AquaCraft Miss Seattle Instruction Manual
  1. Manuals
  2. Brands
  3. AquaCraft Manuals
  4. Toy
  5. Miss Seattle
  6. Instruction manual

AquaCraft Miss Seattle Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
aquacraftmodels.com
WARNING
Never attempt to swim after a stalled R/C boat.
Never operate your R/C boat while standing in the water.
Never operate your R/C boat in the presence of swimmers.
Always use a Personal Flotation Device (PFD) when boarding and operating your
retrieval craft, i.e. Jon boat or duck boat. NOTE: Because of the sharp running
hardware included with this R/C boat, we do not recommend a rubber blow up raft.
R/C boat running hardware is very sharp. Be very careful when working on and around
the metal parts.
While the motor is running, pay close attention to the propeller. Do not come in contact
with the propeller at any time the engine is running or serious injury will result.
AquaCraft products are to be used by ages 14 and over.

Advertisement

Table of Contents
loading

Related Manuals for AquaCraft Miss Seattle

Summary of Contents for AquaCraft Miss Seattle

  • Page 1 While the motor is running, pay close attention to the propeller. Do not come in contact with the propeller at any time the engine is running or serious injury will result. AquaCraft products are to be used by ages 14 and over.

  • Page 2: Items Included

    80% usage target. In the stock configuration and on smooth water you will find your Miss Seattle Hydroplane will use around 200 to 225mAh per minute of operation during wide open operation. On rough water your Miss Seattle Hydroplane will use around 180 to 200mAh per minute.

  • Page 3: Warranty Service

    ➧ Two blade 30mm FRP propeller time you enter your retrieval craft. ➧ Transom drain plug ● AquaCraft products are to be used by ages 14 and over. ● Do not touch the propeller anytime the motor is running. MOTOR Pay equally close attention to items such as loose clothing, KV rating: 2200 kV @ 11.1V...

  • Page 4: Assembly Sequence

    6 Throttle Reversing Switch (“R” is the position the switch needs to be in for your Miss Seattle Hydro) 7 Throttle Trim Dial (this should be in the12:00 to 3:00 o’clock position for your Miss Seattle Hydro)
  • Page 5 Lightly lift the back and carefully slide the cowl forward. Tuck the wires neatly under the decking. Arming IMPORTANT! Always turn the transmitter ON before plugging in the battery. With the transmitter on, plug a charged battery into the controller. You will hear the motor chime, plus one beep letting you know the motor has power.

  • Page 6: Maintenance

    Place the boat in water that is at least 12" (305 mm) deep. Make sure the water is free of weeds, sticks or other floating debris. Your Miss Seattle is FAST and is designed to turn right. Left hand turns should only be performed at lower speeds. It is best to be aggressive with the throttle to overcome any cavatation that the boat might encounter as it starts to move forward.

  • Page 7: Performance Tuning

    Performance Tuning Keep in mind, as you tune your Miss Seattle Hydroplane for top speed and handling, that this boat IS SMALL AND FAST! Because of its size it only needs very small adjustments to change the way the boat performs.

  • Page 8: Ordering Replacement Parts

    The strut can be tweaked to change the ride of the boat but only experienced modelers should attempt this. If you are going to To order replacement parts for the AquaCraft Miss Seattle tweak the strut, remove the prop shaft and prop. Loosen the Hydroplane, use the order numbers in the replacement parts strut bolt.
