Page 1: User Manual
5017T Flat Panel Industrial Touch Monitor User Manual © © © © 2003 XYCOM AUTOMATION, INC. Printed in the United States of America... - Page 2 This document is copyrighted by Xycom Automation Incorporated (Xycom Automation) and shall not be reproduced or copied without expressed written authorization from Xycom Automation. The information contained within this document is subject to change without notice. Xycom Automation does not guarantee the accuracy of the information.
-
Page 3: Table Of Contents
CHAPTER 1 – INTRODUCTION ...........................1 ..............................1 RODUCT VERVIEW Standard Features ..............................1 Unpacking the Unit..............................1 CHAPTER 2 – INSTALLATION.............................3 ..............................3 RODUCT IMENSIONS 5017T Dimensions ..............................3 Front Panel Controls ..............................4 I/O Panel ................................4 .........................5 OCATION AND NCLOSURE ONSIDERATIONS ..............................6 ANEL NSTALLATION ..............................8... -
Page 4: Chapter 1 - Introduction
Unpacking the Unit When you remove the 5017T from its shipping box, verify that you have the parts listed below. Save the box and inner wrapping in case you need to reship the unit. - Page 5 5017T Flat Panel Industrial Touch Monitors Revision Record • Documentation and Support Library CD-ROM, which contains this manual and all drivers required by this unit. 143241(B)
-
Page 6: Chapter 2 - Installation
Chapter 2 – Installation Product Dimensions 5017T Dimensions Note: All dimensions are in inches. Figure 2-1. 5017T Dimensions 143241 (B) -
Page 7: Front Panel Controls
5017T Flat Panel Industrial Touch Monitor Chapter 2 – Installation Front Panel Controls Figure 2-2. 5017T Front Panel Controls Table 2-1. 5017T Front Panel Controls Functions Feature Description Menu This button is used to open and select options in the On Screen Display (OSD) menu. -
Page 8: Location And Enclosure Considerations
5017T Flat Panel Industrial Touch Monitor Chapter 2 – Installation Location and Enclosure Considerations • Account for the unit dimensions when selecting an installation location or enclosure (see page 3 for unit dimensions). • You can maintain the NEMA 4 seal by mounting the unit in an approved enclosure that has a 14-gauge (0.075"/1.9 mm thick) steel or (0.125"/3.2 mm thick) aluminum... -
Page 9: Panel Installation
Figure 2-4. 5017T Cutout Dimensions The 5017T has 14 total mounting clips: 4 on the both the top and bottom of the monitor, and 3 mounting clips on both of the sides. Hold the monitor in place while you install the mounting clips (see Figure 2-5 for mounting clip locations). - Page 10 5017T Flat Panel Industrial Touch Monitor Chapter 2 – Installation Figure 2-5. Mounting Clip Locations Insert the hook section into the slots and tighten the fastener with a screwdriver, as shown. Panel Mounting Clip Display Unit Figure 2-6. Fastening the Monitor to the Panel...
-
Page 11: Power Management
5017T Flat Panel Industrial Touch Monitor Chapter 2 – Installation Power Management The monitor is based on the VESA DPMS and the DVI DMPM standards. To activate the monitor' s Power Management function, both the video card and the computer must conform to the VESA DPMS standard and the DVI DMPM standard. -
Page 12: Excessive Heat
– DC Return Input Protective Earth Ground Caution: Use AWG18 wire or greater for the 5017T’s power cable. Isolate the AC main circuit line, I/O signal lines, and power cord - do not bind or group them together. Excessive Heat... -
Page 13: Line Voltage Variation
Hazardous Locations Installations Xycom Automation designed the systems with the intention of meeting the requirements of Class I, Division 2 Hazardous Locations applications. Division 2 locations are those locations that are normally non-hazardous, but potentially hazardous should an accident expose the area to flammable vapors, gases or combustible dusts. - Page 14 Suitable for use in Class I, Division 2 Groups A, B, C, and D, and Class II, Division 2, Groups F and G hazardous locations or non-hazardous locations only. Temperature Codes: T4A (5017T-24V), T4 (5017T) Warning - Explosion Hazard Substitution of components may impair suitability for Class I, Class II, Division 2.
