- Page 1 CLASS 1 LASER PRODUCT KLASSE 1 LASER PRODUKT I.H.T. IEC 825 Model CC4300 User Guide Multiple Compact Disc Player...
- Page 2 DEUTSCH GARANTIE Bei Garantiefragen wenden Sie sich bitte an Ihren Marantz-Händler. HEBEN SIE IHRE QUITTING GUT AUF Die Quittung dient Ihnen als bleibende Unterlage für Ihren wertvollen Einkauf Das Aufbewahren der Quittung ist wichtig, da die darin enthaltenen Angaben für Versicherungswecke oder bei Korrespondenz...
- Page 3 ENGLISH: CAUTION – USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE. FINNISH: VAROITUS! Laitteen käyttäminen muulla kuin tässä käyttöohjeessa mainitulla tavalla saattaa altistaa käyttäjän turvallisuusluokan 1 ylittävuälle näkymättömälle lasersäteilylle.
-
Page 4: Table Of Contents
Contents General Information ...2 Foreword...2 Unpacking ...2 For Your Safety...2 Compact Discs...3 Placement ...3 Functional Overview ...4 Front Panel Controls ...4 Rear Panel Controls...6 Remote Control Unit (RC4300CC)...7 Connections...9 Connecting other Audio Equipment ...9 Connecting the Remote Control...10 Operations ...11 Playing CDs ...11 Changing Discs during Play...12 Skip and Search Play...12... -
Page 5: General Information
This product is in conformity with the EMC directive and low-voltage directive. Equipment mains working system Your Marantz product complies with the household power and safety requirements in your area. “/N1” Version product can be powered by 230 V AC only. -
Page 6: Compact Discs
• In a cabinet, allow about 2 inches of free space all around the player for adequate ventilation. • If the CD player cannot read CDs correctly, use a commonly-available cleaning CD to clean the lens before taking the CD-player to be repaired. Other cleaning methods may destroy the lens. -
Page 7: Functional Overview
Press this switch to turn the power on and press again to turn to stand by. w w STANDBY indicator Lights up red when the CD player is in Stand-by mode. e e Disc tray Load a compact disc on the disc tray. -
Page 8: Fluorescent Display
§ ! ! 8 8 (Forward skip/Search) button • Press this button to play from the beginning of a next track. • Press and hold down this button to search for a specific passage in fast forward. ! ! 9 9 (Play/Pause) button •... -
Page 9: Rear Panel Controls
For the D-BUS cable connection, use supplied remote control cable or a commercially available RCA-type pin lead. • By connecting this CD player to a Marantz auto reverse cassette deck (such as the SD4050), automatic recording from the CD player to the cassette deck can be carried out. -
Page 10: Remote Control Unit (Rc4300Cc)
Remote Control Unit (RC4300CC) DISC POWER REPEAT RANDOM PROGRAM DELETE INTRO EDIT T.SIZE DIMMER TIME REMOTE CONTROL UNIT RC4300CC q POWER button Press this button to turn the power on and press again to turn to stand by. w REPEAT button Press this button to play a track, a disc or all discs repeatedly. -
Page 11: Operation Of Remote Control Unit
Functional Overview ❖ Operation of Remote Control Unit 1. Remote control The distance between the transmitter of the remote control unit and the IR SENSOR of the CC4300 should be less than about 5 meters. If the transmitter is pointed to a direction other than the IR SENSOR or if there is an obstacle between them, remote control may not be possible. -
Page 12: Connections
Connections Precautions concerning connections : • Do not plug the AC input cord into the AC outlet when plugging and unplugging connection cords. • Be sure to connect the white plugs to the L(Left) and the red plugs to the R(Right) jacks when making connections with the supplied cords. -
Page 13: Connecting The Remote Control
Connections Connecting the Remote Control CC4300 RS232C REMOTE REMOTE DIGITAL OUT DIGITAL OUT ANALOG OUT ANALOG OUT REMOTE CONTROL REMOTE CONTROL CONTROL CONTROL SELECTOR SELECTOR COAX. COAX. OPTICAL OPTICAL EXT. INT. EXT. INT. INT. EXT. REMOTE CONTROL Amplifier / Receiver MODEL NO. -
Page 14: Operations
Operations Playing CDs 1. Press the POWER ON/STANDBY button on the unit or the POWER button on the remote control to turn on the power. STANDBY POWER ON/STANDBY DISC • Each time the POWER ON/STANDBY (or POWER ) button is pressed, this unit is turned on or off. 2. -
Page 15: Changing Discs During Play
Operations Changing Discs during Play 1. Press the OPEN/CLOSE button on the unit to open the disc tray. OPEN/CLOSE 2. Change the desired discs. Disc tray • During playing the disc q, the discs e and r can be changed. •... -
Page 16: Playing Tracks In Random Sequence (Random Play)
Playing Tracks in Random Sequence (Random Play) ❖ 1 Disc Random Play • Press RANDOM button on the unit or the RANDOM button on the remote control to play tracks in random sequence. RANDOM PROGRAM DELETE • “RANDOM” indicator lights up. •... -
Page 17: Repeat Play
Operations Repeat Play ❖ Repeating a Single Track during Play • Press REPEAT button on the unit or the REPEAT button on the remote control after selecting the desired track. REPEAT DISC PROGRAM DELETE ❖ Repeating a Disc during Play •... - Page 18 3. Select the desired track. ∞ § Press buttons on the unit or the button or the NUMERIC buttons on the remote control. (Example) When selecting the track 4. EDIT T.SIZE DIMMER TIME REMOTE CONTROL UNIT RC4300CC PROG TRACK 4. Store the selected track in the memory. Press PROGRAM button on the unit or the PROGRAM button on the remote control.
