- Page 1 SVT-IP Video Intercom System A/B User Manual Please read this user manual prior to installing the system, and keep it well for future use.
-
Page 2: Installation
Quick Start Guide INSTALLATION Install outdoor sta on on the wall as shown below and then wire it up. Plas c wall plug Back case Screws System Wiring Screws Plas c wall plug Screws System Wiring Rain Cover CONTROLCAM SETUP Android users can download ControlCam App from Google Play;... - Page 3 NOMENCLATURE Rear View Front View Speaker LED Light Camera RJ45 Door bell Ethernet Cable Name Plate Call Button Exit Button Antenna Power Supply Electric Keypad Door Lock Microphone Front View Rear View Speaker LED Light Camera RJ45 Door bell Ethernet Cable Name Plate Call Button Exit Button...
-
Page 4: Wifi Wireless Connection
WIFI WIRELESS CONNECTION a. For iPhone or iPad: Step 1: Connect the WiFi from the outdoor sta on in the WiFi list on iPhone or iPad; choose the WiFi name like “LIDxxxxxxxx”; Step 2: Open the ControlCam App; Step 3: Click “Add a Device”; Step 4: Click “Add a New Device”;... -
Page 5: Rj45 Ethernet Cable Connection
Step 7: Set WiFi informa on; Input the WiFi password and wait 100 seconds. Step 8: It will show “Configura on is successful please add the device to the phone”, then click “OK” to confirm; Step 9: Input the default User Name (admin) and Password(1234), click “OK”... - Page 6 Step 3: Click Config – Network Se ngs – L A N– Set I P and Gateway as the same segment as your LAN network (for example, if your LAN network gateway is 192.168.0.1, set IP to the same segment as LAN network gateway, here set as the same as the found WiFi IP address 192.168.0.88) Step 4: A er comple ng the above se ngs, connect your outdoor sta on...
- Page 7 3. How to add more smart phones(or tablets) to the network outdoor sta on Step 1: Open the ControlCam App on the smart phone (or tablet); Step 2: Click “Enter Now”; Step 3: Click “Add a Network Device”; There are three ways to add the network outdoor sta on: a .
- Page 8 3. Monitoring Click the image on the main interface to monitor the outside environment. If you want to talk with the visitor and hear the sound, click the icon on the screen to start talking. 4. Image Capture Click the icon to capture an image.
-
Page 9: Modify The Programming Password
How to set user passwords on outdoor sta on *The below instruc on is for outdoor sta on with keypad only. *The original factory default programming password is 1234(not access code).In the programming mode, 40 groups of 4-digit passwords can be set to unlock door lock. -
Page 10: Add User Passwords
5. Add user passwords 1). Enter the programming mode . 2). Enter 2 digits from 01-40 (the digits 31-40 are for normal open or normal close, these digits are not allowed to set the unlocking me) , along Di sound is heard. 3). -
Page 11: Delete All Settings
9. Delete all settings 1). Enter the programming mode . 2). Press #, when a DiDi sound is heard, press # again, along Di Sound can be heard, then press # for 7 times, after 3 seconds, another long Di sound will be heard, it indicates deleting successfully (The unlock time changes to 1 second and the programming password does not change). - Page 12 The design and specifications of this user manual can be changed without any notification to the user. All copyright and interpretation rights are reserved to SVT Innovations Inc.
