- Page 1 OPERATION MANUAL USF-105DDA-12G Digital Distribution Amplifier Edition...
- Page 2 Precautions Important Safety Warnings [Power] Do not place or drop heavy or sharp-edged objects on the power cord. A damaged cord can cause fire or electrical shock hazards. Regularly check the power cord for excessive wear or damage to avoid possible fire / electrical hazards. Stop [Circuitry Access] Do not touch any parts / circuitry with a high heat factor.
- Page 3 Upon Receipt Congratulations! By purchasing a USF-105DDA-12G Digital Distribution Amplifier, you have entered the world of FOR-A and its many innovative products. Check your received items against the packing list below. Check to ensure no damage has occurred during shipment. If damage has occurred, or items are missing, inform your supplier immediately.
-
Page 4: Table Of Contents
Table of Contents 1. Prior to Starting ............................. 5 1-1. Overview ............................. 5 1-2. Features ............................5 2. Panel Descriptions ..........................6 2-1. Front Panel ..........................6 2-2. Rear Panel ..........................6 3. DIP Switch Settings ..........................7 4. Web GUI ............................... 8 4-1. -
Page 5: Prior To Starting
1. Prior to Starting 1-1. Overview The USF-105DDA-12G is a multi-bit rate video distribution amplifier that can be installed in a USF frame. The USF-105DDA-12G supports 12G-SDI, 3G-SDI, HD-SDI, SD-SDI and DVB-ASI, and is capable of producing up to 5 outputs from 1 input. -
Page 6: Panel Descriptions
Lights green when input SDI signal is 1.5G b/s. 270Mb/s LED Lights green when input SDI signal is 270M b/s. DIP switch Sets input signal switching. Used to upgrade USF-105DDA-12G software. USB connector (Do not connect USB devices.) 2-2. Rear Panel SDI IN... -
Page 7: Dip Switch Settings
3. DIP Switch Settings The front DIP switch settings allow you to set input signal switching, re-clock function settings, etc. Setting SW No. Function Factory Setting － － ON (Do not change the settings.) － － OFF (Do not change the settings.) －... -
Page 8: Web Gui
USF-105DDA-12G does not support simultaneous Web GUI access from multiple PCs. To simultaneously monitor a USF-105DDA-12G from multiple PCs, use the SNMP function. 4-1. WEB Display Information Start the Web GUI and click on a USF-105DDA-12G from slot 1 to 12 of USF-212AS/USF-105AS to open the window as shown below. ... -
Page 9: Syslog Functions
(3) FORA-USF105DDA-12G-MIB.zip File is downloaded. (4) Unzip the file and load it into your SNMP manager. 4-2. syslog Functions The USF-105DDA-12G supports log monitoring and message transmission using syslog protocol. Clicking the syslog tab opens a window shown as below. Item... -
Page 10: About Snmp
5. About SNMP The USF-105DDA-12G can be remotely monitored using an external SNMP monitoring system that supports SNMPv2C. MIB (Management Information Base) files that are required for SNMP monitoring systems can be downloaded from the Web GUI. (Refer to the prior page “Downloading MIB files” for details.) -
Page 11: Specifications And Dimensions
6. Specifications and Dimensions 6-1. Specifications Video Input 12G-SDI: 12Gbps 3G-SDI: 3Gbps HD-SDI: 1.5Gbps SD-SDI: 270Mbps DVB-ASI: 270Mbps 75Ω BNC x 1 Video Output 12G-SDI: 12Gbps 3G-SDI: 3Gbps HD-SDI: 1.5Gbps SD-SDI: 270Mbps DVB-ASI: 270Mbps 75Ω BNC x 5 Cable Automatic Cable Compensation Compensation 12G-SDI: Max.
