TECHNICAL DATA & SERVICE MANUAL
Indoor Unit
Outdoor Unit
MCAV97C5VAB
GRV187M2C5VAA
MULTI-SPLIT SYSTEM AIR CONDITIONER
Indoor Unit
Outdoor Unit
MCAV97C5VAB
GRV187M2C5VAA
0.8180.139.0
03/2001

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MCAV97C5VAB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Technibel MCAV97C5VAB

Summary of Contents for Technibel MCAV97C5VAB

  • Page 1 TECHNICAL DATA & SERVICE MANUAL Indoor Unit Outdoor Unit MCAV97C5VAB GRV187M2C5VAA MULTI-SPLIT SYSTEM AIR CONDITIONER Indoor Unit Outdoor Unit MCAV97C5VAB GRV187M2C5VAA 0.8180.139.0 03/2001...
  • Page 2 IMPORTANT! Please Read Before Starting When Installing… This air conditioning system meets strict safety and operating standards. As the installer or service person, it is …In a Ceiling or Wall an important part of your job to install or service the Make sure the ceiling/wall is strong enough to hold the system so it operates safely and efficiently.

  • Page 3: Table Of Contents

    Table of Contents Page Unit combination iiii OPERATING RANGE SPECIFICATIONS Unit Specification Major Component Specifications Other Component Specifications DIMENSIONAL DATA COOLING CAPACITY AIR THROW DISTANCE CHART REFRIGERANT FLOW DIAGRAM ELECTRICAL DATA Electrical Characteristic Electric Wiring Diagrams Performance Charts INSTALLATION INSTRUCTION Installation Site Selection Remote Control Unit Installation Position Recommended Wire Length and Diameter...
  • Page 4 CHECKING ELECTRICAL COMPONENTS 13-1 Measurement of insulation Resistance 13-2 Checking Continuity of Fuse on PCB Ass’y 13-3 Checking Motor Capacitor APPENDIX INSTRUCTION MANUAL...

  • Page 5: Unit Combination Iiii

    Unit Combination Combine indoor and outdoor units only as listed below. Symbol of Outdoor Unit Indoor Unit Refer to Indoor Unit MCAV97C5VAB Fig.1 GRV187M2C5VAA MCAV97C5VAB Indoor Unit Outdoor Unit Fig.1...

  • Page 6: Operating Range

    1. OPERATING RANGE Temperature Indoor Air Intake Temp. Outdoor Air Intake Temp. Maximum 32°C D.B. / 23°C W.B. 43°C D.B. Cooling Minimum 19°C D.B. / 14°C W.B. 19°C D.B.

  • Page 7: Specifications

    2. SPECIFICATIONS 2-1. Unit Specifications Indoor Unit MCAV97C5VAB Outdoor Unit GRV187M2C5VAA No. of indoor units. 1-unit 2-units Power Source 220 – 240 V ~ 50 Hz Cooling Capacity 2.85 5.30 BTU/h 9,700 18,100 470 × 2 Air circulation (High) Moisture removal (High) Liters/h 1.

  • Page 8: Major Component Specifications

    2-2. Major Component Specifications Indoor Unit MCAV97C5VAB Part No. POW – K8E(A), POW – K8E(B) Controls Microprocessor Control circuit fuse 250 V 3.15 A Remote Control Unit RCS – 8PS3E Type Cross – flow Q'ty ... Dia. and length 1 ... ø95 / L617 Fan motor model ...
  • Page 9 Outdoor Unit GRV187M2C5VAA Type Rotary (Hermetic) Compressor model ... Q'ty C – RN90H5B ... 2 / 80228345 ... 2 Nominal output DAPHNE-FV68S ... 47 0× 2 Compressor oil ... Amount Ω Coil resistance (Ambient temp. 25°C) C – R : 3.07 C –...

  • Page 10: Other Component Specifications

    2-3. Other Component Specifications Indoor Unit MCAV97C5VAB Transformer (TR) ATR-J105 Rating Primary AC 230V, 50 / 60 Hz Secondary 19V, 0.526A Capacity 10VA Ω (at 21°C) Coil resistance Primary (WHT – WHT): 205 ± 10% Secondary (BRN – BRN): 2.0 ± 10% Thermal cut-off temp.

