Summary of Contents for Xycom XT1502
-
Page 1: Hardware Guide
XT1502 FLAT PANEL INDUSTRIAL MONITOR FLAT PANEL INDUSTRIA Hardware Guide 142027(G) - Page 2 Xycom and Xycom Automation are trademarks of Xycom Automation, L.L.C. Xycom Automation, L.L.C. now is referred to as Pro-face through a D.B.A. The Pro-face name and logo will replace the Xycom name and logo on all documents where possible. Pro-face is a trademark of Digital Electronics Corporation.
-
Page 3: Table Of Contents
Table of Contents 1. Product Overview..…..................1 Product Features…………………………………………….……………………………………1 Standard XT1502 Features…………………………………………………………………….1 Parts List…………………………………………………….……………………………………1 Standard XT1502 Parts List…………………………………………………………………...1 Manual Overview…………………………………………….…………………………………..2 Text Conventions Used in this Manual …………………….……………………………………2 Product Dimensions ……………………………………….…………………………………….3 Front Panel Controls …………………………………………….……………………………3 Product Specifications and Ratings……..………………….……………………………………4 Environmental……...…….……………………………………………………………………4 Electrical ……………………………………………………………………………………...4 Front Panel/Enclosure ..…….…………………………….…………………………………..4... -
Page 4: Product Overview
Units ship with all necessary cables and software Parts List When you remove the XT1502 from its shipping carton, verify that you have the parts listed below. Save the box and inner wrapping in case you need to reship the unit. -
Page 5: Manual Overview
Manual Overview The manual is divided in the following chapters: • Chapter 1 – Product Overview • Chapter 2 – Installation • Chapter 3 – Monitor Settings • Chapter 4 – Hardware Text Conventions Used in this Manual Throughout this manual, certain terms are formatted in ways that indicate what type of object is being described. -
Page 6: Product Dimensions
Product Dimensions 13.48[342.4] in.[mm] 16.48[418.6] 3.25[82.60] Front Panel Controls The front panel controls, from left to right are Menu, Select, Increment, Decrement. Their use is detailed in Chapter 3— Monitor Settings. 142027(G) -
Page 7: Product Specifications And Ratings
Product Specifications and Ratings Environmental Operating Nonoperating Thermal 0°C to 50°C (32°F to 122°F) -20°C to 60°C (32°F to 122°F) Humidity 20% to 80% RH, noncondensing 20% to 80% RH, noncondensing 15 g peak acceleration, 30 g peak acceleration, Shock 11 msec duration 11 msec duration Vibration,... -
Page 8: Installation
2. Installation Environmental Considerations The rugged design of the XT1502 allows it to be installed in most industrial environments. Refer to the electrical and environmental specifications and tolerances (pg. 4) for more detailed information. System Power It is a good practice to use isolation transformers on the incoming AC power line to the system. -
Page 9: Electrical Noise
Electrical Noise Electrical noise is seldom responsible for damaging components, unless extremely high energy or high voltage levels are present. However, noise can cause temporary malfunctions that can result in hazardous machine operation in certain applications. Noise may be present only at certain times, may appear at widely spread intervals, or in some cases may exist continuously. -
Page 10: Location And Enclosure
contaminants from entering the enclosure. • Do not select a location near equipment that generates excessive electromagnetic interference (EMI) or radio frequency interface (RFI) (equipment such as high-power welding machines, induction heating equipment, and large motor starters). • Do not place incoming power line devices (such as isolation or constant voltage transformers, local power disconnects, and surge suppressers) near the system. -
Page 11: Monitor Settings
Not all video controllers produce exactly the same video output levels or the same timing. The XT1502 uses onscreen programming to make setup and adjustment easy. The menus are selected and the menu items are adjusted using the buttons located on the monitor front panel. -
Page 12: Onscreen Display (Osd) Functions
Onscreen Display (OSD) Functions Front Panel Controls The front panel controls, from left to right are Power, Menu, Select, Increment/Decrement. Power: Power on LED. Menu: Turns on the onscreen menu. Also steps to the next menu group. Select: These buttons highlight and select menu items. They also increase or decrease brightness. -
Page 13: Osd Submenu
OSD Submenu Menu Option Description Menu Horizontal Position Move the OSD horizontally Press ←or → (- >>>>>>>>>>>>>>> + nn), range: 0 to 62 Menu Vertical Position Move the OSD vertically Press ←or → (- >>>>>>>>>>>>>>> + nn), range: 0 to 60 Menu Transparency Adjust the transparent level of the OSD menu Press ←or →... -
Page 14: Installing The Touch Screen Driver
Installing the Touch Screen Driver If your Pro-face/Xycom flat panel monitor has the touch screen option, you will have to load the correct touch screen driver on the computer to which you will be connecting the monitor. The following steps should be performed on that computer. -
Page 15: Hardware
4. Hardware VGA Input Connector Pin Out Signal Name 15-pin D-Shell (Female) Green Blue GND-Digital GND-Red return GND-Green return GND-Blue return GND-Digital Hsync Vsync Back Light Replacement Procedure After 50,000 hours of use, the two lamps used for LCD back lighting may become dim or burn out. -
Page 16: Back Light Replacement Procedure
Reconnect the lamp wires to the inverter. These are keyed connectors permitting insertion in only one orientation. You may now want to clean the LCD and the inside of the monitor window or touchscreen with a slightly damp soft cloth. Carefully reunite the two monitor halves remembering to reconnect the touchscreen cable if the unit is so equipped. -
Page 17: Appendix A: Reaching Technical Support
Appendix A – Technical Support Reaching Technical Support Pro-face Technical Support offers a variety of support options to answer any questions on Pro-face products and their implementation. Refer to the relevant chapter(s) in your documentation for a possible solution to any problem you may have with your system. -
Page 18: Appendix B: Dimensions And Weight
Appendix B – Dimensions/Weight XT1500-ENC FRONT AND BOTTOM VIEW 13.50"[342.90 FRONT PANEL CONTROLS DISABLE REAR AND SIDE VIEW 9.72 SECTION SECTION 6.77 10-32 6 PLACES 11.17 8.22 5.26 TOUCH 3.15 POWER 1.39 ENTRY 2.93 4.84 11.64 WEIGHT: 19 lbs. 142027(G) - Page 19 142027(G) Xycom Automation, LLC. 734-429-4971 • Fax: 734-429-1010 750 North Maple Drive http://www.profaceamerica.com Saline, MI 48176...
