Keylock, speaker, power and reset switch connectors to the corresponding pins. If you enable “Suspend Mode” item in BIOS Setup, the ACPI & Power LED will keep flashing while the system is in suspend mode. Locate the power switch cable from your ATX housing. It is 2-pin female connector from the housing front panel.

  • Page 30: Atx Power Connector

    This motherboard comes with a 20-pin ATX power connector and an extra 4-pin connector as shown below. Make sure you plug in the right direction. We strongly recommend you to insert the 4-pin connector before connecting the 20-pin connector. Ground Ground Pin1 PS-ON...

  • Page 31: Ide And Floppy Connector

    Connect 34-pin floppy cable and 40-pin IDE cable to floppy connector FDC and IDE connector. The blue connector is IDE1 for clear identification. Be careful of the pin1 orientation. Wrong orientation may cause system damage. Primary Primary Master Slave (2nd) (1st) IDE 1 (Primary) IDE 2 (Secondary)
  • Page 32 IDE1 is also known as the primary channel and IDE2, IDE3 and IDE4 are other channels. Each channel supports two IDE devices that make a total of eight devices. In order to work together, the two devices on each channel must be set differently to Master and Slave mode. Either one can be the hard disk or the CDROM.

  • Page 33: Irda Connector

    The IrDA connector can be configured to support wireless infrared module, with this module and application software such as Laplink or Windows 95 Direct Cable Connection, the user can transfer files to or from laptops, notebooks, PDA devices and printers. This connector supports HPSIR (115.2Kbps, 2 meters) and ASK-IR (56Kbps).

  • Page 34: Agp (Accelerated Graphic Port) Expansion Slot

    The MX46L provides an 4x slot. The AGP 4x is a bus interface targeted for high-performance 3D graphic. AGP supports only memory read/write operation and single-master single-slave one-to-one only. AGP uses both rising and falling edge of the 66MHz clock, for 2X AGP,...

  • Page 35: Wom (Zero Voltage Wake On Modem) Connector

    Pin 1 WOM Connector +5VSB...

  • Page 36: Wom By External Box Modem

    Serial Port (Modem Side) Pin 1 Serial Port (Motherboard Side)

  • Page 38: Wol (Wake On Lan)

    To use Wake On LAN function, you must have a network card with chipset that supports this feature, and connect a cable from LAN card to motherboard WOL connector. The system identification information (probably IP address) is stored on network card and because there is a lot of traffic on the Ethernet, you need to install network management software, such as ADM, for the checking of how to wake up the system.
  • Page 39 WOL Connector (Ethernet Card Side) WOL Connector (Motherboard Side)

  • Page 40: Support 10/100 Mbps Lan Onboard

    On the strength of Realtek RTL8100 LAN controller on board, which is a highly-integrated Platform LAN Connect device, it provides 10/100M bps Ethernet for office and home use, the Ethernet RJ45 connector is located on top of USB connectors. The green LED indicates the link mode, it lights when linking to network and blinking when transferring data.

  • Page 41: Cnr (Communication And Network Riser) Expansion Slot

    is a riser card specification to replace the AMR (Audio/Modem Riser) that supports V.90 analog modem, multi-channel audio, and phone-line based networking. Owing to CPU computing power getting stronger, the digital processing job can be implemented in main chipset and share CPU power. The analogy conversion (CODEC) circuit requires a different and separate circuit design, which is put on CNR card.

  • Page 42: Pc99 Color Coded Back Panel

    The onboard I/O devices are PS/2 Keyboard, PS/2 Mouse, RJ-45 LAN Connector, COM1 and VGA, Printer, USB, AC97 sound and game ports. The view angle of drawing shown here is from the back panel of the housing. SPP/EPP/ECP PS/2 Mouse RJ-45 LAN Parallel Port MIDI/Game Port...

  • Page 43: Support 3 Usb V1.1 Ports

    This motherboard provides six connectors to connect USB devices, such as mouse, keyboard, modem, printer, etc. There are two connectors on the PC99 back panel. You can use proper cable to connect other USB connectors to the back panel or front panel of chassis. Pin 1 Pin 1 USB_FP_OC0...

