Page 1: Hardware Guide
5015T 15” FLAT PANEL INDUSTRIAL MONITOR FLAT PANEL INDUSTRIA Hardware Guide... - Page 2 Xycom Automation Part Number 142029(D) Trademark Information Xycom Automation is a trademark of Xycom Automation, Inc. Brand or product names may be registered trademarks of their respective owners. Windows is a registered trademark of Microsoft Corporation in the United States and other countries.
-
Page 3: Table Of Contents
Chapter 1 Product Overview ............................1 Product Features ..................................1 Standard 5015T Features ................................1 Parts List....................................... 2 Standard 5015T Parts List ................................2 Manual Overview ..................................2 Text Conventions Used in this Manual ............................2 Product Dimensions..................................3 External Features..................................4 Product Specifications and Ratings............................... -
Page 4: Chapter 1 Product Overview
CRTs cannot. The 5015T and the 5015T-24V units are self-contained, requiring only to be panel mounted in an appropriate enclosure and connected to 100-240 VAC and VGA source or to a 24 VDC and VGA source accordingly. -
Page 5: Parts List
Analog RGB Cable (10 ft.) RS-232C Cable (10 ft.) Documentation and Support Library CD-ROM. In addition to containing this manual, the DOC CD contains all drivers required by this unit (touchscreen drivers in the case of 5015T and 5015T-24VDC units). Manual Overview The manual is divided in the following chapters: Chapter 1 –... -
Page 6: Product Dimensions
5015T Flat Panel Industrial Monitor Chapter 1 Product Overview Product Dimensions 142029 (D) -
Page 7: External Features
Host. Serial I/F Connector Serial RS-23C interface. This connects a serial cable to the (RS-232C) 5015T, and sends the 5015T touch panel data to the host. Position OSD SELECT All Front buttons are in an operable state. OSD can be Switch started. -
Page 8: Product Specifications And Ratings
CSA-C22.2, #213* * Suitable for use in Class I, Division 2, Groups A, B, C and D and Class II, Division 2, Groups F and G Hazardous Locations or Non-Hazardous Locations only. Temperature Codes: T4 (5015T), T4A (5015T-24V) 142029 (D) -
Page 9: Chapter 2 Installation
Environmental Considerations The rugged design of the 5015T allows it to be installed in most industrial environments. Refer to the electrical and environmental specifications and tolerances in the Product Specifications and Ratings section for more detailed information. Power Management The monitor is based on the VESA DPMS and the DVI DMPM standards. -
Page 10: Excessive Heat
Protective Earth Ground Power Input Terminal Block Caution: Use AWG18 wire or greater for the 5015T’s power cable. Isolate the AC main circuit line, I/O signal lines, and power cord - do not bind or group them together. Excessive Heat To keep the temperature in range, the cooling air at the base of the system must not exceed the maximum temperature specification. -
Page 11: Line Voltage Variation
5015T Flat Panel Industrial Monitor Chapter 2 Installation noise generators include switching components, relays, solenoids, motors, and motor starters. Refer to the relevant Federal, State/Provincial, and local electric codes, which provide data such as the size and types of conductors, color codes and connections necessary for safe grounding of electrical components. -
Page 12: Panel Installation
5015T Flat Panel Industrial Monitor Chapter 2 Installation Panel Installation This monitor should be mounted in and used where NEMA 4 and NEMA 12 type enclosures are employed. When mounted properly, the monitor meets or exceeds the sealing requirements set forth in the NEMA 4 and NEMA 12 specifications. The monitor uses "U"-shaped clips and a special gasket to achieve the proper seal. - Page 13 5015T Flat Panel Industrial Monitor Chapter 2 Installation The following figures show the twelve (12) insertion slot locations of the 5015T installation fasteners. Insert the hook section into the slot and tighten the fastener with a screwdriver, as shown. 142029 (D)
-
Page 14: Hazardous Locations Installations
Chapter 2 Installation Hazardous Locations Installations Xycom Automation designed the systems with the intention of meeting the requirements of Class I, Division 2 Hazardous Locations applications. Division 2 locations are those locations that are normally non-hazardous, but potentially hazardous should an accident expose the area to flammable vapors, gases or combustible dusts. -
Page 15: Definitions
