AllMounts AS64F Installation Manual

Universal portrait fixed wall mount

Enlarged version

3. Hanging the TV onto the Wall Plate

wall

Before releasing the TV, make sure the adapter brackets have been securely hooked onto the mount.

Insert the safety bar at the bottom of the

mount to prevent the TV from falling

accidentally.

Maintenance

• Check that the bracket is secure and safe to use at regular intervals(at least every three months).

• Please contact your

distributor

if you have any questions.

wall

A padlock can be used in the safety bar to help

prevent theft of your TV.

Note: Padlock is not included.

Universal Portrait Fixed Wall Mount

200x200/400x200

AS64F

400x400/400x600

INSTALLATION MANUAL

CAUTION:

DO NOT EXCEED

RATED LISTED WEIGHT. SERIOUS

INJURY OR PROPERTY DAMAGE

MAY OCCUR!

70kg

MAX

(154lbs)

RATED

ISSUED: JUN. 2013

Table of Contents

Do you have a question about the AS64F and is the answer not in the manual?

Page 1 TV from falling prevent theft of your TV. accidentally. Note: Padlock is not included. 200x200/400x200 " Maintenance AS64F 70kg 70kg 400x400/400x600 • Check that the bracket is secure and safe to use at regular intervals(at least every three months). (154lbs) (154lbs) •...
Page 2 Component Checklist NOTE: Read the entire instruction manual before you start installation and assembly. IMPORTANT: Ensure that you have received all parts according to the component checklist prior to installation. If any parts are missing or faulty, telephone your local distributor for a replacement. WARNING •...
Page 3 (16") (17.7") (23.6") (24") Model AS64F WARNING • Make sure that mounting screws are anchored into the center of the studs. The use of a stud WARNING finder is highly recommended. • Installers are responsible to provide hardware for other types of mounting situations.
Page 4 2 Installing the Adapter Brackets 2-2 For Recessed Back Screens or to Access A/V Inputs Top of the display 2-1 For Flat Back Screens Note: Choose the appropriate screws, washers and spacers (if necessary) according to the type of screen. ·...