  • Page 44: Cd Audio Connector

    This connector is used to connect CD Audio cable from CDROM or DVD drive to onboard sound. CD-IN...

  • Page 45: Modem Audio Connector

    This connector is used to connect Mono In/MIC Out cable from internal modem card to onboard sound circuit. The pin 1-2 is Mono In, and the pin 3-4 is MIC Out. Please note that there is no standard for this kind of connector yet, only some internal modem cards implement this connector.

  • Page 46: Front Audio Connector

    If the housing has been designed with an audio port on the front panel, you’ll be able to connect onboard audio to front panel through this connector. By the way, please remove 5-6 and 9-10 jumper caps from the Front Audio Connector before connecting the cable. Please do not remove these 5-6 and 9-10 yellow jumper caps if there’s no audio port on the front panel.

  • Page 47: Dr. Led Connector (Upgrade Optional)

    In conjunction with Dr. LED (Upgrade Optional), which can easily shows what kind of problems may occur on your system during assembly. It can clearly indicate whether there is a component issue or an installed issue by the 8 LEDs on the front panel of Dr. LED. This can helps you to have a self-diagnostic to your system status quickly.
  • Page 48 Dr. LED is a CD disc storage box with 8 LEDs on its front panel, the size of Dr. LED is exactly the same as 5.25 in floppy drive, so that it can be mount into normal 5.25 in drive bay of any housing. Floppy Boot O.K.

  • Page 49: Battery-Less And Long Life Design

    This Motherboard implements Flash ROM and a special circuit that allows you to save your current CPU and CMOS Setup configurations without the need of a battery. The RTC (real time clock) can also keep running as long as the power cord is plugged. If you lose your CMOS data by accident, you can just reload the CMOS configurations from Flash ROM and the system will recover as usual.

  • Page 50: Over-Current Protection

    The Over Current Protection was very popular implemented on ATX 3.3V/5V/12V switching power supply. However, the new generation CPU uses different voltage that has regulator to transfer 12V to CPU voltage (for example, 2.0V). This motherboard is with switching regulator onboard supports CPU over-current protection; in conjunction with 3.3V/5V/12V power supply provide the full line over-current protection.

  • Page 51: Hardware Monitoring

    This motherboard implements a hardware monitoring system. As you turn on your system, this smart design will continue to monitor your system’s working voltage, fan status and CPU temperature. If any of these systems’ status goes wrong, there will be an alarm through the chassis external speaker or buzzer of motherboard (if existed) to warn the user.

  • Page 52: Resettable Fuse

    Traditional motherboard has fuse for Keyboard and port to prevent over-current or shortage. These fuses are soldered onboard that when it is broken (function as protecting the motherboard), user still cannot replace it and the motherboard is still malfunctioning. With expensive Resettable Fuse, the motherboard can be resumed back to normal function after the fuse had done its protection job. Resettable Fuse...

  • Page 53: 1500Μf Low Esr Capacitor

    CPU power. The idea of where to put these capacitors is another know-how that requires experience and detail calculation. Not only that, MX46L implements 1500μF capacitors, which is much larger than normal capacitor (1000μF) and it provides better stability for CPU power.

  • Page 54: Layout (Frequency Isolation Wall)

    For high frequency operation, especially overclocking, layout is the most important factor to make sure chipset and CPU working in stable condition. The layout of this motherboard implements our unique design called “ Frequency Isolation Wall”. Separating each critical portion of motherboard into regions where each region operates in a same or similar frequency range to avoid cross talk and frequency interference between each region’s operations and condition.

  • Page 55: Pure Aluminum Heatsink

    Cool down CPU and Chipset is important for system reliability. Aluminum heat sink provides better heat consumption especially when you are trying to over clocking the CPU.

  • Page 56: Driver And Utility

    There are motherboard drivers and utilities included in AOpen Bonus CD disc. You don’t need to install all of them in order to boot your system. But after you finish the hardware installation, you have to install your operation system first (such as Windows 98) before you can install any drivers or utilities.

  • Page 57: Auto-Run Menu From Bonus Cd Disc

    You can use the auto-run menu of Bonus CD disc. Choose the utility and driver and select model name.