5015T Flat Panel Industrial Monitor Chapter 2 Installation Advertissement Risque D’ Explosion Avant de deconnecter l’equipment, coupler le courant ou s’assurer que l’emplacement est designe non dangereux. Warning - Explosion Hazard When in hazardous locations, turn off power before replacing or wiring modules. -
Page 16: Power Switch
5015T Flat Panel Industrial Monitor Chapter 2 Installation NOTE Xycom Automation 5015T, 5015T-24V systems are not suitable for installation within Division 1 locations. NOTE Electrical equipment cannot be installed in Division 1 locations unless they are intrinsically safe, installed inside approved explosion-proof enclosures, or installed inside approved purged and pressurized enclosures. -
Page 17: Cable Connections
5015T Flat Panel Industrial Monitor Chapter 2 Installation cable length between the workstation and the power switch may apply. Otherwise the switch must be compliant with Class I, Division 1 requirements (intrinsically safe). These switches are built in a manner that prevents the possibility of a spark when contacts are made or broken. -
Page 18: Safety Agency Approval
These workstations are designed to require no service in the course of normal operation by an operator. Safety Agency Approval The Xycom Automation systems are designed to meet the following standards: • Underwriters Laboratories Inc., UL 1604 Standard for Safety Electrical equipment for use in Class I and Class II, Division 2, locations •... -
Page 19: Chapter 3 Monitor Settings
Not all video controllers produce exactly the same video output levels or the same timing. The 5015T uses onscreen programming to make setup and adjustment easy. The menus are selected and the menu items are adjusted using the buttons located on the monitor front panel. -
Page 20: Video Modes Supported
5015T Flat Panel Industrial Monitor Chapter 3 Monitor Settings Video Modes Supported Horizontal Vertical Sync Mode Sync Rate Dot Frequency (MHz) Rate (KHz) (KHz) (640x400) 31.469 70.000 25.175 (640x480) 31.469 59.992 25.175 37.500 75.000 31.500 35.000 66.667 30.240 (720x400) 31.469 70.000... -
Page 21: Adjustment Menu Reset
[RESET] appears on the screen, the reset is complete. Automatic Screen Adjustment Before connecting the 5015T to your computer, make sure your computer’s VGA card is set to one of the supported modes listed in the “Video Mode Supported” table on page 15. It is important not to exceed the vertical refresh rate listed in the table. -
Page 22: Manual Screen Adjustment
If you are using Windows, you can use the Adjustment Pattern. This software can be downloaded from the Xycom DOC CD. If you have a different operating system, display an image that makes the entire screen light and adjust it through checking its actual tone. -
Page 23: Gain Control Menu
5015T Flat Panel Industrial Monitor Chapter 3 Monitor Settings Gain Control Menu Menu Option Description Total screen brightness can be adjusted while viewing the Black Level color pattern using the buttons. While viewing the color pattern, adjustments can be made... - Page 24 5015T Flat Panel Industrial Monitor Chapter 3 Monitor Settings Menu Option Description Adjusts the image to optimum sharpness when screen is Scaling expanded ( buttons). Set color tone: STD: Displays image with the color tone results from original scheme of liquid crystal panel.
-
Page 25: Chapter 4 Operator Input
Touchscreen Installing the Touchscreen Driver 1. Insert the Xycom Automation CD in the CD-ROM. 2. Navigate to the UTP_touch_panel_Driver folder. 3. Run setup.exe* 4. When you get to the Select Controller window during the installation process, select the Gunze AHL Serial driver. -
Page 26: Chapter 5 Hardware
VGA Input Connector Pin Out Analog Signal Input Connector Pin (D-sub connector with 15 pins) Signal Name 15-pin D-Shell Green Blue GND-Digital GND-Red return GND-Green return GND-Blue return GND-Digital Hsync Vsync Serial Interface Function Data Transmission Speed: 9600 bps Data Length: 8 bits RS-232C Stop Bit: 1 bit Parity: None... -
Page 27: Rs-232 Cable
Chapter 5 Hardware RS-232 Cable The RS-232 cable is shipped with both the 5015T and 5015-24V flat panel monitors. Should you decide to assemble your own RS-232 cable, it is highly recommended that you use parts equivalent to those listed below. -
Page 28: Appendix A: Technical Support
5. Details of attempts made to rectify the problem(s) and results. 6. The log number assigned from Xycom Automation Technical Support if this is an ongoing problem. 7. The name of the Technical Support Engineer with whom you last spoke, if known. - Page 29 142029(C) Xycom Automation, Inc. 734-429-4971 • • • • Fax: 734-429-1010 750 North Maple Drive http://www.xycom.com Saline, MI 48176...