-
Page 15: Definitions
Combustible dusts of an electrically conductive nature may be present in • • • • hazardous quantities. Note Xycom Automation 5017T, 5017T-24V systems are not suitable for installation within Division 1 locations. -
Page 16: Division 2 Locations
5017T Flat Panel Industrial Touch Monitor Chapter 2 – Installation Note Electrical equipment cannot be installed in Division 1 locations unless they are intrinsically safe, installed inside approved explosion-proof enclosures, or installed inside approved purged and pressurized enclosures. Division 2 Locations Class I volatile flammable liquids or flammable gasses are handled, processed, •... -
Page 17: Power Switch
5017T Flat Panel Industrial Touch Monitor Chapter 2 – Installation Power Switch The systems do not have a power switch. The amount of input power required by these systems classifies a power switch as an incendiary device because the voltage and current across the make/break device are capable of creating a spark. -
Page 18: Operation And Maintenance
Safety Agency Approval The Xycom Automation systems are designed to meet the following standards: • Underwriters Laboratories Inc., UL 1604 Standard for Safety Electrical equipment for use in Class I and Class II, Division 2, locations •... -
Page 19: Chapter 3 - Monitor Settings
Not all video controllers produce exactly the same video output levels or the same timing. The 5017T uses onscreen configuration menus to make setup and adjustment easy. The menus are selected and the menu items are adjusted using the buttons located on the front panel of the monitor. - Page 20 5017T Flat Panel Industrial Touch Monitor Chapter 3 – Monitor Settings Display utility menu Auto adjustment function Press MENU to select the highlighted adjustment menu; the first adjustment option in the menu will be highlighted. Use LEFT or RIGHT to adjust the value of the highlighted option.
-
Page 21: Reset Factory Default Settings
5017T Flat Panel Industrial Touch Monitor Chapter 3 – Monitor Settings Figure 3-4. Display Utility Menu Figure 3-5. Auto Adjustment Function Reset Factory Default Settings 1. Navigate to the menu and highlight Reset. 2. Press RIGHT to choose yes. 3. Press EXIT twice to reset the unit. A message will appear saying that factory defaults are being restored. -
Page 22: Video Modes
5017T Flat Panel Industrial Touch Monitor Chapter 3 – Monitor Settings Video Modes Table 3-1. Supported Video Modes NOTE All video modes are non-interlaced. If the monitor is receiving timing signals that are not compatible, [OUT OF TIMING] will appear. Follow your computer’s instruction manual to set the timing so that it is compatible with the monitor. -
Page 23: Chapter 4 - Operator Input
Chapter 4 – Operator Input Installing the Touch Screen Driver 1. Insert the Xycom Automation Documentation and Support CD in the CD-ROM. 2. Navigate to the \DRIVERS\TOUCHSCREEN\ELOGRAPHICS 141349 folder. 3. Run setup.exe -- it is recommended that you keep all default settings when installing the driver. -
Page 24: Accessing The "Mouse Right Button" Functionality With The Touch Screen
5017T Flat Panel Industrial Touch Monitor Chapter 4 – Operator Input Accessing the “Mouse Right Button” Functionality with the Touch Screen Note The Mouse Right Button functionality is supported on Windows 2000 and Windows XP models with either USB or RS-232 touch screens. It is also supported on Windows 98 models with RS-232 touch screens. -
Page 25: Chapter 5 - Hardware
Chapter 5 – Hardware VGA Input Connector Analog Signal Input Connector Pin (D-sub connector with 15 pins) Table 5-1. VGA Input Connector Pinout D-Shell (Female) Signal Name Green Blue GND-Digital GND-Red return GND-Green return GND-Blue return DDC 5V GND-Digital DDC SDA Hsync Vsync DDC SCL... -
Page 26: Serial Interface
Request Send Clear Send No Connection CD, DSR, and DTR are mutually connected inside the 5017T. Note Since all serial interface signals are the same on the PC side, use a straight cable to connect the 5017T to the PC. -
Page 27: Appendix A - Technical Specifications
Appendix A – Technical Specifications Hardware Specifications Table A–1. 5017T Hardware Specifications Characteristic Specification Mechanical* Height 14.70” (373.4 mm) Width 17.36” (440.9 mm) Depth 2.85” (72.4 mm) Weight 17 lbs (7.7 kg) Electrical AC Power 100-240 V AC, 1A, 50/60 Hz DC Power 18-30 V DC, 2.5A maximum... -
Page 28: Environmental Specifications
5017T Flat Panel Industrial Touch Monitor Appendix A – Technical Specifications Environmental Specifications Table A-2. 5017T Environmental Specifications Characteristic Specification Temperature Operating 0° to 50° C (32° to 122° F) Non-operating -20° to 60° C (-4° to 140° F) Humidity... -
Page 29: Appendix B - Technical Support
5. Details of attempts made to rectify the problem(s) and results. 6. The log number assigned from Xycom Automation Technical Support if this is an ongoing problem. 7. The name of the Technical Support Engineer with whom you last spoke, if known. -
Page 30: Product Repair Program / Returning A Unit To Xycom Automation
Xycom with the standard Xycom test diagnostics. Follow the steps below to prepare the unit for shipment: 1. Obtain an RMA number for your unit by calling your nearest Xycom Automation Repair Department or Xycom Automation, Inc. at 734-429-4971 or 1-800-AT- XYCOM. - Page 31 143241 (A) Xycom Automation, Inc. Canada Sales: 905-607-3400 734-429-4971 Northern Europe Sales: +44-1604-790-767 Fax: 734-429-1010 Southern Europe Sales: +39-011-770-53-11 http://www.xycom.com...