  • Page 58: Installing Lan Driver

    You can install LAN Driver under Windows95/98, Windows NT, Windows 2000 and Windows XP for RealTek RTL8100 PCI Fast Ethernet adapter by following steps. Installing driver procedure on Microsoft Windows 95 : --------------------------------------------------------------------- 1. Ask you to select which driver you want to install, select "Driver” from disk provided by hardware manufacturer".

  • Page 59: Installing Onboard Sound Driver

    This motherboard comes with a RealTek ALC201A AC97 CODEC. You can find the audio driver from the Bonus Pack CD disc auto-run menu.

  • Page 60: Acpi Suspend To Hard Drive

    ACPI Suspend to Hard Drive is basically controlled by Windows operation system. It saves your current work (system status, memory and screen image) into hard disk, and then the system can be totally power off. Next time, when power is on, you can resume your original work directly from hard disk within few seconds without go through the Windows booting process and run your application again.

  • Page 61: System Requirement

    System Requirement AOZVHDD.EXE 1.30b or later. Delete config.sys and autoexec.bat. Fresh installation of Windows 98 on a new system 1. Execute "Setup.exe /p j" to install Windows 98 2. After Windows 98's installation is complete, go to the Control Panel > Power Management. a.
  • Page 62 Changing from APM to ACPI (Windows 98 only) 1. Run "Regedit.exe" a. Go through the following path HKEY_LOCAL_MACHINE SOFTWARE MICROSOFT WINDOWS CURRENT VERSION DETECT b. Select "ADD Binary" and name it as "ACPIOPTION". c. Right click and select Modify, add "01" after "0000" to make it "0000 01". d.
  • Page 63 HKEY_LOCAL_MACHINE SOFTWARE MICROSOFT WINDOWS CURRENT VERSION DETECT ACPI OPTION b. Right click and select "Modify, change "01" to "02" to make it "0000 02". Tip: "02" means Windows 98 is ACPI acknowledged but the ACPI function is disabled. c. Save changes. 2.

  • Page 64: Acpi Suspend To Ram (Str)

    This motherboard supports ACPI Suspend to RAM function. With this function, you can resume your original work directly from DRAM without going through the Windows 98 booting process and run your application again. Suspend to DRAM saves your current work in the system memory, it is faster than Suspend to Hard Drive but requires power supplied to DRAM, while Suspend to Hard Drive requires no power.
  • Page 65 To implement ACPI Suspend to DRAM, please follow the procedures as below: System Requirement Currently, except Windows 95 and Windows NT, all other Windows Systems support ACPI. An ACPI OS is required. Please refer to ACPI Suspend to Hard Drive of how to setup ACPI mode.

  • Page 66: Award Bios

    Most BIOS setting of MX46L had optimized by our R&D engineering team. But, the default setting of BIOS still can’t fine-tune the chipset controlling entire system. Hence, the rest of this chapter is intended to guide you through the process of configuring your system using setup.

  • Page 67: About Bios Function Description

    … … We always dedicate to give users a more friendly computer system. Now, we include all function descriptions of BIOS setup program into the BIOS Flash ROM. When you select one function of BIOS setup program, the function description will appeared at right side of screen. Hence, you don’t need read this manual while you changing the BIOS setting.

  • Page 68: How To Use Award™ Bios Setup Program

    ™ ™ Generally, you can use the arrow keys to highlight items that you want to choose, then press <Enter> key to select, and use the <Page Up> and <Page Down> key to change setting value. You also can press <F1> key for help and press <Esc> key to quit Award™ BIOS setup program.
  • Page 69 Description Load fail-save setting value from CMOS. Load turbo setting value from CMOS. Save changed setting and exit setup program. Note: We always dedicate to give users a more friendly computer system. Now, we include all function descriptions of BIOS setup program into the BIOS Flash ROM.

  • Page 70: How To Enter Bios Setup

    After you finish the setting of jumpers and connect correct cables. Power on and enter the BIOS Setup, press <Del> during POST (Power-On Self Test). Choose "Load Setup Defaults" for recommended optimal performance. Warning: Please avoid of using "Load Turbo Defaults", unless you are sure your system components (CPU, DRAM, HDD, etc.) are good enough for turbo setting.

