SVT-4 Outdoor Station C

User Manual

Please read this user manual prior to installing the system, and keep it well for future use.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SVT-4 Outdoor Station C and is the answer not in the manual?

Questions and answers

Related Manuals for SVT innovations SVT-4 Outdoor Station C

Summary of Contents for SVT innovations SVT-4 Outdoor Station C

  • Page 1: User Manual

    SVT-4 Outdoor Station C User Manual Please read this user manual prior to installing the system, and keep it well for future use.

  • Page 2: Table Of Contents

    CONTENTS 1. Parts and Functions....................1 2. Terminal Descriptions ..................2 3. Specifications....................... 3 4. Mounting ....................... 3 4.1 Mounting without the Rain Guard..............3 4.2 Mounting with the Rain Guard................4 4.3 Mounting the Indoor Monitor................4 5. System Wiring and Connections ................. 5 5.1 SVT-4 System with one entrance ..............

  • Page 3: Parts And Functions

    1.Parts and Functions Description LED lights High resolution camera Built-in speaker Call button Built-in microphone Keypad Status light. Calling in: red light Monitoring/Talking: blue light Description Built-in microphone Monitor button Intercom button Door unlock button Talk button TFT 7” color display Built-in speaker Talking/Ring volume Brightness...

  • Page 4: Terminal Descriptions

    2.Terminal Descriptions...

  • Page 5: Specifications

    3.Specifications INDOOR MONITOR OUTDOOR STATION Voltage: DC 14.5V Voltage: DC 14.5V Communication duration: 120s. NO/NC: Max. 14.5V, 120mA Lock Power Supply: Must be used according to lock. Communication transmission: 2-way communication Working temperature: 14°F to 131°F / -10°C to 55°C Unlocking time: 01 - 99 seconds Communication duration: 120s.

  • Page 6: Mounting With The Rain Guard

    4.2. MOUNTING WITH THE RAIN GUARD Screw anchors Wall hole Rain cover Screws Screws (fix with rain cover) 4.3. MOUNTING THE INDOOR MONITOR...

  • Page 7: System Wiring And Connections

    System Wiring and Connections 5.1. SVT-4 SYSTEM WITH ONE ENTRANCE Power supply for lock Outdoor station 1...

  • Page 8: Svt-4 System With Two Entrances

    5.2. SVT-4 SYSTEM WITH TWO ENTRANCES Power supply for lock Power supply for lock Outdoor station 2 Outdoor station 1...

  • Page 9: Svt-4 Wiring Connection

    5.3. SVT-4 WIRING CONNECTION 5.3.1 Indoor Monitor 1. Red 2. Blue 3. Yellow 4. White 1-Audio 2-GND 3-V+ 4-Video 1. Red 1. Red 2. Blue 2. Blue 3. Yellow 3. Yellow 4. White 4. White NOTE: Do not remove any of the jumpers from the back of the indoor monitors.
  • Page 10 Adjust Camera Position Adjust Talking Volume To Indoor Monitor Exit Button Door Lock...

  • Page 11: Electric Door Lock Connection

    5.3.3 Electric Door Lock Connection 1. Use the port J3 of the lower module to connect a door lock. 2. The door lock is limited to 14.5V, 120mA. 3. Must use an additional power supply for the door lock. Ensure the power supply is compatible with the door lock specifications.

  • Page 12: Cable Requirements

    6.Cable Requirements Cable Usage CAT5 cable (must solder the wires together to ensure a good connection). 230 feet 30 feet Using different cables may affect the maximum distance the system can reach. 70 meters 10 meters NOTE: 1. The system expands to a maximum of 2 outdoor stations and 4 indoor monitors. 2.

  • Page 13: User Instructions

    7.User instructions Visitor calls The visitor presses The visitor presses the call button the call button on outdoor on outdoor station-1 station-2 Ring Ring Press the call button at anytime, the indoor monitor will show the view The visitor image shown on from front door...

  • Page 14: Monitor

    Monitor Press the monitor button Press once Press twice Monitor outdoor Monitor outdoor station 1 station 2 The indicator light of The indicator light of Door 1 is on. Door 2 is on. Press the Press the monitor talk button button Monitor the Press the...

  • Page 15: Intercom

    Intercom In the standby mode, press intercom button indoor monitor All indoor monitors ring indoor monitor presses button or pick up the handset to talk. During the talking, any indoor monitor presses the intercom Talk begins button Press the TALKPress the TALKING button hang-upbutton or hang-...

  • Page 16: How To Set Up User Codes

    8. How to set up the user codes 1. The original factory default programming password is 1234. 2. In the programming mode, set 40 groups of 4-digit codes for door open. Set programming code 1. Switch off the power, press * and hold, switch on the power. After hearing a long sound, release *.
  • Page 17 Add user passwords 1. Enter to the programming mode first. 2. Enter position 01- 30 (31-40 can not set unlocked time as they are normal open/closed). 3. Enter 4-digit password. If long "DI" sound is heard twice, it indicates password stored fails, and this password exists somewhere else.
  • Page 20 The design and specifications of this user manual can be changed without any notification to the user. All copyright and interpretation rights are reserved to SVT Innovations Inc.
