Technibel GRV72L5TA Technical Data & Service Manual

Split system air conditioner
Hide thumbs
Table of Contents

Advertisement

Quick Links

TECHNICAL DATA

& SERVICE MANUAL
OUTDOOR UNIT: GRV72L5TA-
SPLIT SYSTEM AIR CONDITIONER
Model No.
GRV72L5TA-
GRV92L5TA-
GRV122L5TA-
GRV92L5TA-
GRV122L5TA-
Product Code No.
387107050
387107051
387107052
0.8180.274.0
05/2002

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GRV72L5TA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Technibel GRV72L5TA

Summary of Contents for Technibel GRV72L5TA

  • Page 1: Technical Data

    TECHNICAL DATA & SERVICE MANUAL OUTDOOR UNIT: GRV72L5TA- GRV92L5TA- GRV122L5TA- SPLIT SYSTEM AIR CONDITIONER Model No. Product Code No. GRV72L5TA- 387107050 GRV92L5TA- 387107051 GRV122L5TA- 387107052 0.8180.274.0 05/2002...
  • Page 2 • Ground the unit following local electrical codes. IMPORTANT! • The Yellow/Green wire cannot be used for any connection Please read before installation different from the ground connection. • Connect all wiring tightly. Loose wiring may cause overheating This air conditioning system meets strict safety and operating at connection points and a possible fire hazard.

  • Page 3: Table Of Contents

    Table of Contents Page 1. OPERATING RANGE 2. SPECIFICATIONS 2-1 Unit specifications 2-2 Major Component specifications 2-3 Other Component specifications 3. DIMENSIONAL DATA 4. REFRIGERANT FLOW DIAGRAM 5. PERFORMANCE DATA 5-1 Performance Charts 5-2 Cooling Capacity 6. ELECTRICAL DATA 6-1 Electrical characteristics 6-2 Electric Wiring Diagram 6-3 System Wiring Diagram...

  • Page 4: Operating Range

    1. OPERATING RANGE Temperature Indoor Air Intake Temp. Outdoor Air Intake Temp. Maximum 32°C D.B. / 23°C W.B. 43°C D.B. Cooling Minimum 19°C D.B. / 14°C W.B. -15°C D.B.

  • Page 5: Specifications

    2. SPECIFICATIONS 2-1 Unit Specifications GRV72L5TA- 220 - 240 V ~ 50 Hz Power source 230 V Voltage rating Cooling Performance * MCAV72C5TA- Capacity 1,90 6485 BTU/h Air circulation (High) m³/h 0,40 Moisture removal (High) Liters/h Cooling Electrical Rating 198 ~ 264...
  • Page 6 GRV92L5TA- 220 - 240 V ~ 50 Hz Power source 230 V Voltage rating Cooling Performance * MCAV92C5TA- 2,60 Capacity BTU/h 8874 Air circulation (High) m³/h 0,80 Moisture removal (High) Liters/h Cooling Electrical Rating Available voltage range 198 ~ 264 4,40 Running amperes Power input...
  • Page 7 GRV122L5TA- 220 - 240 V ~ 50 Hz Power source 230 V Voltage rating Cooling Performance * MCAV122C5TA- 3,40 Capacity BTU/h 11604 Air circulation (High) m³/h 1,50 Moisture removal (High) Liters/h Cooling Electrical Rating Available voltage range 198 ~ 264 6,30 Running amperes 1380...

  • Page 8: Major Component Specifications

    2-2 Major Component Specifications Outdoor Unit: GRV72L5TA- Controller PCB POW-CL128E Part No. 250 V 3,15 A Control circuit fuse Compressor Rotary (Hermetic) Type 802 060 35B C-1RN60H5C Compressor model Nominal output FV68S…350 Compressor oil…Amount Ω C-R: 4,66 Coil resistance (Ambient temp. 25°C)
  • Page 9 Outdoor Unit: GRV92L5TA- Controller PCB POW-CL128E Part No. Control circuit fuse 250 V 3,15 A Compressor Rotary (Hermetic) Type 802 282 45G C-RN80H5A Compressor model Nominal output FV68S…470 Compressor oil…Amount Ω C-R: 3,07 Coil resistance (Ambient temp. 25°C) C-S: 7,97 External (OLR A) External (OLR T) Overload relay...
  • Page 10 Outdoor Unit: GRV122L5TA- Controller PCB POW-CL128E Part No. Control circuit fuse 250 V 3,15 A Compressor Rotary (Hermetic) Type 802 356 45B C-RN110H5B Compressor model 1100 Nominal output FV68S…520 Compressor oil…Amount Ω C-R: 1,962 Coil resistance (Ambient temp. 25°C) C-S: 5,38 External (OLR A) External (OLR T) Overload relay...