  • Page 11: Dimensional Data

    3. DIMENSIONAL DATA Indoor Unit MCAV97C5VAB Drain hose ø18 Remote control unit 18.5 99.5 58.5 Narrow tube ø6.35 (1/4") Center of tubing hole (2 places) Wide tube ø9.52 (3/8") Unit : mm...
  • Page 12 Outdoor Unit GRV187M2C5VAA Air intake 4 – ø12 holes Air discharge Magnified illustration To Indoor Unit A To Indoor Unit B Narrow tube service valve ø6.35(1/4") Wide tube service valve ø9.52(3/8") Unit : mm...

  • Page 13: Cooling Capacity

    4.COOLING CAPACITY INDOOR UNIT: MCAV97C5VAB 230V 50 Hz RATING CAPACITY 2.85 kW AIR FLOW RATE 470 m³/h EVAPORATOR CONDENSER ENT.TEMP. °C OUTDOOR AMBIENT TEMP. °C W.B. D.B. 2.70 2.62 2.50 2.34 2.16 0.84 0.90 0.96 1.06 1.15 1.85 1.82 1.75 1.68...

  • Page 14: Air Throw Distance Chart

    5. AIR THROW DISTANCE CHART Indoor Unit MCAV97C5VAB Room air temp. : 27°C Fan speed High Horizontal distance (m) Axis air velocity 0° Flap angle 30°...

  • Page 15: Refrigerant Flow Diagram

    6. REFRIGERANT FLOW DIAGRAM Indoor Unit MCAV97C5VAB (x2) Outdoor Unit GRV187M2C5VAA Outdoor Unit Indoor Unit A Accumulator Wide tube O.D. ø9.52mm Accumulator (3/8 ") Wide tube service valve Indoor Unit B Narrow tube Narrow tube service O.D. valve ø6.35 mm (1/4")

  • Page 16: Electrical Data

    7-1. Electrical Characteristics NOTE The values in the table below indicate the sum of indoor and outdoor units which are in running condition. Indoor Unit MCAV97C5VAB Outdoor Unit GRV187M2C5VAA 230V Single phase 50 Hz 1 - Unit 2 - Units...

  • Page 17: Electric Wiring Diagrams

    7-2 Electric Wiring Diagrams Indoor Unit MCAV97C5VAB To avoid electrical shock hazard, be sure to disconnect power before WARNING checking, servicing and/or cleaning any electrical parts...
  • Page 18 Outdoor Unit GRV187M2C5VAA To avoid electrical shock hazard, be sure to disconnect power before WARNING checking, servicing and/or cleaning any electrical parts...

  • Page 19: Performance Charts

    7-3. Performance Charts Indoor Unit MCAV97C5VAB (x1) Outdoor Unit GRV187M2C5VAA ■ Cooling Characteristics Indoor inlet air D.B. temp. (°C) Outdoor inlet air D.B. temp. (°C) Indoor inlet air D.B. temp. (°C) Outdoor inlet air D.B. temp. (°C) NOTE ..Points of Rating condition Black dots in above charts indicate the following rating conditions.

  • Page 20: Installation Instruction

    8. INSTALLATION INSTRUCTIONS           8-1. Installation Site Selection Tubing length (L) INDOOR Maximum Allowable Tubing Length(L)and Elevation UNIT Difference(H). Less than elevation The Multi-Split System outdoor unit should be installed as difference (H) between OUTDOOR close to the indoor units as possible.
  • Page 21 Outdoor Unit AVOID: heat sources, exhaust fans, etc. (Fig. 3) damp, humid or uneven locations. Exhaust fan Hot air Heat source choose a place as cool as possible. Outdoor unit choose a place that is well ventilated. allow enough room around the unit for air intake/exhaust and possible maintenance.

  • Page 22: Remote Control Unit Installation Position

    8-2. Remote Control Unit Installation Position The remote control unit can be operated from either a Removable mounting non-fixed position or a wall-mounted position. Wall To ensure that the air conditioner operates correctly, do not install the remote control unit in the following places: In direct sunlight Behind a curtain or other place where it is covered Special...

