OPERATION
MANUAL
USF-1040VEA
USF-1100VEA
Analog Video Equalizing Distribution
Amplifier
USF-VEAIF
VEA Interface
st
1
Edition - Rev.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the USF-1040VEA and is the answer not in the manual?

Questions and answers

Related Manuals for FOR-A USF-1040VEA

Summary of Contents for FOR-A USF-1040VEA

  • Page 1 OPERATION MANUAL USF-1040VEA USF-1100VEA Analog Video Equalizing Distribution Amplifier USF-VEAIF VEA Interface Edition - Rev.1...

  • Page 2: Important Safety Warnings

    Precautions Important Safety Warnings [Installation/Operation] Do not install or operate the module under high temperature, high humidity, dusty, or high-vibration conditions. Installing the unit in conditions other than those specified may cause malfunction, fire, or electric shock hazards. Stop [Transportation] Handle with care to avoid impact shock during transit, which may cause malfunction.
  • Page 3 Unpacking Congratulations! By purchasing a USF-1040VEA/ USF-1100VES Analog Video Equalizing Distribution Amplifier you have entered the world of FOR-A and its many innovative products. Check your received items against the packing lists below. Check to ensure no damage has occurred during shipment. If damage has occurred, or items are missing, inform your supplier immediately.

  • Page 4: Table Of Contents

    Table of Contents 1. Features Overview ........................5 1-1. Overview ..........................5 1-2. Features ..........................5 2. Part Descriptions ......................... 6 2-1. Front Panel ........................... 6 2-2. Rear Panel ........................... 7 3. Connection ..........................8 4. Front Module DIP Switch Settings ....................9 5.

  • Page 5: Features Overview

    1. Features Overview 1-1. Overview The USF-1040VEA is an Analog Video Equalizing Distribution Amplifier that can distribute 1 analog video input signal to 4 output signals. The USF-1100VEA is an Analog Video Equalizing Distribution Amplifier that can distribute 1 analog video input signal to 10 output signals. It supports composite and HD/SD analog component signals.

  • Page 6: Part Descriptions

    2. Part Descriptions 2-1. Front Panel  USF-1040VEA USF-1040VEA  USF-1100VEA USF-1100VEA Name Description POWER LED lights green when DC power is supplied normally. LED indicates analog video input signal status. Green Indicates that a signal is being input.(-10dB to +6dB) INPUT Off Indicates that no signal is being input or signal level is too low.(less...

  • Page 7: Rear Panel

    2-2. Rear Panel  USF-1040VEA VIDEO IN THRU VIDEO OUT USF-1040VEA  USF-1100VEA VIDEO OUT VIDEO IN THRU USF-1100VEA Name Description VIDEO IN Analog video signal input connector. THRU Loop through terminal for VIDEO IN. Connect to 75Ω terminator when not in use.

  • Page 8: Connection

    3. Connection Connect a USF-1040VEA or USF-1100VEA to external devices referring to the charts below.  USF-1040VEA VIDEO IN THRU VIDEO OUT USF-1040VEA USF Frame Analog Video Signal （VIDEO IN) VIDEO IN OUT 1 Through OUT THRU （THRU) OUT 2...

  • Page 9: Front Module Dip Switch Settings

    (*3) Set the SW3 and SW4 to LOCAL when the USF-VEAIF option is not installed. Installing a USF-VEAIF enables USF-1040VEA/1100VEA status displays. Set both SW3 and SW4 to REMOTE to set GAIN and COMPENSATION through Web GUI. Refer to Sec.

  • Page 10: Internal Block Diagram

    5. Internal Block Diagram The internal block diagrams of USF-1040VEA and USF-1100VEA are shown as below.  USF-1040VEA Internal Block Diagram VIDEO IN ･Gain Adjust ･Cable Compensation ･Input Detection ･Clamp Setting ･SD/HD Setting THRU OUT 1 OUT 2 OUT 3 OUT 4 ...

  • Page 11: Usf-Veaif (Option)

    Align the red squared connector portion and click. 3) Fasten the USF-VEAIF with the 4 supplied screws from the rear. (Circled in red, above.) * If a USF-VEAIF is already installed on a USF-1040VEA or 1100VEA, this process is not necessary.

  • Page 12: Web Gui

    PCs. 7-1. Web Page The USF-1040VEA or 1100VEA web page allows you to show the module status and settings. As factory default, Cable Compensation and Video Gain cannot be adjusted from the Web GUI. To adjust them from the Web GUI, change internal switches (SW3 and SW4) to REMOTE on the USF-1040VEA/1100VEA front module.
  • Page 13 (Refer to Coupling in Sec. 4. “Front Module DIP Switch Settings.”) Video Gain Video gain setting (set on the front panel) Compensation Mode Compensation mode of USF-1040VEA or 1100VEA. (Refer to SD/HD in Sec. 4.”Front Module DIP Switch Settings.”) Cable Compensation Cable compensation level setting (set on the front panel)

  • Page 14: About Snmp

    8. About SNMP The USF-1040VEA/1100VEA can be remotely monitored using an external SNMP monitoring system that supports SNMPv2C. MIB (Management Information Base) files that are required for SNMP monitoring systems can be downloaded from Web GUI. Refer to the prior section for details on downloading MIB files.

  • Page 15: Specifications And Dimensions

    9. Specifications and Dimensions 9-1. Specifications USF-1040VEA USF-1100VEA Video Input Analog Video 1.0 Vp-p High-impedance loop through BNC x 1 (Looped output x 1 separately) Video Output Analog Video 1.0 Vp-p Analog Video 1.0 Vp-p 75Ω BNC x 4 75Ω BNC x 10 Frequency 100 kHz to 30 MHz within ±...

  • Page 16: Dimensions

    9-2. Dimensions (All dimensions in mm) USF-1040VEA USF-1100VEA USF-1 040VEA USF-1100VEA...

This manual is also suitable for:

Usf-1100vea

Table of Contents
