- Page 1 MANLEY LABORATORIES, INC. OWNER'S MANUAL MANLEY 250 / 100 WATT MONOBLOCK AMPLIFIER MANLEY LABORATORIES, INC. 13880 MAGNOLIA AVE. CHINO, CA. 91710 TEL: (909) 627-4256 FAX: (909) 628-2482...
-
Page 2: Table Of Contents
CONTENTS SECTION INTRODUCTION MAINS CONNECTIONS CONNECTING YOUR AMPLIFIER DIAGRAM 2 TOP PANEL BIAS PROCEDURES OPERATIONAL NOTES SPECIFICATIONS WARRANTY WARRANTY REGISTRATION PAGE... -
Page 3: Introduction
The output transformer is a revolutionary new design by David Manley which is wound on the Manley Labs factory premesis. Its stellar performance will be obvious upon first listening. The secret is in keeping both phases of the push-pull halves always equal, and in this new output transformer design, David has achieved just that. -
Page 4: Mains Connections
MAINS CONNECTIONS Your amplifier has been factory set to the correct mains voltage for your country. The voltage setting is marked on the serial badge, located on the rear panel. Check that this complies with your local supply. Export units for certain markets have a moulded mains plug fitted to comply with local requirements. -
Page 5: Connecting Your Amplifier
CONNECTING YOUR AMPLIFIER Setting up your amplifiers is rather easy. 1. Connect all source components (turntable, CD, Tuner, Tape DAT, etc.) to your preamplifier. 2. Connect the interconnects from the output of the preamplifier or switching center to the RCA input on the top rear of the amplifiers. IF your source has a truly BALANCED output, connect TO the XLR input and select the balanced input. - Page 6 INPUT OUTPUT TUBES:10 x RUSSIAN EL34G The EL34 type we recommend are the Russian up-rated EL34G. This has been proven to be the most rugged and reliable of this type and we strongly emphasize that only the RUSSIAN EL34G's should be used in this amplifier. The MANLEY 250/100 WATT MONOBLOCK has been thoroughly optimised around this tube.
- Page 7 MAINS IN MAINS FUSE SLO-BLO B+ FUSE INPUT SLO-BLO BALANCED UNBALANCED SWITCH REAR VIEW OF AMPLIFIER SPEAKER BALANCED OUTPUT INPUT BINDING POSTS...
- Page 8 POWER STANDBY (BLINKING) FRONT VIEW OF AMPLIFIER TRIODE TETRODE GROUND FRONT VIEW OF AMPLIFIER WITH INSERT REMOVED SHOWING BIAS MEASUREMENT POINTS AND BIAS ADJUST POINTS OPERATE STANDBY OPERATE STANDBY EVER-WARM SOFT START SWITCH MAINS POWER ON / OFF SWITCH...
-
Page 9: Bias Procedures
The Manley 250/100 Monoblock Amplifiers uses a fixed bias system that requires very little attention. If you wish to adjust or check the bias, follow the following steps. For this procedure you will need a voltmeter (a hand held autoranging DMM digital multimeter is the easiest), a 3/32"... -
Page 10: Operational Notes
OPERATIONAL NOTES SWITCHING ON -- SOFT START The MANLEY 250/100 is equipped with a SOFT-START circuit which lessens the initial stress the amplifier takes upon turn-on. We recommend that you use this soft start facility whenever you turn the amplifier on and especially when cold. 1. -
Page 11: Specifications
SPECIFICATIONS Vacuum Tubes: Output Power Frequency Response, +/- .5 dB Input Sensitivity Input Impedance Load Impedance S/N Ratio @440W Power Consumption Mains Fuse B+ Fuse Dimensions Shipping Weight 10 x EL34G (Output), 2 x 6414 (Driver), 1 x 12AT7 (Input) TETRODE: 240 Watts (@1.5% THD 5 ohm load) TRIODE: 100 Watts (@1.5% THD 5 ohm load) 10 Hz - 80 KHz... -
Page 12: Warranty
WARRANTY All Manley Laboratories equipment is covered by a limited warranty against defects in materials and workmanship for a period of 90 days from date of purchase to the original purchaser only. A further optional limited 5 year warranty is available to the original purchaser upon proper registration of ownership within 30 days of date of first purchase. -
Page 13: Warranty Registration
WARRANTY REGISTRATION We ask that you please fill out this registration form and send the bottom half to: Registration entitles you to product support, full warranty benefits, and notice of product enhancements and upgrades. You MUST complete and return the following to validate your warranty and registration.