  • Page 23: Recommended Wire Length And Diameter

    8-3. Recommended Wire Length and Diameter Regulations on wiring diameter differ from locality to locality. For field wiring requirements, please refer to your local electrical codes. Carefully observe these regulations when carrying out the installation. Table 2 lists recommended wire lengths and size for power supply systems.

  • Page 24: Function

    9. FUNCTION 9-1. Room Temperature Control Room temperature control is obtained by cycling the compressor ON and OFF under control of the room temperature sensor in the remote control unit. The room temperature (and other information) is transmitted every 3 minutes by the remote control unit to the controller in the indoor unit.

  • Page 25: Dry Operation

    9-2. Dry Operation (Dehumidification) Dry operation uses the ability of the cooling cycle to remove moisture from the air, but by running at low level to dehumidify without greatly reducing the room temperature. The air conditioner repeats the cycle of turning ON and OFF automatically as shown in the chart below according to the room temperature.

  • Page 26: Freeze Prevention

    9-3. Freeze Prevention This function prevents freezing of the indoor heat exchange coil. When the compressor has been running for 10 minutes or more and the temperature of the indoor heat exchange coil falls below –1°C, the control circuit stops the compressor for at least 6 minutes. The compressor does not start again until the temperature rises above 8°C or 6 minutes has elapsed.

  • Page 27: Refrigerant R407C:special Precaution When Servicing Unit

    10. REFRIGERANT R407C : SPECIAL PRECAUTIONS WHEN SERVICING UNIT 10-1. Characteristics of new refrigerant R407C 10-1-1. What is new refrigerant R407C R407C is a new refrigerant that contains three types of non-azeotropy-type mixed refrigerant which does not adversely affect the Earth's ozone layer. Its refrigeration capacity and energy efficiency are about the same level as the conventional refrigerant R22 10-1-2.

  • Page 28: Tools Specifically For R407C

    10-3. Tools specifically for R407C For servicing, use the following tools for R407C Tool Distinction Tool Name • Gauge manifold • Charging hose • Gas leak detector • Refrigerant cylinder • Charging cylinder Tools specifically for R407C • Refrigerant recovery unit •...

  • Page 29: In Case Of Compressor Malfunction

    10-5. In case of compressor malfunction Should the compressor malfunction, be sure to replace compressor as quickly as CAUTION possible. Use only the tools indicated exclusively for R407C. See "10-3. Tools specifically for R407C". 10-5-1.Procedure for replacing compressor (1) Recovering refrigerant •...
  • Page 30 (5) Recharging Valve • Be sure to charge the specified amount of refrigerant in liquid state using the service port of wide tube service valve. The proper amount is listed on the unit's nameplate. When the entire amount cannot be charged all at once, charge gradually while operating the unit in Cooling Operation.

  • Page 31: In Case Refrigerant Is Leaking

    10-6. In case refrigerant is leaking Never attempt to charge additional refrigerant when refrigerant has been leaking CAUTION from the unit. Follow the procedure described below to locate points of leaks and carry out repairs, then recharge the refrigerant. (1) Detecting Leaks •...
  • Page 32 (6) Recharging Valve • Be sure to charge the specified amount of refrigerant in liquid state using the service port of wide tube service valve. The proper amount is listed on the unit's nameplate. When the entire amount cannot be charged all at once, charge gradually while operating the unit in Cooling Operation.

  • Page 33: Charging Additional Refrigerant

    10-7. Charging additional refrigerant 10-7-1.When tubes are extended • Observe the proper amount of refrigerant as stated in this service manual or the installation manual that came with the indoor unit. Charge additional refrigerant in liquid state. Never charge additional refrigerant if refrigerant is leaking from the unit. Follow CAUTION instructions given in "10-6.

  • Page 34: Troubleshooting

    11. TROUBLESHOOTING 11-1. Check before and after troubleshooting WARNING Hazardous voltage can cause ELECTRIC SHOCK or DEATH. Disconnect power or turn off circuit breaker before you start checking or servicing. 11-1-1. Check power supply wiring. Check that power supply wires are correctly Outdoor Unit connected to terminals No.1 and No.2 on the terminal ndoor Unit A...