  • Page 71: Bios Upgrade Under Windows Environment

    With outstanding R&D ability of AOpen, we now bring you a whole new BIOS Flash wizard ---- EZWinFlash. With an eye to users convenience, EZWinFlash combines the BIOS binary code and flash module together, so the only thing you have to do is just clicking on the utility you downloaded from web and let it helps you complete the flash process automatically.
  • Page 72 1. Download the new version of BIOS package file from AOpen official web site. (ex: http://www.aopen.com) 2. Unzip the download BIOS package (ex: WMX46L102.ZIP) with WinZip (http://www.winzip.com) in Windows environment. 3. Save the unzipped files into a folder, for example, WMX46L102.EXE & WX46L102.BIN.

  • Page 73: Overclocking

    As a leading manufacturer in motherboard industry, AOpen always listens to what customers want and develop products to fit different user's requirements. Reliability, compatibility, leading technology and friendly features are our basic goals when designing motherboards. Other than above mentioned design criteria, there are power users who are always seeking to push the limitation of the system performance by overclocking which we call them "Overclocker".

  • Page 74: Vga Card & Hard Disk

    VGA and HDD is key components for overclocking, for your reference, the following list are what have been successful overclocked in our lab. Please note that AOpen can not guaranty they can be successful overclocked again. Please check the Available Vendor List (AVL) by link to our official website.

  • Page 75: Glossary

    Basically, AC97 specification separates sound/modem circuit to two parts, digital processor and a CODEC for analogy I/O they are linked by AC97 link bus. Since digital processor can be put into motherboard main chipset, the cost of sound/modem onboard solution can be reduced.

  • Page 76: Amr (Audio/Modem Riser)

    CODEC circuit of AC97 sound/modem solution can be put on motherboard or put on a riser card (AMR card) that connects to motherboard through AMR connector. A disc bundled with our motherboard product; there are motherboard drivers, Acrobat Reader for online manual and other useful utilities.

  • Page 77: Ata/100

    ATA/100 is a new IDE specification under developing. ATA/100 uses both rising edge and falling edge as ATA/66 but clock cycle time is reduced to 40ns. The data transfer rate is (1/40ns) x 2 bytes x 2 = 100MB/s. To use ATA/100, you need special 80-wire IDE cable, the same as ATA/66.

  • Page 78: Cnr (Communication And Networking Riser)

    The CNR specification provides the PC industry the opportunity to deliver a flexible and cost reduced method of implementing LAN, home networking, DSL, USB, wireless, audio and modem subsystems widely used in today's "connected PCs". The CNR specification is an open industry specification and is supported by OEMs, IHV card manufacturers, silicon supplier and Microsoft.

  • Page 79: Dma (Direct Memory Access)

    Channel for communications between the memory and surrounding devices. The ECC mode needs 8 ECC bits for 64-bit data. Each time memory is accessed; ECC bits are updated and checked by a special algorithm. The ECC algorithm has the ability to detect double-bit error and automatically correct single-bit error while parity mode can only detect single-bit error.

  • Page 80: Ev6 Bus

    EV6 Bus in the technology of Alpha processor from Digital Equipment Corporation. EV6 bus uses both rising and falling clock edge to transfer data, similar as DDR SDRAM or ATA/66 IDE bus. EV6 Bus Speed = CPU external bus clock x 2. For example, 200 MHz EV6 bus is actually using 100 MHz external bus clock, but the equivalent speed is 200 MHz.

  • Page 81: Fsb (Front Side Bus) Clock

    FSB Clock means CPU external bus clock. CPU internal clock = CPU FSB Clock x CPU Clock Ratio See SMBus. IEEE 1394 is a low-cost digital interface originated by Apple Computer as a desktop LAN and developed by the IEEE 1394 working group. The IEEE 1394 can transport data at 100, 200 or 400 Mbps.

  • Page 82: Parity Bit

    The parity mode uses 1 parity bit for each byte, normally it is even parity mode, that is, each time the memory data is updated, parity bit will be adjusted to have even count "1" for each byte. When next time, if memory is read with odd number of "1", the parity error is occurred and this is called single bit error detection.

