- Page 1 OPERATION MANUAL UFM-14DADA Digital Audio Distribution Amplifier UFM-18DADA Digital Audio Distribution Amplifier Edition - Rev. 2...
-
Page 2: Important Safety Warnings
Precautions Important Safety Warnings [Power] Do not place or drop heavy or sharp-edged objects on power cord. A damaged cord can cause fire or electrical shock hazards. Regularly check power cord for excessive wear or damage to avoid possible fire / electrical hazards. Stop [Circuitry Access] Do not touch any parts / circuitry with a high heat factor. - Page 3 Upon Receipt Unpacking UFM-14DADA/18DADA units and their accessories are fully inspected and adjusted prior to shipment. Operation can be performed immediately upon completing all required connections and operational settings. Check your received items against the packing lists below. ITEM REMARKS...
-
Page 4: Table Of Contents
Table of Contents 1. Prior to Starting ..........................1 1-1. Welcome ..........................1 1-2. About the UFM-14DADA/18DADA ..................1 1-3. About This Manual ........................ 1 2. Panel Descriptions ........................2 2-1. Front Panel ..........................2 2-2. Rear Panel ..........................3 3. -
Page 5: Prior To Starting
Congratulations! By purchasing UFM-14DADA/18DADA Digital Audio Distribution Amplifier you have entered the world of FOR-A and its many innovative products. Thank you for your patronage and we hope you will turn to FOR-A products again and again to satisfy your video and audio needs. -
Page 6: Panel Descriptions
2. Panel Descriptions 2-1. Front Panel UFM-14DADA POWER (OPTION) UFM-14DADA INPUT INTERFACE UFM-18DADA POWER (OPTION) UFM-18DADA INPUT INTERFACE The power indicator is lit whenever the supply curcuit on the board Power indicator is operating properly. This indicator lights whenever the proper digital audio signal is INPUT 1 input to IN 1. -
Page 7: Rear Panel
2-2. Rear Panel UFM-14DADA DIGITAL AUDIO IN OUT 1 OUT 2 OUT 3 OUT 4 OUT 2-2 OUT 1-2 OUT 2-1 IN 2 OUT 1-1 UFM-14DADA Single channel mode DIGITAL AUDIO IN Used for digital audio input connection. IN 1 IN 1 is used to input digital audio signals. - Page 8 UFM-18DADA IN 1 OUT 1-1 OUT 1-2 OUT 1-3 OUT 1-4 DIGITAL AUDIO IN 2 OUT 2-1 OUT 2-2 OUT 2-3 DIGITAL AUDIO OUT UFM-18DADA Single channel mode DIGITAL AUDIO IN Used for digital audio input connection. IN 1 Used for digital audio output connection.
-
Page 9: Connection
3. Connection Refer to figure below for connecting the UFM-14DADA/18DADA to other devices. Note that before installing the UFM-14DADA/18DADA into the universal frame, you should thoroughly read the operation manual for the Universal Frame where you will be installing. UFM-14DADA... - Page 10 UFM-18DADA (1) Single channel mode (one input to eight outputs) Universal frame UFM-18DADA module OUT 1 OUT 2 Digital Audio OUT 3 Input Device Digital OUT 4 DIGITAL Input Audio Detection AUDIO IN OUT 5 Device OUT 6 OUT 7 OUT 8 (2) Dual channel mode (one input to four outputs and one input to three outputs) Universal frame...
-
Page 11: Internal Settings
4. Internal Settings The following settings can be made via the front module of the UFM-14DADA/18DADA. Switch settings must be made prior to installing any module to the universal frame. Single channel mode/dual channel mode toggle switch SW 1 4-1. Operation Mode (SW1) SW1 is used to select between single channel mode (one way) and dual channel mode (two ways). -
Page 12: Other Settings (Sw2)
4-2. Other Settings (SW2) SW2 is for maintenance use only. If these settings are changed by mistake, refer to the table below to return them to the default settings. 1 2 3 4 6 7 8 Switch No. Factory Default Description For maintenance use only. -
Page 13: Specifications And Dimensions
5. Specifications and Dimensions 5-1. Specifications UFM-14DADA UFM-18DADA Distribution Single channel mode Input 1 to four outputs Input 1 to eight outputs Dual channel mode Input 1 to two outputs Input 1 to four outputs Input 2 to two outputs... -
Page 14: Dimensions
5-2. Dimensions (All dimensions in mm.) UFM-14DADA UFM-18DADA 108.5 108.5 POWER (O PTIO N) UFM-14DADA INTERFACE INPUT POWER (OPTION) UFM-18DADA INPUT INTERFACE... - Page 15 Warning This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