- Page 19 Operations ❖ Rectifying Any Wrong Programmed Selection (Example) When the track 3, 5 and 7 of the disc 1 are programmed and you want to store the track 7 of the disc 3 instead of the track 5 of the disc 1. 1.
- Page 20 ❖ Clearing the Programmed Selections - To Clear One by One • Each time Stop/Clear button on the unit or the Stop/Clear button on the remote control is pressed in the program mode, the programmed selections are cleared one by one in the opposite sequence. PROGRAM DELETE EDIT...
-
Page 21: Editing For Recording
Operations Editing for Recording Note : • Up to 30 tracks for auto edit or 32 tracks for manual edit can be edited according to the tape length. • It is possible only on the current disc. Disc selector DISC SKIP •... - Page 22 ❖ Setting Up Manual Edit 1. In the stop mode, select the manual edit mode. Press EDIT button on the unit or the EDIT button on the remote control. EDIT EDIT T.SIZE DIMMER REMOTE CONTROL UNIT RC4300CC EDIT 2. Select the tape length as you do in “Making auto edit”...
- Page 23 Programmed Selections” on page 16 and 17. ❖ Start Edit Recording Before start editing, connect remote control input of Marantz cassette deck with remote control output of CC4300 by remote control cable. RANDOM Reverse mode switch may be set to any of one side (O), both sides (p) and continuous play (∏).
- Page 24 - Synchro recording with Marantz one-way cassette deck, or Marantz auto reverse cassette deck set to one side (O) mode. 1. After setting up Edit program automatically or manually, setup the cassette deck to rec pause state. 2. Press Play/Pause button of the unit to start A side program.
-
Page 25: Deleted Play
Operations Deleted Play When there are the undesired discs or tracks, you can delete up to 32 selections. ❖ Deleting the Undesired Discs or Tracks 1. In the stop mode, enter the delete mode. Press DELETE button on the unit or the DELETE button on the remote control. - Page 26 5. When deleting other tracks on that disc within 8 seconds after the above step 4, repeat the above steps 3 and 4 and when deleting the tracks on other discs, repeat the above steps 2, 3 and 4. 6. Start the deleted play. Press Play/Pause button on the unit or the Play button on the remote control.
-
Page 27: Selecting A Brightness Of The Display
Operations ❖ Recovering the Deleted Selections - To Recover One by One • Each time Stop/Clear button on the unit or the Stop/Clear button on the remote control is pressed in the delete mode, the deleted selections are recovered one by one in the opposite sequence. PROGRAM EDIT T.SIZE... -
Page 28: Selecting A Time Display
Selecting a Time Display • Each time TIME button is pressed during play, time display changes as follows: TIME EDIT T.SIZE DIMMER REMOTE CONTROL UNIT RC4300CC Elapsed playing time of the current track. TRACK INDEX Remaining playing time of the current track TRACK INDEX Remaining playing... -
Page 29: External Control (Serial Interface) Rs-232C
Operations External Control (Serial Interface) RS-232C The unit can receive external control signals and transmit status information by connecting a cross cable on the market to the D-sub 9 pin connector for RS-232C external control. ❖ Pin Assignment of the Connector RS-232C ❖... - Page 30 • Remote Control Unit (RC4300CC) RC-5 Code The unit can be controlled through its infrared IR sensor on the front panel when it receives remote control signals that supports RC-5 signals as shown in the table on the following. These remote control (RC-5) codes can also be used if sent through the RS232C port found on the rear panel of the unit.
-
Page 31: Troubleshooting
Troubleshooting If your unit should not perform as expected, consult the table below to see if the problem can be corrected before seeking help from your dealer or our service organization. Problem No power No play No sound Poor or distorted sound Sound skips Programming or deleting does not perform. -
Page 32: Specifications
Specifications SYSTEM ... Compact Disc Digital Audio TYPICAL AUDIO PERFORMANCES Number of channels ... 2 Frequency response, 20~20,000 Hz ... ±0.5 dB Signal to noise ratio, A Wtd..110 dB Dynamic range ... 95 dB Total harmonic distortion, 1 kHz ... 0.005 % Wow and flutter ... - Page 33 P.O. Box 685, Bell Village, Port Louis, Mauritius PO BOX 1280, Sandhausen 69200, Germany A division of Marantz Europe B.V., Building SFF2, P.O. Box 80002, 5600 JB Eindhoven, The Netherlands 14 Malvern Road, Mt. Albert, Auckland, New Zealand Sandkerveien 64, Oslo 0483, Norway P.O.