  • Page 83: Pci (Peripheral Component Interface) Bus

    Bus for the internal connection of peripheral devices, high-speed data channel between the computer and expansion card. A file format for electronic document, PDF format is independent from platform, you can read PDF file under Windows, Unix, Linux, Mac … with different PDF reader.

  • Page 84: Rdram (Rambus Dram)

    Rambus is a memory technology that uses large burst mode data transfer. Theoretically, the data transfer should be high than SDRAM. RDRAM is cascaded in channel operation. For Intel 820, only one RDRAM channel is supported, 16-bit data per channel, and this channel may have maximum 32 RDRAM devices, no matter how many RIMM sockets.

  • Page 85: Simm (Single In Line Memory Module)

    SIMM socket is only 72-pin, and is only single side. The golden finger signals on each side of PCB are identical. That is why it was called Single In Line. SIMM is made by FPM or DRAM and supports 32-bit data. SIMM had been phased out on current motherboard design. SMBus is also called I2C bus.

  • Page 86: Usb (Universal Serial Bus)

    16.6MB/s x2 = 33MB/s 16.6MB/s x4 = 66MB/s 16.6MB/s x6 = 100MB/s USB is a 4-pin serial peripheral bus that is capable of cascading low/medium speed peripherals (less than 10Mbit/s) such as keyboard, mouse, joystick, scanner, printer and modem. With USB, the traditional complex cables from back panel of your PC can be eliminated. NEC’s Virtual Channel Memory (VCM) is a new DRAM core architecture that dramatically improves the memory system’s ability to service multimedia requirements.

  • Page 87: Troubleshooting

    If you encounter any trouble to boot you system, follow the procedures accordingly to resolve the problem. Start Turn off the power and unplug the AC power cable, then remove all of the add-on cards and cables, including VGA, IDE, FDD, COM1, COM2 and printer. Make sure if all jumper settings are correct.
  • Page 88 Continue Install the VGA card. Then connect your monitor and keyboard. Turn on the power and check if the power supply and CPU fan work properly. The problem is probably caused by power supply or motherboard failure. Next Please contact your reseller or local distributor for repairing.
  • Page 89 Continue Perhaps your VGA card Check if there is display? or monitor is defective. Press <Ctrl> and <Alt> key at the same time, hold them and then press <Del> to reboot the system. It is very possible that your Check if the system keyboard is defective.
  • Page 90 Continue During system rebooting, press <Del> to enter BIOS setup. Choose “Load Setup Default”. Turn off the system and re-connect IDE cable. The problem should be Check if the system can caused by the IDE cable reboot successfully? or HDD itself.

  • Page 91: Technical Support

    Dear Customer, Thanks for choosing AOpen products. To provide the best and fastest service to our customer is our first priority. However, we receive numerous emails and phone-calls worldwide everyday, it is very hard for us to serve everyone on time. We recommend you follow the procedures below and seek help before contact us.
  • Page 92 News Group: Our support engineer or professional users on the news group probably had answered your problem. http://www.aopen.com/tech/newsgrp/default.htm Contact Distributors/Resellers: We sell our products through resellers and integrators. They should know your system configuration very well and should be able to solve your problem efficiently and provide important reference for you if next time you want to buy something else from them.
  • Page 93 Model name and BIOS version can be found on upper left corner of first boot screen (POST screen). For example: MX46L R1.00 Mar.08.2002 AOpen Inc. Award Plug and Play BIOS Extension v1.0A Copyright © 1998, Award Software, Inc. MX46L is the model name of the motherboard; R1.00 is BIOS version.

  • Page 94: Product Registration

    Be able to join the discussions of web-based news groups. AOpen makes sure that the information you provide is encrypted, so that it cannot be read or intercepted by other people or companies. Further, AOpen will not disclose any of information you submitted under any conditions. Please consult our...

  • Page 95: How To Contact Us

    Please do not hesitate contact us if you have any problem about our products. Any opinion will be appreciated. Pacific Rim Europe America AOpen Inc. AOpen Computer b.v. AOpen America Inc. Tel: 886-2-3789-5888 Tel: 31-73-645-9516 Tel: 1-408-922-2100 Fax: 886-2-3789-5899 Fax: 31-73-645-9604...
