KY102
7.2 CoVERAGE SwITCh
KY102 features a switch which allows users to select the vertical coverage of the speaker.
Flood coverage sets a wide vertical diffusion angle of 30°. Flood coverage is suggested for single
speakers in diffused short throw applications to obtain maximum diffusion with a minimum footprint.
Spot coverage sets a narrower vertical diffusion angle of 7° and is recommended for long throw or
monitoring application.
When more units are combined in a line array configuration, make sure to set the coverage to Spot.
SPOT Coverage - 7°
FLOOD Coverage - 30°
Ver. 1.2
9
