- Page 1 20V WORX saw Elektrische kreissäge Scie circulaire électrique Motosega circolare Sierra circular eléctrica Elektrische cirkelzaag Pilarka elektryczna Elektromos körfűrész Ferăstrău circular electric P106 Elektrická okružní pila P118 Elektrická okružná píla P130 WX523...
- Page 2 Original instructions Originalbetriebsanleitung Notice originale Istruzioni originali Manual original Oorspronkelijke gebruiksaanwijzing Tłumaczenie oryginalnych instrukcji Eredeti használati utasítás Traducerea instrucţiunilor iniţiale Překlad původních pokynů Preklad pôvodných pokynov...
- Page 7 17. BLADE BOLT (See Fig. B) 18. OUTER FLANGE (See Fig. B) 19. LASER ON-OFF SWITCH (See Fig. G1) 20. LASER BATTERIES (TWO) (See Fig. G2) Not all the accessories illustrated or described are included in standard delivery. 20V WORX saw...
-
Page 8: Technical Data
TECHNICAL DATA Type WX523 (5-designation of machinery, representative of Saw) Voltage 100-240V ~ 50/60Hz No load (rated) speed 2200/min TCT blade 85mmx15mmx1.2mmx24T Blade size HSS blade 85mmx15mmx1.2mmx44T Diamond disc 85mmx15mmx1.2mmx60G Max cutting depth 27mm Wood 27mm Aluminum Recommended maximum material... - Page 9 Use good quality accessories marked with a well-known brand name. Choose the type according to the work you intend to undertake. Refer to the accessory packaging for further details. Store personnel can assist you and offer advice. 20V WORX saw...
-
Page 10: Cutting Procedures
If saw blade is binding, it may walk up or kickback from the workpiece as the saw is restarted. d) Support large panels to minimize the risk of blade pinching and kickback. 20V WORX saw... -
Page 11: Safety Instructions For Battery Pack
Be aware of the time it takes for m) Always purchase the correct cell or battery the blade to stop after switch is released. 20V WORX saw... -
Page 12: Safety Instructions For Abrasive Cutting- Off Operations
The eye protection tool. Accessories running faster than their must be capable of stopping flying debris 20V WORX saw... -
Page 13: Kickback And Related Warnings
Corners, sharp edges or bouncing have a tendency to snag the rotating accessory and cause loss of control or kickback. e) Do not attach a saw chain, woodcarving blade, segmented 20V WORX saw... -
Page 14: General Safety
650nm wavelength. CLASS 2 LASER RADIATION, DO NOT STARE INTO BEAM GENERAL SAFETY WARNINGS FOR YOUR LASER WARNING: Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in serious injury. 20V WORX saw... - Page 15 Please recycle where facili- ties exist. Check with your local authorities or retailer for recycling HSS blade advice. Make sure the battery is removed prior to changing accessories. TCT blade Wear protective gloves Wood Metal 20V WORX saw...
-
Page 16: Working Hints For Your Tool
Check with your local authorities or retailer for run your circular saw no load for 2-3 minutes recycling advice. to cool the motor. Avoid prolonged usage at very low speeds. Protect saw blades against impact and shock. 20V WORX saw... -
Page 17: Troubleshooting
Saw is not being guided mounted. properly. Use a parallel guide. Allow the saw blade to reach full Blade kicks back when Blade is not spinning fast speed prior to beginning a cut in the beginning a cut enough material. 20V WORX saw... -
Page 18: Declaration Of Conformity
CONFORMITY POSITEC Germany GmbH Konrad-Adenauer-Ufer 37 50668 Köln Declare that the product, 20V WORX saw Description Type WX523 (5-designation of machinery, representative of Saw) Function Cutting various materials with a rotating toothed blade Complies with the following Directives, 2006/42/EC 2004/108/EC... - Page 19 Copyright © 2014, Positec. All Rights Reserved. 2CSC08APK11001A0...
