Page 1: User Manual
SVT-2 Outdoor Station B User Manual Dan Smith SVT-2 Outdoor Station B 2W12120 Please read this user manual prior to installing the system, and keep it well for future use. -
Page 2: Table Of Contents
CONTENTS 1.Parts and Functions..................... 1 2.Terminal Descriptions ..................1 3.Specification ...................... 2 4.Mounting ......................2 4.1 Mounting Without Rain Guard ............... 2 4.2 Mounting With Rain Guard ................3 4.3 External Motion Detection................4 5.System Wiring and Connections ................. 4 5.1 Basic Connection................... -
Page 3: Parts And Functions
1.Parts and Functions [10] [11] [12] [13] [1] Microphone [6] Front panel [10] Rain cover [11] Mounting hook [2] UNLOCK indicator [7] Speaker [3] CALL indicator [8] Night view LED [12] Connection port [13] Screw hole [4] Call button [9] Camera lens [5] Nameplate 2.Terminal Descriptions Lock Control... -
Page 4: Specification
Lock Control Jumper: To select the lock type. Motion Detector Connect Port: To connect external PIR motion detector. Main Connect Port: To connect the bus line and the electronic locks. • L1,L2: Connect to the bus line, no polarity. • PL: External lock power input, connect to the power positive(power +). •... -
Page 5: Mounting With Rain Guard
4.2 Mounting With Rain Guard The distance between the top of main unit and rain cover should be not less than 3mm. Rainy cover Main unit Rainy cover Main unit AcDbMLeader (ACDB_MLEADER_CLASS) AcDbMLeader (ACDB_MLEADER_CLASS) 1. . Connect the cable correctly . 2. -
Page 6: External Motion Detection
4.3 External Motion Detection The door station is equipped with a terminal to connect external motion detector. If the external motion detector is connected to the system,following functions will be effec- tive: If detect someone passing by, the door station Motion detector can be activated operation to unlock or turn... -
Page 7: Electric Lock Connection
5.2 Electric Lock Connection 5.2.1 Door Lock Controlled with Internal Power 1 2 3 1.Electronic lock of Power-on-to-unlock type should be used. Jumper position on 2&3 2.The door lock is limited to 12V, and hold- ing current must be less than 250mA. PL S+ S- 3.The jumper should be placed on position 2 and 3 before connecting. -
Page 8: Multi Outdoor Stations Connection
5.3 Multiple Outdoor Stations Connection door station door station door station door station ID=0 ID=1 ID=2 ID=3 L1 L2 PL S+ S- L1 L2 PL S+ S- L1 L2 PL S+ S- L1 L2 PL S+ S- To monitors 100~240VAC A B C D SVT-2 DBC4 SVT-2 PC6... -
Page 9: Multi Indoor Monitors Connection
5.4 Multiple Indoor Monitors Connection 5.4.1 Basic IN-OUT Wiring Mode 100~240VAC SVT-2 PC6 BUS(IM) BUS(DS) Optional modules ID=0... -
Page 10: With Dbc-4 Wiring Mode
5.4.2 Using SVT-2 DBC-4 distributor device - Wiring Mode Code=1 Code=2 Impedance OFF ON switch Code=3 Code=4 SVT-2 SVT-2 85~260AC SVT-2 BDU SVT-2 DBC4 SVT-2 RCL ID=0 Optional modules... -
Page 11: Setup Instructions
Setup Instructions This section explains the settings of each function,please refer to the following table: To perform the settings for the function LED_UNLOCK you want,you should move away the metal LED_TALK front panel. Please refer to the sketch KEY_SET map. KEY_4 LED_NAME KEY_3... - Page 12 Setting Door Station Address Total 4 addresses can be configured. It can be modified either before or after installatio 0 is default, to change the setting, please follow the steps: ID=0,1 door station ID=1,2 door station ID=2,3 door station ID=3,4 door station In standby mode, press UNLOCK Indicator:OFF...
- Page 13 • If setting mode has not been exited, you can change the address of door station by pressing KEY1~4 freely. • The LED_NAME indicator will always blink until exit out the setting mode. • If without any operation in 10 seconds, it will exit out setting mode automatically. •...
- Page 14 Setting Nameplate Illumination Mode There are 3 illumination modes for nameplate indicator, Normally on,Normally off and Auto. Normally on is default, to change the setting, please follow the steps: In standby mode, press Press KEY_3 button to set Press KEY_3 button again Press KEY_3 button again KEY_SET button three the nameplate illumination...
- Page 15 Setting Ring-back Tone If allow ring-back tone, press the call button to call monitor, a ring-back call tone can be heard from door station. There are 3 ring-back call tones, Ringing one time,Ringing continuously and No ring-back tone. Ringing one time is default, to change the setting, please follow the steps: In standby mode, press Press KEY_1 button to set Press KEY_1 button again...
- Page 16 6.2 DIP Switches Settings of Indoor Monitor There are 3 DIP switches in total. Bits 1 and 2 are reserved and must be on the default position. The Bit 3 is used to configure the position of each indoor monitor in the connection line. It must be set to ON if the indoor monitor is in the end of the line, parallel connection, or connected to a SVT-2 DBC-4 module.
-
Page 17: Power Supply
6.3 Power Supply Specifications Name Description It supplies power for the outdoor stations, Input Voltage: 100 ~ 240Vac indoor monitors and other accessories. It Input Frequency: 50 ~ 60Hz SVT-2 PC6 supports up to 8 indoor monitors. Rated Output Voltage: DC 28V, 2V Rated Output Current: 1.5A It provides power for the outdoor stations, Input Voltage: 100~120VAC (2.5A),... -
Page 18: Cable Requirements
7.Cable Requirements Using different cables may affect the maximum distance which the system can reach. When Monitor quantity ≤ 2 Cable Usage 328 feet 200 feet CAT5 cable (1 pair of wire per 60 meters 100 meters conductor - must solder the ends) 14 AWG Speaker Wire 260 feet 393 feet... - Page 19 -17-...
- Page 20 The design and specifications of this user manual can be changed without any notification to the user. All copyright and interpretation rights are reserved to SVT Innovations Inc.
