SVT-IP Video Intercom System A User Manual Please read this user manual prior to installing the system, and keep it well for future use. -
Page 2: Table Of Contents
CONTENTS 1. Parts and Functions..................... 1 2. Terminal Descriptions ..................1 3. Specification ...................... 2 4. Mounting ......................2 5.System Wiring and Connections................3 5.1 System Wiring Diagram.................. 3 5.2 Electric Door Lock Connection ............... 4 6. Setup ........................4 6.1 Wi-Fi Wireless Connection .... -
Page 3: Parts And Functions
1.Parts and Functions Front View Rear View Speaker LED Light Camera RJ45 Door bell Call Button Name Plate Ethernet Cable Exit Button Antenna Power Supply Keypad Electric Door Lock Microphone 2.Terminal Descriptions... -
Page 4: Specification
Wi-Fi: Wireless connection. Connect the antenna to enable Wi-Fi connection RJ45: Ethernet cable connection. Connect the Ethernet cable to a modem when Wi-Fi is out of the range of your Wi-Fi network. CN2: 1&2: Exit Button connection. 3, 4 & 5: Door Lock connection. DOORBELL: External doorbell connection POWER: Outdoor Station's power supply connection. -
Page 5: System Wiring And Connections
5.System Wiring and Connections 5.1 System Wiring Diagram... -
Page 6: Electric Door Lock Connection
Android users can download the ControlCam App directly from the Google Play Store, and IOS users can download it from the Apple Store. Both download and usage are free for SVT Innovations users. >Download the ControlCam App, and install it in your smart phone or tablet. -
Page 7: Wi-Fi Wireless Connection
>There are two ways to connect the Outdoor Station to the network/router: 1. Wi-Fi wireless connection (Note that ControlCam App works with 2.4Ghz network) 2. RJ45 Ethernet cable connection 6.1 Wi-Fi Wireless Connection: 6.1.1. iPhone/iPad users: Step 1: Once the ControlCam App is downloaded and installed, ensure your iPhone or iPad is connected to the same Wi-Fi network as the one you are going to connect the SVT-IP system;... -
Page 8: Android Users
6.1.2. Android users: Step 1: Once the ControlCam App is downloaded and installed, ensure your smart phone or tablet is connected to the same Wi-Fi network as the one you are going to connect the SVT-IP system; Step 2: Attach the Antenna to the Wi-Fi pin on the back of the outdoor station; Step 3: Open the ControlCam App, and select "Enter Now";... -
Page 9: Rj45 Ethernet Cable Connection
6.2 RJ45 Ethernet Cable Connection If you are installing the SVT-IP Outdoor Station in a place out of the range of your Wi-Fi network, you may use the RJ45 Ethernet cable connection instead. You must first connect it to the Wi-Fi network following the instructions on pages 5 or 6. -
Page 10: How To Add Additional Users To The Svt-Ip Outdoor Station
Step 5: You can now connect the RJ45 cable to the SVT-IP Outdoor Station and then connect the Ethernet cable to the router. Step 6: The setup is complete. You can now remove the antenna from the SVT-IP Outdoor Station. 6.3 How to add additional users to the SVT-IP Outdoor Station: Step 1: Open the ControlCam App, select "Enter Now";... -
Page 11: System Settings
7. System settings The system settings can be reviewed and changed on the "IP Camera configuration page. To login, follow the steps 1 - 3 on page number 7. Adjust the date and time: Select Config. - System - System time. You may adjust the settings selecting NTP Server, Synchronize with local computer or set the time manually. -
Page 12: How To Delete A Device/Change The Unlock Code
8.6 How to delete a device: Step 1: Select "..." on the top right corner of the screen; Step 2: Select "OFF" in the Outdoor call-in option; Step 3: Select "Edit", then "Delete"; Step 4: Select "OK" to confirm the action and delete the device. 8.7 Change the unlock code: Step 1: Select "..."... -
Page 13: How To Enter The Programming Mode
9.2 How to enter the programming mode: 1. Press the * button and after a "Di" sound is heard, enter the programming code. Another "Di" sound is heard. To exit the programming mode, press the button at any time. Note, the system will exit the programming mode automatically if no action is made within 30 seconds. -
Page 14: Delete User Codes Directly
9.6 Delete user codes directly: 1. To delete user codes directly, enter the programming mode. 2. Press the # button and after a "DiDi" sound is heard, enter the 2-4 digits user code you would like to delete. 3. A long "Di" sound is heard; it indicates the user code has been successfully deleted. -
Page 15: Power Supply
10. Power Supply Specifications Name Description Input Voltage: 100 ~ 240Vac Input SVT-IP It supplies power for the outdoor station Frequency: 50 ~ 60Hz 0.6A POWER SUPPLY only. Output: DC 15V 1.5A (IP14310) Working temperature: 14°F to 104°F / -10°C to 40°C -13-... - Page 16 The design and specifications of this user manual can be changed without any notification to the user. All copyright and interpretation rights are reserved to SVT Innovations Inc.