  • Page 11: Other Component Specifications

    2-3 Other Component Specifications Outdoor Unit: GRV72L5TA- GRV92L5TA- GRV122L5TA- Transformer ATR-J105 Type 230 V ~ 50/60 Hz Rating Primary 19 V 0,526 A Secondary 10 VA Capacity Ω Primary (WHT-WHT): 205 ± 10% Coil resistance (at 21°C) Secondary (BRN-BRN): 2,0 ± 10% Thermal cut-off temp.

  • Page 12: Dimensional Data

    3. DIMENSIONAL DATA 4 – ø12 holes Air intake Wide tube service valve ø9.52 (3/8") 7000/9000 BTU/h ø12.7 (1/2") 12000 BTU/h Narrow tube service valve Air discharge ø6.35 (1/4") Unit : mm...

  • Page 13: Refrigerant Flow Diagram

    4. REFRIGERANT FLOW DIAGRAM Indoor Unit: Outdoor Unit: GRV72L5TA- GRV92L5TA- Indoor Unit Outdoor Unit Wide tube service Compressor Accumulator Wide tube valve Muffler O.D. ø9.52 mm (3/8 ") Narrow tube service Narrow tube valve Capillary tube O.D. ø6.35 mm (1/4")

  • Page 14: Performance Data

    5. PERFORMANCE DATA 5-1 Performance charts GRV72L5TA- Cooling Characteristics Indoor inlet air D.B. (°C) Outdoor inlet air D.B. temp. (°C) 0,90 Indoor inlet air D.B. (°C) 0,80 0,70 0,60 0,50 0,40 0,30 0,20 0,10 0,00 Outdoor inlet air D.B. (°C)
  • Page 15 GRV92L5TA- Cooling Characteristics Indoor inlet air D.B. (°C) Outdoor inlet air D.B. temp. (°C) 0,90 Indoor inlet air D.B. (°C) 0,80 0,70 0,60 0,50 0,40 0,30 0,20 0,10 0,00 Outdoor inlet air D.B. (°C) Notes: Points of Rating condition Data referred to indoor unit MCAV92C5TA-...
  • Page 16 GRV122L5TA- Cooling Characteristics Indoor inlet air D.B. (°C) Outdoor inlet air D.B. temp. (°C) 0,90 Indoor inlet air D.B. (°C) 0,80 0,70 0,60 0,50 0,40 0,30 0,20 0,10 0,00 Outdoor inlet air D.B. (°C) Notes: Points of Rating condition Data referred to indoor unit MCAV122C5TA-...

  • Page 17: Cooling Capacity

    5-2 Cooling Capacity GRV72L5TA- OUTDOOR UNIT: 220 - 240 V ~ 50 Hz RATING CAPACITY 1,90 kW moisture removal 0,4 l/h COMP. POWER INPUT 0,586 kW max comp input 0,666 kW AIR FLOW RATE m³/h CONDENSER EVAPORATOR ENT.TEMP. °C OUTDOOR AMBIENT TEMP. °C W.B.
  • Page 18 GRV92L5TA- OUTDOOR UNIT: 220 - 240 V ~ 50 Hz RATING CAPACITY 2,60 kW moisture removal 0,8 l/h COMP. POWER INPUT 0,89 kW max comp input 1,02 kW AIR FLOW RATE m³/h EVAPORATOR CONDENSER ENT.TEMP. °C OUTDOOR AMBIENT TEMP. °C W.B.
  • Page 19 GRV122L5TA- OUTDOOR UNIT: 220 - 240 V ~ 50 Hz RATING CAPACITY 3,40 kW moisture removal 1,5 l/h COMP. POWER INPUT 1,271 kW max comp input 1,491 kW AIR FLOW RATE m³/h EVAPORATOR CONDENSER ENT.TEMP. °C OUTDOOR AMBIENT TEMP. °C W.B.

  • Page 20: Electrical Data

    6. ELECTRICAL DATA 6-1 Electrical characteristics OUTDOOR UNIT: GRV72L5TA- Outdoor unit Indoor Unit Complete Unit Fan Motor Fan Motor Compressor 230 V 1-Phase 50 Hz Performance at Rating conditions Running Amps. 0,110 0,316 2,774 3,200 Power input 0,025 0,069 0,586...

  • Page 21: Electric Wiring Diagram

    6-2 Electric Wiring Diagram 6-3 System Wiring Diagram...
  • Page 22 R.D. 28 Reyrieux BP 131 - 01601 Trévoux CEDEX France Tél. 04.74.00.92.92 - Fax 04.74.00.42.00 R.C.S. Bourg-en-Bresse B 759 200 728...
