- Page 1 TECHNICAL DATA & SERVICE MANUAL OUTDOOR UNIT: GRV72C5TA- GRV92C5TA- GRV122C5TA- SPLIT SYSTEM AIR CONDITIONER Model No. Product Code No. GRV72C5TA- 387107047 GRV92C5TA- 387107048 GRV122C5TA- 387107049 0.8180.273.0 05/2002...
- Page 2 • Ground the unit following local electrical codes. IMPORTANT! • The Yellow/Green wire cannot be used for any connection Please read before installation different from the ground connection. • Connect all wiring tightly. Loose wiring may cause overheating This air conditioning system meets strict safety and operating at connection points and a possible fire hazard.
-
Page 3: Table Of Contents
Table of Contents Page 1. OPERATING RANGE 2. SPECIFICATIONS 2-1 Unit specifications 2-2 Major Component specifications 3. DIMENSIONAL DATA 4. REFRIGERANT FLOW DIAGRAM 5. PERFORMANCE DATA 5-1 Performance Charts 5-2 Cooling Capacity 6. ELECTRICAL DATA 6-1 Electrical characteristics 6-2 Electric Wiring Diagram 6-3 System Wiring Diagram... -
Page 4: Operating Range
1. OPERATING RANGE Temperature Indoor Air Intake Temp. Outdoor Air Intake Temp. Maximum 32°C D.B. / 23°C W.B. 43°C D.B. Cooling Minimum 19°C D.B. / 14°C W.B. 19°C D.B. -
Page 5: Specifications
2. SPECIFICATIONS 2-1 Unit Specifications GRV72C5TA- 220 - 240 V ~ 50 Hz Power source 230 V Voltage rating Cooling Performance * MCAV72C5TA- Capacity 1,90 6485 BTU/h Air circulation (High) m³/h 0,40 Moisture removal (High) Liters/h Cooling Electrical Rating 198 ~ 264 Available voltage range 3,20 Running amperes... - Page 6 GRV92C5TA- 220 - 240 V ~ 50 Hz Power source 230 V Voltage rating Cooling Performance * MCAV92C5TA- 2,60 Capacity BTU/h 8874 Air circulation (High) m³/h 0,80 Moisture removal (High) Liters/h Cooling Electrical Rating Available voltage range 198 ~ 264 4,40 Running amperes Power input...
- Page 7 GRV122C5TA- 220 - 240 V ~ 50 Hz Power source 230 V Voltage rating Cooling Performance * MCAV122C5TA- 3,40 Capacity BTU/h 11604 Air circulation (High) m³/h 1,50 Moisture removal (High) Liters/h Cooling Electrical Rating Available voltage range 198 ~ 264 6,30 Running amperes 1380...
-
Page 8: Major Component Specifications
2-2 Major Component Specifications Outdoor Unit: GRV72C5TA- Compressor Rotary (Hermetic) Type 802 060 35B C-1RN60H5C Compressor model Nominal output FV68S…350 Compressor oil…Amount Ω C-R: 4,66 Coil resistance (Ambient temp. 25°C) C-S: 8,89 External (OLR A) External (OLR T) Overload relay MRA 38072-3229 CS-7C115 Safety devices... - Page 9 Outdoor Unit: GRV92C5TA- Compressor Rotary (Hermetic) Type Compressor model 802 282 45G C-RN80H5A Nominal output FV68S…470 Compressor oil…Amount Ω C-R: 3,07 Coil resistance (Ambient temp. 25°C) C-S: 7,97 External (OLR A) External (OLR T) Overload relay MRA 38066-3229 CS-7C115 Safety devices Type 145 ±...
- Page 10 Outdoor Unit: GRV122C5TA- Compressor Rotary (Hermetic) Type Compressor model 802 356 45B C-RN110H5B Nominal output 1100 FV68S…520 Compressor oil…Amount Ω C-R: 1,962 Coil resistance (Ambient temp. 25°C) C-S: 5,38 External (OLR A) External (OLR T) Overload relay MRA 38065-3229 CS-7C115 Safety devices Type 145 ±...