  • Page 35: Air Conditioner Does Not Work

    11-2. Air conditioner does not operate. 11-2-1. Circuit breaker trips (or fuse blows). A. When the circuit breaker is set to ON, it is tripped soon. (Resetting is not possible.) There is a possibility of ground fault. Check insulation resistance. If resistance value is 2MΩ...
  • Page 36 B.Circuit breaker trips in several minutes after turning the air conditioner on. There is a possibility of short circuit. • Check capacity of circuit breaker. Replace with suitable one (larger capacity). Capacity of circuit breaker is suitable. Measure resistance of outdoor fan •...
  • Page 37 11-2-2. Neither indoor nor outdoor unit runs. A. Power is not supplied. Circuit breaker Reset breaker. is tripped. • Check power supply. Power is being supplied to the Wait for recovery outdoor unit. Power failure or contact power company. B. Check remote control unit. Does not run.
  • Page 38 E. Check fuse on the indoor PCB Ass'y. • Measure resistance of indoor and If fuse has been blown, • Check fuse on indoor PCB Ass'y outdoor fan motor winding. for continuity. (FM) • Check operation lamp to see • Measure coil resistance of if light is ON.
  • Page 39 11-2-3. Only outdoor unit does not run. A. Check setting temperature. Is room temperature too low ? Try to lower setting temperature by temperature setting button ( button). Outdoor unit still does not run. • Try to run using another remote control unit.

  • Page 40: Some Parts Of Air Conditioner Does Not Operate

    11-3. Some part of air conditioner does not operate. 11-3-1. Only indoor fan does not run. • Check fan casing Remove foreign foreign matter on matter or repair. Fan cannot inside. be turned. • Check fan rotation. Turn fan gently once or twice by hand.
  • Page 41 11-3-3. Only compressor does not run. • Check compressor moter Overload relay is working. (OLR 1 to 4) capacitor. (C2, C3) • Measure resistance of Temperature of compressor is abnormally high. compressor motor winding. Refrigerant gas shortage. Charge refrigerant gas (R407c). •...

  • Page 42: Air Conditioner Operates, But Abnormalities Are Observed

    11-4. Air conditioner operates, but abnormalities are observed. 11-4-1. Poor cooling. • Check position of remote control unit. Change position of remote • Cool air from air conditioner reaches control unit. position directly. • Wide and narrow tubes between Insulate both wide and narrow indoor unit and outdoor unit are tubes separately and then insulated.

  • Page 43: If A Sensor Is Defective

    11-5. If a sensor is defective. 11-5-1. Indoor coil temp. thermistor (TH1) is defective. • Operation lamp on front side of • Thermistor (TH1 ) is defective. indoor unit is flashing on and off. (*) • Replace thermistor. Alarm Signal (*) NOTE Operation lamp on the front side of the indoor unit will flash on and off when the indoor coil thermistor is defective.

  • Page 44: Arrangement Of Electrical Components

    12. ARRANGEMENT OF ELECTRICAL COMPONENTS Outdoor Unit GRV187M2C5VAA Parts Layout in Unit Heat exchenger coil Compressor A (CMA) Compressor B (CMB) Fan motor Electric Parts Compressor motor capacitor (C3) Compressor motor capacitor (C2 ) Fan motor capacitor C1 Relay B (RB) Overload relay 1 Overload relay 3 Relay A (RA)
  • Page 45 13. CHECKING ELECTRICAL COMPONENTS 13-1. Measurement of Insulation Ground wire Resistance Clip The insulation is in good condition if the resistance exceeds 2MΩ. 13-1-1. Power Supply Wires Probe Clamp the ground wire of the power supply wires with Insulation tester Fig.
  • Page 46 13-2. Checking Continuity of Fuse on PCB Ass'y Fuse Remove the PCB Ass'y from the electrical component box. Then pull out the fuse from the PCB Ass'y. Check for continuity using a multimeter as shown in Indoor Fig. 6. PCB Ass’y Fig.
  • Page 47 R.D. 28 Reyrieux BP 131 - 01601 Trévoux CEDEX France Tél. 04.74.00.92.92 - Fax 04.74.00.42.00 R.C.S. Bourg-en-Bresse B 759 200 728...
