OPERATION
MANUAL
USF-1053DDA
Digital Distribution Amplifier
Edition – Rev. 3
nd
2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the USF-1053DDA and is the answer not in the manual?

Questions and answers

Related Manuals for FOR-A USF-1053DDA

Summary of Contents for FOR-A USF-1053DDA

  • Page 1 OPERATION MANUAL USF-1053DDA Digital Distribution Amplifier Edition – Rev. 3...
  • Page 2 Precautions Important Safety Warnings [Power] Do not place or drop heavy or sharp-edged objects on the power cord. A damaged cord can cause fire or electrical shock hazards. Regularly check the power cord for excessive wear or damage to avoid possible fire / electrical hazards. Stop [Circuitry Access] Do not touch any parts / circuitry with a high heat factor.
  • Page 3 Upon Receipt Congratulations! By purchasing a USF-1053DDA Digital Distribution Amplifier, you have entered the world of FOR-A and its many innovative products. Check your received items against the packing list below. Check to ensure no damage has occurred during shipment. If damage has occurred, or items are missing, inform your supplier immediately.

  • Page 4: Table Of Contents

    2-2. Rear Panel ..........................6 3. DIP Switch Settings ..........................7 4. USF-1053DDA I/O via USF-212S/AS Internal Bus ................9 4-1. Distributing another USF-1053DDA module input (1 x 10) ............10 4-1-1. Input Settings via DIP Switch .....................10 4-1-2. Input Settings via Web GUI ....................10 4-2.

  • Page 5: Product Overview

    1. Product Overview 1-1. Overview The USF-1053DDA is a multi-bit rate video distribution amplifier that can be installed in a USF frame. The USF-1053DDA supports 3G-SDI, HD-SDI, SD-SDI, and DVB-ASI, and is capable of producing up to 5 outputs from 1 input.

  • Page 6: Panel Descriptions

    *1 When video signals routed from USF frame internal bus are distributed, video signal bit rate detection is not available. All the LEDs; 270Mb/s, 1.5Gb/s, and 3.0Gb/s are turned off. Refer to Sec. 4 “USF-1053DDA I/O via USF-212S/AS Internal Bus” for switching the video signal source.

  • Page 7: Dip Switch Settings

    IMPORTANT SW Nos. 5 to 8 are factory use only. Do not change these settings. Table 1: Input Signal Switch Settings Slot: USF frame slot no. into which USF-1053DDA is installed. Slot Input signal for distribution Set by Web GUI.
  • Page 8 Distributes Slot 10 input. (Via frame internal bus) Distributes Slot 11 input. (Via frame internal bus)  In case SW1 to SW4 are set to other than those described in Table 1: Input Signal Switching Settings, USF-1053DDA will distribute its input.

  • Page 9: Usf-1053Dda I/O Via Usf-212S/As Internal Bus

    Distributing another USF-1053DDA module input (1 x 10) The number of outputs can be increased up to 10 by installing two USF-1053DDA modules into a USF frame and using internal bus lines. Install module pairs according to the figure shown above (e.g., into Slot 1 and Slot 2.).

  • Page 10: Distributing Another Usf-1053Dda Module Input (1 X 10)

    3G/HD/SD SDI IN USF-1043FS 4-1-1. Input Settings via DIP Switch Set the front panel DIP switches on USF-1053DDA modules to those shown in the tables below and install them into Slot 1 and Slot 2 on the USF frame. USF-1053DDA Uses the rear panel input.

  • Page 11: Distributing Another Type Module Input

    USF-1043FS 4-2-1. Input Settings via DIP Switch (1) Set USF-1053DDA DIP switch settings to those shown in the table below and install the module into Slot 1 on the USF Frame. (2) Install a USF-1043FS into Slot 4 of the USF frame.

  • Page 12: Usf-1053Dda I/O Via Usf-105S/As Internal Bus

    USF-1053DDA modules can output an SDI signal via USF-105S/AS frame internal bus. The number of outputs can be increased up to 10 by installing two USF-1053DDA modules into a USF frame and using internal bus lines. Install a module pair into Slot 1 and Slot 2 or Slot 3 and Slot 4 on...

  • Page 13: Slot 2 To Slot 1

    3G/HD/SD SDI IN USF-1043FS 5-2-1. Input Settings via DIP Switch Set the DIP switch settings to those shown in the tables below for two USF-1053DDA modules and install them into Slot 1 and Slot 2 on the USF frame. USF-1053DDA Uses the Slot 2 input.

  • Page 14: Input Settings Via Dip Switch

    Uses the Slot 3 input. Slot 4 5-3-2. Input Settings via Web GUI (1) Install two USF-1053DDA modules into Slots 3 and 4. (2) Start the 1053DDA Web GUI and set as follows. Set Slot 3 Input Source to Rear In.

  • Page 15: Web Gui

    6. Web GUI Status parameters of USF-1053DDA can be displayed on the Web display if the module is installed in a USF frame. SNMP monitoring is also available. Refer to the USF frame operation manual for details on displaying the Web GUI window.
  • Page 16 Input Source Displays the USF-1053DDA Input Source. Rear In or Slot 1 to 12 Input Sources are settable via Web GUI if SW1 to SW4 are all Off. The slot number(s) set by “Table 1: Input Signal Switch Settings” are...

  • Page 17: Syslog Functions

    6-2. syslog Functions The USF-1053DDA supports log monitoring and message transmission via syslog protocol. Clicking the syslog tab opens a window shown as below. Item Descriptions Send syslog Select Enable to send syslog messages to the management terminal. Send address Sets the IP address to send syslog messages to.

  • Page 18: About Snmp

    7. About SNMP The USF-1053DDA can be remotely monitored using an external SNMP monitoring system that supports SNMPv2C. MIB (Management Information Base) files that are required for SNMP monitoring systems can be downloaded from the Web GUI. Refer to the prior section for details on downloading MIB files.

  • Page 19: Specifications And Dimensions

    8. Specifications and Dimensions 8-1. Specifications Video Input 3G-SDI: 3Gbps HD-SDI: 1.5Gbps SD-SDI: 270Mbps DVB-ASI: 270Mbps 75Ω BNC x 1 Video Output 3G-SDI: 3Gbps HD-SDI: 1.5Gbps SD-SDI: 270Mbps DVB-ASI: 270Mbps 75Ω BNC x 5 Cable Compensation Automatic Cable Compensation 3G-SDI: Max. 70m (Using 5C-FB-equivalent cable) HD-SDI: Max.100m (Using 5C-FB-equivalent cable) SD-SDI: Max.