-
Page 11: Dimensional Data
3. DIMENSIONAL DATA 4 – ø12 holes Air intake Wide tube service valve ø9.52 (3/8") 7000/9000 BTU/h ø12.7 (1/2") 12000 BTU/h Narrow tube service valve Air discharge ø6.35 (1/4") Unit : mm... -
Page 12: Refrigerant Flow Diagram
4. REFRIGERANT FLOW DIAGRAM Indoor Unit: Outdoor Unit: GRV72C5TA- GRV92C5TA- Indoor Unit Outdoor Unit Wide tube service Compressor Accumulator Wide tube valve Muffler O.D. ø9.52 mm (3/8 ") Narrow tube service Narrow tube valve Capillary tube O.D. ø6.35 mm (1/4") Indoor Unit: Outdoor Unit: GRV122C5TA-... -
Page 13: Performance Data
5. PERFORMANCE DATA 5-1 Performance charts GRV72C5TA- Cooling Characteristics Indoor inlet air D.B. (°C) Outdoor inlet air D.B. temp. (°C) 0,90 Indoor inlet air D.B. (°C) 0,80 0,70 0,60 0,50 0,40 0,30 0,20 0,10 0,00 Outdoor inlet air D.B. (°C) Notes: Points of Rating condition Data referred to indoor unit... - Page 14 GRV92C5TA- Cooling Characteristics Indoor inlet air D.B. (°C) Outdoor inlet air D.B. temp. (°C) 0,90 Indoor inlet air D.B. (°C) 0,80 0,70 0,60 0,50 0,40 0,30 0,20 0,10 0,00 Outdoor inlet air D.B. (°C) Notes: Points of Rating condition Data referred to indoor unit MCAV92C5TA-...
- Page 15 GRV122C5TA- Cooling Characteristics Indoor inlet air D.B. (°C) Outdoor inlet air D.B. temp. (°C) 0,90 Indoor inlet air D.B. (°C) 0,80 0,70 0,60 0,50 0,40 0,30 0,20 0,10 0,00 Outdoor inlet air D.B. (°C) Notes: Points of Rating condition Data referred to indoor unit MCAV122C5TA-...
-
Page 16: Cooling Capacity
5-2 Cooling Capacity GRV72C5TA- OUTDOOR UNIT: 220 - 240 V ~ 50 Hz RATING CAPACITY 1,90 kW moisture removal 0,4 l/h COMP. POWER INPUT 0,592 kW max comp input 0,672 kW AIR FLOW RATE m³/h CONDENSER EVAPORATOR ENT.TEMP. °C OUTDOOR AMBIENT TEMP. °C W.B. - Page 17 GRV92C5TA- OUTDOOR UNIT: 220 - 240 V ~ 50 Hz RATING CAPACITY 2,60 kW moisture removal 0,8 l/h COMP. POWER INPUT 0,90 kW max comp input 1,03 kW AIR FLOW RATE m³/h EVAPORATOR CONDENSER ENT.TEMP. °C OUTDOOR AMBIENT TEMP. °C W.B.
- Page 18 GRV122C5TA- OUTDOOR UNIT: 220 - 240 V ~ 50 Hz RATING CAPACITY 3,40 kW moisture removal 1,5 l/h COMP. POWER INPUT 1,286 kW max comp input 1,506 kW AIR FLOW RATE m³/h EVAPORATOR CONDENSER ENT.TEMP. °C OUTDOOR AMBIENT TEMP. °C W.B.
-
Page 19: Electrical Data
6. ELECTRICAL DATA 6-1 Electrical characteristics OUTDOOR UNIT: GRV72C5TA- Outdoor unit Indoor Unit Complete Unit Fan Motor Fan Motor Compressor 230 V 1-Phase 50 Hz Performance at Rating conditions Running Amps. 0,110 0,280 2,810 3,200 Power input 0,025 0,063 0,592 0,680 Full load conditions Running Amps. -
Page 20: Electric Wiring Diagram
6-2 Electric Wiring Diagram 6-3 System Wiring Diagram... - Page 21 R.D. 28 Reyrieux BP 131 - 01601 Trévoux CEDEX France Tél. 04.74.00.92.92 - Fax 04.74.00.42.00 R.C.S. Bourg-en-Bresse B 759 200 728...
