ELECTRICAL CONNECTION

+12V
Anode of power connection terminals. Connect to the anode of car battery.
13 REM
Terminal to be connected with Remote cable, which comes from the source and which
controls the amplifier switching on. Applied voltage must be between 7 and 15 VDC.
GND
Ground terminal. Connect to the car chassis. Keep the length of the ground cable
to a minimum.
Connect to chassis
ground of vehicle*

SPECIFICATIONS

Model
RMS Power @ 13.8 VDC
Power @ 4 Ohms
Power @ 2 Ohms
Bridged Power @ 4 Ohm
Min. Speaker Impedance
THD Distortion
IMD Distortion
Frequency Response
Input Sensitivity
Input Impedance
Signal-to-Noise Ratio
Channel Separation
Remote gain Control
Crossover Network
Low Pass Filter
Bass Boost
High Pass Filter
Fuse Rating
Size Lx W x H
GND
Connect to +12Vof battery with
appropriate FUSE value.
CD PLAYER
SEL
Connect to remote
turn-on lead of
source unit.
PY-C4B39R
150W x 2
20Hz~20KHz
200mV~6V
0.25V~+6V
50Hz~300Hz
0dB~+12dB
50Hz~300Hz
350 x 242 x 52mm
60W x 4
90W x 4
2 Ohm
0.2%
0.2%
15K
90 dB
50 dB
25A x 2
2
