SVT-2 Outdoor Station A

User Manual

Please read this user manual prior to installing the system, and keep it well for future use.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SVT-2 Outdoor Station A and is the answer not in the manual?

Questions and answers

Related Manuals for SVT innovations SVT-2 Outdoor Station A

Summary of Contents for SVT innovations SVT-2 Outdoor Station A

  • Page 1: User Manual

    SVT-2 Outdoor Station A User Manual Please read this user manual prior to installing the system, and keep it well for future use.

  • Page 3: Parts And Functions

    Parts and Functions: The SVT-2 Outdoor Station A is audio outdoor station with external camera suitable for any angle mount. The front panel is made of zinc alloy for better protection against vandalism & cauterization. The call button is also made of zinc alloy and it has a blue backlight for auxiliary illumination.
  • Page 4 Unit Mounting The location of outdoor station should keep away from snow,rain,and intensity light. Accessory contents: Accessories include a screwdriver T20, one M4X10 screw, two PA4X25 screws,three PA3x25 screws,three PM3x12 screws,and five screw stoppers Φ6X30. Installation steps: Installation height for door station usually is 145~160cm. 1.
  • Page 5 Multi Outdoor Station Connection: 4# Camera 3# Camera 2# Camera 1# Camera ID=11 ID=01 ID=10 ID=00 Indoor Monitors Bus PL S2+ S1+ S1- Bus PL S2+ S1+ S1- Bus PL S2+ S1+ S1- Bus PL S2+ S1+ S1- DIP=on,off,off A B C D SVT-2 SVT-2 PC6 DBC-4...
  • Page 6 With SVT-2 DBC-4 Wiring Mode Indoor Indoor Monitor Monitor Impedance OFF ON switch DIP=on,off,off Indoor Indoor Monitor Monitor Indoor Indoor Monitor Monitor OFF ON Impedance switch DIP=on,off,off Indoor Indoor Monitor Monitor SVT-2 PC6 ID=00...
  • Page 7 Wiring diagram with SVT-2 AC31 camera: The SVT-2 audio Outdoor Station A works as a Video Outdoor Station when connected to the SVT-2 AC31 camera. SVT-2 AC31 Indoor SVT-2 PC6 Monitor Bus PL S2+ S1+ S1- SVT-2 Outdoor Station A Electric Lock Connection Door Lock Controlled with Internal Power Note:...
  • Page 8 Door Lock Controlled with Dry Contact Take off the Jumper Note: 1. The external power supply must be used PL S2+ S1+ S1- according to the lock. 2. The jumper must be taken off before connecting. 3. . Setup the Unlock Mode of Monitor for d ferent lock types.
  • Page 9 ON(1) OFF(0) SVT-2 Outdoor Station A DIP setting: Total 3 bits can be configured, bit-1 and bit-2 are used to assign ID code for the outdoor station, bit-3 is used to match the video impedance.The switches can be modified either before or after installation.

  • Page 10: Power Supply

    Bit State Description DIP1&2 Reserved. left to default. Set to OFF. When the monitor is in the middle of the line in daisy chain connection. DIP3 Set to ON. When the montior is at the end of the line or connected to a SVT-DBC4. Each indoor monitor should be assigned with an address in the system.

  • Page 11: Cable Requirements

    Cable Requirements Using different cables may affect the maximum distance which the system can reach. The farest monitor Indoor Monitor with two or four monitors Indoor Indoor Monitor Monitor SVT-2 DBC-4 SVT-2 PC6 When Monitor quantity < 20 Cable Usage 100 feet 200 feet 200 feet...
  • Page 12 The design and specifications of this user manual can be changed without any notification to the user. All copyright and interpretation rights are reserved to SVT Innovations Inc. . Right to interpret and copyright of this manual are preserved. Printed 2012. 09...
