Xycom SXT2011 Hardware Manual

Flat panel industrial monitor

Advertisement

Quick Links

SXT2011
FLAT PANEL INDUSTRIAL MONITOR
FLAT PANEL INDUSTRIA

Hardware Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SXT2011 and is the answer not in the manual?

Questions and answers

Summary of Contents for Xycom SXT2011

  • Page 1: Hardware Guide

    SXT2011 FLAT PANEL INDUSTRIAL MONITOR FLAT PANEL INDUSTRIA Hardware Guide...
  • Page 2 Xycom Automation Part Number 142026(A) Trademark Information Xycom Automation is a trademark of Xycom Automation, Inc. Brand or product names may be registered trademarks of their respective owners. Windows is a registered trademark of Microsoft Corporation in the United States and other countries.
  • Page 3: Table Of Contents

    Table of Contents 1. Product Overview..…..................1-1 Product Features…………………………………………….……………………………………1-1 Standard SXT2011 Features…………………………………………………………………….1-1 Parts List…………………………………………………….……………………………………1-1 Standard SXT2011 Parts List…………………………………………………………………...1-1 Manual Overview…………………………………………….…………………………………..1-2 Text Conventions Used in this Manual …………………….……………………………………1-2 Product Dimensions ……………………………………….…………………………………….1-3 Front Panel Controls …………………………………………….……………………………1-3 Product Specifications and Ratings……..………………….……………………………………1-4 Environmental……...…….……………………………………………………………………1-4 Electrical ……………………………………………………………………………………...1-4 Front Panel/Enclosure ..…….…………………………….…………………………………..1-4...
  • Page 4: Product Overview

    Units ship with all necessary cables and software Parts List When you remove the SXT2011 from its shipping carton, verify that you have the parts listed below. Save the box and inner wrapping in case you need to reship the unit.
  • Page 5: Manual Overview

    Manual Overview The manual is divided in the following chapters: • Chapter 1 – Product Overview • Chapter 2 – Installation • Chapter 3 – Monitor Settings • Chapter 4 – Hardware Text Conventions Used in this Manual Throughout this manual, certain terms are formatted in ways that indicate what type of object is being described.
  • Page 6: Product Dimensions

    Product Dimensions 3.65 [92.7] 20.32 [516.13] P OWE R ME N U S E L U P S E L D N D E C 17.18 I N C [436.37] S E T OF F in.[mm] Front Panel Controls The front panel controls, from left to right are Menu, Select, Increment, Decrement. Their use is detailed in Chapter 3—...
  • Page 7: Product Specifications And Ratings

    Product Specifications and Ratings Environmental Operating Nonoperating Thermal -20°C to 60°C (32°F to 122°F) 0°C to 50°C (32°F to 122°F) Humidity 20% to 80% RH, noncondensing 20% to 80% RH, noncondensing 15 g peak acceleration, 30 g peak acceleration, Shock 11 msec duration 11 msec duration Vibration,...
  • Page 8: Installation

    2. Installation Environmental Considerations The rugged design of the SXT2011 allows it to be installed in most industrial environments. Refer to the electrical and environmental specifications and tolerances (pg. 1-4) for more detailed information. System Power It is a good practice to use isolation transformers on the incoming AC power line to the system.
  • Page 9: Electrical Noise

    Electrical Noise Electrical noise is seldom responsible for damaging components, unless extremely high energy or high voltage levels are present. However, noise can cause temporary malfunctions that can result in hazardous machine operation in certain applications. Noise may be present only at certain times, may appear at widely spread intervals, or in some cases may exist continuously.
  • Page 10: Panel Installation

    sure that outside air is not brought inside the enclosure unless a fabric or other reliable filter is used. This filtration prevents conductive particles or other harmful contaminants from entering the enclosure. • Do not select a location near equipment that generates excessive electromagnetic interference (EMI) or radio frequency interface (RFI) (equipment such as high-power welding machines, induction heating equipment, and large motor starters).
  • Page 11: Monitor Settings

    Turn the SET UP switch to the ‘On’ position to enable set up and adjustment. If you are using a “Plug and Play” operating system adjust your desktop display settings to the following before connecting the SXT2011 to your computer:...
  • Page 12: Video Modes Supported

    Video Modes Supported Mode Horizontal Sync Vertical Sync Dot Freq. Expansion Factor Rate (KHz) Rate (KHz) (MHz) Vertical Horizontal VESA VGA 31.5 25.175 (640x480) 37.9 31.500 37.5 31.500 43.3 36.000 IBM (720x400) 31.5 28.322 37.9 35.500 VESA SVGA 35.1 36.000 (800x600) 37.9 40.000...
  • Page 13 Color Adjust video color level Tint Adjust video tint level Sharpness Adjust video image sharpness level Video Adjustment** Video Type Change bandwidth to match the source (DVD/VCR) Frequency Adjust the image horizontal size Phase Fine tune the data sampling position (adjust image quality) Frequency&Phase* AUTO automatic detection of NTSC and PAL...
  • Page 14 User Setting: User Timeout Adjust the OSD menu timeout period in a step of 5 seconds DPMS Disable/Enable the DPMS function Auto Source Select Off / Low / High (disable or enable video source deletion) OSD Setting: OSD Horz Position Move the OSD menu horizontally OSD Vert Position Move the OSD menu vertically...
  • Page 15: Hardware

    After 50,000 hours of use, the two lamps used for LCD back lighting may become dim or burn out. You may return the monitor to Xycom for lamp replacement or you can order new lamps and follow the procedure below to install them. You can perform the lamp replacement procedure without removing the monitor from the NEMA enclosure where it is mounted, but you should do this only in a clean environment.
  • Page 16 Carefully slide the new lamps fully into place noting the top lamp has a small triangle molded in the end where the wires protrude. Similar triangles a stamped in the LCD sheet metal near the top hole. Reconnect the lamp wires to the inverter. These are keyed connectors permitting insertion in only one orientation.
  • Page 17: Appendix A: Reaching Technical Support

    5. Details of attempts made to rectify the problem(s) and results. 6. The log number assigned from Xycom Automation Technical Support if this is an ongoing problem. 7. The name of the Technical Support Engineer with whom you last spoke, if known.
  • Page 18 142026(A) Xycom Automation, Inc. 734-429-4971 • Fax: 734-429-1010 750 North Maple Drive http://www.xycom.com Saline, MI 48176...
