OPERATION
MANUAL
DDA-106
HD/SD Digital Distribution Amp
st
1
Edition

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DDA-106 and is the answer not in the manual?

Questions and answers

Related Manuals for FOR-A DDA-106

Summary of Contents for FOR-A DDA-106

  • Page 1 OPERATION MANUAL DDA-106 HD/SD Digital Distribution Amp Edition...
  • Page 2 Edition Revision History Edit. Rev. Date Description Section/Page 2012/07/11...

  • Page 3: Important Safety Warnings

    Precautions Important Safety Warnings [Power] Operate unit only on the specified supply voltage. Caution Disconnect power cord by connector only. Do not pull on cable portion. Do not place or drop heavy or sharp-edged objects on power cord. A damaged cord can cause fire or electrical shock hazards.
  • Page 4 [Circuitry Access] Do not remove covers, panels, casing, or access circuitry with power applied to the unit! Turn power off and disconnect power cord prior to removal. Internal servicing / adjustment of unit should only be performed by qualified personnel. Do not touch any parts / circuitry with a high heat factor.
  • Page 5 Upon Receipt Unpacking DDA-106 units and their accessories are fully inspected and adjusted prior to shipment. Operation can be performed immediately upon completing all required connections and operational settings. Check your received items against the packing lists below. ITEM REMARKS...
  • Page 6 Installing the Ladder Strap/Retaining Clip Assembly Secure the AC cord with the supplied ladder strap/retaining clip assembly to prevent accidental removal from the DDA-106.  Installing the clip 1) Wrap the retaining clip around the AC cord (with the anchor of the ladder strap toward the unit.) 2) Insert the anchor into the insertion hole next to the AC IN socket.

  • Page 7: Table Of Contents

    Table of Contents 1. Prior to Starting ......................... 1 1-1. Welcome ..........................1 1-2. Features ..........................1 1-3. About This Manual ......................1 2. Panel Descriptions ........................2 2-1. Front Panel ........................2 2-2. Rear Panel ......................... 2 3. Connection ..........................3 4.

  • Page 9: Prior To Starting

    FOR-A provides a wide range of products, from basic support units to complex system controllers, which have been increasingly joined by products for computer video based systems. Whatever your needs, talk to your FOR-A representative. We will do our best to be of continuing service to you.

  • Page 10: Panel Descriptions

    2. Panel Descriptions 2-1. Front Panel DDA-106 HD/SD DIGITAL DISTRIBUTION AMP LOCK POWER (2) (3)(4) Name Description POWER switch Switch used to turn the unit power ON/OFF. POWER LED Lights whenever power is applied to the unit. LOCK LED Lights whenever an input signal is properly input.

  • Page 11: Connection

    3. Connection Refer to the figure below and connect the DDA-106 and other devices. HD-SDI, HD/SD-SDI HD/SD SD-SDI, OUT1 DVB-ASI signal HD/SD OUT2 HD/SD HD-SDI, OUT3 SD-SDI, DDA-106 HD/SD DVB-ASI signal OUT4 HD/SD OUT5 HD/SD OUT6...

  • Page 12: Specifications And Dimensions

    Power Consumption 15VA (7W) 212 (W) × 44 (H)× 161.5 (D) mm, EIA 1RU (excluding protruding parts) Dimensions Weight 1.0 kg To ensure the product is used under specified conditions, do not stack the DDA-106 on or under other equipment.

  • Page 13: External Dimensions

    4-2. External Dimensions (All dimensions in mm.) D DA-106 HD/SD DIGITAL DISTRIBUTION AMP LOCK POWER...
  • Page 15 Warning This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
  • Page 16 FOR-A America East Coast Office 2 Executive Drive, Suite 670, Fort Lee Executive Park, Fort Lee, NJ 07024, USA Phone: +1-201-944-1120 Fax : +1-201-944-1132 FOR-A America Distribution & Service Center 2400 N.E. Waldo Road, Gainesville, FL 32609, USA Phone: +1-352-371-1505 Fax: +1-352-378-5320...
